HEAT RECLAIMER ASSEMBLY INSTRUCTIONS
TABLE OF CONTENTS

4
WARRANTY
EXCEPT FOR THE ABOVE STATED EXPRESS LIMITED WARRANTIES, GSI MAKES NO WARRANTY OF
ANY KIND, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF MER-
CHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE OR USE IN CONNECTION WITH (i) PROD-
UCT MANUFACTURED OR SOLD BY GSI OR (ii) ANY ADVICE, INSTRUCTION, RECOMMENDATION OR
SUGGESTION PROVIDED BY AN AGENT, REPRESENTATIVE OR EMPLOYEE OF GSI REGARDING OR
RELATED TO THE CONFIGURATION, INSTALLATION, LAYOUT, SUITABILITY FOR A PARTICULAR PUR-
POSE, OR DESIGN OF SUCH PRODUCT OR PRODUCTS.
IN NO EVENT SHALL GSI BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL OR CONSEQUEN-
TIAL DAMAGES, INCLUDING, WITHOUT LIMITATION, LOSS OF ANTICIPATED PROFITS OR BENEFITS.
PURCHASER'S SOLE AND EXCLUSIVE REMEDY SHALL BE LIMITED TO THAT STATED ABOVE, WHICH
SHALL NOT EXCEED THE AMOUNT PAID FOR THE PRODUCT PURCHASED. THIS WARRANTY IS NOT
TRANSFERABLE AND APPLIES ONLY TO THE ORIGINAL PURCHASER. GSI SHALL HAVE NO OBLIGA-
TION OR RESPONSIBILITY FOR ANY REPRESENTATIVE OR WARRANTIES MADE BY OR ON BEHALF
OF ANY DEALER, AGENT OR DISTRIBUTOR OF GSI.
GSI ASSUMES NO RESPONSIBILITY FOR FIELD MODIFICATIONS OR ERECTION DEFECTS WHICH
CREATE STRUCTURAL OR STORAGE QUALITY PROBLEMS. MODIFICATIONS TO THE PRODUCT NOT
SPECIFICALLY COVERED BY THE CONTENTS OF THIS MANUAL WILL NULLIFY ANY PRODUCT WAR-
RANTY THAT MIGHT HAVE BEEN OTHERWISE AVAILABLE.
THE FOREGOING WARRANTY SHALL NOT COVER PRODUCTS OR PARTS WHICH HAVE BEEN
DAMAGED BY NEGLIGENT USE, MISUSE, ALTERATION OR ACCIDENT. THIS WARRANTY COVERS
ONLY PRODUCTS MANUFACTURED BY GSI. THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL
OTHER WARRANTIES EXPRESS OR IMPLIED. GSI RESERVES THE RIGHT TO MAKE DESIGN OR SPECI-
FICATION CHANGES AT ANY TIME.
PRIOR TO INSTALLATION, PURCHASER HAS THE RESPONSIBILITY TO RESEARCH AND COM-
PLY WITH ALL FEDERAL, STATE AND LOCAL CODES WHICH MAY APPLY TO THE LOCATION AND
INSTALLATION.
THE GSI GROUP, INC. ("GSI") WARRANTS ALL PRODUCTS MANUFACTURED BY GSI TO BE FREE OF
DEFECTS IN MATERIAL AND WORKMANSHIP UNDER NORMAL USAGE AND CONDITIONS FOR A PE-
RIOD OF TWELVE MONTHS AFTER RETAIL SALE TO THE ORIGINAL END USER OF SUCH PROD-
UCTS. GSI'S ONLY OBLIGATION IS, AND PURCHASER'S SOLE REMEDY SHALL BE FOR GSI, TO RE-
PAIR OR REPLACE, AT GSI'S OPTION AND EXPENSE, PRODUCTS THAT, IN GSI'S SOLE JUDGMENT,
CONTAIN A MATERIAL DEFECT DUE TO MATERIALS OR WORKMANSHIP. ALL DELIVERY AND SHIP-
MENT CHARGES TO AND FROM GSI'S FACTORY WILL BE PURCHASER'S RESPONSIBILITY. EXPENSES
INCURRED BY OR ON BEHALF OF THE PURCHASER WITHOUT PRIOR WRITTEN AUTHORIZATION
FROM AN AUTHORIZED EMPLOYEE OF GSI SHALL BE THE SOLE RESPONSIBILITY OF THE PURCHASER.

5
General
The HEAT RECLAIMER PACKAGE has been designed
to reduce the amount of heat loss to the atmosphere and
to recycle this heat in order to help reduce fuel consump-
tion.
Hardware Notes
All HEAT RECLAIMER COMPONENTS should be bolted
together using the 5/16" WHIZ BOLTS and NUTS included
in the HEAT RECLAIMER HARDWARE PACKAGE un-
less noted otherwise.
Platform Preparations
* SOME OF THIS SECTION DOES NOT AP-
PLY TO NEW INSTALLATIONS (HEAT
RECLAIMER INSTALLED BEFORE STACK-
ING.) BUT SHOULD BE READ TO SEE
WHICH PARTS SHOULD BE ASSEMBLED
WITH THE PLATFORM.
In order to install the HEAT RECLAIMER INLET BOX
some components of the SERVICE PLATFORM must be
removed.
Remove both UPPER SIDE GUARD RAILS, 79.125" (D61-
0029).
Remove the UPPER FRONT GUARD RAIL, 105" (D61-
0030) and the LOWER FRONT GUARD RAILS, 53.063"
(D61-0032).
Remove the three OUTER GUARD RAIL SUPPORT
CHANNEL (D61-0037) and the OUTER FRONT TOE
BOARDS, 104.938" (D61-0043).
Remove the RH OUTER TOE BOARDS, 82.125" (D61-
0042) and the LH FRONT TOE BOARD, 35.563" (D61-
0044).
Remove the INNER FRONT TOE BOARD, 44.062" (D61-
0049).
Remove the three 102.25" FLOOR PANELS (D61-0069).
HEAT RECLAIMER ASSEMBLY INSTRUCTIONS
Heat Reclaimer Platform Installation
Install the replacement 45.063" UPPER SIDE GUARD RAIL
(D01-0643) and the TOP and BOTTOM OUTER TOE
BOARDS (D01-0644 & D01-0645).
Install the PLATFORM SUPPORT BEAM (D01-0591, Figure
1) to the SERVICE PLATFORM FRAMEWORK.
Install the INLET BOX DECK PLATE (D01-0571, Figure 1)
to the SERVICE PLATFORM FRAMEWORK using the ex-
isting corner bolts. Drill a 3/8" diameter hole for every hole
around the outer edge of the INLET BOX DECK PLATE.
Place a 5/16" WHIZ BOLT AND NUT into each of these
holes to secure the DECK PLATES into position.
Install the INLET BOX DECK SPLICE PLATE (D01-0570,
Figure 1) to the INLET BOX DECK PLATE. Two SPLICE
PLATES bolt to the top and two to the bottom of the DECK
PLATES.
Install the LONG WALL ANGLE (D01-0587, Figure 1),
SHORT WALL ANGLE (D01-0588, Figure 1), and DUCT SIDE
ANCHOR ANGLE (D01-0590, Figure 1) onto the INLET BOX
DECK PLATE. Keep the bolts loose until the INLET BOX
ASSEMBLY can be completed.
Bracing of Assemblies
Cross bracing should be used on the INLET BOX, SIDE
DUCT CORNER, SIDE TRANSITION DUCT, and TRANSI-
TION COLUMN ASSEMBLIES. This bracing should form a
“W” when installed. The flanges on these angles should
point in the direction of the airflow (toward the fans). Two
angles are included in the package. The INNER SUPPORT
ANGLE (D01-0632) is used on the narrow ducts of the SIDE
DUCT CORNER, SIDE TRANSITION DUCT, and TRANSI-
TION COLUMN ASSEMBLIES. The LONG INNER SUP-
PORT ANGLE (D01-0633) is used on the wide ducts of the
INLET BOX and the SIDE DUCT CORNER.
The bracing should be installed as the major components
are assembled.

6
HEAT RECLAIMER ASSEMBLY INSTRUCTIONS
Inlet Box Assembly
Mark a line 4.5625" (4 9/16") down from the top of the
DRYER FAN SUPPORT. This line will mark the top side
of the INLET BOX BACK PANELS for proper alignment.
The INLET BOX BACK PANELS meet on the centerline
of the fan cans.
Mount the INLET BOX BACK PANELS (D01-0566 & D01-
0567, Figure 1) using the 5/16" SELF TAPPING SCREWS
included in the hardware package.
Mount the INLET BOX SUPPORT ANGLE (D01-0586,
Figure 2) to each of the INLET ENTRY PANELS (D01-
0572 LH & D01-0573 RH, Figure 1).
Mount the INLET ENTRY PANELS to the INLET BOX
BACK PANELS with the flanges pointing to the rear of
the dryer and the door close to the inside of the platform.
Mount the INLET BOX FRONT PANELS (D01-0657 &
D01-0858, Figure 1) to the LONG WALL ANGLE on the
SERVICE PLATFORM.
Attach the INLET BOX CORNER PLATE (D01-0658, Fig-
ure 1) to the INLET BOX FRONT PANELS with the offset
pointing away from the dryer.
Mount the INLET BOX TOP (D01-0568 LH & D01-0569
RH, Figure 1) to the rest of the INLET BOX ASSEMBLY.
The INLET BOX TOP should fit over the whole assembly
.Screw the INLET BOX C CHANNEL SUPPORT (D01-
0859) to the INLET BOX FRONT PANELS. There are (2)
C-CHANNELS per FRONT PANEL. Attach the INLET
BOX WINDOW SILL C CHANNELS (D01-0782 & D01-
0783) around the square holes on the INLET BOX FRONT
PANELS along with the AIR ACCESS DOOR FRAME
ANGLES (D01-0395 & D01-0396) and OPERATOR’S
DOOR HINGE BRACKET (D31-0161).
Screw the PERFORATED AIR ACCESS DOOR PANEL
(D01-0781) & the PERFORATED SIDE DUCT PANEL
(D01-0780) to the inside of the FRONT PANELS.
Place the INLET BOX FLASHING (D01-0860, Figure 1)
over the dryer hitch and bolt it to the INLET BOX DECK
PLATES.
Walkway Door Assembly
The WALKWAY DOOR ASSEMBLY is the same for both
doors except that one door mounts upside down from the
other. The hinge holes show the difference in mounting.
Mount the INLET WALKWAY DOOR TOP/BOTTOM
FRAME ANGLE (D01-0575, Figure 2) to the top and bot-
tom of the large hole in the INLET ENTRY PANEL. There
are two angles on each door.
Mount the INLET WALKWAY DOOR SIDE FRAME
ANGLE (D01-0576, Figure 2) to each side of the large
hole in the INLET ENTRY PANEL. There are two angles
on each door.
Mount the WALKWAY DOOR HINGE—HR SEGMENT
(D01-0595, Figure 2) to the INLET ENTRY PANEL.
Mount the WALKWAY DOOR CATCH ANGLE (D01-0597,
Figure 2) to the INLET ENTRY PANEL with the angle
pointing to the center of the door hole.
Mount the WALKWAY DOOR HINGE—DOOR SEG-
MENT (D01-0596, Figure 2), STANDOFF BRACKET
(D01-0548, Figure 2), 2 MOUNTING BRACKETS (D01-
0549, Figure 2), and the POWER BOX DOOR LATCH
MECHANISM (D01-0547) to each of the WALKWAY
DOORS (D01-0574, Figure 2).
Mount the WALKWAY DOORS to the INLET ENTRY
PANELS.
Side Duct Assembly
The SIDE DUCT ASSEMBLY can be completed on the
ground or in place on the dryer. Assemble the SIDE
DUCT CORNER by bolting the SIDE DUCT FRONT COR-
NER (D01-0562, Figure 4), SIDE DUCT BACK CORNER
(D01-0563, Figure 3), SIDE DUCT CORNER TOP (D51-
0219 RH, D51-0220 LH, Figure 4), SIDE DUCT COR-
NER BOTTOM (D51-0217 RH, D51-0218 LH, Figure 3),
and three SIDE DUCT PANELS (D01-0561, Figure 3)
together with the flanges out and (4) INNER SUPPORT
ANGLES (D01-0632). at each vertical seam on the heat
reclaimer. Assemble the TRANSITION DUCT by bolting
the SIDE DUCT TOP (D51-0213, Figure 4), SIDE DUCT
BOTTOM (D01-0564, Figure 3), and four SIDE DUCT
PANELS (D01-0561, Figure 4) together with the flanges out.
Keep the bolts on this assembly loose, so that it can be
pulled into place later on. In this assembly the tops fit
over the side panels, and the side panels fit over the bot-
tom panels.
Transition Column Assembly
The TRANSITION COLUMN ASSEMBLY is attached to
the left and right

7
HEAT RECLAIMER ASSEMBLY INSTRUCTIONS
Figure 1b: Inlet Box Assembly Noise Suppressor Panel Installation
Figure 1a: Inlet Box Assembly

8
HEAT RECLAIMER ASSEMBLY INSTRUCTIONS
side of the fan end of the dryer on the first three columns
for the 2012 & 2014 Series dryers, the first four columns
for the 2018 & 2020 Series dryers, and the first six col-
umns for the 2022 & 2026 Series dryers.
Mount the SIDE DUCT MOUNTING SHEET (D01-0565,
Figure 3) to the DRYER COLUMN with the 3/8" holes
and with the slot side out. The holes on both sides of the
SIDE DUCT MOUNTING SHEET should line up closer
to the bottom of the sheet as mounted on the dryer. The
SIDE DUCT MOUNTING SHEET mounts to the top holes
on the DRYER COLUMN SIDE SCREEN SHEET on both
sides of the first DRYER COLUMN. Use two SIDE DUCT
MOUNTING SHEETS per column joint where possible.
One left and right hand panel is used on each side
of the dryer in this assembly.
Mount the LH SMALL, MEDIUM, AND LARGE TRAN-
SITION COLUMN PANELS (D01-0621, D01-0623, D01-
0625, Figure 3), the TRANSITION COLUMN VENT
PANELS (D01-0627, Figure 3), and the TRANSITION
COLUMN BUTTRESS VENT PANEL (D01-0628, Fig-
ure 3) to the SIDE DUCT MOUNTING SHEETS with
the flanges pointing to the dryer. The top bolt hole on
the joint where the two TRANSITION COLUMN PAN-
ELS bolt together should go into the top slot on the
SIDE DUCT MOUNTING SHEET toward the rear of the
first dryer column.
Bolt the TRANSITION COLUMN and BUTTRESS VENT
PANELS to the bottom of each TRANSITION COLUMN
PANEL.
Mount the TRANSITION REAREND COVER (D01-0629,
Figure 3) to the rear of the SMALL TRANSITION COL-
UMN PANEL.
Anchor the TRANSITION COLUMN AND BUTTRESS
VENT PANELS to the bottom module using the COL-
UMN PANEL BRACKET (D51-0171, Figure 3). This
bracket bolts to the top three holes on the vertical joint
of the dryer column.
Bolt one TRANSITION FRONTEND COVER (D01-0630,
Figure 3) to the bottom of the TRANSITION REAREND
COVER, TRANSITION VENT PANEL, and the corre-
sponding vertical joint of the dryer column. Bolt one
TRANSITION FRONTEND COVER to the SIDE DUCT
BOTTOM, first COLUMN BUTTRESS VENT PANEL,
and to the first column joint. Bolt the TRANSITION
COLUMN ROOF PANEL (D01-0631, Figure 3) to the
top of the TRANSITION COLUMN PANELS.
Mount the RH SMALL, MEDIUM, AND LARGE TRAN-
SITION COLUMN PANELS (D01-0622, D01-0624, D01-
0626, Figure 4) to the outer portion of the TRANSI-
TION COLUMN ASSEMBLY.
Mount the LOWER OUTSIDE TRANSITION PANELS
(D01-0560, Figure 4) to the lower outer portion of the
TRANSITION COLUMN ASSEMBLY.
Mount the LOWER REAREND PANEL (D61-0245,
Figure 4) to the LOWER OUTSIDE TRANSITION
PANEL and the first dryer column. Mount the
LOWER INNER PANEL (D61-0248, Figure 4) to fill in
the area over the dryer leg.
Brace the LOWER OUTSIDE TRANSITION PANELS
with the COLUMN BRACE (D61-0249, Figure 5).
NOTE: If the assembly does not seem to line up,
loosen the bolts to allow the SIDE
DUCT ASSEMBLIES to flex into place.
Column Assembly
Mount two COLUMN BRACES (D61-0249, Figure 5) to
the bottom hole of the vertical dryer column joint along
the length of the dryer.
Mount the COLUMN PANEL LOWER BRACKET (D61-
0247, Figure 5) to the lower COLUMN BRACE along the
length of the dryer.
Mount the COLUMN PANEL BRACKET (D51-0171, Fig-
ure 5) to each dryer joint using the top three bolts on the
vertical dryer column joint along the length of the dryer.
Mount the COLUMN PANELS (D61-0246, Figure 5) to each
COLUMN PANEL BRACKET and to the COLUMN PANEL
BRACES along the dryer side.
Bolt each panel together.
Mount the LOWER INNER PANEL and the LOWER
REAREND PANEL (D61-0245, Figure 5) at the rearend
of the dryer to fill in the back of the COLUMN PANEL
ASSEMBLY.
When mounting the BUTTRESS COLUMN PANELS
attach these to the buttresses using the BUTTRESS
COLUMN PANELS HANGER (D01-0792) to make the
panels sit level near the buttresses.

9
HEAT RECLAIMER ASSEMBLY INSTRUCTIONS
Figure 2: Walkway Door Assembly
Air Access Door Assembly
Mount the OPERATOR’S DOOR HINGES (D31-0296,
D31-0297) to the SQUARE REAR ACCESS DOOR (D01-
0394) using the 0.25" NUTS
and BOLTS (S-1101 & S-1102).
Mount the door to the hinge bracket using the 5/16"
BOLTS and LOCKNUTS (S-4276 & S-5220).
Assemble the LINKAGE MECHANISM (BLK-10049, D15-
0156, D51-0157, D51-0158, D51-0159, D51-0165, & S-
4318) according to the drawings number Figure 6. Drill a
0.75" hole in the INLET BOX DECK PLATE to allow the
chain to pass and be located for easy access and away
from the lower fan inlets.
Decals
The DECALS (D01-0614) should be mounted on the front
of the TRANSITION REAREND PANEL on the fan end of
the dryer. Place one decal on each side.

10
HEAT RECLAIMER ASSEMBLY INSTRUCTIONS
Figure 3a: 2012 and 2014 Outside Side Duct Assembly

11
HEAT RECLAIMER ASSEMBLY INSTRUCTIONS
Figure 3b: 2018 and 2020 Outside Side Duct Assembly

12
HEAT RECLAIMER ASSEMBLY INSTRUCTIONS
Figure 3c: 2022 and 2026 Outside Side Duct Assembly

13
HEAT RECLAIMER ASSEMBLY INSTRUCTIONS
Figure 4a: 2012 and 2014 Inside Side Duct Assembly

14
HEAT RECLAIMER ASSEMBLY INSTRUCTIONS
Figure 4b: 2018 and 2020 Inside Side Duct Assembly

15
HEAT RECLAIMER ASSEMBLY INSTRUCTIONS
Figure 4c: 2022 and 2026 Inside Side Duct Assembly

16
HEAT RECLAIMER ASSEMBLY INSTRUCTIONS
Figure 5: Column Panel Assembly

17
HEAT RECLAIMER ASSEMBLY INSTRUCTIONS
Figure 6: Air Access Door Assembly

18
AI R S T R E A M GR A I N CO N D I T I O N I N G SY S T E M S
1004 E. Illinois St., Box 20
Assumption, IL 62510-0020
phone: [phone]
fax: [phone]
May 1997
