GSi RFS-1000 User manual

Roof Stairs
Models:
12 FT. – 156 FT. DIAMETER BINS
Installation Manual
PNEG-2062
Version 6.0
Date: 05-02-19
PNEG-2062

All information, illustrations, photos, and specifications in this manual are based on the latest
information available at the time of publication. The right is reserved to make changes at any
time without notice.
2PNEG-2062 12'-156' Diameter Bin Roof Stairs

Contents
Chapter 1 Safety Precautions ....................................................................................................................5
Safety Guidelines........................................................................................................................5
Cautionary Symbol Definitions......................................................................................................6
Safety Cautions...........................................................................................................................7
Safety Decals ........................................................................................................................... 11
Safety Sign-off Sheet.................................................................................................................13
Chapter 2 Roof Stairs ..............................................................................................................................15
General Information...................................................................................................................15
Assembling the 3-Step Stairs Section .........................................................................................16
Assembling the 4-Step Stairs Section .........................................................................................17
Assembling the 8-Step Stairs Section .........................................................................................18
Assembling the Roof Stair Sections ............................................................................................19
Installing the Roof Stairs ............................................................................................................24
Installing the Handrails ..............................................................................................................26
Limited Warranty — N.A. Grain Products ................................................................................29
PNEG-2062 12'-156' Diameter Bin Roof Stairs 3

NOTES
4PNEG-2062 12'-156' Diameter Bin Roof Stairs

1Safety Precautions
Topics Covered in this Chapter
▪ Safety Guidelines
▪ Cautionary Symbol Definitions
▪ Safety Cautions
▪ Safety Decals
▪ Safety Sign-off Sheet
Safety Guidelines
Safety guidelines are general-to-specific safety rules that must be followed at all times. This manual is
written to help you understand safe operating procedures and problems that can be encountered by the
operator and other personnel when using this equipment. Read and save these instructions.
As owner or operator, you are responsible for understanding the requirements, hazards, and precautions
that exist and to inform others as required. Unqualified persons must stay out of the work area at all
times.
Alterations must not be made to the equipment. Alterations can produce dangerous situations resulting in
SERIOUS INJURY or DEATH.
This equipment must be installed in accordance with the current installation codes and applicable regula-
tions, which must be carefully followed in all cases. Authorities having jurisdiction must be consulted
before installations are made.
When necessary, you must consider the installation location relative to electrical, fuel and water utilities.
Personnel operating or working around equipment must read this manual. This manual must be delivered
with equipment to its owner. Failure to read this manual and its safety instructions is a misuse of the
equipment.
ST-0001–4
PNEG-2062 12'-156' Diameter Bin Roof Stairs 5

Chapter 1: Safety Precautions
Cautionary Symbol Definitions
Cautionary symbols appear in this manual and on product decals. The symbols alert the user of potential
safety hazards, prohibited activities and mandatory actions. To help you recognize this information, we
use the symbols that are defined below.
Table 1-1 Description of the different cautionary symbols
Symbol Description
This symbol indicates an imminently hazardous situation which, if
not avoided, will result in serious injury or death.
This symbol indicates a potentially hazardous situation which, if not
avoided, can result in serious injury or death.
This symbol indicates a potentially hazardous situation which, if not
avoided, can result in minor or moderate injury.
This symbol is used to address practices not related to personal
injury.
This symbol indicates a general hazard.
This symbol indicates a prohibited activity.
This symbol indicates a mandatory action.
ST-0005–2
6PNEG-2062 12'-156' Diameter Bin Roof Stairs

Chapter 1: Safety Precautions
Safety Cautions
Use Personal Protective Equipment
• Use appropriate personal protective equipment:
Eye
Protection
Respiratory
Protection
Foot
Protection
Hearing
Protection
Head
Protection
Fall
Protection
Hand
Protection
• Wear clothing appropriate to the job.
• Remove all jewelry.
• Tie long hair up and back.
ST-0004–1
Follow Safety Instructions
• Carefully read all safety messages in this manual and safety
signs on your machine. Keep signs in good condition.
Replace missing or damaged safety signs. Be sure new
equipment components and repair parts include the current
safety signs. Replacement safety signs are available from
the manufacturer.
• Learn how to operate the machine and how to use controls
properly. Do not let anyone operate without instruction.
• If you do not understand any part of this manual or need
assistance, contact your dealer.
ST-0002–1
PNEG-2062 12'-156' Diameter Bin Roof Stairs 7

Chapter 1: Safety Precautions
Maintain Equipment and Work Area
• Understand service procedures before doing work. Keep
area clean and dry.
• Never service equipment while it is operating. Keep hands,
feet, and clothing away from moving parts.
• Keep your equipment in proper working condition. Replace
worn or broken parts immediately.
ST-0003–1
Sharp Edge Hazard
• This product has sharp edges, which can cause serious
injury.
• To avoid injury, handle sharp edges with caution and always
use proper protective clothing and equipment.
ST-0036–2
Fall Hazard
• Ladders, stairways and platforms are for use by competent
and trained personnel only. Do not allow children or other
unauthorized persons to have access to the equipment.
• Access to the equipment must be restricted by the use of
security fencing and lockable gates.
• Lower sections of ladders must be fitted with a lockable
safety gate to prevent unauthorized access.
• Make sure that hot surfaces have had adequate time to cool
before working on or in the equipment.
• Lock out and tag out power supplies and fuel supplies to all
equipment.
• Do not attach lifting equipment to ladders or platforms.
• Do not go outside of the safety rails provided on elevated
platforms.
• Do not work at heights during high winds, rain, snow, or ice
storms.
ST-0056–1
8PNEG-2062 12'-156' Diameter Bin Roof Stairs

Chapter 1: Safety Precautions
Do Not Enter Bin
• Rotating flighting will kill or dismember.
• Flowing material will trap and suffocate.
• Crusted material will collapse and suffocate.
— If you must enter the bin:
1. Shut off and lock out all power sources.
2. Use a safety harness and safety line.
3. Station another person outside the bin.
4. Avoid the center of the bin.
5. Wear proper breathing equipment or respirator.
ST-0061–1
PNEG-2062 12'-156' Diameter Bin Roof Stairs 9

Chapter 1: Safety Precautions
Confined Space Hazards and Entry Procedures
• Note that the interior of this equipment is considered a con-
fined space. Maintenance of this equipment can require
access to the confined space.
• Access doors must be shut and locked except when access
is required.
• Doors giving access to dangerous equipment must be safety
interlocked.
• The following entry procedures must be followed:
— Be aware of all possible hazards present inside the con-
fined space and wear personal protective equipment
(PPE) as needed.
— Complete a permit to work and follow all permit required
confined space entry procedures defined by the site
manager.
— Make sure that the area has been purged of any hazard-
ous products or gases. Check the atmosphere for harm-
ful gases or vapors with a suitable gas analyzer and
make sure levels are safe before entering.
— Do not smoke or use naked flames.
— Lock out and tag out power supplies and fuel supplies to
all equipment.
— Do not work alone. Work in teams of at least three so
that help is immediately available in the event of an
emergency.
— Confirm that all personnel have safely exited the equip-
ment and tools have been recovered once work is
complete.
ST-0055–1
10 PNEG-2062 12'-156' Diameter Bin Roof Stairs

Chapter 1: Safety Precautions
Safety Decals
The safety decals on your equipment are safety indicators which must be carefully read and understood
by all personnel involved in the installation, operation, service and maintenance of the equipment.
To replace a damaged of missing decal, contact us to receive a free replacement.
GSI Decals
1004 E. Illinois Street
Assumption, IL 62510
Phone: [phone]
Location Decal No. Decal Description
Located next to
aeration system. DC-969 Caution Vacuum Pressure
PNEG-2062 12'-156' Diameter Bin Roof Stairs 11

Chapter 1: Safety Precautions
Location Decal No. Decal Description
On bin door
covers DC-GBC-1A Danger Keep Clear of
Augers
On bin door
covers DC-GBC-2A Warning Unload Instructions
12 PNEG-2062 12'-156' Diameter Bin Roof Stairs

Chapter 1: Safety Precautions
Safety Sign-off Sheet
Below is a sign-off sheet that can be used to verify that all personnel have read and understood the safety
instructions. This sign-off sheet is provided for your convenience and personal record keeping.
Date Employee Name Supervisor Name
ST-0007
PNEG-2062 12'-156' Diameter Bin Roof Stairs 13

NOTES
14 PNEG-2062 12'-156' Diameter Bin Roof Stairs

2Roof Stairs
Topics Covered in this Chapter
▪ General Information
▪ Assembling the 3-Step Stairs Section
▪ Assembling the 4-Step Stairs Section
▪ Assembling the 8-Step Stairs Section
▪ Assembling the Roof Stair Sections
▪ Installing the Roof Stairs
▪ Installing the Handrails
General Information
Roof Stairs may consist of a combination of 3-step, 4-step and 8-step sections (varies with diameter)
which are spliced together before being installed onto the roof.
Refer to the table for stair step sections used for different bin diameters.
Table 2-1 Stair step sections
Bin Diameter (ft.) No. of 3-step stair
Section
No. of 4-step stair
Section
No. of 8-step Stair
Section
12 1*– –
15 –1–
18 2 – –
21 1 1 –
24 3 – –
27 2 1 –
30 1 2 –
33 0 3 –
36 2 2 –
42 3 –1
48 –1 2
54 3 1 1
60 – – 3
66 3 –2
72 –1 3
75 2–3
78 1 1 3
90 2 –4
105 3 1 4
135 2 1 6
156 –1 8**
*RFS-1012 is a 3-step stair section used only for 12 ft. diameter bin.
** RFS-1005 is a 8-step stair section used only for 156 ft. diameter bin.
PNEG-2062 12'-156' Diameter Bin Roof Stairs 15

Chapter 2: Roof Stairs
Assembling the 3-Step Stairs Section
1. Place a left 3-step stringer section (35) and a right 3-step stringer section (36) at a distance and
assemble the three stair steps (34) in between using flange bolts (2) and flange nuts (3).
NOTE:
• Install the flange bolts (2) from the outside of the stringer sections and flange nuts (3)
on the inside.
• Place the stringers with flanges at the bottom and towards the inside.
Figure 2-1 Assembling the 3-step stair section
25/16 x 3/4 in. flange bolt (S-6606) 35 Left 3-step stringer section (RFS-0013)
35/16 in. flange nut (S-3611) 36 Right 3-step stringer section (RFS-0014)
34 Stair step (WBS-0007)
2. Repeat the above step to assemble the multiple sets of 3-step stair sections (if required).
16 PNEG-2062 12'-156' Diameter Bin Roof Stairs

Chapter 2: Roof Stairs
Assembling the 4-Step Stairs Section
1. Place a left 4-step stringer section (61) and a right 4-step stringer section (62) at a distance and
assemble the four stair steps (34) in between using flange bolts (2) and flange nuts (3).
NOTE:
• Install the flange bolts (2) from the outside of the stringer sections and flange nuts (3)
on the inside.
• Place the stringers with flanges at the bottom and towards the inside.
Figure 2-2 Assembling the 4-step stair section
25/16 x 3/4 in. flange bolt (S-6606) 61 Left 4-step stringer section (RFS-0015)
35/16 in. flange nut (S-3611) 62 Right 4-step stringer section (RFS-0016)
34 Stair step (WBS-0007)
2. Repeat the above step to assemble the multiple sets of 4-step stair sections (if required).
PNEG-2062 12'-156' Diameter Bin Roof Stairs 17

Chapter 2: Roof Stairs
Assembling the 8-Step Stairs Section
1. Place a left 8-step stringer section (32) and a right 8-step stringer section (33) at a distance and
assemble the eight stair steps (34) in between using flange bolts (2) and flange nuts (3).
NOTE:
• Install the flange bolts (2) from the outside of the stringer sections and flange nuts (3)
on the inside.
• Place the stringers with flanges at the bottom and towards the inside.
Figure 2-3 Assembling the 8-step stair section
25/16 x 3/4 in. flange bolt (S-6606) 33 Right 8-step stringer section (RFS-0018)
35/16 in. flange nut (S-3611) 34 Stair step (WBS-0007)
32 Left 8-step stringer section (RFS-0017)
2. Repeat the above step to assemble the multiple sets of 8-step stair sections (if required).
18 PNEG-2062 12'-156' Diameter Bin Roof Stairs

Chapter 2: Roof Stairs
Assembling the Roof Stair Sections
Roof Stairs may consist of a combination of 3-step, 4-step and 8-step sections (varies with diameter)
which are spliced together before being installed onto the roof.
Before You Begin
The following assembly instructions are for splicing three 8-step sections to form a roof stair section.
Refer to the table in General Information, page 15, for the number of stair step sections required for each
diameter bin.
1. Connect the assembled sets of stair sections (O) together using stringer splice plates (37), bolts (2)
and nuts (3).
Figure 2-4 Assembling the stair sections
25/16 x 3/4 in. flange bolt (S-6606) 37 Splice plates (RFS-0019)
35/16 in. flange nut (S-3611) O 8-step stair section
PNEG-2062 12'-156' Diameter Bin Roof Stairs 19

Chapter 2: Roof Stairs
2. Align and install the handrail posts (38) to the stair sections using the flange bolts (2) and flange
nuts (3).
NOTE:
• Determine the location of the handrail posts (38) for each diameter (see Figure 2-7,
page 22 and Figure 2-8, page 23).
• The handrail post connections should have the bolts oriented so the nut is outside the
walking area to eliminate a trip hazard.
• Do not tighten the flange bolts (2), leave hand tight until the stairs assembly is installed
onto the roof.
Figure 2-5 Assembling the roof stair handrail posts
25/16 x 3/4 in. flange bolt (S-6606) 38 Roof stair handrail post (RFS-0048)
35/16 in. flange nut (S-3611) O 8-step stair section
20 PNEG-2062 12'-156' Diameter Bin Roof Stairs
