GSM Activate SWV2G-RS2 User manual

GSM 240V ROLLER SHUTTER OPENER
No More Key Fobs! Open roller shutters with your mobile phone
www.gsm-activate.co.uk
Page 1
MODEL NUMBER SWV2G-RS2

Product Information
The GSM Roller Shutter/Opener incorporates a professional industrial grade GSM engine
that receives calls at its SIM number as any ordinary GSM phone. The system operates in
the GSM module Quad-band frequency 850/900/1800/1900Mhz.
Just to give an example, if your SIM has a phone number 0775775236,that is the number
you have to call to open the shutter door. The system has a memory where you will store the
numbers of people enabled to open your shutter (up to 50).
When the Roller Shutter/Opener receives a call it will check the calling number and if the
number is in the list you have prepared it will answer the call. You then use your telephone
keypad to open and close the roller shutter.
The advantages of this over other systems are that you do not have to leave the car to open
the shutter avoiding weather or safety issues. You don't need to carry a separate remote
device or indeed replace it if it were to get lost.
Specification
● Simply dial the simcard number to open the gate/shutter door.
● Phone list for added security up to 50 stored numbers.
● Text for Signal Strength
● Call and use keypad to move shutter up or down.
● Antenna supplied.
● Sim Active Function.
● Dimensions - L150 x W90 x H45mm.
● Dimensions PCB Only - L125 x W67mm.
● INPUT 240VAC
● Output Relays are 10AMP N/O or N/C Volt free.
● Quad band freq 850, 900, 1800, 1900mhz
● No need to keep replacing remote keyfobs when the keyfobs are lost!
Page 2

INSTRUCTIONS
IMPORTANT- PLEASE READ
PLEASE MAKE SURE YOU DISCONNECT THE POWER WHEN YOU FIT THE
SIMCARD AND YOU PLACE THE SIMCARD WITH THE CLIPPED CORNER FACING
OUT WARDS.
PLEASE SEE PICTURE ABOVE.
1: First you must register and put credit on your simcard. Please follow the instructions
given with your simcard
2: Insert the simcard into a mobile phone and disable the voicemail using the codes
below
Vodaphone: call 1210 Tesco call 2915
T-Mobile: call 222 O2 call 1760
Orange: call 4502 Giff Gaff call 1626
EE - send the text message command VM OFF to 150
3: Refer to steps 1 - 4 in Fig 1 above
Important Notice
You must remove the PIN request from the SIM before inserting it into the unit otherwise
the device will not work. In order to do so, insert the SIM in a phone and disable the PIN
request.
1. Slide back the sim door and lift it up.
2. Slide the simcard into the door making sure that the clipped corner of the simcard lines
up with the clipped corner of the simcard holder.
3. Close the simcard door.
4. Slide the simcard door to lock the simcard in place.
When you first switch the unit on, the red and blue LED will come on for 3 seconds.
The blue LED will then go out leaving just the red LED on.
When the unit finds a signal the red LED will go out and the blue will come on and must
stay on before you can operate the unit.
Page 3

Page 4
How to program the roller shutter opener
Text message entry
You must first enter the telephone numbers that are authorized to use the Roller shutter
opener. Insert your simcard into the Roller Shutter opener and turn on the unit and wait
until you receive a steady blue light this will indicate that you have a mobile signal.
You will now need to send a text with the contact numbers.
Example: (Hash) (store) (Star) (phone number) (star)
To avoid confusion we have colour coded the hash (#) and the star (*) symbols.
#store*01798123456* Then send this as a text to the simcard
#store*07713099515*
NOTE
PLEASE NOTE YOU CAN ONLY SEND ONE NUMBER AT A TIME. (Max 50 numbers)
PLEASE SEND THE TEXT MESSAGE AND WAIT FOR THE ROLLER SHUTTER
OPENER TO SEND YOU BACK THE TEXT ACKNOWLEDGEMENT “STORED” BEFORE
YOU TRY TO ADD ANOTHER NUMBER VIA TEXT ENTRY.
If you do not need authorized numbers you can turn Dip switch 1 to the OFF position as in
fig.1. This will allow any number to operate the roller shutter if they call the simcard number
used inside the unit. Automated calls will not be able to operate the unit as they would be
unable to use the keypad commands.
If you wish to cancel a number follow this example. (Hash) (delete) (Star) (Star)
#delete*01798123456* Then send this as a text to the simcard.
Please make sure you have credit on your simcard to receive the text acknowledgment.
It may take a time to receive a text acknowledgement. This depends upon how busy your
telephone network is.

How to use the Roller Shutter Opener
Using your mobile or landline phone, dial the simcard number. You will hear 2 ring tones.
The unit will then answer the call. Once the call is open you can then use the keypad on
your phone to operate the device.
Pressing key 1 will cause relay 1 to pulse
Pressing key 2 will cause relay 2 to pulse
Pushing key number 1 or 2 again will stop the command and the shutter will hold in a
stationery position.
We recommend connecting relay 1 to OPEN/UP and relay 2 to CLOSE/DOWN on your
roller shutter control board.
When you press 1 you will here a fast dialling tone.
When you press 2 you will hear a slower dialling tone.
Please view the diagram on page 6 for wiring information.
SIGNAL STRENGTH
To help make sure that you place the unit in a suitable position you can text the unit to see
how much signal strength the dialler is receiving by texting the command #SIGNAL
The unit will perform a test on the signal strength.
You will receive a text telling you a signal strength score between 0 up to 30 we strongly
recommend that you place the unit where you can receive a signal strength score of at
least 10.
You will find that with a score less then 10 the unit will be unreliable and is n o t suitable.
Factory Reset
To perform a quick factory reset which will delete all stored numbers please use the text
command #RESET
The red LED will flash 6 times to indicate that the reset has been successful.
QUICK REFERENCE OPERATION ACKNOWLEDGE
#store*number* STORE NUMBER NUMBER STORED
#delete*number* DELETE NUMBER NUMBER STORED
#RESET FACTORY RESET RED LED FLASH x6
#SIGNAL SIGNAL STRENGTH SCORE BETWEEN 1-30
Page 5

For more technical support please browse the FAQ’s on our website at www.gsm-
activate.co.uk. Alternatively email or call our technical support team on 0800 246 1583 or
at [email protected] and we will reply or call within 24 hours Monday - Friday.
