GT GT8 User manual
Page 1
Version 1.1 January 2021
GT8 Terminal
User Guide
Disclaimer
Copyright © 2021, Grosvenor Technology Ltd. All rights reserved.
All brands, names, or trademarks appearing in this document are acknowledged as the trademarks of their
respective owners.
No part of this document may be reproduced in any form or by any means for any purpose without the
written permission of Grosvenor Technology.
Whilst we make every eort to ensure the accuracy of our publications, Grosvenor Technology assumes no
responsibility or liability for any errors or inaccuracies that may appear in this document.
www.gtclocks.com
Page 2
Contents
Preface 5
Certications 6
BatteryLife 6
Maintenance 6
Cleaning 6
InstallationSafety 6
WEEE 7
About the GT8 Terminal 7
About this Guide 7
RelatedDocuments 7
TechnicalSupport 7
Europe,MiddleEastandAfrica 7
NorthAmerica 7
Hardware Specication 8
Display 8
Processor 8
OperatingSystem 8
Input/Output 8
Memory 8
Internal Persistent Storage 8
HostConnectivity 8
Power 8
OperatingTemperature&Humidity 9
PlugandPlayDeployment 9
Integration 9
Sound 9
Camera 9
PhysicalSecurity 9
Page 3
Contents
Dimensions 9
Sustainability 9
Reader Modules 10
ExpansionModules 11
Comms Modules 11
BiometricModules 11
Software 12
Installation 13
Fitting the Terminal 13
Location: 13
Power Options 14
AC110-240VviaAdapter 14
DC 12V 14
PoweroverEthernetPoE 14
BatteryBackup 15
Installing Optional Modules 16
FrontPlate 16
FittingInternalFingerprintReaderModule 17
FittingProximityorCardSwipeReaderModules 18
FittingtheWi-FiModule 19
Page 4
Contents
System Start-up 20
TerminalSetupNavigation 20
Terminal Shut Down 21
Terminal Recovery 22
Software Reset 22
RecoveryMenu 22
Terminal Setup 23
AccessingtheTerminalSetup 23
ConguringNetworkSettings 24
EnableandCongureWi-Fi 24
CongureWiredNetworks 25
ConguringReaders 26
WiegandBitmask 27
ParityMask 27
Testing Card Readers 28
Testing the Camera 28
TestingBiometricReader 29
Terminal Health Information 30
Software Deployment 31
DeploymentfromUSBmemorydevice 31
ApplicationSetup 32
Care and Maintenance 33
MaintenanceInstructions 33
Page 5
Preface
Important Note:
Menus and options will vary depending on the hardware
options supplied and software version installed. Please
refer to additional instructions supplied with your terminal
for additional information.
Page 6
Preface
Certications
The GT8 has been certied for use in the following markets
Europe CE Certication
USA FCC, UL 62368-1
India BIS Certication
In addition, the clock has been certied to comply with the requirements of the CB certication authority
which may meet compliance requirements in their member countries. For further information regarding CB
certication please see www.iecee.org/dyn/www/f?p=106:40:0 , or discuss with Grosvenor Technology’s
professional services team.
If the GT8 is intended to be used in countries other than those listed above, please contact Grosvenor
Technology’s professional services team to discuss how we can assist with certication.
Battery Life
The GT8 terminal is tted with a Lithium-Ion battery which typically has a service life of between 3 and 5
years. In order to ensure the continued reliable operation of the back-up battery function we recommend
regularly checking the condition of the battery and replacing it when it has reached the end of its service life.
The GT8 is also tted with a button cell type battery on the main PCB to maintain the real-time clock (RTC)
of the device when power is removed. This battery typically has a service life of around 10 years. The
battery should only be replaced by suitably qualied engineers and care should be taken to avoid damage to
the PCB caused by ESD (ElectroStatic Discharge). Replacement batteries must be of the same type as the
original, and the old battery should be disposed of in accordance with local regulations.
Care should be taken when recycling the terminal to ensure that the batteries are removed and recycled in
accordance with local regulations/legislation.
Maintenance
The GT8 terminal does not require any regular maintenance during its service life.
It is however recommended that periodically (once every 6 months) the condition of the battery should be
checked to see if there are signs that it’s reaching the end of its life. Occasionally, the battery may start
to swell towards the end of its life, if this is noticed, the battery should be replaced (Part Number: EM-BB-
2HR-A).
Cleaning
Cleaning of the outside of the terminal can be undertaken at intervals appropriate to the environment
that it is being used and the frequency of use. In all cases it is recommended that the surface of the
clock is wiped with a lint free cloth that has been dampened with up to 70% isopropyl alcohol. We do not
recommend spraying liquids directly onto the surface of the clock as this could potentially cause damage to
the electronics. Particular care should be taken when cleaning the display and biometric devices to prevent
damage.
Installation Safety
The GT8 clock should be installed in accordance with the instructions documented in this user guide. The
clock should be installed in compliance with any Health and Safety legislation and it is recommended that
any electrical or network connections to the clock are undertaken by a suitably qualied engineer.
The GT8 clock is designed to be installed indoors only with a normal ambient operating temperature
between 0-35 Deg C (32-95 Deg F).
i
!
Page 7
Preface
About the GT8 Terminal
GT8 is more than just a next generation time and attendance terminal - it’s designed to open up a world of
possibilities for wider integration with Human Resources Management Systems (HRMS) and a myriad of
potential new applications beyond workforce management.
About this Guide
This User Guide is intended for users who will be responsible for installing and conguring the GT8 terminal.
This guide was written with the following rmware, application and optional modules installed.
Firmware: v2.0.0
Application: GTEasyClock v2.0.0
RM-LUM-M320-GT8 Fingerprint reader
RM-HID-B Prox/card reader
CM-WIFI-M2-22 Wi-Fi module
Related Documents
You should also refer to the following documents, available from Grosvenor Technology:
GT API Reference Manual - This document is targeted at software developers writing Android applications
for the GT8 terminal.
Application User Guide - Relevant to your application.
Technical Support
Technical Support can be obtained from Grosvenor Technology from the following points of contact:
Europe, Middle East and Africa
Phone: +44 (0)1202 627611
E-mail: HCM-EMEAsupport@grosvenortechnology.com
Website: www.grosvenortechnology.com
North America
Phone: +1 800.989.5197
E-mail: HCM-USsupport@grosvenortechnology.com
Website: www.gtclocks.com
Care should be taken when installing the clock to ensure that it does not present any possible hazards to
people or property within its vicinity. The clock should be installed at a height that ensures compliance with
any local disability legislation
WEEE
In accordance with EN 50419 the GT8 clock must be disposed at the end of its life by returning to a
designated recycling organisation for waste electrical and electronic equipment as dened within the WEEE
directive. The clock must not be disposed of in normal domestic waste.
Batteries should be carefully removed from the clock prior to disposal taking care to prevent short-circuits,
crushing or damage to the battery housing.
Page 8
HardwareSpecication
Display
8 inch full colour capacitive multi-touch display with toughened glass for use in high trac environments
16:10 aspect ratio, 1280 x 800 pixel resolution
A separate glass inlay, below the display, provides the capability to customise the terminal with backlit
corporate branding
Processor
1.6GHz Quad Core
Operating System
Android 10.0
Input / Output
4 + 2 Internal USB 2.0 ports
Facial recognition
A choice of optional input/output accessories are available, including:
Suprema SFM Slim
Lumidigm M320
Expanded ngerprint database of 10,000+ using fast matching on clock algorithm
Contactless smart card readers: Mifare, iClass SE, Feig and Multi-tech readers
Proximity card reader: supports a range of readers, including HID Prox 125kHz
Magnetic stripe card reader
Barcode reader or external scanner: multi-format, Visible and IR
I/O relay modules
Memory
3GB
Internal Persistent Storage
16GB high performance ash storage
Host Connectivity
Ethernet: 10/100/1000MHz
Wi-Fi: Intel dual band, dual stream 802.11ac (optional)
Bluetooth (optional)
Power
12VDC ±5%
Power over Ethernet Plus (POE+) 802.3at
Internal lithium ion battery, up to 2 hours backup
Page 9
HardwareSpecication
Operating Temperature & Humidity
0°C - 35°C (32ºF to 95ºF)
5-90% Non-condensing
Plug and Play Deployment
Fast easy installation
Easy to t reader modules and peripherals
VESA mount xings
Integration
Supports native Android and HTML 5 Apps
Software Development Kit available
Sound
Integrated stereo speakers
Integrated microphone
Camera
5 Megapixel with front illumination; supports photo and video
Physical Security
Metal wall-mount bracket with optional security xing
Optical tamper detection
Dimensions
216mm (H) x 206mm (W) x 78mm (D)
8.5 inches (H) x 8.1 inches (W) x 3.8 inches (D)
Weight: 1.5Kg (3.3Lbs)
Sustainability
7-year design life
Minimal footprint with industry-leading aesthetics
Page 10
HardwareSpecication
Subject Illumination
Visible and IR lighting
Camera
Customisable Inlay
Congurable back lighting
Prox Reader Module
Or custom logo with illumination
Touch Screen
Lumidigm or SF Slim Bio
Module with illumination
Swipe Reader Module
Mag, Barcode Visible & IR
The GT8 Terminal can be customised by tting a range of optional modules.
Reader Modules
125KHz Reader Module RM-HID-B
iClass SE Reader Module RM-ICLSE-B
Elatec MultiTech Reader Module RM-ELATEC-B
Feig HI Reader Module RM-FEIG-HI-B
Feig FC Reader Module RM-FEIG-FC-B
Barcode Visible Red Reader Module RM-BARV-B
Barcode Infra Red Reader Module RM-BAR-B
Magnetic Stripe Reader Module RM-MAG-B
RFIdeas MultiTech Reader Module RM-RFID-B
Page 11
HardwareSpecication
Battery Connector
For connection of the GTL Li-Ion
Battery Pack
EM-BB-2HR-A
Provides up to 2 hour runtime
Battery backup may be used with all
power options including PoE
Note: Units are shipped with battery
disconnected. Please connect
battery before rst use (tuck wires
into space at side of battery to avoid
obscuring Power IN Connector.
Power IN Connector (2.1mm)
12V DC External PSU (centre
positive) 12V± 5% with minimum 2A
capacity (refer to Power Loading for
current calculation)
Warning: Only t battery pack
specied, failure to observe may
result in re hazard
Ethernet Connector
10/100/1000baseT Full duplex, auto
crossover, supports PoE+
USB Connector
USB2 x 4, for connecting
external I/O devices
USB Connector
USB2 x 2, for connecting
internal modules
Accessory Mounting
Stereo Speakers
One each side
Bio Module Location
SF Slim or Lumidigm
Battery Location
Dotted line
Micro USB Connector
Debug/ADB port
Reset Button
Initiates hardware reset, terminal
will reboot. Accessible via hole in
back cover (using straightened
paper clip or similar).
Proximity Reader & Card Swipe
Mounting Position
Camera ModuleJP4 Socket
Supports WiFi extension modules
Swipe Reader Module Connector
Reader Modules include
- Mag Swipe
- Barcode Swipe
RECOVERY Button
To access the on-screen
options menu for functions
including Factory Reset.
RTC Backup Battery
Real Time Clock Backup Battery
maintains time during power
disconnection. 10 year life
Expansion Modules
IO Relay Module EM-IO-RLY-B
IO External Reader Relay Module EM-IO-ER-B
Temperature Module EM-TM-B
Comms Modules
WiFi Comms Module CM-WIFI-M2-22
Biometric Modules
Lumidigm Reader Module GT8 RM-LUM-M320-GT8
Suprema SF Slim Reader Module GT8 RM-SP-SFSLIM-GT8
Page 12
Software
Operating System Android 10.0
Supports native Android and HTML 5 Apps
Remotely upgradeable/congurable
Page 13
Installation
Before starting the installation consider
Which power option is to be used - as this may inuence cabling requirements, vicinity to power outlets
and accessory modules required (refer to Power Options for GT8)
Fitting the Terminal
Location:
The Terminal should be xed to a at surface at a height that is comfortable for users to view and interact
with the screen without glare from reections and in a suitable level of ambient light. Take care to adhere to
any local regulations such as disabled access when determining the height of the unit.
Fitting GT8 to Wall Bracket
1. Remove wall bracket securing screw to release
wall bracket from GT8.
2. With the wall bracket against the wall, mark the 4
screw mount xing points (C) and the preferred
cable routing position.
3. Drill holes in the wall and mount the wall bracket
with screws taking care to feed the cables
through the bracket aperture.
4. Oer the GT8 unit close to the wall bracket and
connect Ethernet and/or power cables.
5. Position the GT8 unit slightly above the wall
bracket with its back parallel with the wall and
make sure all cables are free to move.
6. Centralise the GT8 unit against the wall bracket
and slowly lower the terminal by sliding it down
the wall until metal tangs ‘A’ engage into slots ‘B’.
7. With the terminal fully down until it stops against
the wall bracket re-t the M4 screw in the base
making sure to press the lower portion of the
terminal into the wall to make sure it sits snug
against the wall.
VESA Mounting Points
A
A
B
B
Optical Tamper
Reective Strip
Do not remove!
C
C
C
C
For optimum xing
we recommend using
the outer wall plate
mounting holes ‘C’.
D
Cable Apertures
For ease of cable routing we recommend using
the lower (larger) aperture where possible.
When running cables from underneath, please
remove the blanking plate ‘D’ from the GT8.
Wall Bracket
Securing Screw
Page 14
PowerOptions
AC 110-240V via Adapter
The GT8 Terminal can be powered from an AC power outlet using an optional plug-top or wall wart power
supply. Adapters include
AE-PSU-PT-12VDC universal adapter with UK, Europe, Australia and US interchangeable AC plugs
AE-PSU-NA-12VDC adapter with US AC plug
DC 12V
The Terminal can be powered from a suitable
12Vdc power supply with 2.1mm DC plug centre
positive connected to the ‘+12V DC’ power in jack.
The supply should have a stabilised voltage output
of 12VDC ±5% with minimum 2A capacity. The
power supply should incorporate suitable overload
protection.
The GT8 power indicator will show blue when power
is supplied via the 12V power jack either with direct
DC connection or with an AC power adapter.
Power over Ethernet PoE
The GT8 may be powered via the Ethernet cable
with suitable upstream PoE+ switch or injector.
Supported standards
IEEE 802.3at (PoE+) injector provides Terminal
with 2000mA @12V
Note: PoE+ is recommended to ensure there
is sucient power available to support dierent
congurations of the terminal.
When the GT8 is running from PoE the power
indicator on the front of the Terminal will show green.
Page 15
PowerOptions
Battery Backup
As standard the GT8 is tted with a backup battery
(EM-BB-2HR-A) to run the Terminal should the normal
power supply fail, providing up to 2-hours runtime.
When the battery pack is installed the terminal will
continue to run when power is removed until the
battery charge level reaches its lower threshold. The
terminal may be shut down prior to battery exhaustion
by using the ‘Shut Down’ option accessible through
the launcher menu. Once shut down the terminal will
remain o until power is restored. When in the shut
down state there is very little draw on the battery and
it can remain in this state for extended periods. For
optimum battery life it is recommended that the battery
is charged a minimum of every six months if the unit is
in shut down for prolonged periods by applying power
to the Terminal.
Charging of the EM-BB-2HR-A battery pack is
managed by the GT8 terminal and depending on
power source typical recharge time from 0% to 100%
will range from 3 hours to 12 hours. Charging times
will be extended in elevated ambient temperatures to
protect the battery.
When the GT8 is running from battery the power
indicator on the front of the Terminal will show red.
The EM-BB-2HR-A battery pack comprises a
rechargeable li-Ion battery along with protection
circuitry to prevent safety hazards caused by
overload, over-charging or over-discharge.
WARNING: ONLY FIT BATTERY PACK
SPECIFIED, FAILURE TO OBSERVE MAY
RESULT IN FIRE HAZARD
Service life of the EM-BB-2HR-A battery pack is
typically 3 to 5 years depending on conditions
and regular replacement is recommended. The
battery may become swollen towards the end of
its service life, if swelling is observed the battery
should be replaced.
Battery Retaining Clip
Ensure the retaining clip pops out to
secure the battery
Battery Connector
For connection of the GTL Li-Ion
Battery Pack
EM-BB-2HR-A
Provides up to 2 hour runtime
Battery backup may be used with all
power options including PoE
Note: Units are shipped with battery
disconnected. Please connect
battery before rst use (tuck wires
into space at side of battery to avoid
obscuring Power IN Connector)..
Warning: Only t battery pack
specied, failure to observe may
result in re hazard
Note: Position of battery cable connections.
Page 16
InstallingOptionalModules
When tting any optional modules place the terminal face down on a clean at surface that will not scratch
the glass front and remove the lower and upper rear covers. Remove battery, this is optional but generally
makes the tting of modules easier. Once the chosen modules have been tted, ret the upper rear cover
rst, ensuring no cables are trapped, followed by the lower cover.
Tip: You may nd it easier to ret the lower cover with the battery removed and then t the battery
afterwards, ensuring the battery retaining clip pops out to secure the battery in place.
Front Plate
Depending on the option chosen the GT8 lower glass front plate may be either.
With ngerprint aperture.
Without ngerprint aperture.
Both versions may be (optionally) customised to include a company logo etc.
Warning: Once secured the
lower glass front plate cannot be
removed without damaging it.
Page 17
InstallingOptionalModules
Fitting Internal Fingerprint Reader Module
RM-LUM-M320-GT8
Fixing screws
USB Connection
1. Remove lower cover.
2. Slide ngerprint reader
module under the PCBA
ensuring ribbon cable does
not detach.
3. Secure with screws provided
(do not over tighten).
4. Connect USB cable to one of
the left-hand ports.
5. Replace lower cover (do not
over tighten screws).
Note: The ngerprint reader module
is normally a factory t option only.
Page 18
InstallingOptionalModules
Fitting Proximity or Card Swipe Reader Modules
Note: Proximity and card swipe readers use the same mounting location, only one internal module may
be tted to the GT8 at the same time. When tting swipe card readers ensure the reader head is located
correctly in the aperture at the bottom of the GT8 before fully securing using the screws supplied.
RM-MAG-B
RM-BAR-B
RM-HID-B
Proximity Reader & Card Swipe
Mounting Position
Fixing screws
RM-HID-B in position with ngerprint reader tted.
1. Remove lower cover.
2. Position proximity/card swipe module and
secure with screws provided (do not over
tighten).
3. Connect ribbon cable to connector on
PCBA, circled right.
4. Replace lower cover (do not over tighten
screws).
Note: To avoid undue stress on the cables,
the ribbon cable should pass underneath the
ngerprint USB cable (when tted).
Page 19
InstallingOptionalModules
Fitting the Wi-Fi Module
CM-WIFI-M2-22
Wi-Fi Module Bus Connector
PCIe and USB connections to GT8 ‘JP4’
socket. Observe key-way when tting.
Antenna Fixing
Press hooked side to
fabric on Terminal sides.
Wireless Antennae
Two antennae, one
for each stream. Both
antennae are duel band.
Antenna Connections
Push t antenna connections
for each antenna.
1. Position Wi-Fi module against
the JP4 socket (at a vertical
angle of approximately 45
degrees), observing key-way,
and gently push in.
2. Secure Wif-Fi module with
screw supplied (do not over
tighten).
Tip: You may need to press down
lightly on the module to make
tting the securing screw easier.
3. Applying light pressure,
attach antennae to the fabric
strips on the sides of the GT8
Terminal.
(The fabric strips are attached
during manufacture and are
not supplied separately.)
Securing Screw
JP4 Socket
Antenna Fixing
Press hooked side to
fabric on Terminal sides.
Page 20
SystemStart-up
When the system is powered on, a bootloader runs which loads the Android operating system. This runs
start-up scripts to set up and congure the terminal and to start enabled services.
Once the unit is fully booted, the initial screen gives you the opportunity to enter the Terminal Setup by
pressing the cog icon on the launcher start-up screen as shown below.
After a short delay the terminal will automatically proceed to run the installed application. If no application is
congured to auto-start the Terminal will stay on the launcher start-up screen.
Note: If an application is installed but not congured the terminal continues to switch between the initial
screen and the application set up screen.
Terminal Setup Navigation
Navigating using the touch screen.
Touch icon to open menu.
Touch label text to open a menu item e.g.
This opens the item options menu e.g.
To activate/deactivate a toggle switch touch it.
To go back touch the back arrow displayed at
the top left or bottom centre (location varies
depending on menu item opened).
To return to initial screen (from any screen) touch
the circle button on the bottom menu.
Note: The square button (in the bottom menu) is
reserved for future functionality and is currently
inactive.
Touch and drag your nger across/down/up
the screen to scroll left/right or up/down to view
hidden content.
Table of contents
