Partner C10-1R User manual

RFID
(optional)
USB Micro SD Card
USB
Kensington lock
Power Switch*
10.1” Touch Panel
Feed Button
Printer Door
Release Button
Printer Door
MSR (optional) IC Card Reader
(optional)
Fingerprint
(optional)
Identifying Components
Cash Drawer
DC-in Jack COMUSB COM
HDMI
COMCOMUSBLAN
LINE OUT
Before installing and using the machine, take note of the following precautions:
• Do not place the unit on an unstable surface, cart, or stand.
• Do not block the slots and opening on the unit, which are provided for ventilation.
• Only use the power source indicated on the marking label. If you are not sure, contact your dealer or the
Power Company.
• When replacing parts, ensure that your service technician uses parts specified by the manufacturer.
• Do not place anything on the power cord. Place the power cord where it will not be in the way of foot
traffic.
Safety information
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm between the radiator & your
body.
FCC Radiation Exposure Statement:
低功率射頻器材技術規範:
取得審驗證明之低功率射頻器材,非經核准,公司、商號或使用者均不得擅自變更頻率、加大功率或變更原設計之特性及功能。
低功率射頻器材之使用不得影響飛航安全及干擾合法通信;經發現有干擾現象時,應立即停用,並改善至無干擾時方得繼續使用
。前述合法通信,指依電信管理法規定作業之無線電通信。低功率射頻器材須忍受合法通信或工業、科學及醫療用電波輻射性電
機設備之干擾。
NCC 警語
VCCI-A
この装置は、クラスA機器です。この装置を住宅環境で使用すると電波妨害を引き起こすことがあります。この場合には使用者が適切
な対策を講ずるよう要求されることがあります。
VCCI Information
警告使用者
This is Class A Product. In domestic environment this product may cause radio interference in which case the
user may be required to take adequate measures.
WARNING
The system uses a 3V CR2032 battery mounted on the mainboard to keep time. There is a risk of explosion if the
wrong battery type is used when replacing. Dispose of used batteries according to local ordinance regulations.
WARNING
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This device has been tested and found to comply with the limits for a Class A digital device, pursuant to part
15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Federal Communications Commission (FCC) Statement
這是甲類的資訊產品,在居住的環境中使用時,可能會造成射頻干擾,在這種情況下,使用者會被要求採取某些適當的對策。
警告:若置換不同型式之電池有起火或爆炸風險
警告:在居住环境中,运行此设备可能会造成无线干扰。
消费者若使用电源适配器供电,则应购买配套使用获得CCC认证并满足标准要求之电源适配器。
Quick Start Guide
C10-1R
拍檔科技股份有限公司/Partner Tech Corporation
新北市新店區寶橋路233之1號10樓
10F., 233-1, Baoqiao Road, Xindian, New Taipei City 231, Taiwan
Phone: +886-2-29188500
http://www.partner.com.tw/
聯絡資訊/Contact Information
CE RF Feature
RF Spec. NFC
Frequency Range
Max. Output Power (dBm)
13.56MHz
NA
This table is prepared in accordance with the provisions of SJ/T 11364.
Indicates that said hazardous substance contained in all of the homogeneous materials for this part is below the limit
requirement of GB/T 26572.
Indicates that said hazardous substance contained in at least one of the homogeneous materials used for this part is above the
limit requirement of GB/T 26572.
○○○○○○
○○○○○○
○○○○○○
○○○○○○
○○○○○○
○○○○○○
╳ :
○ :
表示该有害物质至少在该部件的某一均质材料中的含量超出 GB/T 26572 规定的限量要求。
表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572 规定的限量要求以下。
╳ :
○ :
本表格依据 SJ/T 11364 的规定编制。
“○”係指該項限用物質之百分比含量未超出百分比含量基準值。
“-”係指該項限用物質為排除項目。備考2.
備考1.
電源線/电源线/Power Cable
其他線材/其他线材/ Other
Wire
電路板/ 电路板/Circuit
board
液晶面板/ 液晶面板/LCD
Panel
塑膠外殼/ 塑料外壳/Plastic
Shell
喇叭/ 扬声器/Speaker
多溴二苯
醚(PBDE)/
Polybrominated
diphenyl ethers
(PBDE)
多溴聯苯(PBB)/
多溴联苯(PBB)/
Polybrominated
biphenyls
(PBB)
六價鉻(Cr6+)及
其合物/
六价铬(Cr6+)及
其合物/
Hexavalent
chromium
(Cr6+) and its
compounds
鎘(Cd)及其化
合物/
镉(Cd)及其化
合物/
Cadmium(Cd)
and its
compounds
汞(Hg)及其化
合物/
Mercury(Hg)
and its
compounds
鉛(Pb)及其化
合物/
铅(Pb)及其化
合物/
Lead(Pb) and
its compounds
單元/ 部件名称/
Part name
限用物質及其化學符號/ 有毒有害物质或元素/ Hazardous substances' name
設備名稱:POS Terminal (電子收銀機/电子收款机) Model (型號/型式): C 1 0 -1R
10.1”, Resolution 800 x 1280
PCAP touch
Rockchip RK3568
DDR4 4GB
Emmc64GB + 1x Micro SD Card Slot
4 x USB 3.2 + 2 x USB 2.0
4 x Serial ports, RS232 (RJ45), 0V/5V/12V selected in UI
(COM1, COM2, COM3, COM4)
1 x LAN, (IEEE 802.3 10/100/1000 Mbps Ethernet, RJ45)
1 x RJ11 port supports 2 cash drawers with 24V / 12V by jumper setting
1 x Audio (1 x line out)
1 x HDMI 2.1
1 x DC +24V input
1 x Micro SD card
1 x Speaker 3W
3" Thermal printer
MSR (Beep), IC Card Reader, Fingerprint, RFID
2D Bar Code Scanner
5M Camera
CD-101C
2 Independent Displays (Main Display + CD-101C or HDMI)
N/A
Android 12
N/A
AC-In 100~240V / DC-Out 24V,72W
System Operating Temperature:0~40°C
System Humidity: 15% ~ 80%
Storage Temperature: -20~60°C
262.26 (W) x 291.77 (H) x 247.13 (D) mm
3.3 Kgs
Display
Touch
CPU
Memory
Storage
External I/O
Interface
Speaker
Printer
Optional Peripheral
Display Support
Spill & Dust resistant
Operation System
SW
Power Adaptor
Reliability
Dimensions
Weight
C10-1R
Item
Specification
