GTCO CalComp Accutab VI User manual

AccuTab VI 1

AccuTab VI 2
Table of Contents
Introduction
Parts Checklist
What You Will Need to Use AccuTab VI
PC Requirements
For a USB Installation
For an Optional Serial Installation
AccuTab VI Overview
Active Area
AccuSet Menu
Indicator Light
Transducer
Setting Up Your AccuTab VI
Preparing the AccuTab VI
Mounting on the Stand
Attaching the Optional Accessory Tray or Plan Holder
Software Configuration
Configuring Non-Wintab Applications
Installing the TabletWorks Driver
Hardware Configuration
Transducer Connection
USB Connection
Optional RS-232 Serial Connection
Tablet Power On
Using the AccuSet Menu
Resetting the AccuTab VI
Turning the Alarm Off and On
Testing the Active Area
Configuring Your AccuTab VI for Specific Applications
Example: Configuring for a Specific Application
Table 1: AccuSet Menu Codes for Selected Applications
Table 2: Configuration Details for AccuSet Menu Codes
AccuTab VI Tones
Table 3: AccuTab VI Tones
Introduction to the Tablet Configuration Utilities
Communication Options
Output Format Options
5
5
7
7
7
7
8
8
8
8
8
9
9
9
9
10
10
10
10
11
11
12
12
13
14
14
14
15
15
16
17
20
20
21
21
21

AccuTab VI 3
Mode Options
Using the Tablet Configuration Utilities
Learning the Basics
Using the Cursor
Learning Basic Movements
Clicking and Double-Clicking
Dragging
Caring for the Tablet and Transducer
Cleaning the Tablet
Cleaning the Cursor
Troubleshooting
Tablet Checklist
Computer Checklist
Software Checklist
Does the tablet work with some software?
Did the software work in the past?
Troubleshooting Chart
Procedure A: Begin Troubleshooting
Procedure B: Troubleshooting
Returning your Tablet for Repair
Repacking for Shipment
Appendix: Optional Transducers
Transducers
Cursors
Pens
Care and Maintenance
Replacing the Pen Tip
Replacing the Cordless Pen Batteries
Replacing the Cordless Cursor Batteries
Reducing Monitor Interference
Changing the Frequency of Cordless Cursor
Changing the Frequency of Cordless Pen
Regulatory Statements and Warranty
Radio and Television Interference
Canada
Declaration of Conformity
Japan
European Union Emission Directive
22
23
25
25
26
26
26
26
26
27
27
28
28
29
29
29
30
31
32
33
33
33
33
34
34
35
35
36
37
38
38
38
38
38
39
40
41
41

AccuTab VI 4
European Union WEEE Directive
Bescheinigung des Herstellers/Importeurs
Limited Warranty for the AccuTab VI
41
42
43

AccuTab VI 5
Introduction
Designed for the GIS professional, the AccuTab VI series offers a variety of large format
digitizers with the highest level of accuracy on the market today. Guaranteed superior data
integrity and compatibility with the leading GIS hardware and software packages –
including Class One compatibility with ESRI’s ARC/INFO® software –make the AccuTab VI
the only choice for your GIS requirements. The integrity of the data produced by a digitizer
can be only as good as the digitizer’s underlying technology. Every aspect of both the
design and the production of an AccuTab VI large format digitizer is engineered to meet
one single objective –to provide the highest level of data integrity possible –guaranteed.
This includes coordinate resolution, measurement accuracy, repeatability, product
reliability and system compatibility.
To support our unique performance guarantee, a high precision automated measurement
system is used to complete a Performance Verification on each AccuTab VI digitizer prior to
its leaving our factory. This system generates a detailed performance verification report
that is shipped with the unit.
Setup and Installation Overview
An integrated mounting channel around the perimeter of the digitizer facilitates the quick
and easy mounting of the AccuTab VI on a pedestal or stand. The mounting channel can
also be used for the attachment of accessories, such as the Accessory Tray and Plan Hold
Down.
In order to send data from AccuTab VI to your digitizing application, the digitizer must be
physically connected to your computer and it must be able to transmit the data in such a
way that the digitizing application recognizes and understands it. Before setting up
AccuTab VI, you should determine:
Requirements of the digitizing software application being used
Whether the digitizing application requires software drivers to communicate with
AccuTab VI
Hardware communications connection (USB or Serial) you will be using between
AccuTab VI and the computer
When the AccuTab VI is setup for a serial connection, it must be configured so that it can
send data in a way the application software will recognize and understand. Different

AccuTab VI 6
applications have diverse requirements when interacting with a digitizer. AccuTab VI is
designed to provide the appropriate serial requirements for a variety of GIS applications
using a simple code system. The AccuSet Menu located at the top of the AccuTab VI is used
to enter the appropriate code for the software being used. Table 1in Using the AccuTab
Menu section of this manual lists the AccuSet Codes for a variety of GIS applications. Input
the code for the application being used and the AccuTab VI will be able to communicate
properly with the application software on your computer. Table 2 lists the configuration
details for each AccuSet Code in Table 1.
If for some reason the communication requirements for your software cannot be found in
the two tables provided in the AccuSet Menu section, the Tablet Configuration Utilities on
the enclosed TabletWorks CD can be used to configure your AccuTab VI so it has the
appropriate information it needs to communicate successfully with your software.
Parts Checklist
AccuTab VI digitizing tablet
16-button high-accuracy, illuminated
cursor
USB cable
Universal mounting brackets
CD (TabletWorks drivers,
documentation or third party
software drivers)
User’s guide
Registration card
Optional Equipment
RS-232 cable with 9-pin connector for
serial connection
Power supply –required only for a
serial installation
Transducer (corded or cordless pen,
4-button or 16-button cursor
Accessory tray
Plan holder
Tablet feet
Manual lift / manual tilt pedestal

AccuTab VI 7
What You Will Need to Use AccuTab VI
AccuTab VI is equipped with a standard USB interface and has an optional RS-232 serial
interface. It is compatible with most industry-standard PCs. The TabletWorks CD contains
drivers provided by GTCO CalComp by Turning Technologies and is the only software
described in this manual. TabletWorks supports reduced functionality Wintab and TabCon-
compatible applications. If you are not sure which drivers are required, consult with your
application vendor.
A USB connection requires the use of a TabletWorks driver, while the optional serial
installation necessitates the use of a TabletWorks driver and/or a custom application
program. After installing the TabletWorks software, the AccuTab VI will work with ALL
Windows-based applications as a mouse, in addition to working as a digitizer with
Windows-based applications that are specifically designed for use with digitizers.
PC Requirements
For a USB Installation
Microsoft Windows 98 SE, ME, 2000 or XP
One available USB port
10 MB of free disk space
Application software that accepts digitizer input via the Wintab API or TabCon API
For an Optional Serial Installation
Microsoft Windows 98, ME, NT 4.0, 2000 or XP
One available RS-232C serial communication port (Serial signal levels must conform
to EIA RS-232C specifications.)
10 MB of free disk space
Application software that directly accepts digitizer input via the computer’s RS-232C
serial port, or via the Wintab API or TabCon API

AccuTab VI 8
AccuTab VI Overview
The AccuTab VI digitizer consists of:
Active Area
The drawing area –the Active Area –is that portion of the tablet surface designated for
digitizing. Its boundaries are marked at each corner by a right-angle crop mark.
AccuSet Menu
Row of keys located across the top of the digitizer. It provides a means of configuring your
tablet so that it sends the appropriate information for a serial connection to the software
being used on the computer.
Indicator Light
The power/proximity LED in the upper right corner of the AccuTab VI is the Indicator
Light. It remains off when the power is on. However, it is solid green when the transducer
is in prox (within the range) of the Active Area.
Transducer
AccuTab VI uses a 16-button high-accuracy, illuminated cursor as the system transducer.
The corded high-accuracy cursor gets its power from the digitizer.

AccuTab VI 9
Setting Up Your AccuTab VI
The instructions below describe how to set up your AccuTab VI.
Preparing the AccuTab VI
Mounting on the Stand
You can place AccuTab VI on a table, desk or drafting table or mount it on a stand or
pedestal. The tablet’s Universal Mounting Brackets attach directly to stands that have tilt
arms. Stands with tilt pads require right-angle mounting brackets, which are attached to
the right-angle mounting brackets. Center the tablet over the attached universal mounting
brackets and screw the Thumbscrews into the T-Nuts in the mounting channel in the
tablet’s frame.
Attaching the Optional Accessory Tray or Plan Holder
Additional T-Nuts have been included in the perimeter mounting channels on the AccuTab
VI frame. You can position the Plan Holder or Accessory Tray where it is most convenient
for you by attaching it to any one of the available T-Nuts. The following instructions and
the graphic below detail the installation of the Accessory Tray.
Simply slide the Tray Rails into the channel and line up the hole in the tray with the hole in
the T-Nut. Tighten the Thumb Screw to secure the Accessory Tray.

AccuTab VI 10
Software Configuration
Software drivers provide the communication bridge between your digitizing software
application and AccuTab VI. You should install only the drivers necessary for the AccuTab
VI to work with your application software. If you are not sure which drivers are required,
consult with your application vendor.
Configuring Non-Wintab Applications
Many application programs provide configuration information for specific digitizers. If the
AccuTab VI is not listed, you can use the configuration for GTCO CalComp by Turning
Technologies Digi-Pad Type 5 or Type 5A (T5/T5A), Roll-Up II, CalComp 3400, DrawingBoard
or Summagraphics Microgrid III.
Installing the TabletWorks Driver
Insert the CD into the CD-ROM drive on your computer. The installer will autoload. If it
does not, click on the Start button on the Windows Task Bar and select Run from the
menu. Type X:\setup.exe (Xrepresents the CD drive letter). Follow the onscreen prompts
to complete the installation.
A TabletWorks icon will display in the System Tray on the Windows Task Bar. Right
click on the icon to display the TabletWorks Menu, which provides access to all the
TabletWorks features.
Hardware Configuration
When you use the USB interface, no hardware configuration is required. When you choose
the optional serial interface, the AccuTab VI must be configured to send data in a format
that is compatible with the application software. Different applications have diverse
requirements when interacting with a digitizer. The AccuTab VI is designed to provide the
appropriate serial requirements for a wide variety of GIS, graphic, CAD and estimating
applications using a simple code system. The AccuSet Menu on the surface of the AccuTab
VI is used to enter the appropriate code for the software being used. A table in the Using
the AccuSet Menu section of this manual lists the AccuSet Codes for a wide variety of
applications.
Determine if you have not already, which communication connection you will be using –
USB or the optional serial.

AccuTab VI 11
Transducer Connection
1. Connect the corded high-accuracy cursor to the appropriate jack on the digitizer’s
Connector Panel. The connector is keyed and will fit only the correct jack. Do not
force it.
USB Connection
The AccuTab VI USB port connection is USB 1.1and 2.0 compatible. When the digitizer is
connected to the USB port, Windows will recognize that there is a new device connected. If
Windows displays the Found New Hardware prompt, follow the onscreen instructions to
complete the driver installation.
1. Connect the interface cable to the USB jack on the AccuTab VI Connector Panel. The
connector is keyed and will fit only the correct jack. Do not force it. Join the other
end of the USB cable to any one of the USB ports on your computer or USB
hub.
2. Turn the power switch on. The digitizer will beep four short tones, indicating it has
power. See the AccuTab VI Tones section of this manual for a complete table of
AccuTab VI tones.

AccuTab VI 12
Optional RS-232 Serial Connection
1. Connect the RS-232 serial cable to the serial jack on the Connector Panel. The
connector is keyed and will fit only the correct jack. Do not force it. Join the other
end of an RS-232 serial port on your computer.
2. Plug the power supply into an AC outlet. Connect the power supply to the
appropriate jack on the AccuTab VI Connector Panel. Turn the power switch on.
The digitizer will beep four short tones (see AccuTab VI Tones section of this manual
for a complete table of AccuTab VI tones), indicating it has power.
Tablet Power On
The AccuTab VI power switch is located at the rear of the tablet on the Controller
Connector Panel. When turned on, AccuTab VI’s Indicator Light will begin blinking and the

AccuTab VI 13
tablet will beep four times. The Indicator Light will glow steadily when the transducer is
inside the Active Area of the tablet. When the transducer moves outside the Active Area,
the Indicator Light will go off.
Using the AccuSet Menu [RS-232 Only]
The AccuSet Menu is the row of buttons printed across the top of the digitizer. It allows
you to configure your AccuTab VI to send the appropriate information through an RS-232
serial connection to the software being used on the computer.
The AccuSet Menu is used to prepare the digitizer to receive specific, detailed custom
configuration information from the Tablet Configuration Utilities for some serial
installations.
In addition, for both serial and USB connections, the AccuSet Menu can be used to reset
AccuTab VI, turn the digitizer alarm off and on and test the grid or Active Area. Use the
cursor to click on the menu buttons to make your selections.
The menu button initiates Select Mode. Two-digit numeric codes are entered after
Select Mode is activated.
NOTE: Select Mode will not work with the USB interface. USB digitizers are used exclusively
with Wintab drivers.
Most software supports Wintab using the TabletWorks drivers, whose AccuSet Code is
on the AccuSet Menu. The AccuTab VI comes from the factory with the
AccuSet Code pre-configured.

AccuTab VI 14
The button toggles the digitizer alarm off and on. The button tests the digitizer
grid in the Active Area.
When using the AccuSet Menu, a tone will sound indicating a successful selection when you
click on the button. Four tones will sound when you click on the button. (See
the AccuTab VI Tones section of this manual for a complete table of the AccuTab VI tones.)
The number buttons through are active only after clicking on the button to
activate Select Mode.
Resetting the AccuTab VI
The AccuTab VI can be reset by:
Turning off the power switch on the Connector Panel
Unplugging and re-plugging the power supply
Clicking on the AccuSet Menu.
When one of these events occurs, AccuTab VI will revert to the configuration that was last
defined. Any remote commands that were active before the reset will be lost.
Turning the Alarm Off and On
You can disable the alarm if you do not want to hear a tone each time the cursor button is
pressed. When the alarm is off, you will still hear diagnostic and menu-related tones.
To turn the alarm Off and On:
To toggle the tones on or off, click on the button on the AccuSet Menu.
Testing the Active Area
To test the AccuTab VI grid, or Active Area:
1. Using the cursor, click on the button to activate the test.

AccuTab VI 15
2. Move your cursor around in the Active Area. If there is a break in the grid or the
cursor is out of prox, the digitizer will beep.
3. Click the button again to end the test.
NOTE: The following is relevant only for RS-232 serial installations. USB does not require
configuration.
Configuring Your AccuTab VI for Specific Applications
To configure AccuTab VI for use with specific applications:
1. In Table 1, find the application program you will be using with your AccuTab VI.
Note the corresponding AccuSet Code.
If the application program is not listed in Table 1, find the configuration
settings in Table 2 that your application program requires and use the
corresponding AccuSet Code.
If an appropriate AccuSet Code is not listed in Table 2, use the Tablet
Configuration Utilities to configure your AccuTab VI.
2. On the AccuSet Menu, select the button and then click on the two digits of the
AccuSet Code indicated for the application. You will hear four short tones after a
successful menu configuration.
Example: Configuring for a Specific Application
To configure AccuTab VI to operate with Autodesk’s AutoCAD application, you would:
1. Find the entry for AutoCAD in Table 1. The AccuSet Code is
2. Click on the button on the AccuSet Menu. You will hear one short tone,
indicating the digitizer is in Select Mode.
3. Select from the AccuSet Menu. You will hear one short tone. This enters the
first digit of the AccuSet Code for AutoCAD.
4. Click on the button on the AccuSet Menu. This enters the second digit of the
AccuSet Code for AutoCAD.

AccuTab VI 16
You will hear four short tones, indicating that the configuration is complete. The AccuTab
VI is now configured to operate with AutoCAD. Select Mode is no longer active and you can
begin digitizing.
NOTE: For more information about digitizer software application driver requirements,
please visit the Technical Support section of the GTCO CalComp by Turning Technologies
website.
Table 1: AccuSet Menu Codes for Selected Applications

AccuTab VI 17
Table 2: Configuration Details for AccuSet Menu Codes
NOTE: Max = 100 coordinates/second lpi = lines per inch lpmm = lines per millimeter

AccuTab VI 18

AccuTab VI 19

AccuTab VI 20
AccuTab VI Tones
The AccuTab VI produces an alarm in the form of audio tones to inform you of various
events. The table below describes the kinds of tones you might hear while operating the
digitizer.
Table 3: AccuTab VI Tones
NOTE: You might hear tones produced by AccuTab VI which are actually sent by your
application program. (Programs can send commands to the digitizer to turn the audio tone
generator on and off.) If you hear tones during digitizing and they do not correspond to
the tones listed in the table above, they are produced by the application program.
