GTEN ADVANCED User manual

GTEN®Fail Over Guide 2023
1
ADVANCED Cellular Modem Gateway
Quick Reference WAN Fail-over guide
Thank you for purchasing this GTEN®modem product.
You can visit www.gtenamerica.com/support to obtain more information about your product, get help,
access the latest downloads and manuals.
We recommend that you use only official GTEN®support resources.

GTEN®Fail Over Guide 2023
2
GTEN®Advanced Modem
Table of Contents –Modem Features
Introduction Page No.
Introduction 3
Hardware Overview 4
Front Panel with WAN LED Status 5
Get Started Page No.
Internet Connection Over Mobile Broadband 5
Setting the modem’s Internet priority connection 6
The Main page (Network Map) 7
Advanced Settings Page No.
Manage the LAN Settings 8
Connected Devices 10
Tips for connection issues 11
This guide covers the following devices:
All GTEN Model 5,6,7 devices
including the GTEN Model 5
Lite and the GTEN Advanced
Modem and 5G Modem series.

GTEN®Fail Over Guide 2023
3
Introduction
Using the GTEN modem to back up your existing internet connection is a smart investment
to ensure continuous internet connection regardless of any outage with your primary
provider.
How does it work? The GTEN Advanced modem is a cellular based internet device that uses
your local wireless towers to provide internet connections so if you have hard line internet
services like cable or fiber, you can plug your existing hard wire internet into the WAN port of
the GTEN modem and then connect to the GTEN modem for all your connection needs.
(See example below)
Using the GTEN Advanced modem in the configuration above will provide the most protect to your critical
internet infrastructure and will reduce downtime, when having internet is a must, protect your network
with GTEN.

GTEN®Fail Over Guide 2023
4
Hardware Overview
What is required to setup a fail over using a GTEN modem and an existing WAN connection
like Fiber, Cable or Satellite services:
• You will need at least one Ethernet Cable (provided) to connect between your existing hard
wired modem device and the GTEN modem using the WAN port. (See Below)
1. WAN Gigabit Ethernet port allows for Modem-to-Modem connection with your existing internet device.
(See example:)

GTEN®Fail Over Guide 2023
5
Front Panel with WAN LED Status
Upon successful WAN connection your WAN light will light up.
1. WAN light solid indicates connection is established.
2. WAN light blinking indicates that the connection is active and transferring data over
the Ethernet cable.
Internet Connection Over Mobile
Broadband
By default, when the modem powers up with a SIM card installed, it automatically
searches for and connects to your network provider’s mobile broadband network.
This process might take several minutes. The SIM card that is installed determines the
mobile broadband network to which the modem connects.
Even though the modem might connect to the mobile broadband network of the same
service provider each time that you start the modem, the type of mobile broadband
service to which the modem connects might differ.
Pro Tip: If the modem does not automatically connect to the mobile broadband network
after 5 minutes, the SYS Power LED remains solid, and you might need to contact your
mobile service provider to get the access point name (APN) profile information and
activate a custom APN profile in the modem. If your mobile service provider informs you
that your APN profile is correct, but the modem still does not connect to the mobile
broadband network.

GTEN®Fail Over Guide 2023
6
Set the modems Internet Priority
settings.
(Does not require internet)
The modem comes configured and ready to use. You can use the modem’s web pages to monitor data
usage and change basic settings.
You can log in to the modem’s web pages over an Ethernet cable, The modem’s web pages run on any
device with a web browser such as Google Chrome, Mozilla Firefox, and Microsoft EDGE.
To access the modem’s web pages:
1. Launch a web browser from a device that is connected to the modem.
The device can be a computer that is directly connected to the modem or a client from a router that is
connected to the modem.
2. In the URL address field of your browser, enter 192.168.2.1
3. To access the full Dashboard page and other pages, you must enter your username and password
which are both set by default to GTEN or admin
See the modem label for the default password.
While the password that you enter is unique to your modem and is secure, we
recommend that you change it to a password that you want to use.
a. If you do not want to enter your password each time that you access the modem’s web pages,
select the Remember me check box on your browser.
b. Click the Sign In button or hit <enter>. (See example)
When the full GTEN “Network Map” page displays. You are now ready to monitor the modem and
manage the settings.
If you cannot log in to the modem or your browser does not display the Dashboard page, check the following:
• Make sure that the computer, router, or WiFi router is connected to the LAN Gigabit Ethernet port
of the modem or you have established a Wi-Fi connection.
• Make sure that your browser does not cache the previous page by closing and reopening the
browser.
• If your computer is set to a static or fixed IP address (this type of setting is uncommon), change
the setting to obtain an IP address automatically from the modem.

GTEN®Fail Over Guide 2023
7
What you should see when first logged in: (The Main Page)
Menu Options: The Main page (Network Map)
Options related to WAN control and operation only, see the full manual for additional options.
Internet
Source
Priority:
You can choose the type of internet connection you want to use like
WIRED WAN or SIM card connections. This is were you will choose
the WIRED WAN Connection
option.
Wired WAN First then SIMs
Connection
Status:
Connected –This means the modem has a valid connection to the
internet and is actively passing broadband data.
Any other status means the modem is not connected to the internet.
DHCP
Lease
Expires
After:
Indicates how long the current tower connection will last.

GTEN®Fail Over Guide 2023
8
Internet Network (WAN) –Information from the common carrier.
IPv4
Address
WAN:
The IP address provided by the carrier assigned to your device.
DNS:
The primary Dynamic Name servers used by the common carrier.
Secondary
DNS:
The secondary Dynamic Name servers used by the common carrier.
MAC
Address:
This is your modem’s unique MAC address. (Gateway address)
Menu Options: Advanced Settings
Sub menu options under Advanced settings to be discussed:
1. LAN
2. WAN
3. Wireless and Wired Information
4. System Log
Manage the Modem LAN Settings
This section describes how to manage the Basic LAN settings. Additional features are
available for this device, you can search the web for more information regarding:
LAN IP, DHCP Server, Route, IPTV, Ethernet Switch, Wake-on-LAN
LAN IP
IP Address:
192.168.2.1
192.168.10.254

GTEN®Fail Over Guide 2023
9
This section is where you can modify your modem’s IP
address. By default, the address is 192.168.2.1
Subnet Mask:
This section is where you can modify your modem’s
Mask address. By default, the address is
255.255.255.0
255.255.255.0
255.255.255.0
DHCP Server
Enable DHCP Server
This section is where you can allow your modem to
Dynamically produce local IP addresses to your
connected devices. By default, this option is
ENABLED
Enable IPV6
This section is where you can allow your modem to
Dynamically produce local IPv6 addresses to your
connected devices. By default, this option is
ENABLED
IP Pool Starting Address:
This section sets the beginning range of your DHCP
pool. By default, this option is set to 192.168.2.2 to
allow for the maximum amount of DHCP devices.
192.168.2.2
IP Pool Ending Address: Set to the end of the range
192.168.2.254
DHCP Lease Time (sec):
This section sets the lease time of each device on
your DHCP pool. By default, this option is set to
604800 to allow for the maximum amount of time for
the connected DHCP devices.
604800 (default)
Pro tip: Once your settings are saved, you may lose connection to your devices or the
WEB interface, if this happens you may need to restart the modem also any device

GTEN®Fail Over Guide 2023
10
that is connected to the modem is disconnected when the modem restarts.
Connected Devices
This section shows what devices are connected to your modem.
How do I disconnect from the mobile broadband network?
Some suggestions listed below:
The simplest way to disconnect from the mobile broadband network is removing the power
cord from the device, however if you want to keep the device on but kill the 5G/LTE
connection then on the “Network Map” just hit the disconnect button.
How do I find my computer’s WAN IP address?
Some suggestions listed below:

GTEN®Fail Over Guide 2023
11
You can find this information on the “Network Map” main page under Internet Network
(WAN)
Why can I not log into the Modem Web interface?
Some suggestions listed below:
This usually can be solved by restarting the router. Also make sure you are connected to
the correct wireless network; it is best to use an Ethernet when connecting to the modems
Web Interface.
Pro Tip: While many Laptops and Tablets do not offer Ethernet ports this is easily fixed by
obtaining an inexpensive USB or USB3 Ethernet adapter for your device. They small
device will save you a lot of headaches in the future and offer faster connection speeds vs
Wi-Fi.
Troubleshoot the Mobile Broadband Internet Connection?
Some suggestions listed below:
The very first recommendation is to power your device off (removing the power cord), wait 30
seconds and turn it on again. This usually fixes all connection issues. You may also:
1. Check that your SIM card is correctly inserted into your device.
2. Change your modem's location which can improve your signal.
3. Log into the modem’s Web Interface to ensure the device is connected. (See below)
Connection
Status:
Connected –This means the modem has a valid connection to the internet and is actively
passing broadband data. If anything else is displayed you are NOT connected.
4. On the modems “Network Map” page try disconnecting and then reconnecting the
connection by using the connection buttons.
5. Ensure your APN is correctly spelled.
6. Make sure your modems’ mobile broadband channels are set for the right carrier.

GTEN®Fail Over Guide 2023
12
Pro Tip: If you have tried everything and nothing works, contact your Internet service provider
immediately, do not FACTORY RESET the device as this will wipe out all of your modems
programming.
Can a Public Static Internet “IP”Address be used?
Some suggestions listed below:
YES, this is obtained from your service provider.
Pro FYI: Static IP means the IP address never changes if you stay with the same provider
or same server. Dynamic means the IP address can change from time-to-time. Public
means the IP address can be visited from any computer in the world. Private means the IP
address can only be used by those on the same network.
