Gude Expert net control 2304 User manual

Manual

Expert Net Control 2304

Manual Ver. 1.0.0

from Firmware Ver. 1.0

Table of contents

1. Device Description 5

1.1 Security Advice ....................................................................................................... 6

1.2 Content of Delivery ................................................................................................. 6

1.3 Description ............................................................................................................. 6

1.4 Installation ............................................................................................................. 7

1.4.1 Connection Example ................................................................................................ 8

1.5 Technical Specifications .......................................................................................... 9

1.6 Sensor .................................................................................................................... 9

2. Operating 13

2.1 Operating the device directly ................................................................................ 14

2.2 Control Panel ........................................................................................................ 14

2.3 Maintenance ........................................................................................................ 16

2.3.1 Maintenance Page ................................................................................................. 18

2.3.2 Configuration Management .................................................................................. 20

2.3.3 Bootloader Activation ............................................................................................ 21

3. Configuration 23

3.1 Output Ports ......................................................................................................... 24

3.1.1 Watchdog ............................................................................................................... 25

3.2 Input Ports ............................................................................................................ 27

3.3 Ethernet ............................................................................................................... 28

3.3.1 IP Address ............................................................................................................... 28

3.3.2 IP ACL ..................................................................................................................... 29

3.3.3 HTTP ....................................................................................................................... 31

3.4 Protocols .............................................................................................................. 32

3.4.1 Console ................................................................................................................... 32

3.4.2 Syslog ..................................................................................................................... 33

3.4.3 SNMP ...................................................................................................................... 33

3.4.4 Radius ..................................................................................................................... 35

3.4.5 Modbus TCP ........................................................................................................... 36

3.4.6 MQTT ...................................................................................................................... 37

3.5 Clock ..................................................................................................................... 38

3.5.1 NTP ......................................................................................................................... 38

3.5.2 Timer ...................................................................................................................... 39

3.5.3 Timer Configuration ............................................................................................... 39

3.6 Sensors ................................................................................................................. 46

3.6.1 Port Switching ........................................................................................................ 47

3.7 E-Mail ................................................................................................................... 48

3.8 Front Panel ........................................................................................................... 49

Table of contents

4. Specifications 50

4.1 Automated Access ................................................................................................ 51

4.2 Messages .............................................................................................................. 51

4.3 IP ACL ................................................................................................................... 53

4.4 IPv6 ...................................................................................................................... 54

4.5 Radius ................................................................................................................... 54

4.6 SNMP ................................................................................................................... 55

4.6.1 Device MIB 2304 .................................................................................................... 57

4.7 SSL ........................................................................................................................ 58

4.8 Console ................................................................................................................. 60

4.8.1 SSH ......................................................................................................................... 64

4.8.2 Console Cmd 2304 ................................................................................................. 65

4.9 Modbus TCP ......................................................................................................... 72

4.10 MQTT ................................................................................................................... 77

4.10.1 Example HiveMQ .................................................................................................... 79

5. Support 81

5.1 Data Security ........................................................................................................ 82

5.2 Contact ................................................................................................................. 82

5.3 Declaration of Conformity ..................................................................................... 83

5.4 FAQ ...................................................................................................................... 83

Index

Device Description

1 Device Description

1.1 Security Advice

·The device must be installed only by qualified personnel according to the following

installation and operating instructions.

·The manufacturer does not accept responsibility in case of improper use of the

device and particularly any use of equipment that may cause personal injury or ma-

terial damage.

·The device contains no user-maintainable parts. All maintenance has to be per-

formed by factory trained service personnel.

·Connect the device to the mains (230V AC) or to an AC Adaptor (10V to 24V AC,

12V to 28V DC, at 4 watts of power). Under no circumstances should the unit be fed

with the mains and the AC Adaptor at the same time!

·The device is intended for indoor use only. Do NOT install them in an area where ex-

cessive moisture or heat is present.

·Because of safety and approval issues it is not allowed to modify the device without

our permission.

·The device is NOT a toy. It has to be used or stored out or range of children.

·Care about packaging material. Plastics has to be stored out of range of children.

Please recycle the packaging materials.

·In case of further questions, about installation, operation or usage of the device,

which are not clear after reading the manual, please do not hesitate to ask our sup-

port team.

1.2 Content of Delivery

The package includes:

·Expert Net Control 2304

·Quick Start Guide

1.3 Description

The Expert Net Control 2304 can switch 8 different relay outputs and monitor 8 pass-

ive signal inputs. The device has the following features:

·8 switchable, potential-free relay outputs, switching voltage 230 V AC 16 A / 24 V

DC, 10 A

·Relays dispose of high contact reliability also at very small loads

·8 passive inputs for monitoring NO and NC devices, e.g. door contacts, smoke de-

tectors etc.

·Operation with 230 V AC or 24 V DC voltage

·Optional sensor for environmental monitoring (temperature, humidity and air pres-

sure)

·Console commands via SSH and Telnet

·SSH support with public key and passwords

·Individually parameterisable switch-on delay of all outputs

·Programmable timetables and turn-on/turn-off sequences

Device Description

·Individually adjustable watchdog for each output, which switches depending on ac-

cessibility (network ping)

·Dual TCP/IP stack with IPv4 and IPv6 support (IPv6-ready)

·Control and monitoring of the device via Ethernet with an integrated web server with

SSL encryption (TLS 1.1, 1.2, 1.3)

·Control and configuration with CGI parameters and JSON messages via HTTP

(REST API)

·SNMP (v1, v2c and v3, traps)

·MQTT 3.1.1 Support

·Modbus TCP support

·Radius support

·Generation of messages (e-mail, syslog and SNMP traps) and switching of relays

depending on sensor measurement limits

·Firmware update during operation via Ethernet possible

·Encrypted e-mails (SSL, STARTTLS)

·Access protection through IP access control

·Low own consumption

·Developed and produced in Germany

1.4 Installation

1. Low voltage power supply (12Vto 24V AC, 12V to 30V DC)

2. 8x passive inputs ( each with GND ( ) )

3. Pushbuttons for Select and OK

4. 4x 7-segment display (partly with unit LEDs e.g. "°C" )

5. 8x plain text displays (on/off) for the status of inputs and outputs

6. Indicators ( Input or Output ) for the 8 plain text displays (on/off)

7. Status LED

8. Ethernet port status and activity (green and orange)

9. external sensor ("Sen.") plugged in indicator

10.Network connection (RJ45)

11.sensor connection (RJ45)

Device Description

12.AC mains power supply

13.8x relay switching contacts (NO)

Commissioning

·Connect the device to the mains (100-240V AC) or to a plug-in power supply (12V to

24V AC, 12V to 30V DC).

·Plug the network cable into the Ethernet socket (RJ45).

·Connect the relays to the loads that are to be operated.

·Establish contact between the lines to be monitored and the digital inputs.

·Connect a sensor (if available).

1.4.1 Connection Example

Here is an example with block diagram in which the device is supplied with 230V AC

and in which eight AC loads (L1 - L8) are connected. In addition, the inputs are as-

signed eight switches (S1 - S8).

Device Description

As an alternative to connecting "In 1-8" and "GND", voltages can also be fed in

between "In 1-8" and GND. The maximum input voltage is 24V, voltages below 3V are

detected as LOW state, and voltages above 8V are detected as HI.

1.5 Technical Specifications

Connections

1 x Ethernet connection (RJ45)

1 x RJ45 for external sensor

1 x mains connection AC (picoMAX 7.5)

1 x low voltage (screw terminal)

16 x screw terminal with 8 x input and 8 x GND

8 x relay switching contacts NO (picoMAX 5.0)

Network connection

10/100 MBit/s 10baseT Ethernet

Relay output

max. 240V AC 16A, 50/60Hz

24V DC 10A

Power supply

internal power supply (100V to 240V AC, 50/60Hz)

Low voltage 12V to 24V AC (50/60Hz), 12V to 30V DC

Environment

·Operating temperature

·Storage temperature

·Humidity

0°C to 50°C

-20°C - 70°C

0% - 95% (non-condensing)

Housing

White plastic

Dimensions

143mm x 65mm x 90mm (L x H x D)

Weight

approx. 400g

picoMAX® eCOM 5.0 and 7.5

Connection technology

Push-in CAGE CLAMP®

Actuation type

Push-button

Solid conductor

0.2 ... 2.5 mm² / 24 ... 12 AWG

Fine-stranded conductor

0.2 ... 2.5 mm² / 24 ... 12 AWG

Fine stranded conductor; with insulated

ferrule

0.25 ... 1.5 mm²

1.6 Sensor

One external sensor can be connected to the Expert Net Control 2304. The following

sensors are currently available

Device Description

Humidity/Temperature Sensor 7102 (End-of-Life)

Cable length

Connector

RJ45

temperature range

-20°C to +80°C, ±0,5°C (maximum) and ±0,3°C (typical)

air humidity range

(non-condensing))

0-100%, ±3% (maximum) and ±2% (typical)

Device Description

Product Name

7101

7104-1

7105-1

7106-1

Calibrated

Sensor

7104-2

7105-2

7106-2

Cable length

Connector

RJ45

temperature range

-20°C to +80°C at

±2°C (maximum)

and ±1°C (typical)

-20°C to +80°C at

±2°C (maximum)

and ±1°C (typical)

-20°C to +80°C at

±2°C (maximum)

and ±1°C (typical)

-20°C to +80°C at

±2°C (maximum)

and ±1°C (typical)

air humidity range

(non-condensing)

0-100%, ±3%

(maximum) and

±2% (typical)

0-100%, ±3%

(maximum) and

±2% (typical)

air pressure range

(full)

± 1 hPa (typical)

at 300 ... 1100

hPa, 0 ... +40 °C

air pressure range

(ext)

± 1.7 hPa (typical)

at 300 ... 1100

hPa, -20 ... 0 °C

Protection

IP68

Product Name

7201

7202

Cable length

Connector

RJ45

temperature range

-20°C to +80°C at ±2°C (max-

imum) and ±1°C (typical)

-20°C to +80°C at ±2°C (max-

imum) and ±1°C (typical)

air humidity range

(non-condensing)

0-100%, ±3% (maximum) and

±2% (typical)

The sensors are detected automatically after connection. The sensor values are

displayed directly on the "Control Panel" website:

A click on the link in the "Name" column opens the display of the Min and Max values.

The values in a column can be reset using the "Reset" button. The "Reset" button in

the name column deletes all stored Min and Max values.

Device Description

Operating

2 Operating

2.1 Operating the device directly

Port Switching

The current status of the output is indicated by the color of the LED. Red indicates that

the output is off, green shows that the output is on. On the device are the buttons "se-

lect" and "ok". If you press "select", you can select the following modes one by one:

1. At first, all LEDs flash green. If you press the "Ok" button for 2.5 seconds, all ports

are switched on. (If all ports are switched on, this is skipped).

2. After that, all LEDs flash red. If you hold the "Ok" button for 2.5 seconds, all ports

will be switched off. (If all ports are switched off, this will be skipped).

3. If you press "Select" again, the LED for the first output starts blinking, i.e. the output

is selected. Press "Select" again to select the next output. If you keep the "Ok" but-

ton pressed for one second, the state of the selected output will be toggled.

You can switch off in the front panel configuration that all ports with the modes

1 and 2 can be switched by pushbutton.

Status-LED

The Status LED shows the different states of the device:

·red: The device is not connected to the Ethernet.

·orange: The device is connected to the Ethernet and waits for data from the DHCP

server.

·green: The device is connected to the Ethernet and the TCP/IP settings are alloc-

ated.

·periodic blinking: The device is in Bootloader mode.

2.2 Control Panel

Access the web interface: http://"IP-address" and log-in.

Operating

The web page provides an overview of the switching state, as well as the external

sensor, provided that it is connected. When a single port is clicked at the Expert Net

Control 2304, a panel with buttons to control a single port appear:

The Port icon is green when the relay is closed, or red in the open state. An additional

small clock icon indicates that a timer is active. Timer can be activated by delay, reset

or batch mode.

Operating

An activated Watchdog is represented by an eye icon. An "X" means, that the address

that should be observed, could not be resolved. Two circular arrows show a booting

status.

The ports can be switched manually with the "On" and "Off" buttons. If the port is

turned on, it can be turned off by pressing the "Reset" button, until after a delay it turns

itself on again. The delay time is determined by the parameter Reset Duration, which is

described in the chapter "Configuration - Output Ports ". The "Close" button dis-

solves the panel again.

Batchmode

Each individual port can be set for a selectable period of time to the state "switch on"

or "switch off". After the selected time they are automatically switched to the second

preselected state.

Optionally the device can be switched via a Perl script or external tools like wget. More

information is available on our support wiki at www.gude.info/wiki.

The website contains a status overview of all passive signal inputs, the time since the

last change, and a counter of switching changes. The name and text for a logical state

of each input can be configured in the chapter Configuration-Input Ports .

2.3 Maintenance

The actual device generation with IPv6 and SSL allows all maintenance functions in

the web interface to be carried out on the Maintenance Page .

Maintenance in the web interface

Operating

The following functions are available from the maintenance web page:

·Firmware Update

·Change the SSL certificate

·Load and save the configuration

·Restart the device

·Factory Reset

·Jump into the Bootloader

·Delete the DNS cache

Upload Firmware, Certificate or Configuration

On the Maintenance Page , select the required file with "Browse .." in the sections

"Firmware Update", "SSL Certificate Upload" or "Config Import File Upload" and press

"Upload". The file is now transferred to the update area of the device and the contents

are checked. Only now, pressing the "Apply" button will permanently update the data,

or abort with "Cancel".

Only one upload function can be initiated with a reboot, eg. you cannot transmit

firmware and configuration at the same time.

If after a firmware update, the web page is not displayed correctly anymore, this

may be related to the interaction of Javascript with an outdated browser cache. If a

Ctrl-F5 does not help, it is recommended that you manually delete the cache in the

browser options. Alternatively, you can test start the browser in "private mode".

During a firmware update, old data formats are sometimes converted to new struc-

tures. If an older firmware is newly installed, the configuration data and the energy

meters may be lost! If the device then does not run correctly, please restore the factory

settings (e.g. from the Maintenance Page ).

Actions in Bootloader mode

If the web interface of the device is no longer accessible, the device can be put into

Bootloader mode (see chapter Bootloader activation ). The following functions can

be executed using the GBL_Conf.exe application:

·Set IPv4 address, net-mask and gateway

·Turn HTTP password on and off

·Turn IP-ACL on and off

·Factory Reset

·Jump into the bootloader (can be switched on and off)

·Restart the device

For devices with relays, entering or exiting the bootloader mode does not change

the state of the relays as long as the operating voltage is maintained.

The GBL_Conf.exe program is available free of charge on our website www.gude.info

and can also be found on the enclosed CD-ROM.

Operating

Interface GBL_Conf

To check the network settings with GBL_Conf.exe, start the program and choose "All

Devices" in the "Search" menu. From the list select the appropriate device. The lower

part of the left half of the window now shows the current network settings of the device.

If the IP address is displayed with the default settings (192.168.0.2), either no DHCP

server is present on the network, or there could be no free IP address assigned to it.

·Activate the Bootloader Mode (see Chapter Bootloader Mode) and choose in menu

"Search" the item "Bootloader-Mode Devices only"

·Enter the desired settings in the edit window and save them with "Save Config".

·Deactivate the boot loader mode for the changes to take effect. Select again "All

Devices" in the "Search" menu of GBL_Conf.exe.

The new network configuration is now displayed.

Factory Reset

The device can be reset to the factory default via the web interface from the Mainten-

ance Page or from the Bootloader mode (see chapter Bootloader activation ). All

TCP/IP settings are reset in this operation.

If a unit is set to factory defaults, an uploaded certificate or updated firmware will

be preserved.

2.3.1 Maintenance Page

This section provides access to important functions such as Firmware Update or Re-

start Device. It is advisable to set an HTTP password for this reason.

18 21

Operating

Firmware Update: Start a firmware update.

SSL Certificate Upload: Saves your own SSL certificate. See chapter "SSL " for the

generation of a certificate in the right format.

Config Import File Upload: Loads a new configuration from a text file. To apply the new

configuration, a "Restart Device" must be executed after the "Upload".

Config File Export: Saves the current configuration in a text file.

Saving the configuration should only be carried out in an SSL connection, since it

contains sensitive password information (even if it is encrypted or hashed).

Restart Device: Restarts the device without changing the status of the relays.

Some functions such as a firmware update or changing of the IP-address and

HTTP settings require a restart of the device. A jump to the boot loader or a restart of

the device lead by no means to a change of the relay states.

Restore Fab Settings and Restart Device: Performs a restart and resets the device to

factory default .

Enter Bootloader Mode: Jumps into bootloader mode, where additional settings can be

made with GBL_Conf.exe.

Flush DNS Cache: All entries in the DNS cache are discarded and address resolutions

are requested again.

Config/Status View: status.html: Displays the status.html page with the JSON data.

Operating

Config/Status Download: export.json: Direct file download of JSON data from

status.hml.

2.3.2 Configuration Management

The device configuration can be saved and restored in the maintenance area .

The "Config File Export" function can be used to save the current configuration as a

text file. The syntax used in the configuration file corresponds to the commands of the

Telnet console. If the configuration of a device is to be restored from a text file, load

the file with "Upload" and restart the device with "Restart Device".

Saving the configuration should only be carried out in an SSL connection, since it

contains sensitive password information (even if it is encrypted or hashed). For the

same reasons, it is advisable to carefully handle the generated configuration files when

archiving.

Editing the configuration file

It is possible to customize a saved configuration file with a text editor for your own

needs. For example, one scenario would be to use a script language to automate the

creation of many customized versions of a configuration, then equip a large number of

devices with an individualized configuration. Also Upload and restart with CGI com-

mands can be done in scripting languages. With use of the comment sign "#" you can

quickly hide single commands or add personal notes.

If you modify a configuration file manually, it is not always clear which limits are allowed

for parameters. After uploading and restarting, commands with invalid parameters are

ignored. Therefore, the generated configuration includes comments describing the

boundaries of the parameters. Where "range:" refers to a numeric value, and "len:" to a

text parameter. E.g:

email auth set 0 #range: 0..2

email user set "" #len: 0..100

The command "system fabsettings" from the beginning of a generated configuration

file brings the device into the factory state, and then executes the individual commands

that modify the configuration state. It may be desirable to make the changes relative to

the current configuration, and not out of the factory state. Then the "system fabset-

tings" should be removed.

No output of default values

The configuration file contains (with exceptions) only values which differ from the de-

fault. The command "system fabsettings" (go to the factory state) from the beginning of

a generated configuration file should not be removed, otherwise the device can get in-

completely configured.

Table of contents

Other Gude Controllers manuals

Gude

Gude Expert Power Control 8042 Series User manual

Gude

Gude Expert Power Control NET 8x User manual

Popular Controllers manuals by other brands

Lexicon

Lexicon MC-1 Service manual

Channel Vision

Channel Vision Aria A4603 instruction manual

Traxon

Traxon e:cue SYMPL Instructions for use

Leviton

Leviton FEBC Operation manual

ACC

ACC RC-85 owner's manual

Grandstream Networks

Grandstream Networks HA100 user manual

Renishaw

Renishaw UCC PI 80 installation guide

PI PIMag V-277.630 user manual

Festo

Festo VPPM operating instructions

ON Control

ON Control KSUG manual

Parasound

Parasound 7100 owner's guide

DT Research

DT Research DT136 Basic operation guide

Honeywell

Honeywell MSR PolyGard 2 MGC2-K quick start guide

Tech Controllers

Tech Controllers EU-T-4.1 user manual

Danfoss

Danfoss VLT FC Series Spare Brake IGBT installation instructions

Multiplex

Multiplex MULTIcont BL-20 SD instructions

Kramer

Kramer PT-12 quick start guide

Flycolor

Flycolor Raptor S-Tower F4-20A user manual

Gude Expert Net Control 2304 User manual

Popular Controllers manuals by other brands
