Guide TL Series User manual

Thank you for choosing our product. Please thoroughly go through
user manual before operation and keep it well for future reference.
All photos here are for reference only. and specifications are
subject to the physical product.
Quickstart Guide
TL Multi-spectrum Monocular
GB RU DE FR IT ES JP KR PL

- CONTENTS -
Quick User Guide for
TL Multi-spectrum Monocular ................................ 1-20
Краткое руководство по эксплуатации
многоспектрального монокуляра серии TL .......21-43
Kurzanleitung für
TL Multispektrum-Monokular ...............................45-66
Guide rapide d’utilisation pour le monoculaire multi-
spectral de série TL ...............................................67-89
Guida rapida per l'utente per
il monocolo multispettro TL ................................91-113
Guía de Inicio Rápido del
Monocular Multiespectro TL .............................115-136
󱻤󵹻󹔰
 137-154
󼐃󻫓󼪯󾋊󻐏󼙯󾋊󻭧󽐗󾋊󼏋󽓀󽏟󻤣
󻬄󼟷󺷤󾋊󻾇󻪟󾋊󼇓󼟐󾋊󼉋󻮬󼉃 155-173
Skrócona instrukcja obsługi dla
monokularu TL Multi-spectrum ........................175-196
GB
IT
RU
ES
DE
JP
FR
KR
PL

1
GB RU DE FR IT ES JP KR PL
- IMPORTANT -
Thank you for choosing this product. Please read this guide
before use and keep it for future reference. We hope you'll
be satis󶀄ed with this product.
This guide is a general guide for a series of products, which
means that the speci󶀄c model you receive may di󶀃er from
the picture in the guide. Please refer to the actual product
you receive.
This user guide is organized for the convenience of users
to use and understand our products. We will do our best
to ensure the accuracy of the contents of this guide,
however, we still cannot guarantee the completeness of the
contents thereof. As our products are subject to continuous
upgrading, we reserve the right to modify this guide from
time to time without prior notice.

2
GB RU DE FR IT ES JP KR PL
- FCC WARNING -
This equipment may generate or use radio frequency energy.
Changes or modifications to this equipment may cause
harmful interference unless the modifications are expressly
approved in the instruction manual. The user could lose
the authority to operate this equipment if an unauthorized
change or modification is made.
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
The device has been evaluated to meet general RF exposure
requirement. The device can be used in portable exposure
condition without restriction.
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful

3
GB RU DE FR IT ES JP KR PL
interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
• The rating information is located at the bottom of the
unit.

4
GB RU DE FR IT ES JP KR PL
- PRECAUTIONS -
DANGER
1) Please charge the battery with the method
described in this guide and follow the charging
procedure and precautions. Improper battery
charging will cause heating, damage and even
physical injury.
2) Do not try to open or disassemble the battery
at any time. Once the battery leaks and the spill
enters the human eye, wash the eyes with clean
water immediately and take medical care.
WARNING
1) When using the equipment, please try to keep it
stable and avoid violent shaking;
2) Do not use or store the equipment in an environment
that exceeds the allowable operating temperature
or storage temperature;
3) Do not directly aim the equipment at high-intensity
thermal radiation sources, such as the sun, lasers,
spot welding machines, etc.;
4) Do not plug the holes on the equipment;
5) Do not knock, throw or vibrate instruments and

5
GB RU DE FR IT ES JP KR PL
accessories to avoid damage;
6) Do not disassemble the machine by yourself,
which may cause equipment damage and loss of
warranty rights;
7) Do not use soluble or similar liquids on equipment
and cables, which may cause damage to the
equipment;
8) Please do not use the equipment in an environment
that exceeds the operating temperature of the
equipment, which may cause damage to the
equipment;
9) Please observe the following measures when
wiping this device:
· Non-optical surface: Use clean and soft
cloth to wipe the non-optical surface of the
thermographic camera;
· Optical surface: When using the thermographic
camera, please avoid polluting the optical
surface of the lens, especially avoid touching
the lens with your hands, because the sweat on
your hands will leave traces on the lens glass
and may corrode the optical coating on the
glass surface. When the surface of the optical
lens is polluted, use special lens paper to wipe

6
GB RU DE FR IT ES JP KR PL
it carefully;
10) Do not place the battery in a high temperature or
near a high-temperature object;
11) Do not short circuit the positive and negative poles
of the battery;
12) Do not expose the battery to moisture or water;
13) Do not use non-original adapters or chargers (the
contents of the original packaging shall prevail).
NOTES
1) Do not expose the device to dust or moisture. Avoid
water splashing to the device when being used in
an environment with water. Cover the lens when
not using the device;
2) When this device is not used, please put the device
and all accessories in a special packing box;
3) Avoid using SD cards for other purposes;
4) Using the eyepiece for a long time will reduce the
contrast of the eyepiece, and the picture will turn
white. You can switch to LCD display, and then to
eyepiece display after a period of time.

7
GB RU DE FR IT ES JP KR PL
- LIST OF PARTS -


Options：
PLUG
18650 BATTERY 5V2A ADAPTERCHARGER
TYPE-C CABLE WRIST STRAP
· BLUETOOTH REMOTE CONTROL
· 18650 BATTERY*1
· DOVETAIL GUIDE

8
GB RU DE FR IT ES JP KR PL
- INTRODUCTION TO PRODUCT PARTS -
This guide is applicable to many models of this series, and
only one model is shown in the figure.
SHUTTER BUTTON
LASER POINTER
LASER
RANGEFINDER
INFRARED
LENS
EYEPIECE
BATTERY
BOX
POWER BUTTON
VISIBLE LIGHT LENS
DOWN BUTTON
MENU BUTTON
UP BUTTON

9
GB RU DE FR IT ES JP KR PL
- QUICKSTART INSTRUCTIONS -
Buttons Current Device
Status Short Press Long Press


  󽗈
󽗈
󽗈  
󽗈  


  
 󽗉





   



 






   
【BUTTON DESCRIPTION]
1. Power button
· Power on
Long press the Power button until the boot screen
appears in the eyepiece, then the device is turned on
successfully.

10
GB RU DE FR IT ES JP KR PL
· Power o
Manual power-o: Long press the Power button to
display the shutdown progress bar until the progress
bar is completed and the shutdown is successful.
· Display o
Long press the Power key to display the shutdown
progress bar. Before the progress bar is completed,
release the Power key to cancel the shutdown and
enter the Display o mode.
· Display on
In Display o mode, press any button to wake up the
screen.
· Compensation
Short press the Power button briefly to complete the
corresponding compensation action.
2. Menu button
· Shortcut menu
Short press the Menu button to call up the shortcut
menu.
· Main menu
Long press the Menu button to call up the main
menu.
· Move the menu and option
When it is turned on and the menu is called up, short

11
GB RU DE FR IT ES JP KR PL
press the Down button or Up button to switch the
menu options.
· Exit menu
When it is turned on and the menu is called up,
long press the Menu button to save and back to the
previous menu.
3. Up button
· Zoom in
Long press the Up button to zoom in at the specified
point;
In the real-time interface and infrared mode, long
press the Up button to zoom in the picture at 0.1x in
combination of optical zoom and digital zoom (as
shown in the table below) to 4X (ZG20A), 8X (ZG20B).
In visible light mode, there is only digital zoom
multiple (1X, 2X, 4X and 8X), and UI displays the
optical zoom multiple * digital zoom multiple.

12
GB RU DE FR IT ES JP KR PL
Model Optical Zoom
Multiple
Digital
Zoom
Optical Zoom *
Digital Zoom
ZG20A
+
35mm
2.3X 1.0~4.0 2.3X~9.2X
ZG20A
+
50mm
3.2X 1.0~4.0 3.2X~12.8X
ZG20B
+
35mm
2.0X 1.0~8.0 2.0X~16.0X
ZG20B
+
50mm
2.8X 1.0~8.0 2.8X~22.4X
4. Down button
· Zoom out
In zoom in mode, long press the Down button to
zoom out at the specified point, and the multiple
display of zoom out is opposite to that of zoom in.
5. Shutter button
· Take photos
Short press the Shutter button to take photos.
· Take videos
Long press the Shutter button to start video recording
and long press it again to stop video recording and
save the video.

13
GB RU DE FR IT ES JP KR PL
FUNCTION DESCRIPTION
Icon Definition Icon Definition
Photo taking
successfully
Video recording
successfully
Photo taking failed Video recording
failed
WiFi Video recording
Bluetooth
Do not adjust
the screen
brightness
Do not take photos Do not record
videos
Do not adjust the
screen brightness
Do not turn on
WIFI
Do not turn on
serial port mode
Do not turn on
Bluetooth
Do not turn on
hotspot tracking
Do not turn on
GPS
Do not turn on
compass
Do not turn on
holding prompt
Do not turn on
ranging Serial port mode
Super power
saving mode Memory full
Memory is to be
full Hotspot tracking
Ranging

14
GB RU DE FR IT ES JP KR PL
· PIP:
PIP can be switched among four states: upper left, upper
middle, upper right and o.
· Screen brightness: The screen brightness can be
adjusted from level 1 to 10.
· Hotspot tracking: A cursor will be displayed when it is
enabled to track the spot with the highest temperature
on the entire map (this function can be turned on in
infrared mode only).
· Super power saving: When the super power saving
mode is enabled, the ARM switches to the low power
mode, and the OLED brightness is fixed at 20%, which
cannot be adjusted, and WIFI, Bluetooth, Ranging, GPS,
Compass and Holding prompt cannot be turned on. If
these functions have been already turned on, turn o
them.
· Ranging: When it is enabled, the ranging cursor and
ranging information are displayed, and the ranging
cursor is aligned with the target to display the target
distance.
· Image enhancement: The imaging quality can be
adjusted.
· Scene mode (infrared): Natural/Enhanced/Highlighted
(only displayed in infrared mode).

15
GB RU DE FR IT ES JP KR PL
· Pseudo color: Colors can be adjusted to White hot, Black
hot, Red hot, Iron red and Blue hot.
· Scene mode (visible light): Daylight/Night vision/
Glimmer (only displayed in infrared mode).
· Brightness: The detector brightness can be adjusted
from level 1 to 10.
· Contrast: The detector contrast can be adjusted from
level 1 to 10.
· Compensation mode: Scene compensation/Shutter
compensation.
· WIFI: WIFI switch. When the mobile client and the device
are connected, real-time videos can be transmitted to
the mobile phone, the device can be operated through
the APP.
· GPS: This function shall be used in open space. When
it is enabled, the location coordinates of the device is
displayed on the screen.
· Compass: When it is enabled, the orientation is
displayed on the screen. The compass can be calibrated
with the calibration function.
· Holding prompt: This function shall be used in open
space. When it is enabled, the holding oset information
of the current device is displayed on the screen and the
way of holding the device can be adjusted based on the

16
GB RU DE FR IT ES JP KR PL
information.
· Target indication: When it is enabled, ranging and
background GPS are enabled at the same time. When
the ranging cursor indicates the target, the locating
information of the target is displayed.
· Auto sleep: Auto sleep time can be set at 5/10/15min. If
no operation is made within the set time, the camera will
enter the sleep mode.
· Automatic power o: Automatic power o time can be
set at 15/30/60min. If no operation is made within the
set time, a countdown to power o will appear and the
camera will be powered o when the countdown is over.
· Power indication: When it is enabled, the power
indicator lights on and when it is disabled, the indicator
lights o.
· Date format: The date format can be YYYY-MM-DD/MM-
DD-YYYY/DD-MM-YYYY.
· Time format: The time format can be 12H/24H.
· Time adjustment: The device time and date can be
adjusted in the time adjustment interface.
· Watermark settings: Options can be made from Date
only/Time only/Time and date/O.
· Language settings: Foreign version: English/Russian/
German/French/Spanish/Italian/Japanese/Korean/

17
GB RU DE FR IT ES JP KR PL
Polish; domestic version: Simplified Chinese.
· Memory card formatting: All files in the memory card
can be deleted.
· Restore default: The default values of the device can be
restored.
· About: The software version and MAC address are
displayed.
· Bluetooth: The Bluetooth remote control can be
connected to control the device.
· Laser pointer: The laser pointer can be in "Red, Yellow
and Green". When it is enabled, the laser pointer lights
on.
· Indication calibration: The coordinate of the laser
pointer can be adjusted to adapt to the indication
consistency of the laser and laser cursor in dierent
distances.
· Calibration blending: The display range of the infrared
image on the screen can be adjusted in the blending
mode (only displayed in blending mode).
· Capacity indication
When the thermographic camera is turned on and the
battery capacity changes, the capacity indicator is
displayed in the lower left corner of the screen, and
the part of the lit power indicator shows the remaining
