Guilin Feiyu Technology FY WG2 3 Axis User manual

EN V 1.0
Instruction Manual
FY WG2 3 Axis Wearable Gimbal
Compatible with Gopro Hero5 / Gopro Hero4
and cameras with similar dimensions
GuiLin FeiYu Technology Incorporated Company

User Guide
1Install the Camera
Attention! (1) Please install the camera before powering on the gimbal.
(2) When not in use, turn off the gimbal and then remove the camera.
!
Install the camera on retainer plate, then fix the camera with retainer bar and screw.
1
Hero5
Hero4
Reference point

2Power on / off
Power On: Press and hold function button until the green light is on.
Power Off: Press and hold function button until the red light changes from quick flashing to
always on.
Attention: Make sure the camera is secure before powering on the Gimbal.
2
In case of low battery, the red LED
indicator flashes for three times for
every 5 seconds.Please charge WG2
or replace the battery.
!

3
Charge with micro USB cable.
Charging
micro USB
（equipped by user）
Please make sure the battery is fully charged before you use the gimbal for the first time.
3

Tilting axis
Rolling axis
Panning axis
USB port
1/4 inch
screw hole
T-Clamp
Screw Hole
Product Overview
* The showing sports camera is only for reference
1/4 inch screw hole
T-Clamp Screw Hole
Function Button
Indicator Status
Long screw Waterproof
4
Bluetooth

102.5mm
89.3mm 40mm
61.1～78.1mm
5

Camera in right
Forward
Camera in left Camera in left
Camera in right
Inverted
Camera in right
Vertical
Camera in left
6

APP download and connect
1
2Connect to APP
Start the app on your smartphone, follow the instructions to connect the smartphone with gimbal
via Bluetooth.
App Store
Download APP
Download "Feiyu ON" and install it.
(1) iOS version:
(2) Android version:
Google play
7
Feiyu ON
Download
GuiLin FeiYu Technology Incorporated Company
Feiyu ON
WG2
Gimbals Update Settings
Panning Pan&Tilt Lock
Standby Reverse Reset
360°
Choose a device
FY_WG2_XX
D7:58:42:2D:DD：xx
Searching...
Rssi=xx
cancel

Mode /Function
8
The orientation of the camera is fixed.
Panning Mode
Tilting and rolling direction are fixed, and the camera
lens moves according to the hand movement of the user.
Panning and Tilting Mode
The rolling direction is fixed, and the camera lens moves
according to the hand movement of the user.
Lock Mode
Reset
Reset to initial status.
Reset the tilting axis of the gimbal to initial orientation and initial mode
Function Button
Double tap
Single tap
Mode /Function Explanation
Panning Mode / Lock Mode
Panning and tilting mode
Triple tap
Single tap to switch between panning mode and lock mode
When in panning and tilting mode, press once to switch to lock mode
Inversion Mode
Pressing the function button three consecutive times in any operating mode, the gimbal
will switch to the Inverted Mode . Pressing the function button three more times while in
Inverted Mode to switch back to the original orientation.
Quadruple tap Reset
Long press until the red
light flashes quickly Single tap again to awake the gimbal, or triple tap to initialize the gimbalStandby
Mode /Function Operation Instructions
Blue light flashes once
Blue light flashes twice
Panning
Panning and tilting mode
Lock mode / InitializingBlue light on steadily
Blue light keeps flashing Initialization failure /
Malfunction
Blue light flashes three times Standby
Low battery
Red light flashes three times
Red light keeps flashing Switching to standby mode/
Gimbal will power off
Indicator Status Mode / Status

micro USB
Firmware Upgrade
PC
Upgrade........
Please visit the official website www.feiyu-tech.com to download the relevant programs for
upgrading, including USB driver, firmware upgrade software and product firmware, and install the
relevant software, decompress the firmware files for standby application.
Feiyu ON
Option 1: connect the gimbal with PC via micro USB cable, and then upgrade the firmware.
Option 2: connect the gimbal with Smarphone via bluetooth, and then upgrade the firmware.
(1)
(2)
9
new firmware is available,
do you want to upgrade?
×
Firmware upgrade
Yes No

Gimbal initialization
You can initialize your gimbal: 2
31
10
（1） when camera is not level
（2） if not used for a long period of time
（3） in case of extreme temperature variations
Adjusting steps:
（2）Single tap
press and
hold
Red light flashes
(1) Stands on table
(1) Stands on table
Blue light flash
three times quickly
Initialization successful
(2) Triple tap
Blue light
is on

11
Parameters
Weight 188 g（Not including camera ）
Adaption Weight 115 g
Usage time 2.5 Hours
Panning Increments min 3°/s max 150°/s
Titling Increments min 2°/s max 75°/s
Panning Angle
Titling Angle
Rolling Angle 50°
360°
360°

12
DISCLAIMER
Attention Please correctly assemble the gimbal in accordance with the diagram
Please install the camera before powering on the gimbal
When the gimbal is not in use or placed on the table, please ensure it
is powered off
Prohibit any user for any illegal purpose. Users will be responsible for all behaviors of
purchase and use products.
The Company assumes no liability for any risks related to or resulting from the debug
and use of this product (including the direct, indirect or third-party losses).
For any unknown sources of using, we will not be at any services.
The updating and changes of product firmware and program may cause changes in
function descriptions in this user manual, please read the instructions carefully before
upgrading the firmware and use the corresponding user manual.
You can get the latest user manual from the official website: www.feiyu-tech.com
FeiyuTech reserves the right to amend this manual and the terms and conditions of
use the product at any time.

www.feiyu-tech.com
Create More Possibilities
For more information, please visit our official website: www.feiyu-tech.com
Support Email: [e-mail]
Due to software and hardware improvements, your actual product might differ from
the descriptions and pictures in this user manual. You can get the latest user manual
from the official website.
