Guilin Woodpecker Medical Instrument CURING LIGHT LED.C User manual

CURING LIGHT LED.C
USER’S MANUAL

Content
1. Introduction ................................................................. 1
2. Principle and usage ..................................................... 1
3. Structure and components ........................................... 1
4. Technical specications .............................................. 1
5. Instruction of recharging ............................................. 2
6. Operation ..................................................................... 3
7. Cleaning , Disinfection and Sterilization..................... 4
8. Precaution ................................................................. 12
9. Contraindication ........................................................ 13
10. Maintenance ............................................................ 13
11. After service ............................................................ 13
12. Packing List ............................................................ 14
13. Troubleshooting ..................................................... 14
14. Storage and transportation ...................................... 15
15. Environmental protection ........................................ 15
16. Manufacturer’s right ............................................... 16
17. Symbol instruction .................................................. 16
18. Statement ................................................................. 17
19. EMC - Declaration of conformity ........................... 17

1
1. Introduction
Guilin Woodpecker Medical Instrument Co., Ltd. is a high-
tech enterprise in researching, developing, and producing dental
equipment, and has a perfect quality assurance system, main
products including ultrasonic scaler, curing light, micro motor,
apex locator and ultrasurgery etc.
2. Principle and usage
2.1 LED.C adopts the principle of ray radiation to solidify the
light-sensitive resin by shooting at it in a short time.
2.2 This product is used to restore teeth and solidify material
for whitening teeth.
3. Structure and components
LED.C (dental) is composed mainly of high power LED,
optical ber and main unit. (Picture 1)
4. Technical specications
4.1 Power supply:
Rechargeable Lithium battery
Battery model: ICR18490
Battery voltage and capacity: 1400mAh
Input of adapter: 100V to 240V~ 50Hz/60Hz
Built-in fuse of adapter: 1A/250V
4.2 Applied part: optical ber
4.3 Light source:
Wavelength: 385nm-515nm(wide-spectrum) / 420-480nm
(Please refer to the label to see if this curing light is wide-
specturm).
Light intensity: 1000mW/cm2~1200mW/cm2

2
4.4 Working condition:
Environment temperature: 5℃ to 40℃
Relative humidity: 30%~75%
Atmosphere pressure: 70kPa to 106kPa
4.5 Dimensions: Φ23mm×263mm
4.6 Net weight: 124g
4.7 Consumption power: ≤8W
4.8 Protection type against electrical shock: classⅡ
4.9 Protection against electrical shock: type B
4.10 Protection against harmful ingress of water or particular
matter: ordinary equipment (IPX0)
4.11 Safety in the presence of ammable anesthetic mixture
with air, oxygen or nitrous oxide: not suitable under this
condition.
5. Instruction of recharging
5.1 Load the battery into the compartment of the pedestal
charger. Be sure not to opposite the electrode.
5.2 Connect adapter to the AC100V~240V.Machine standby
when indicator lighting green. Put the battery into the pedestal,
when indicator turns yellow, starts recharging. After recharging
indicator turns green, and shut o the electricity and take out the
battery from the compartment.
5.3 The battery has no memory and can be recharged any
time.
5.4 The main unit should be in a full charge when it's used for
the rst time, the ordinary charge time for a full charge is 4 to 6
hours.
5.5 After recharging, shut o the electricity and take out the
battery from the compartment.

3
Picture 1
6. Operation
6.1 Let the cathode of the battery face down to the battery
compartment, and tighten it to the main unit (See Picture 1).
6.2 Take o the red cap from the optical ber and then insert
the metal part into the front of LED.C, make sure to screw the
ber to the end.
6.3 To install the light hood on as show in picture 1.
6.4 Press the time button to choose the solidication time.4
working time modes are available: 5, 10, 15, 20 seconds.
6.5 Lightly press the mode key. Following three modes are
available.
6.5.1 Full power mode: blue light shine in full power.
6.5.2 Ramping mode: The power of the blue light turns from
weak to stronger, and reaches the highest power in 5 seconds.
6.5.3 Pulse mode: blue light work in the mode of pulse.

4
6.6 During the operation, aim blue light at the position
needing solidication. Press the ON/OFF switch, the LED starts
to work under the selected mode. Then it counts down to “0”
second to end the solidication.
6.7 After the operation, please clean the ber with calico in
order not to aect the light intensity.
6.8 The depth of solidification of composite is no less than
4mm per 10 seconds.
6.9 The optical fiber can be spinned off by 360°and should
be sterilized for 4 minutes with 134℃ and 2.0bar~2.3bar
(0.20MPa~0.23MPa) before each use.
6.10 During operation, if the indicator light of mode twinkles,
it means low volume, recharge it at once.
6.11 Please take out the battery and store it carefully when
not operating regularly.
6.12 The curing light is equipped with over-heat protection
system. It can continuously work 200s, For example,
continuously operate the curing light for 10 times under 20s
working mode (even the curing light works less than 20s, it is
counted as a full operation), then it will come into over-heat
protection status. And only after 2-minute sleep, it can restart
working 200s continuously.
7. Cleaning , Disinfection and Sterilization
The cleaning, disinfection and sterilization of optical ber is
as follow.
Unless otherwise stated, they will be hereinafter referred to as
“products”.
Warnings
The use of strong detergent and disinfectant (alkaline pH>9
or acid pH <5) will reduce the life span of products. And in such

5
cases, the manufacturer takes no responsibility.
This device shall not be exposed to high temperature above
138℃.
Processing limit
The products have been designed for a large number of
sterilization cycles.
The materials used in manufacture were selected accordingly.
However with every renewed preparation for use, thermal and
chemical stresses will result in ageing of the products. The
maximum number of sterilizations for optical ber is 500 times.
7.1 Initial processing
7.1.1 Processing principles
It is only possible to carry out eective sterilization after the
completion of eective cleaning and disinfection. Please ensure
that, as part of your responsibility for the sterility of products
during use, only sufficiently validated equipment and product-
specific procedures are used for cleaning/disinfection and
sterilization, and that the validated parameters are adhered to
during every cycle.
Please also observe the applicable legal requirements in your
country as well as the hygiene regulations of the hospital or
clinic,especially with regard to the additional requirements for
the inactivation of prions.
7.1.2 Post-operative treatment
The post-operative treatment must be carried out immediately,
no later than 30 minutes after the completion of the operation.
The steps are as follows:
1. Remove the optical ber from the Curing light Device,and
rinse away the dirt on the surface of product with pure water (or
distilled water/deionized water);
2. Dry the product with a clean, soft cloth and place it in a

6
clean tray.
Notes
a) The water used here must be pure water, distilled water or
deionized water.
7.2 Preparation before cleaning
Steps
Tools: tray, soft brush, clean and dry soft cloth Remove
optical ber from main unit and put it into the clean tray.
Use a clean soft brush to carefully brush the optical ber until
the dirt on surface is not visible. Then use soft cloth to dry the
optical ber and put them into a clean tray. The cleaning agent
can be pure water, distilled water or deionized water.
7.3 Cleaning
The cleaning should be performed no later than 24 hours after
the operation.
The cleaning can be divided into automated cleaning and
manual cleaning. Automated cleaning is preferred if conditions
permit.
7.3.1 Automated cleaning
•The cleaner is proved to be valid by CE certificationin
accordance with ENISO 15883.
▪There should be a ushing connector connected to the inner
cavity of the product.
▪The cleaning procedure is suitable for the product, and the
irrigating period is sucient.
It is recommended to use a washer-disinfector in accordance
with EN ISO15883. For the specific procedure, please refer
to the automated disinfection section in the next section
“Disinfection”.
Notes
a) The cleaning agent does not have to be pure water. It can

7
be distilled water, deionized water or multi-enzyme. But please
ensure that the selected cleaning agent is compatible with the
product.
b) In washing stage, the water temperature should not exceed
45 °C, otherwise the protein will solidify and it would be
dicult to remove.
c) After cleaning, the chemical residue should be less than
10mg / L.
7.4 Disinfection
Disinfection must be performed no later than 2 hours after the
cleaning phase.
Automated disinfection is preferred if conditions permit.
7.4.1 Automated disinfection-Washer-disinfector
·The washer-disinfector is proved to be valid by CE
certication in accordance with EN ISO 15883..
·Use high temperature disinfection function. The temperature
does not exceed 134 ℃, and the disinfection under the
temperature cannot exceed 20 minutes.
·The disinfection cycle is in accordance with the disinfection
cycle in EN ISO 15883.
Cleaning and disinfecting steps by using Washer-disinfector
1. Carefully place the product into the disinfection basket.
Fixation of product is needed only when the product is
removable in the device. The products are not allowed to contact
each other.
2. Use a suitable rinsing adaptor, and connect the internal
water lines to the rinsing connection of the washer-disinfector.
3. Start the program.
4. After the program is finished, remove the product from
the washer-disinfector, inspect (refer to section “Inspection and
Maintenance”) and packaging (refer to chapter “Packaging”).

8
Dry the product repeatedly if necessary (refer to section
“Drying”).
Notes
a) Before use, you must carefully read the operating
instructions provided by the equipment manufacturer to
familiarize yourself with the disinfection process and
precautions.
b) With this equipment, cleaning, disinfection and drying will
be carried out together.
c) Cleaning: (c1) The cleaning procedure should be suitable
for the product to be treated. The flushing period should be
sufficient (5-10 minutes). Pre-wash for 3minutes, wash for
another 5 minutes, and rinse it for twice with each rinse lasting
for 1 minute. (c2) In the washing stage, the water temperature
should not exceed 45 °C, otherwise the protein will solidify
and it is dicult to remove. (c3) The solution used can be pure
water, distilled water, deionized water or multi-enzyme solution,
etc., and only freshly prepared solutions can be used. (c4)During
the use of cleaner, the concentration and time provided by
manufacturer shall be obeyed.
The used cleaner is neodisher MediZym (Dr. Weigert).
d) Disinfection: (d1) Direct use after disinfection: temperature
≥ 90 ° C, time ≥ 5 min or A0 ≥ 3000.
(d2)Sterilize it after disinfection and use: temperature ≥ 90 °
C, time ≥ 1 min or A0 ≥ 600.
(d3) For the disinfection here, the temperature is 93 ° C, the
time is 2.5 min, and A0>3000.
e) Only distilled or deionized water with a small amount of
microorganisms (<10 cfu/ml) can be used for all rinsing steps.
(For example, pure water that is in accordance with the European

9
Pharmacopoeia or the United States Pharmacopoeia).
f) After cleaning, the chemical residue should be less than
10mg / L.
g)The air used for drying must be ltered by HEPA.
h) Regularly repair and inspect the disinfector.
7.5 Drying
If your cleaning and disinfection process does not have an
automatic drying function, dry it after cleaning and disinfection.
Methods
1. Spread a clean white paper (white cloth) on the at table,
point the product against the white paper (white cloth), and then
dry the product with filtered dry compressed air (maximum
pressure 3 bar). Until no liquid is sprayed onto the white paper
(white cloth), the product drying is completed.
2. It can also be dried directly in a medical drying cabinet (or
oven). The recommended drying temperature is 80℃~120℃ and
the time should be 15~40 minutes.
Notes
a) The drying of product must be performed in a clean place.
b) The drying temperature should not exceed 138 °C;
c) The equipment used should be inspected and maintained
regularly.
7.6 Inspection and maintenance
In this chapter, we only check the appearance of the product.
After inspection, if there is no problem, the optical ber can only
be used.
7.6.1 Check the product. If there is still visible stain on
the product after cleaning/disinfection, the entire cleaning/
disinfection process must be repeated.
7.6.2 Check the product. If it is obviously damaged, smashed,
detached, corroded or bent, it must be scrapped and not allowed

10
to continue to be used.
7.6.3 Check the product. If the accessories are found to be
damaged, please replace it before use. And the new accessories
for replacement must be cleaned, disinfected and dried.
7.6.4 If the service time (number of times) of the product
reaches the specified service life (number of times), please
replace it in time.
7.7 Packaging
Install the disinfected and dried product and quickly package
it in a medical sterilization bag (or special holder, sterile box).
Notes
a) The package used conforms to ISO 11607;
b) It can withstand high temperature of 138 °C and has
sucient steam permeability;
c) The packaging environment and related tools must
be cleaned regularly to ensure cleanliness and prevent the
introduction of contaminants;
d) Avoid contact with parts of different metals when
packaging.
7.8 Sterilization
Use only the following steam sterilization procedures
(fractional pre-vacuum procedure*) for sterilization, and other
sterilization procedures are prohibited:
1. The steam sterilizer complies with EN13060 or is certied
according to EN 285 to comply with EN ISO 17665;
2. The highest sterilization temperature is 138 ° C;
3. The sterilization time is at least 4 minutes at a temperature
of 132℃/134℃ and a pressure of 2.0 bar ~ 2.3 bars.
4. Allow a maximum sterilization time of 20 minutes at 134
°C.
Verication of the fundamental suitability of the products for

11
effective steam sterilization was provided by a verified testing
laboratory.
Notes
a) Only products that have been effectively cleaned and
disinfected are allowed to be sterilized;
b) Before using the sterilizer for sterilization, read the
Instruction Manual provided by the equipment manufacturer and
follow the instructions.
c) Do not use hot air sterilization and radiation sterilization as
this may result in damage to the product;
d) Please use the recommended sterilization procedures
for sterilization. It is not recommended to sterilize with other
sterilization procedures such as ethylene oxide, formaldehyde
and low temperature plasma sterilization. The manufacturer
assumes no responsibility for the procedures that have not been
recommended.
If you use the sterilization procedures that have not been
recommended, please adhere to related eective standards and
verify the suitability and eectiveness.
* Fractional pre-vacuum procedure = steam sterilization with
repetitive pre-vacuum. The procedure used here is to perform
steam sterilization through three pre-vacuums.
7.9 Storage
7.9.1 Store in a clean, dry, ventilated, non-corrosive
atmosphere with a relative humidity of 10% to 93%, an
atmospheric pressure of 70KPa to 106KPa, and a temperature of
-20 °C to +55 °C;
7.9.2 After sterilization,the product should be packaged in a
medical sterilization bag or a clean sealing container, and stored
in a special storage cabinet. The storage time should not exceed
7 days. If it is exceeded, it should be reprocessed before use.

12
Notes:
a) The storage environment should be clean and must be
disinfected regularly;
b) Product storage must be batched and marked and recorded.
7.10 Transportation
1. Prevent excessive shock and vibration during
transportation, and handle with care;
2. It should not be mixed with dangerous goodsduring
transportation.
3. Avoid exposure to sun or rain or snow during
transportation.
The cleaning and disinfection of main unit are as follows.
• Before each use, wipe the surface of the machine with a soft
cloth or paper towel soaked in 75% medical alcohol. Repeat the
wipe for at least 3 times.
• After each use, wipe the surface of the device with a soft
cloth soaked in clean water (distilled or deionized water) or a
clean disposable wipe.
Repeat the wipe for at least 3 times.
8. Precaution
8.1 Please recharge the battery at least 4 hours before first
time usage.
8.2 Connect adapter to the AC100V~240V.Machine standby
when indicator lighting green. Put the battery into the pedestal,
when indicator turns yellow, starts recharging. After recharging
indicator turns green, and shut o the electricity and take out the
battery from the compartment.
8.3 Avoid aiming at eyes directly.
8.4 It is advised to use the original pedestal charger, adapter

13
and Lithium battery, because other brand pedestal charger,
adapter and Lithium battery are likely to damage the circuit.
8.5 Please recharge the battery in cool and ventilated room.
8.6 It is forbidden to self-taking apart the battery, in order not
to result in short-circuit or leakage.
8.7 It is forbidden to extrude, shake or rock the battery. The
Lithium battery is forbidden to be in short-circuit situation and it
is forbidden to put the battery with metal or other conductors.
① WARNING: If the curing light works for 40s
continously,the temperature of the top of optical ber may reach
56℃.
② WARNING: Do not modify this equipment without
authorization of the manufacturer.
9. Contraindication
The heart disease patients, pregnant women and children
should be cautious to use this equipment.
10. Maintenance
9.1 Only the optical fiber can be autoclaved under high
temperature and pressure.
9.2 After operation each time, please shut off the power
source and clean the optical ber.
11. After service
From the date this equipment has been sold, base on the
warranty card, we will repair this equipment free of charge if it
has quality problems, please refer to the warranty card for the
warranty period for units and parts.

14
12. Packing List
The components of the equipment are listed in the packing
list.
13. Troubleshooting
Faulty Possible cause Solution
Non-indication
Non-act.
l. Battery has run down.
2. Battery is xed upside
down.
3. The LED.C works
continuously too long and
the heat protection system
works.
1. Charge the LED.C.
2.Rex the battery, pay
attention to the ends of the
battery.
3. Stop the operation for
several minutes.
Light intensity
insucient.
1. The optical ber is not
inserted till the botton.
2. The optical ber has
cracked
3. There is resin remained
on the surface of optical
ber.
4. Low battery.
1. Insert the optical ber
again correctly.
2. Change the optical ber.
3. Wipe o the resin.
4 Charge the LED.C.
Show "Er".
1. The battery's voltage is
low.
2. The LED.C is damaged.
1. Charge the LED.C.
2. Contact the local
distributor or us.
Battery lasting
time becomes
shorter.
The battery's capacity
becomes smaller. Change a new battery.

15
Faulty Possible cause Solution
Indicator light
of pedestal
doesn't shine in
the process of
recharging.
1.Power supply cord is
not connected well.
2. Battery is xed upside
down.
1.Check the power supply
cord and connect it well.
2.Rex the battery, pay
attention to the ends of the
battery.
If all the above solutions have been completed, the machine
still can not work normally. Please contact our special repair
shop or us.
14. Storage and transportation
14.1 This equipment should be handled carefully, kept away
from shaking point, installed or stored at shadowy, dry, cool and
ventilated places.
14.2 Don't store it together with articles that are combustible,
poisonous, caustic and explosive.
14.3 This equipment should be stored in the environment
where the relative humidity is10%~93%, the atmosphere
pressure is 70kPa to 106kPa and the temperature is -20℃ to
+55℃.
14.4 Excess impact or shake should be avoided during
transportation.
14.5 Don't mix it with dangerous articles during
transportation.
14.6 Keep it away from sun or snow or rain during
transportation.
15. Environmental protection
Please dispose according to the local laws.

16
16. Manufacturer’s right
We reserve the rights to change the design of the equipment,
the technique, ttings, the instruction manual and the content of
the original packing list at any time without notice. If there are
some dierences between blueprint and real equipment, take the
real equipment as the norm.
17. Symbol instruction
CE marked product
Type B applied part Ordinary equipment
Class Ⅱ equipment Date of manufacture
Alternating current Manufacturer
Recovery Used indoor only
Keep dry Screw inside/ outside
Handle with care
Sterilizable up to the temperature specied
Temperature limitation for storage
Humidity limitation for storage

17
Atmospheric pressure for storage
Appliance compliance WEEE directive
Follow Instructions for Use
Authorised Representative in the EUROPEAN
COMMUNITY
18. Statement
All rights of modifying the product are reserved to the
manufacturer without further notice. The pictures are only for
reference. The final interpretation rights belong to GUILIN
WOODPECKER MEDICAL INSTRUMENT CO., LTD. The
industrial design, inner structure, etc, have claimed for several
patents by WOODPECKER, any copy or fake product must take
legal responsibilities.
19. EMC - Declaration of conformity
The device has been tested and homologated in accordance
with EN 60601-1-2 for EMC. This does not guarantee in any
way that this device will not be effected by electromagnetic
interference Avoid using the device in high electromagnetic
environment.

18
