01. INTRODUCTION
05
A
B
E
C
D
(A) Glasses
(B) Cans
(C) Transformer
(D) MicroDraught unit
(E) User manual
01. INTRODUCTION
Guinness_MicroDraught_Booklet_FA 6 19/10/21 12:40

01. INTRODUCTION
05 06
NOTE:
DO NOT POSITION UNIT IN DIRECT SUNLIGHT /
OUTDOORS AS THIS WILL AFFECT THE
TEMPERATURE READING (12)
(1) Handle
(2) Screen
(3) Eject Button
(4) Spout Assembly
(5) Spout Chamber Lid
(6) Spout Chamber
(7) Drip Tray
(8) Drip Tray Cover
(9) Clamps
(10) Power Input
(11) Power Lead
01. INTRODUCTION
1
2
3
45
6
7
8
9
10
11
12
Guinness_MicroDraught_Booklet_FA 7 19/10/21 12:40

02.
SET UP
Guinness_MicroDraught_Booklet_FA 8 19/10/21 12:40

02.
SET UP
Guinness_MicroDraught_Booklet_FA 9 19/10/21 12:40

11
C. Clamp and connect
Fix to counter and connect using the
power cable supplied. Ensure ON/
OFF switch is accessible.
B. Chilled can
Remove from outer packaging.
Chill cans in suitable fridge for
at least 24 hours.
A. Clean Guinness™ pint glass
IMPORTANT: All Guinness™ glasses
should be:
• Perfectly clean
• Dried naturally i.e. never use a drying cloth
• Stored upside down on plastic griding
• Used only for Guinness™
• Cleaned with other beer glasses only
Refrigerate
for 24 HRS
at 4-5°C
02. SET UP
02. SET UP
Counter
NOTE:
DO NOT POSITION
UNIT IN
DIRECT SUNLIGHT /
OUTDOORS
AS THIS WILL
AFFECT THE
TEMPERATURE
READING (12)
Guinness_MicroDraught_Booklet_FA 10 19/10/21 12:40

11 12
D. Ready to pourC. Clamp and connect
Fix to counter and connect using the
power cable supplied. Ensure ON/
OFF switch is accessible.
B. Chilled can
Remove from outer packaging.
Chill cans in suitable fridge for
at least 24 hours.
Refrigerate
for 24 HRS
at 4-5°C
02. SET UP
02. SET UP
Counter
NOTE:
DO NOT POSITION
UNIT IN
DIRECT SUNLIGHT /
OUTDOORS
AS THIS WILL
AFFECT THE
TEMPERATURE
READING (12)
Guinness_MicroDraught_Booklet_FA 11 19/10/21 12:40

13
2. Insert the can
Angle can and insert, push top to
click in place. Condensation may
impact operation, move can from
fridge to unit as quickly as possible.
1. Lift the lid
Use MicroDraught Can only.
Lift lid and hold to insert can.
02. SET UP
02. SET UP
Guinness_MicroDraught_Booklet_FA 12 19/10/21 12:40

13 14
4. Pull the handle
If can is within temperature range
unit will pour. Gently pull handle
backwards to start. Note: if can is out
of range refer to screen instructions
or troubleshooting guide.
3. First Pour, Glass angle
Place Glass at 45° with spout close
to the glass. Angle glass slowly
through first pour.
02. SET UP
02. SET UP
45°
Guinness_MicroDraught_Booklet_FA 13 19/10/21 12:40

15
04. POURING INSTRUCTIONS
04. POURING INSTRUCTIONS
6. Allow 1st pour settle
The settle will take approximately
60 Seconds. Refer to the screen for
progress.
5. Return the handle
When first pour is complete, return
handle to upright position. Place
Glass under the spout to settle.
Note: liquid may run on and drip into
glass – this is a normal operating
procedure.
60
sec
Guinness_MicroDraught_Booklet_FA 14 19/10/21 12:40

15 16
04. POURING INSTRUCTIONS
04. POURING INSTRUCTIONS
8. Stop at the top
IMPORTANT: hold handle forward
until head is level with the top
of the glass.
7. Second Pour, push and hold
When prompted on screen, push and
continue to hold the handle to top
up. Note: handle must be pushed
forward until head reaches top
of the Glass.
Guinness_MicroDraught_Booklet_FA 15 19/10/21 12:40

17
04. POURING INSTRUCTIONS
04. POURING INSTRUCTIONS
10. Serve pint
Unit will prompt that serve is ready...
Enjoy!
9. Allow dome to form
Liquid will continue to flow into
the Glass creating a beautifully
domed head.
17
Guinness_MicroDraught_Booklet_FA 16 19/10/21 12:40

17 18
04. POURING INSTRUCTIONS
04. POURING INSTRUCTIONS
12. Recycle
Cans are 100% recyclable aluminum.
11. Eject can
Press Eject button (3) and remove
can top first.
Note: can now has a small hole in
both the top and bottom. Carry
carefully to avoid spillage of any
residual liquid.
100%
Eject button (3)
17
Guinness_MicroDraught_Booklet_FA 17 19/10/21 12:40

19
05. CRADLE INSTALLATION
05. CRADLE INSTALLATION
1. Unit installation
Remove rubber grommets and
store safely.
A. Clean Guinness™ pint glass
IMPORTANT: All Guinness™ glasses
should be cleaned as follows:
• Perfectly clean
• Dried naturally i.e. never use a drying cloth
• Stored upside down on plastic griding
• Used only for Guinness™
• Cleaned with other beer glasses only
Guinness_MicroDraught_Booklet_FA 18 19/10/21 12:40

19 20
05. CRADLE INSTALLATION
05. CRADLE INSTALLATION
3. Insert Guinness™ Glass
Use Guinness™ pint glass in the
cradle at shown angle. Glass will
automatically tilt in unit in 1st pour.
2. Installation
Compress Cradle carefully into place
and press firmly into position on
MicroDraught unit.
Maintenance:
Clean Regularly with a
soft damp cloth. Do not
put cradle in Dishwasher.
Troubleshooting:
• Ensure fitted correctly
• Check hinges for debris
• Use only Guinness™ Pint
Glass
• Clean thoroughly
45°
Guinness_MicroDraught_Booklet_FA 19 19/10/21 12:40

21
06. MAINTENANCE
06. MAINTENANCE
A. Spout assembly maintenance cycle
Wash regularly before and after each use in hot water. If spout/chamber is
not cleaned regularly the operation of the unit will be impacted. Press eject
button (3) to confirm cleaning has been completed.
Spout Assembly
Chamber Base
DO NOT
DISASSEMBLE
SPOUT
ASSEMBLY
21
