GULFSIP G1S User manual

1
VoIPAnalog TelephoneAdapter
G-157Land LineConverter
User’s manual
Version1.1
CommunicationServices

2
Copyright
Copyright(C)2008GULFSIPCommunicationServices.Allrightsreserved.
Theproductsand programsdescribedinthisUser sManualarelicensedproductsof GULFSIPCommunication
Services,ThisUser sManualcontainsproprietaryinformationprotectedbycopyright,andthisUser sManualand
allaccompanying hardware,software, and documentation arecopyrighted.
Nopart ofthisUser sManualmaybecopied, photocopied,reproduced,translated, orreducedtoanyelectronic
mediumormachine-readableformbyanymeansbyelectronicormechanical.Includingphotocopying,recording,or
information storageandretrievalsystems, foranypurposeotherthanthepurchaser'spersonaluse, andwithout the
priorexpress writtenpermission ofGULFSIPCommunicationsServices.
Disclaimer
GULFSIPCommunicationServicesdoesnot warrant thatthehardwarewillworkproperlyinallenvironmentsand
applications, andmakesnowarrantyandrepresentation,eitherimpliedorexpressed, withrespecttothequality,
performance, merchantability,orfitness foraparticularpurpose.
GULFSIPhasmadeeveryefforttoensurethatthisUser sManualisaccurate;GULFSIPdisclaimsliabilityforany
inaccuraciesoromissionsthatmayhaveoccurred.
InformationinthisUser sManualissubjecttochangewithoutnoticeanddoesnotrepresent acommitment onthe
partof GULFSIP.GULFSIPassumesnoresponsibilityforanyinaccuraciesthat maybecontainedinthisUser s
Manual.GULFSIPmakesnocommitmenttoupdateorkeepcurrenttheinformationinthisUser sManual,and
reservestheright tomakeimprovementstothisUser sManualand/ortotheproductsdescribedinthisUser s
Manual, atanytimewithout notice.
Ifyoufindinformationinthismanualthatisincorrect,misleading,orincomplete, wewouldappreciateyour
commentsandsuggestions.
CEmarkWarning
Theisaclass Bdevice,Inadomesticenvironment,thisproduct maycauseradiointerference, inwhichcasethe
usermayberequiredtotakeadequatemeasures.
WEEE Warning
Toavoidthepotentialeffectson theenvironment andhumanhealthasaresultofthepresenceof
hazardoussubstancesinelectricalandelectronicequipment,end usersof electricalandelectronic
equipmentshouldunderstandthemeaning ofthecrossed-outwheeledbinsymbol. Donotdisposeof
WEEE asunsortedmunicipalwasteandhavetocollect suchWEEE separately.
Trademarks
TheGULFSIPlogoisatrademarkofGULFSIPCommunication Services.Thisdocumentationmayreferto
numeroushardwareand softwareproductsbytheirtradenames.Inmost,ifnotallcases,theirrespective
companiesclaimthesedesignationsastrademarksorregisteredtrademarks.

3
TABLE OFCONTENTS
Chapter1..............................................................................................................................5
Introduction.........................................................................................................................5
Overview...................................................................................................................................................5
PackageContent.......................................................................................................................................6
PhysicalDetails.........................................................................................................................................6
LEDDisplay&Button........................................................................................................................7
Chapter2Preparations&Installation...............................................................................9
PhysicalInstallationRequirement...........................................................................................................9
LAN IPaddress configurationviawebconfigurationinterface............................................................10
Chapter3NetworkService Configurations......................................................................17
Configuringand monitoringyourATAfrom webbrowser....................................................................17
Overviewonthewebinterface ofATA...............................................................................................17
Manipulationof ATAvia webbrowser...............................................................................................17
Chapter4VoIPTelephoneAdapterConfigurations.........................................................19
PhoneBook.......................................................................................................................................19
CallForward.....................................................................................................................................21
SNTPsettings....................................................................................................................................22
VolumeSetting..................................................................................................................................22
BlockSetting.....................................................................................................................................23
AutoAnswer(ForG-157)..................................................................................................................23
CallerIDsettings...............................................................................................................................24
DialPlanSettings..............................................................................................................................24
FlashTimeSetting.............................................................................................................................26
CallwaitingSettings..........................................................................................................................27
T.38(FAX)Settings...........................................................................................................................27
HotlineSettings................................................................................................................................28
AlarmSettings...................................................................................................................................29
LAN Settings.....................................................................................................................................29
PCSettings........................................................................................................................................30
DDNS Settings..................................................................................................................................31
VLAN Settings..................................................................................................................................32
DMZSettings....................................................................................................................................32
VirtualServer....................................................................................................................................33
PPTPSettings....................................................................................................................................34
Service DomainSettings....................................................................................................................34
PortSettings......................................................................................................................................35
Codec Settings...................................................................................................................................36

4
Codec IDSetting...............................................................................................................................36
DTMF Setting...................................................................................................................................37
RPortSettings....................................................................................................................................37
OtherSettings....................................................................................................................................38
STUNsettings...................................................................................................................................38
AutoConfiguration............................................................................................................................39
PTTSettings......................................................................................................................................39
Cancelwithouttotag.........................................................................................................................40
MACCIoneSetting...........................................................................................................................40
ToneSettings.....................................................................................................................................42
AdvancedSettings.............................................................................................................................42
SystemAuthority...............................................................................................................................43
Save&Reboot..................................................................................................................................44
FirmwareUpgrade.............................................................................................................................44
AutoUpgrade....................................................................................................................................45
ResettoDefault.................................................................................................................................46
Rebootwithoutsaving.......................................................................................................................47
AppendixAThemethodofoperationguide...........................................................................................47
CallTransfer......................................................................................................................................48
3-WayConference.............................................................................................................................48
CallWaiting......................................................................................................................................48
SwitchtheRealm (RegistrationProxyServer)....................................................................................48
AutoUpdatefirmwarebymanual(Keypad).......................................................................................49

5
Chapter1
Introduction
Overview
Based on yearsofVoIPmanufacturing experiences, GULFSIPCommunicationsServicesprovide a
varityof VoIPTelecommunication Solutionswhichmeet GULFSIPCustomersneeds.
Cost-effective, easy-to-install and simple-to-use, the GULFSIP G1S,G157 landlineconverter VoIP
Phone Adapters(“ATA”inthe following term)convertsstandardtelephonestoIP-based networks.
GULFSIP,the serviceproviderwhichofferuserstraditionaland enhanced telephonycommunication
servicesviathe existing broadband connection tothe Internet orcorporation network.
Withthe G-157 Land LineConverter, homeusersand companiesareabletosavethe installation
cost and extend theirpast investmentsintelephones, conferenceand speakerphones. The G-157
Land Line Converter can be the bridge between traditionalanalog systemsand IPnetworkwithan
extremelyaffordableinvestment.
The ATAincludestwoalternativelyEthernetinterfaceforInternet(PPPoE,DHCPorFixed IP), oroffice
LANconnection,whichwillhelpininstallation ofthe deviceat anynetworking invironment.
ProductFeatures
•Feature-richtelephone serviceoverhomeorofficeInternet/Intranetconnection
•Cost effective,fieldprovencompatibility, and stability
•Web-based and telephone keypad machine configuration
•Remotemachineadministration authentication
•Voicepromptformachine configurations
VoIPFeatures
•SIP2.0(RFC3261)compliant
•Peer-to-Peer/SIPproxycalls
•Voicecodecsupport: G.711,G.723.1,G.729A/G.729B
1

6
•T.38 FAXtransmission overIPnetwork
•Voiceprocessing: VoiceActiveDetection,DTMF detection/ generation,G.168 echo cancellation
(16mSec.),Comfort noisegeneration (CNG)
•Inband, out-of-band,and SIP-infoDTMFsupport
PackageContent
The contentsofyourproduct shouldcontainthe following items:
VoIPTelephone Adapter G-157 Land Line Converter
Poweradapter
QuickInstallation Guide
User sManualCD
RJ-11 cablex1
RJ-45 cablex1
Physical Details
The following figureillustratesthe front/rearpanelof ATA.
Respectivemodel/descriptionsareshownbelow:
G-157 Land Line Converter SIPAnalog Telephone Adapter
FrontPanelof G-157 Land Line Converter

7
Left/RightPanelof G-157 Land Line Converter
LEDDisplay&Button
1 PC RJ-45 connector,tomaintainthe existing network struc
ture,
connected directlytothe PC through straight CAT-5cable
2 LAN RJ-45 connector,forInternetaccess,connected di
rectlyto
Switch/Hub through straight CAT-5cable.
3 12VDC 12VDC Powerinput outlet
4 Reset Reset tothe factory defaultsetting
ë
Note Machine default PC Port ip is 192.168.123.1 Press RESET
button on rear panel over 5
seconds will resetthe VoIP Phone
Adapter to factory default value. (Except speed dial and
call forward settings)

8
LEDdisplay ofG-157 LandLineConverter
LEDIndicators Descriptions
STATUS The StatusLEDwillbeflashing when the machine isoperational
LNK/ACT OFF:the deviceisconnected toLANat 10Mb/s.
ON:the deviceisconnected toLANat 100Mb/s.
RING 1 OFF:the phone isidle.
ON:the phone isinuse(offhook).
Blinking:the phone isringing.
RING 2 OFF:the phone isidle.
ON:the phone isinuse(offhook).
Blinking:the phone isringing.

9
Chapter2
Preparations&Installation
Physical InstallationRequirement
Thischapterillustratesbasicinstallation of ATAanalog Phone Adapter((“ATA”inthe following term))
•Network cables. Usestandard10/100BaseT network (UTP) cableswithRJ45 connectors.
•TCP/IPprotocolmust be installed on allPCs.
ForInternet Access, an Internet Access account withanISP, and eitherof aDSLorCablemodem
AdministrationInterface
GULFSIP G-157 Land Line Converter providesGUI(Web based,GraphicalUserInterface)for
machine management and administration.
Web configurationaccess
Tostart G-157 Land Line Converter web configuration,you must haveone of theseweb browsers
installedon computerformanagement
•Microsoft Internet Explorer6.0.0orhigherwithJavasupport
Default PCinterfaceIPaddress ofG-157 Land Line Converter is 192.168.123.1. You maynow
open yourweb browser,and insert http://192.168.123.1 inthe address barofweb browsertologon
ATAweb configuration page.
2

10
ATAwillpromptforlogon username/password,pleaseenter: admin /gulfsip tocontinue machine
administration.
LANIPaddress configurationviawebconfigurationinterface forStaticIPor
PPPoE:
StaticIPconfigurationSettings:
Incaseyou found thatyourInternet connection (DSLRouter, cable,..)doesnot provide yourdevice
G-157 Land Line Converter an IPaddressfromit'sDHCPserver (automaticIPaddress), soyou
need toset astaticIPon the LANportofthe devicewhichisconnected tothe internetconnection.
HowtoinsurethatyourinternetrouterdoesnotprovideanIPaddress?
-Connect anetwork cablebetween the LANport and the Internet routerLANPort.
-Pleasepick up thehandset ofthe phone whichconnected toourdeviceinthe phone port,and dial
#126#, if you hearan IPaddress fromthe samerange whichyourinternetrouterprovide, forexample
192.168.x.x, soyourRouterworking on DHCPServermode.
Butifyou hear 0.0.0.0, or 169.254.x.x, soyourinternet routerdoesnot provide IPaddress, and you
need toset astaticIPmanually.
TosetaStaticIP, pleaseexecutethefollowing Steps:
-Connect anetwork Cablebetween yourPCand the PCportinourdevice G-157 Land Line
Converter, asshowninthe Figureabove.
You must be surethatyourPCisworking on the DHCPClientmode, toensurethat pleasedo the
following steps:
“Start ”=> “ControlPanel”=> "Network Connections"
ë
Note Please make sure
that yourPC is connectedto the PC port
in the G-157 Land Line Converter
to start access to the
device
.If you re not familiar with TCP/IP, please refer
to related chapter on user s manual CD or consult your
network administrator for proper network configurations.

11
1
Figure (5)
Executeyourweb browser, and insert the IPaddress (default: 192.168.123.1)of G-157 Land Line
Converter inthe adddress bar.Afterlogging on machine withusername/password(default:
admin/gulfsip), browseto “Network”--> “LANSettings”configuration menu:
1
2
3
4
5
6
7
8

12
Figure (6)
ParameterDescription
IPaddress LANIPaddress of ATA
Default:None
SubnetMask LANmaskof ATA
Default:None
DefaultGateway Gatewayof ATA
Default:None
1
IPaddress
SubnetMask
Default Gateway
DNS Serveraddress
2
3
4
5
6
7
8

13
Network settings via Keypad commands
The G-157 Land Line Converter support telephone keypad configurations, pleaseconnect analog
telephone set and refertothe following tableformachine network configurations.
!Note:
Pick up thehandsetandpress #190# thenhang up before youdo followingSettings:
IVRMenuChoiceMachineoperationParameter(s)Notes:
#111# Set DHCPclient NoneATAwillchangetoDHCP
Client
#112xxx*xxx*xxx*xxx
#
Setup StaticIP
Address
Usethe*(star)key
whenenteringadecimal
point.
DHCPwill bedisabledand
systemwillchangetothe
StaticIPtype.
#113xxx*xxx*xxx*xxx
# Set NetworkMask
Usethe*(star)key
whenenteringadecimal
point.
Mustset StaticIPfirst.
#114xxx*xxx*xxx*xxx
#
Set GatewayIP
Address
Usethe*(star)key
whenenteringadecimal
point.
Mustset StaticIPfirst.
#115xxx*xxx*xxx*xxx
#
Set PrimaryDNS
Server
Usethe*(star)key
whenenteringadecimal
point.
Mustset StaticIPfirst.
#190# Unlock None
Must unlocktheprotect
function beforeset up
networksettingsandATA
function viakeypad.
#191# Lock None
Thesystemwillbelock
and can tset upnetwork
settingsviakeypad.
#195# Reboot None Thesystemwillreboot
automatically.
#198# FactoryReset None
Thesystemwillbereset to
factorydefaultvalueand
reboot automatically.
0ToswitchPSTNmode None VIP-157only
Following keypad commandscan be used toset up the mainfunction .

14
IVRMenuChoiceMachineoperationParameter(s)Notes:
#138# Enablecallwaiting None EnableCallwaiting
#139# Disablecallwaiting None DisableCall waiting
#160# Updatefirmware None Updatefirmware
#510# BlindTransfer ATABlandTransfer
#511# Attendant Transfer ATAAttendantTransfer
#512# 3-waycalling ATA3-waycalling
#514# IPtransfertoPSTN ATAtransferIPcallto
PSTNside
#130+[1~8]# Set Codec
1:G.711u-Law, 2:G.711
a-Law, 3:G.723.1, 4:
G.729a,5:G.72616K,6:
G.72624K,7:G.726
32K,8: G.726 40K,
You can setthecodecyou
wanttothefirst priority.
#131+[00~15]# Set HandsetGain HandsetGainfrom0~15
You can settheHandset
gaintopropervalue,
default is10
#132+[00~12]# Set Handset Volume Handset Volumefrom
0~12
You can settheHandset
volumetopropervalue,
default is10
#135xxx*xxx*xxx*xxx
#
TFTPServerIP
Address
SetAutoconfigTFTP
ServerIPAddress
You can settheTFTP
ServerIPaddress
#136xxx*xxx*xxx*xxx
#
FTPServerIP
Address
SetAutoconfigFTP
ServerIPAddress
You can settheFTP
ServerIPaddress
#137+[0~2]# Autoconfigmode 0: Disable,1:TFTP
mode,2:FTPmode
You can settheAuto
configurationmode, 0:
Disable, 1:useTFTP
Server,2: userFTPServer
#145# Forwardfunction
disable Disableforwradfunciton
#146+Number# enableforwardtoFXS
Port
EanbleforwardtoFXS
Port
#147+Number# enableforwardto
FXOPort
EanbleforwardtoFXO
Port
#116# EnablePPTPfunction None EnablePPTPfunction
#117# DisablePPTP
function None DisablePPTPfunction
#118# EnableVLANfunction None EnableVLANfunction

15
#119# DisableVLAN
function None DisableVLANfunction
#134 +[numberofrings]
#
Set thenumberof
ringsbeforetheLine
portopen.
Tosetthenumberofrings
forAutoAnswer.
#127 +[portnumber]#
Set aSIPPort None TochangetheSIPPort.
Following keypad commandscan be used todisplaythenetwork settingsenabled on ATAvia voice
prompt withoutrequireingtodial#190# before thecommand:
IVRMenuChoiceMachineoperation Notes:
#120# Check PCIPAddress IVRwill announcethecurrentPC-portIP
address oftheATA.
#126# Check IPAddress oftheLAN
Port
IVRwill announcethecurrentIPaddress of
the G-157LandLineConverter LAN
port.
#121# Check networkconnection
Type
IVRwill announceif DHCPinenabledor
disabled.
#122# Check thePhoneNumber IVRwill announcecurrent enabledVoIP
number.
#123# Check NetworkMask IVRwill announcethecurrentnetworkmask
oftheATA.
#124# Check GatewayIPAddress IVRwill announcethecurrentgatewayIP
address oftheATA.
#125# Check PrimaryDNSServer
Setting
IVRwill announcethecurrentsettinginthe
PrimaryDNSfield.
#126# Check LANIPAddress IVRwill announcethecurrentLANportIP
address oftheATA.
#128# Check FirmwareVersionIVRwillannouncetheversionofthefirmware
runningon theATA.

16
Afterconfirming the modification youvedone, Pleaseclickon the Submit button toapplysettingsand
browseto “Save &Reboot”menu toreboot the machinetomakethe settingseffective.
Connection TypeDatarequired.
FixedIP Inmostcircumstances,itisnoneedtoconfiguretheDHCPsettings.
DHCPclinet TheISPwillassignIPAddress,andrelatedinformation.
PPPoE TheISPwillassignPPPoEusername/ passwordforInternetaccess,
SaveModificationtoFlashMemory
Most of the VoIProuterparameterswilltakeeffectiveaftermodifications, butitisjust temporary stored
on RAM only,it will disappearafteryourreboot orpoweroffthe VoIPPhone Adapter,tosavethe
parametersintoFlashROMand letit takeeffectiveforever, pleaseremembertopress the Save &
Reboot buttonafteryou modifythe parameters.
Please consult your ISP personnel toobtain proper PPPoE/IP
address related information, and input carefully.
If Internet connection cannot beestablished, please check
the physical connection or contact the ISPservice staff
for support information.
iHint
Please contact your Internet service provider to obtain the
Internet access type, andselect the propernetwork settings
in ATA to establish the network connections.
i
Hint

17
Chapter3
NetworkService Configurations
ConfiguringandmonitoringyourATAfromwebbrowser
The G-157 Land Line Converter integratesaweb-basedgraphicaluserinterfacethat can cover
mostconfigurationsand machine statusmonitoring.Viastandardweb browser,you can configureand
check machinestatusfromanywherearound the world.
Overview onthewebinterfaceofATA
Withweb graphicaluserinterface,you mayhave:
wMorecomprehensivesetting feelsthan traditional command line interface.
wProvidesuserinput datafields,check boxes, and forchanging machine configuration settings
wDisplaysmachine running configuration
Tostart G-157 Land Line Converter web configuration, youmust haveone ofthesewebbrowsers
installed on computerformanagement
wMicrosoft Internet Explorer6.0.0orhigherwithJavasupport
ManipulationofATAviawebbrowser
Logon ATAviawebbrowser
AfterTCP/IPconfigurationson yourPC, you maynowopen yourweb browser, and input
http://192.168.123.1 tologon Phone Adapterweb configuration page.
Phone Adapterwillpromptforlogon username/password: admin/gulfsip
3

18
G-157 LandLineConverter log inpage
Whenusersloginthe web page,userscan see the Phone Adaptersysteminformation likefirmware
version,company…etcinthismainpage.
G-157 LandLineConverter mainpage

19
Chapter4
VoIPTelephoneAdapterConfigurations
PhoneBook
ATAcan set up 140 recordsofPhone Book. Usercan dial the Name recordstomakecallsvia Phone
Book feature.
FieldDescription
PhoneBookPage The default isPage1. It canselect Page1 ~Page14 to
lookround Phone Bookrecords.
Phone The recordnumberfrom0~139,itcan set up 140
recordsintotal.
Name The nameof Phone Bookrecords,it onlycan input
4

20
numerals.
URL Fillinthe outgoing number(Line Number)orIP
address.
Select Toselect thisrecord.
Ifyouneed toadd aphone numberintothe Phone Booklist,you need toinputthe position, thename,
and the phone number(byURLtype). When you finished anewphonelist, just clickthe “Add Phone”
button.
Ifyouwant todeleteaphone number, youcan selectthephone numberyou want todeletethen click
“DeleteSelected”button.
Ifyouwant todeleteallphone numbers, you can click “DeleteAll”button.
ForExample:
Ex_1:
ATAhad added the abovephone numbers.Userpickup the handsetand dialthe “301”tomakethe
P2Pcall(301@192.168.1.2).
Ex_2:
Userspick up thehandset and dialthe “206”tomakethe Proxy call(17476433364).
Ex_3:
Userspick up thehandset and dialthe “202”tomakethe P2Pcall(192.168.1.2:5062).
