Gulfstream La Fleur User manual

PLEASE SAVE THIS MANUAL
FOR FUTURE REFERENCE
OWNER MANUAL
® ®
TM
Cleanjet , Paris, La Fleur Pedicure Spa Station , Gulfstream Inc are trademarks of Gulfstream Inc.
www.SpaSalon.us
Patent Pending

Table of Contents
Safety and Precautions
INSTALLATIONS
Attaching Stations
Jet Assembly
Plumbing Connections
1-2
Identifying Parts 3-4
6-7
8
Warranty & Service 12
5
Owner Manual
Operations and Use
Cleaning & Maintenance
9
10-11

SAFETY & PRECAUTION
1
Thank you for purchasing the Paris, La Fleur Pedicure Spa Station from Gulfstream Inc. Please carefully read the
instructions before installing the spa. Carefully follow the instructions, your spa will give you years of beauty and
service.
This product is to be connected to a branch circuit outlet protected by a Class A GROUND FAULT CIRCUIT
INTERRUPTER (GFCI), and the GFCI shall be tested regularly for continued protection and correct
operation. If a Class A GFCI protected outlet is not available, DO NOT USE THIS PRODUCT! Please
contact a licensed electrician for installation of a Class A GFCI according to local electric codes, or equivalent.
THIS PRODUCT IS FOR IN DOOR USE ONLY
DISCONNECT POWER SUPPLY CORD BEFORE SERVICING AND CLEANING
!!
Foot-spa must be installed by a licensed plumber and electrician in accordance with local codes. Plumbing and
Electrical Installation instructions must be adhered to in order for the warranty to be in effect and to insure the utmost
in safety. Chair and spa have a maximum seating capacity of 350 pounds.
The foot-spa is not intended to be stood in or used as a step. The portable foot-spa model is movable, standing in tub
or using as a step may cause severe damage to the unit as well as possible serious injury to the person.
BASIC PRECAUTIONS SHOULD ALWAYS BE OBSERVED, INCLUDING THE FOLLOWING:
1. Read and follow all instructions
2. DANGER. To reduce the risk of injury, do not permit children to use this unit unless they are supervised at all
times
3. Use this unit only for its intended use as described in this manual. Do not use attachments that are not
recommended by the manufacturer.
4. Never drop or insert any object into any opening.
5. Do not block jets during whirlpool operation.
6. The unit must be connected to an electrical supply circuit that is protected by a ground fault circuit interrupter.
7. The clean jet motor is magnetically driven and is insulated twice. Therefore it does not require to be bonded.
Save these instructions
1. Excessive water temperature is dangerous and should be checked BEFORE use.
2. Maximum temperature of the water should never exceed 100 degrees F.
3. Always enter and exit the Foot Spa slowly and carefully.
4. NEVER bring and / or operate any electrical devices into or near the Foot Spa.
If a crack occurs in the glass bowl, DO NOT manually handle the bowl unless the proper attire is worn.
Under no circumstances must the bowl be used by your customers as you can be held accountable for
any injury that may occur. Gulfstream is not liable for any injury that may occur.
Warning
!!
Warning
!!
Warning
!!

SAFETY & PRECAUTION
2
GROUNDING METHODS
Because this unit must be connected to a circuit with a ground-fault circuit interrupter (GFCI), DO NOT use a grounding
adapter.
The use of a grounding adapter is prohibited in Canada by Part I of the Canadian Electrical Code.
GROUNDING INSTRUCTIONS
This appliance must be plugged into an outlet equipped with a ground-fault circuit interrupter. The ground-fault interrupter
can be in the out-let shown in illustration A or in the circuit breaker (fuse) box. If your outlet or circuit breaker (fuse) box is not
equipped with a ground-fault interrupter, you must have your electrician install one.
In the event of an electrical short-circuit, the ground-fault circuit interrupter will turn off the electrical power to the unit
immediately, greatly reducing the likelihood of serious injury. This appliance is for use with a nominal 120-volt circuit and has
a grounding plug that looks like the plug illustrated in the sketch. The outlet must be properly installed and grounded in
compliance with all local codes and ordinances.
If it is necessary to use an extension cord, use only a three-wire extension cord that has a three-blade grounding plug and a
three-blade grounding plug and a three-slot receptacle that will accept the plug on the appliance. Replace or repair a
damaged cord.
OPERATION AND USE INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS.
1. IMPORTANT! At the end of the day, ALWAYS turn the main power OFF!
2. DANGER: To reduce the risk of injury, do not permit children to use this unit unless they are closely supervised
at all times.
3. CAUTION: This unit should not be used by persons with open wounds, cuts or sores on their feet or legs, or by
persons with poor circulation, or by persons with heart conditions. If in doubt, the client should consult with his
or her physician.
4. Use this unit only for its intended use as described in this manual. Do not use attachments not recommended
by the manufacturer
5. Do no operate with a damaged cord or plug. If unit is malfunctions or is damaged in any
manner, contact an authorized service representative for examination or repair.
6. Never drop or insert any objects into any opening.
7. Do not block jets during pedicure operation.
8. Water temperature should be checked before use. Water temperature should never exceed 100 degrees
Fahrenheit.
9. Never bring any electrical devices into the unit or operate electrical devices near it.
10. The unit must be connected to a supply circuit that is protected by a ground-fault circuit interrupter (GFCI).
11. Connect the unit only to a properly grounded outlet. See grounding instructions.
12. Close supervision is necessary when the unit is used by, on or near children or invalids.
COMPLIANCE WITH LOCAL CODES OR
INSPECTIONS IS THE RESPONSIBILITY OF
THE PURCHASER AND/OR INSTALLER

IDENTIFY YOUR FOOT-SPA
3
1
2
3
4
5678
10
1. Back Cushion with Vibration Massage
2. Armrest Cushion
3. Seat Cushion
4. Pull-out Hand Spray & Water Control
5. Drain Control
6. Glass Bowl
7. Drain Control
8. Non-slip Spa Step
9. Accessories Storage
10. Pull-out Manicure Tray
11. Drain
12. Water Control
13. Adjustable Footrest
9
13
9
1
2
3
4
5678 9
10
Front
Back
Front
Back
11
12
11
12
La Fleur Pedicure Spa Station
Paris Pedicure Spa Station

4
IDENTIFY YOUR FOOT-SPA
Paris Pedicure Spa
La Fleur Pedicure Spa
60’’
5’5’
28’’
10’’
60’’
46’’
28.5’’
Curved
14’’
32’’
24’’
16’’
5’’
32’’
24’’
16’’
5’’
36’’
36’’
KickPlate = 4’’

5
INSTALLATIONS
1. Open the front panel by removing these screws then aligning spa stations and step side by side.
2. Secure the spa stations and step with screws on the pre-drilled holes located on the sides.
3. Attach back and seat cushion onto the velcro.
Use the same steps for Paris model
Attaching Spa Stations (Paris / La Fleur Pedicure Spa Models)
Screws
Spa Step
Front Panel
La Fleur Pedicure Spa Model
Paris Pedicure Spa Model
Seat Cushions
Use the same steps as shown above

6
INSTALLATIONS
Cleanjet Unit Removal
Plate & Anchors located on tub/bowl wall
Impeller Housing
Top Plate
Wall
Ball
Washer
Anchor Pins
To remove the jet unit from tub/bowl.
Gently pull out the jet unit from the anchor pins
To remove the jet unit components.
Turn the top plate counter-clockwise in the arrow direction
Jet Unit Components
To install the jet unit. Assemble all jet unit components in order as before removal, snap the jet unit onto the anchor pins located on tub/bowl
wall securely.
Note: All jet unit components must be assembled in sequence of order to avoid malfunction.
Screws
Base Plate & Anchors located inside tub/bowl
Wall
Anchor Pins
Screws
Option 1:
Remove the jet unit and screws from the base plate in Fig.1. Pull out the U-shape clamp and motor behind the tub/bowl wall as shown in Fig.2
Option 2:
Remove the plastic cap lock at the end of the U-shape clamp by turning counter-clockwise. Remove the U-shape clamp and push the motor and base
plate forward inside the tub/bowl as shown in Fig.2
Fig.1
Removing Base Plate and Motor
Clamp to hold
the motor and
seal the cap to tub
Fig.2 Plastic Cap Lock
Motor
Tub/Bowl
Jet motor components are located behind the tub/bowl wall
Disconnect the foot-spa unit from any electrical source before
Disassemble the jet unit. All surface must be dry. Some jet
Components may contain sharp object and very hot after usage.
Warning
!!

7
INSTALLATIONS
Place the plastic liner firmly inside the glass bowl as shown
in the Fig.1
Align the impeller unit onto the anchor pins and snap
it onto the base plate as shown in Fig.2
To remove, gently pull out the impeller unit as shown in Fig.3
from the base plate and pull up the plastic liner.
To avoid risk of infection disease, discard the liner after
each use
Fig.2
Plastic Liner perforated
by the pins
Thin Plastic Liner
Impeller Unit
Plastic Liner
Hole in the heavy plastic liner
Heavy plastic liner
Piece of thin plastic sealed
to the heavy plastic liner
Base Plate fixed to motor behind
Fig.1
Glass Bowl
Fig.3
Poly Liner Installation (La Fleur Pedicure Spa Station Only)
Anchor Pins

INSTALLATIONS 8
1. Discharge pump may be connected to an existing sink drain or floor drain. It can also pump up to 7 ft high, but this
will increase the length of the drain time. The drain connection is at the rear of the unit by a 3/4” fitting.
2. Gravity drain uses a standard gravity drain. A floor drain is recommended. Connection via a P-Trap is supplied.
3. Hot and cold water supply connections are located at the rear of the unit (½” fittings).
Please be advised that the hot and cold water supply lines are not fitted with optional back flow Preventers unless
ordered at initial sale.
4. Have a qualified licensed electrician to install the wiring according to local codes.
The Cleanjets are 1/10 hp, 120V, 1.2 AMP 60OHZ. A 15 amp GFI protected circuit must be used to supply power to
the unit. The roller back massage chair uses a 115V supply.
5. Spa base should be anchored securely to the floor. The base may be anchored through
the opening in the back of the base wherever access is convenient for the installer.
FAILURE TO ANCHOR THE BASE MAY RESULT IN PERSONAL INJURY OR DAMAGE TO THE UNIT.
DAMAGE AS A RESULT WILL VOID THE WARRANTY.
Plumbing Connections
Remove the seat cushion for drainage & plumbing connections
Seat Cushion
Back Station View
Hot & Cold ½” Fitting
P-Trap
1 1/4’’ ABS Pipe
Not provided
For La Fleur Pedicure Spa Model follow the same steps as shown
Paris Model
