Gulfstream La Fleur User manual

© Design and Specifications are subject to change without notice
2010 All rights reserved.
PLEASE SAVE THIS MANUAL
FOR FUTURE REFERENCE
OWNER MANUAL
® ®
TM
Cleanjet , Paris, La Fleur Pedicure Spa Station ,SpaSalonUSInc are trademarks of SSU Inc.

Table of Contents
Safety and Precautions
INSTALLATIONS
Attaching Stations
Jet Assembly
Plumbing Connections
1-2
Identifying Parts 3-4
6-8
9
Warranty & Service 12
5
Owner Manual
Operations and Use
Cleaning & Maintenance
10
11

SAFETY & PRECAUTION
1
Thank you for purchasing the Paris, La Fleur Pedicure Spa Station from Gulfstream Inc. Please carefully read the
instructions before installing the spa. Carefully follow the instructions, your spa will give you years of beauty and
service.
This product is to be connected to a branch circuit outlet protected by a Class A GROUND FAULT CIRCUIT
INTERRUPTER (GFCI), and the GFCI shall be tested regularly for continued protection and correct
operation. If a Class A GFCI protected outlet is not available, DO NOT USE THIS PRODUCT! Please
contact a licensed electrician for installation of a Class A GFCI according to local electric codes, or equivalent.
THIS PRODUCT IS FOR IN DOOR USE ONLY
DISCONNECT POWER SUPPLY CORD BEFORE SERVICING AND CLEANING
!!
Foot-spa must be installed by a licensed plumber and electrician in accordance with local codes. Plumbing and
Electrical Installation instructions must be adhered to in order for the warranty to be in effect and to insure the utmost
in safety. Chair and spa have a maximum seating capacity of 350 pounds.
The foot-spa is not intended to be stood in or used as a step. The portable foot-spa model is movable, standing in tub
or using as a step may cause severe damage to the unit as well as possible serious injury to the person.
BASIC PRECAUTIONS SHOULD ALWAYS BE OBSERVED, INCLUDING THE FOLLOWING:
1. Read and follow all instructions
2. DANGER. To reduce the risk of injury, do not permit children to use this unit unless they are supervised at all
times
3. Use this unit only for its intended use as described in this manual. Do not use attachments that are not
recommended by the manufacturer.
4. Never drop or insert any object into any opening.
5. Do not block jets during whirlpool operation.
6. The unit must be connected to an electrical supply circuit that is protected by a ground fault circuit interrupter.
7. The clean jet motor is magnetically driven and is insulated twice. Therefore it does not require to be bonded.
Save these instructions
1. Excessive water temperature is dangerous and should be checked BEFORE use.
2. Maximum temperature of the water should never exceed 100 degrees F.
3. Always enter and exit the Foot Spa slowly and carefully.
4. NEVER bring and / or operate any electrical devices into or near the Foot Spa.
If a crack occurs in the glass bowl, DO NOT manually handle the bowl unless the proper attire is worn.
Under no circumstances must the bowl be used by your customers as you can be held accountable for
any injury that may occur. Gulfstream is not liable for any injury that may occur.
Warning
!!
Warning
!!
Warning
!!

SAFETY & PRECAUTION
2
GROUNDING METHODS
Because this unit must be connected to a circuit with a ground-fault circuit interrupter (GFCI), DO NOT use a grounding
adapter.
The use of a grounding adapter is prohibited in Canada by Part I of the Canadian Electrical Code.
GROUNDING INSTRUCTIONS
This appliance must be plugged into an outlet equipped with a ground-fault circuit interrupter. The ground-fault interrupter
can be in the out-let shown in illustration A or in the circuit breaker (fuse) box. If your outlet or circuit breaker (fuse) box is not
equipped with a ground-fault interrupter, you must have your electrician install one.
In the event of an electrical short-circuit, the ground-fault circuit interrupter will turn off the electrical power to the unit
immediately, greatly reducing the likelihood of serious injury. This appliance is for use with a nominal 120-volt circuit and has
a grounding plug that looks like the plug illustrated in the sketch. The outlet must be properly installed and grounded in
compliance with all local codes and ordinances.
If it is necessary to use an extension cord, use only a three-wire extension cord that has a three-blade grounding plug and a
three-blade grounding plug and a three-slot receptacle that will accept the plug on the appliance. Replace or repair a
damaged cord.
OPERATION AND USE INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS.
1. IMPORTANT! At the end of the day, ALWAYS turn the main power OFF!
2. DANGER: To reduce the risk of injury, do not permit children to use this unit unless they are closely supervised
at all times.
3. CAUTION: This unit should not be used by persons with open wounds, cuts or sores on their feet or legs, or by
persons with poor circulation, or by persons with heart conditions. If in doubt, the client should consult with his
or her physician.
4. Use this unit only for its intended use as described in this manual. Do not use attachments not recommended
by the manufacturer
5. Do no operate with a damaged cord or plug. If unit is malfunctions or is damaged in any
manner, contact an authorized service representative for examination or repair.
6. Never drop or insert any objects into any opening.
7. Do not block jets during pedicure operation.
8. Water temperature should be checked before use. Water temperature should never exceed 100 degrees
Fahrenheit.
9. Never bring any electrical devices into the unit or operate electrical devices near it.
10. The unit must be connected to a supply circuit that is protected by a ground-fault circuit interrupter (GFCI).
11. Connect the unit only to a properly grounded outlet. See grounding instructions.
12. Close supervision is necessary when the unit is used by, on or near children or invalids.
COMPLIANCE WITH LOCAL CODES OR
INSPECTIONS IS THE RESPONSIBILITY OF
THE PURCHASER AND/OR INSTALLER

IDENTIFY YOUR FOOT-SPA
3
1
2
3
4
5678
10
1. Back Cushion with Vibration Massage
2. Armrest Cushion
3. Seat Cushion
4. Pull-out Hand Spray & Water Control
5. Drain Control
6. Glass Bowl
7. Drain Control
8. Non-slip Spa Step
9. Accessories Storage
10. Pull-out Manicure Tray
11. Drain
12. Water Control
13. Adjustable Footrest
9
13
9
1
2
3
4
5678 9
10
Front
Back
Front
Back
11
12
11
12
La Fleur Pedicure Spa Station
Paris Pedicure Spa Station

4
IDENTIFY YOUR FOOT-SPA
Paris Pedicure Spa
La Fleur Pedicure Spa
60’’
5 ’5’
28’’
10’’
60’’
46’’
28.5’’
Curved
14’’
32’’
24’’
16’’
5’’
32’’
24’’
16’’
5’’
36’’
36’’
KickPlate = 4’’

5
INSTALLATIONS
1. Open the front panel by removing these screws then aligning spa stations and step side by side.
2. Secure the spa stations and step with screws on the pre-drilled holes located on the sides.
3. Attach back and seat cushion onto the velcro.
Use the same steps for Paris model
Attaching Spa Stations (Paris / La Fleur Pedicure Spa Models)
Screws
Spa Step
Front Panel
La Fleur Pedicure Spa Model
Paris Pedicure Spa Model
Seat Cushions
Use the same steps as shown above

6
INSTALLATIONS
Cleanjet Installation
Align fingers to the opening, turn counter-clockwise
and pull in the arrow direction to remove jet cover
Align jet cover on the jet housing then turn clockwise
to install jet cover
1
2
2
1
The Opening
Cleanjet Max Components
Suction Control Screen
(Optional)
Jet Cover Impeller Jet Motor & Housing
Plate & Anchors (Cleanjet Max only)

7
INSTALLATIONS
Anchor
Jet Cover and Impeller
Cleanjet Max Installation
Snap the jet cover and impeller onto the anchors located on the plate
in the direction of arrow as shown. Make sure the jet snapped securely
on the plate.
To remove, simply pull the jet cover and impeller from the anchors
t sFoo re t
I s den i
Liner
Tub Wall
Opening
Handle
Jet
Lock
Cleanjet Max SL Installation
Place the poly liner and drain plug firmly onto the tub, hold the handle and push into the opening located under the footrest in the direction
of the arrow until it is secured. Make certain that the jet is snapped firmly on the tub wall and the handle is secured to the opening.
To remove, simply pull out the handle with jet cover and impeller from the opening
Pull out the lock as shown to remove cover and impeller from the handle

8
INSTALLATIONS
Tub Wall
Under Seat Compartment
1
2
Cap Head
Aluminum Clamp
Motor
Jet Cover & Impeller
1
Turn the Cap Head counter-clockwise to remove, carefully pull the metal clamp and the jet motor backward
There may be water sealant between the Motor and Tub wall
2
Carefully detach the Jet Cover and Impeller from Tub Wall
To assemble the jet unit, install in the reverse steps above. You may have to apply some water sealant
between the Motor and The Tub wall
Cleanjet Max Assembly
Plate located inside the bowl
(Cleanjet Max only)
To remove the jet unit follow the steps below
Jet Handle (Cleanjet Max SL only)
Jet motor components are located behind the tub/bowl wall
Disconnect the foot-spa unit from any electrical source before
Disassemble the jet unit. All surface must be dry. Some jet
Components may contain sharp object and very hot after usage.
Warning
!!

INSTALLATIONS 9
1. Discharge pump may be connected to an existing sink drain or floor drain. It can also pump up to 7 ft high, but this
will increase the length of the drain time. The drain connection is at the rear of the unit by a 3/4” fitting.
2. Gravity drain uses a standard gravity drain. A floor drain is recommended. Connection via a P-Trap is supplied.
3. Hot and cold water supply connections are located at the rear of the unit (½” fittings).
Please be advised that the hot and cold water supply lines are not fitted with optional back flow Preventers unless
ordered at initial sale.
4. Have a qualified licensed electrician to install the wiring according to local codes.
The Cleanjets are 1/10 hp, 120V, 1.2 AMP 60OHZ. A 15 amp GFI protected circuit must be used to supply power to
the unit. The roller back massage chair uses a 115V supply.
5. Spa base should be anchored securely to the floor. The base may be anchored through
the opening in the back of the base wherever access is convenient for the installer.
FAILURE TO ANCHOR THE BASE MAY RESULT IN PERSONAL INJURY OR DAMAGE TO THE UNIT.
DAMAGE AS A RESULT WILL VOID THE WARRANTY.
Plumbing Connections
Remove the seat cushion for drainage & plumbing connections
Seat Cushion
Back Station View
Hot & Cold ½” Fitting
P-Trap
1 1/4’’ ABS Pipe
Not provided
For La Fleur Pedicure Spa Model follow the same steps as shown
Paris Model

1. To fill water:
The foot-spa is provided with a single hot and cold mixing hand spray located to the right of glass bowl.
This is a pressure balance valve that requires you to lift the handle to start the water flow and to adjust to the
temperature that is desired. The clean jet motor must be completely submerged in water.
CAUTION: DO NOT USE FOAMING, SUDSING OR MINERAL OIL BASED ADDITIVES IN THE WATER.
2. To start whirlpool:
Press the button that is situated next to the water fill lever. This will start your Clean Jet motor. You may stop
the whirlpool function at any time by pressing the button again.
3. The foot-spa is equipped with a hand held sprayer. To activate the hand shower, pull the hand shower
from the receptacle and depress the thumb control on the sprayer handle. This will turn on the water. When you
release pressure on the thumb control this will turn the water off.
4. To drain whirlpool tub:
The spa is equipped with a built in optional discharge pump. Open the drain plug by turning the control knob as
shown. Press discharge pump timer button as shown (pump will run for approx. 2 min.) Average time for drain 1
minute.
5. Seat cushion is equipped with vibration massage. Please consult with the massage manual for operations
13
Control Panel (Paris Pedicure / La Fleur Pedicure Bench Models)
Jet (On/Off) Drain Control Pull-out Hand Spray with Water Control
OPERATIONS & USE 10
BASIC PRECAUTIONS SHOULD ALWAYS BE OBSERVED, INCLUDING THE FOLLOWING:
1. Read and follow all instructions
2. DANGER. To reduce the risk of injury, do not permit children to use this unit unless they are supervised at all
times
3. Use this unit only for its intended use as described in this manual. Do not use attachments that are not
recommended by the manufacturer.
4. Never drop or insert any object into any opening.
5. Do not block jets during whirlpool operation.
6. The unit must be connected to an electrical supply circuit that is protected by a ground fault circuit interrupter.
7. The clean jet motor is magnetically driven and is insulated twice. Therefore it does not require to be bonded.
Save these instructions
Shown with La Fleur model

Gulfstream Inc. highly recommends the following cleaning regimen. You should always contact your local governing
agency for their specific cleaning and disinfecting requirements and regulations for pedicure spas. For your clients
safety, always use the regulations as a minimum standard for cleaning and disinfecting. Combining your states
standards with the regimen listed below will provide your clients with a safe and healthy pedicure spa environment
experience.
Routine maintenance:
Powdered cleansers or abrasives are NOT RECOMMENDED. A clean towel or sponge, are all that are usually
needed. A soft bristled brush may be used when excessive residue is present. Use a mild soap and water solution to
clean the upholstery, but do not over wet. Wipe dry with a clean towel. No internal maintenance of the spa
components is necessary. Remove clean jet caps and spray with disinfectant after each use. For extra protection, our
recommendation is that the system be flushed daily or weekly depending on use. To flush the clean jet system fill spa
with hot water to just above the jets. Add disinfectant. Run whirlpool for 15 minutes, drain and then wipe dry with
clean soft cloth.
NOTE:
Cleaning or sanitizing is NOT disinfecting. According to the Centers for Disease Control and Prevention (CDC), and
the US Environmental Protection Agency (EPA), disinfecting occurs only when there is a reduction of pathogenic
microbes at 99.999%. Sanitizing is only a reduction of 99.9%. Cleaning of whirlpool pedicure spas requires surfactant
and chelating detergents that are low-foaming and have the ability to remove body oils, organic oil additives, mineral
oil, skin cells, nail clippings etc that can accumulate both in the basin and the jets which may become a fertile area for
micro organisms to grow.
The use of oil based products can build up in the whirlpool system causing clogging in the jets. Adherence to the
above cleaning will minimize build up. Gulfstream does not recommend the use of mineral oil based products.
TESTING/FLUSHING FOOT SPA
After foot spa has been installed, fill tub with water just above the jets. Carefully check for leaks at drain and over
flow. After checking underside for leaks turn on system by pushing whirlpool button and watch for leaks as water
circulates. Let tub run full cycle. Open drain plug for water discharge.
CLEANING & MAINTENANCE 11
Please refer the diagrams to remove jet covers for cleaning

WARRANTY & SERVICE 12
Gulfstream warrants to the original purchaser that the new pedicure spa will be free from defect during the Standard Warranty Period
(listed below). The shipping date and the uniquely-coded Serial Number on the back of each spa chair will justify the start of the
warranty period for the product. The warranty is null and void if the pedicure spa is taken from its initial place of installation, or it is not
installed in accordance with federal, state or local codes and ordinances. Also, this warranty does not apply if the pedicure spa has been
subject to misapplication, improper installation or maintenance, negligence, improper cleaning or other circumstances beyond
Gulfstream's control.
1. Limited Three(3) Years warranty on Spa Shell.
2. Limited One(1) Year warranty on the Whirlpool Pump.
3. Limited One(1) Year warranty on the Clean Jet.
4. Limited One(1) Year warranty on the Glass Bowl.
5. Limited One(1) Year Parts-Only warranty which covers the Hydraulic System, Discharge Pump, Massage System and All
Electrical Components.
6. Gulfstream will pay standard shipping charges on all replacement parts during the first 90 days of the stated Warranty Period.
After 90 days the consumer is responsible for all labor and shipping costs incurred.
Warranty
1. Damage to pump parts and/or motor parts due to obstruction in plumbing lines etc.
2. Staining, fading or discoloration of plastic surfaces due to exposure and/or the use of harmful cleaning agents or
chemicals.
3. Staining, fading or discoloration caused by improper or poor water additives not related to the maintenance of
proper water are not covered by this warranty.
4. Staining, fading or discoloration of the seat, armrests or footrests.
5. Freight damage, misuse, neglect, accident, natural disaster and abuse.
6. Unauthorized repairs.
Exclusions
No dealer or other person has any authority to bind Gulfstream Inc. to changes or additions to this warranty or its products.
Accordingly, Gulfstream Inc. Is not responsible for such warranties or representations.
1. The Dealer shall forward all warranty-related matters to our Customer Service Department.
2. Serial Numbers and Original Invoice must accompany all warranty claims.
3. Customers are responsible for shipping defective parts back to Gulfstream. These parts must be packaged
correctly in order to protect against any further damage.
4. All parts are to be shipped by UPS Ground Service, average 2-5 days.
5. All defective parts must be shipped back to Gulfstream within 30 days of receiving the new replacement parts or
warranty will be void.
6. Any warranty claim that cannot be determined over the phone, the customer must send photos and original
invoice directly to Gulfstream before any repairs can be performed.
7. Any service performed on the product without Gulfstreams authorization will also void the Warranty.
8. Each service call from the customer will be assigned a Claim Number. The Claim Number will stay open until the
problem is resolved.
Service
