Gurari GCH I 331 PRIME Reference manual

Cooker hood
Manual for installation and
use for model
GCH I 331
PRIME

Dear customer,
we always strive to deliver you faultless products. Should this product not be in perfect condition
upon receipt, please contact us immediately.
Before you start installing and / or using this product, please read this instruction carefully and be
sure to follow the instructions given. Check the delivered parts for completeness and integrity.
Should, despite our efforts, any parts be defective or missing, please contact us. You will receive
immediate replacement in this case.
Never use defective parts!
This cooker hood has been constructed for installation and appropriate use in private households.
Incorrect installation can damage the appliance and / or your kitchen, as well as it could lead to
serious injuries. Do not use parts of the cooker hood or the hood itself for purposes that are not
explicitly listed in the manual. No liability is taken over for accidents or damage, due to incorrect
installation, use of defective parts or incorrect use of delivered utensils.
The supplied mounting parts are not suitable for all ceilings. If you are not sure which material your
ceiling consists of and whether it has sufficient load-bearing capacity,be sure to check with an expert.
You may need special screws and dowels that are not included.
If you do not understand this manual or are concerned about your safety, we recommend the
commissioning of an experienced installer for the assembly. Due to the weight and the dimensions of
this product we recommend to carry out the installation with 2 persons in any case.
We wish you a lot of joy with your new extractor hood.
General information
Pay attention to the environmentally friendly disposal of the packaging.
Please read this manual carefully before use. It contains important information about your safety,
installation, commissioning, cleaning and care of your cooker hood.
Keep the instructions in a safe place if you need to read them again or need further hints and help in
use.
Please to not start a damaged device.
The device is only suitable for use in private households and not in gastronomy.
Assembly and operation may only be carried out in accordance with the instructions in this manual.
Our devices comply with the legal requirements for electrical household appliances and may therefore
only be repaired by authorized personnel. Besides the dangers involved by inappropriate treatment,
we strongly point out, that improper intervention void the warranty.
Delivery content
- hood body incl. LED lights / motor / control / grease filter /carbon filter
- Remote control
- Mounting material
- Drilling template
- Operation manual

Technical specifications
power
- power consumption in watts 226W
- Of which lighting (LED) 2x3W
- Voltage in volts 220-240V
- Fan volume max. 1000m³/h
Dimensions
- Height in cm 28,9cm
- Width in cm 45cm
- Depth in cm 45cm
- Net weight in kg 13,4kg
specifications
- Connection with safety plug
- 4-level control
- LED lighting (2x3W)
- grease filter (dishwasher-safe)
- Suitable for recirculation
safety instructions
power supply
The connection is made via a fixed cable with earthing contact plug.
In the case of a required permanent connection, the hood may only be installed by an electrician,
registered at the responsible electricity supply authority.
On the installation side, a disconnecting device (this includes fuses, contactors and circuit breaker
acc. VDE 0730, §7, Part 1) has to be used.
minimum distances
Distance to an electric hob
From the electric cooking area to the lower edge of the hood a
minimum distance of 600mm must be maintained.
Distance to the gas hob
Between gas hobs (upper edge of pot carrier) and lower edge of the
hood a minimum distance of 700mm should comply.
Other notes
Please take care, that hotplates in operation are always covered, so the device will not be damaged
by excessive heat.
When deep-frying under an extractor hood, the appliance used for frying has to be supervised at all
time during operation.
Oils contained in deep fryers may self-ignite due to overheating. Using old and dirty oil can lead to
this even more easily.
We point out that overheating can cause a fire. Furthermore, we point out expressly that flambé
under the hood is not allowed.

For all work on the cooker hood, even when changing the bulb, the hood has to be de-energized (turn
off circuit breaker or remove the screw fuse from the socket). It is also important to follow the filter
change and cleaning intervals.
If ignored, there is an acute fire hazard due to grease deposits!
Energy-saving tips
Preparation, warming and keeping food warm should always be done in pots or pans with closed lids.
The appliance should be switched off immediately after cooking or, if available, the time-delayed
shutdown be used.
The lighting of the appliance should be switched off after the end of cooking.
Pot sizes should be adapted to the diameter of the cooking zones used.
Use the highest motor speed of the unit only at a high concentration of cooking fumes.
To increase the efficiency of the device, regularly clean the grease filters.
Carbon filters (when used in recirculation mode) should be replaced regularly according to the
manufacturer's specifications.
Parts of the hood
The extractor hood consists of the following parts
1 –Fixing Brackets
2 –Fixing Brackets cover
3 –Electro cable grounded
4 –Metal ropes
5 –Frame
6 –Control panel
7 –Aluminium filter
8 –Lighting

Dimension Drawings
Assembly

1. examination
Before starting the actual installation, the device should be checked. In addition to the control of
externally recognizable damage, a function check has to be done. Take out the device from the
packing, get rid of all packing materials and put the device with the back on the floor / table. After
connecting to a power supply, the lighting as well as the function of each stage should be checked.
Please take care that exhaust outlet is open through check.
2. Installation of the hood
Pass the metal ropes through the holes of the fixing covers and mounting brackets (diagram 1).
Strain the clamps on the metal ropes and make a knot (diagram 2, 3, 4,5).
Tighten the clamps on the metal ropes as far as they will go (diagram 6).
Drill 6 holes in the ceiling for M Ø12x60mm anchors..
Raise the mounting brackets to the ceiling. Tighten the wedge anchors (diagram 7,8).
Lift the bracket cover to the joint with the mounting brackets. Secure the bracket cover with 4 M4x12
screws (diagram 9)
Check the reliability of an extracts mounting.
This completes the assembly.
Usage
Inserting and changing the carbon filter
For recirculation mode we recommend the use of a carbon filter,
which frees the cooking fumes from the smell. The carbon filter
consists of two charcoal-filled cassettes, mounted left and right to
the suction opening of the engine. For mounting please check
picture.
To mount the carbon filter, please take the following steps:
1. First remove the metal grease filters
2. Place the charcoal filter on both sides of the motor in front of the
suction openings
3. In the middle of the filter is a receptacle and on the fan a suitable insert
4. If the filter is seated correctly, you can fix it with a small twisting motion
5. Then reinsert the grease filter
The matching carbon filter for this model is called GE15
Metal grease filter
The aforementioned grease filters are in front of the engine and ensure the absorption of greasy
ingredients from the kitchen haze. The cleaning can be done in the dishwasher. It is recommended to
do this all 14 days (at least once a month). Too long cleaning intervals lead to a blockage of the filter

and thus reduced power.
Cleaning in the dishwasher
The grease filters of your hood are dishwasher safe (55 ° C). However, light discoloration of the metal
can arise. These have no influence on the function of the grease filter and are not considered a
reason for complaint. Put the filters loosely in the dishwasher. Do not bend or pinch them. NOTE: Do
not clean very dirty grease filters together with other dishes.
Cleaning by hand
If cleaned manually, first soak the grease filter extensively in hot rinse liquor, then brush well and
above all, rinse well with clean water. After that drain well. Avoid use of aggressive, acidic or alkaline
detergent. For very stubborn dirt you can resort to commercially available degreaser sprays.
Usage
Extractor hoods with a touch switch have 4 ventilation speeds. Depending on the volume of
evaporation when cooking, you can select low, middle or high ventilation level.
The touch switch of the operation modes of the motor and lighting lams is located on the
decorative glass of the extractor hood:
0- Infrared sensor
1- Light on/off
2- Fan on/off
3- Operating mode indicator
4- Speed increase
5- Speed decrease
Waiting mode turns on as soon as the extractor hood is connected to electricity.
You can select motor speed, switch lamps and activate function “fan timer” with the help of switch
just touching the relevant symbol-button. Display (3) reflects the number of selected speed or time.
To switch the fan on touch the button 2, 4 or 5.
To switch the fan off, touch the button 2.
While switching on the fan will work with the speed, selected before switching off.

The speed is shown on the display.
To increase speed, touch the button 4.
To decrease speed, touch the button 5.
To switch the light on/off touch the button 1.
Turbo level
When the hood is switched on at the 4th speed (turbo mode), after 5 minutes of work the hood
automatically switched to the 3rd speed.
Timer / off timer
To activate timer simultaneously touch the buttons 4 and 5 while switching the fan on. The timer time
will be flashing and the timer time will be shown on the display for 10 seconds.
To change the timer work time, touch the button 4 (to increase) or 5 (to decrease) while the display
is flashing.
The timer time is changed from 15 to 90 minutes.
The number of selected speed will appear on the display in 10 seconds.
To switch off the timer change the speed, or turn off the fan.
Remote control
The remote control controls the corresponding functions. Buttons 4 and 5, as well as button 1 turn on
the hood. Button 1 turns off the hood during operation. Button 2 turns the light on or off. With button
6 one can activate the timer and set it as described above. Button 3 does not work on this unit (no
automatic mode).
Cleaning and care
- De-energize the device to clean it.
- Clean the outer parts with mild soapy water. Avoid hot cleaners, brushes, or scrubbing cloths.
- Conventional glass cleaner can be used for the glass surfaces.
It is important to follow the filter changes and cleaning intervals. Failure to comply
can be a fire hazard as a result of fat deposits.
Disposal of the transport packaging
The packaging protects the device against damage during transport. The packaging materials are
selected to be environmentally friendly and recyclable.The return of the packaging into the material
cycle saves raw materials and reduces waste. Your seller will take back the packaging.
Packing parts (e.g., foils, styrofoam) can be dangerous to children. There is danger of suffocation!
Keep packaging parts out of reach of children and dispose them as soon as possible.

Disposal of the old device
Electrical and electronic devices often contain valuable materials. They also contain
harmful substances that are essential to their function and safety were necessary.
Disposal as residual waste can harmful to human health and the environment in case
of wrong treatment. Therefore do not put your old device to residual waste. Instead,
use those collection and return points established by your community or municipality
for return and recovery of electrical and electronic waste.
