Guzzie+Guss 1+1 User manual

Please read this instrucon manual carefully before using this product.
Be sure to save these instrucons for future reference.
Versatile Stroller
G+G1+1 GABRIOLA
The G+G 1+1 has a Limited Warranty for the period of 1 year from the receipt of
purchase against manufacturers’ defects and workmanship.
For Warranty Registration:
submit online @ www.guzzieandguss.com
Or mail to the address provided below:
Imported by:
Peter John M. Distribution Inc.
88 SW Marine Drive, Vancouver, BC
Canada V5X 2R1
[email protected]
Tel [phone]
Fax [phone]
WARRANTY
Instruction Manual
1. ▲WARNING: Check the rivets, brakes and accessories very carefully before
using this stroller.
2. ▲WARNING: Stop using this product if there is any damaged or broken parts or
pieces.
3. Lubricate all moving parts and joints with a penetrating spray lubricant, from time
to time.
4. Remove front wheel cylinder housings and clean thoroughly from time to time.
5. Clean the stroller frame by wiping with moist cloth and dry thoroughly to prevent
any rusting.
6. Always wipe dry your stroller after using it in the rain or in winter climates, making
sure road salt is removed from frame and joints. Allow the stroller to stand in an open,
warm and ventilated place to dry.
7. Do not leave your stroller outside in wet weather as the fabric could mildew.
8. Only hand-wash the fabric by using mild detergent in warm water. DO NOT wash
in machine. Hang in a ventilated place to dry. DO NOT tumble dry.
9. It may be unsafe to use accessories other than those approved by the manufac-
turer or distributor.
10. It may be unsafe to use replacement parts other than those supplied or approved
by the manufacturer or distributor.
11. If you have any questions regarding the product please contact guzzie + Guss at
1-888-597-0992, or online at www.guzzieandguss.com.
CARE & MAINTENANCE

guzzie+Guss are committed to making the lives of children and parents safe,
uncomplicated and convenient. We would like to thank you for purchasing this
exciting product. It is important that you read and follow the instructions in this
manual carefully. Please make sure all the parts are properly attached and the
removable pieces fit on correctly. Please pay close attention to the opening and
closing mechanism. Read all warnings and safety steps before use.
INTRODUCTION
After completely reading and following all instructions in this manual, please file the
instruction manual in a safe place for future reference. If the product you have
received operates differently from instructions included with the product please
contact guzzie+Guss on the internet at [email protected]. There you can
obtain the most current information regarding your new G+G 1+1 stroller. You may
have to provide the registration number and manufacturing date; this information will
be found on frame of your stroller.
IMPORTANT
A) Handle
B) Handle height adjuster
C) Folding trigger
D) Seat Recline / Seat frame release
E) Second seat bracket
F) Brake (behind wheel)
G) Rear wheel
H) Basket
I) Front wheels
J) Swivel lock
K) Footrest Adjuster
L) Bumper bar
M) Harness
N) Canopy
YOUR STROLLER
INCLUDED PARTS
1) Stroller frame
2) Canopy
3) Seat (x1)
4) Bumper bar
5) Front wheels (x2)
6) Rear wheels (x2)
7) Rain cover
8) Rear wheel fenders (x2)
9) Instruction Manual
1.
3.
2.
4. 5. 6.
7. 8. 9.
Please read this instrucon manual carefully before using this product.
Be sure to save these instrucons for future reference.
Sport Stroller
G+G1+1 GABRIOLA
InstructionManual
A
B
C
D
E
F
GH
I
N
M
L
K
J

ASSEMBLY
Unfold the stroller chassis
1. Lift chassis lock lever and open the frame.
2. Lift handle until frame locks into upright
position as shown.
Attach the front wheels
1. Slide mounting pins into the housing on the
bottom, front wheel housing until they lock into
place.
2. To remove the front wheels, push the
release button, located on the top of the front
wheel housing. Then slide the front wheel out.
ATTENTION: make sure the wheels are
properly attached by lightly tugging on the
wheel.
Parking brake
1. To apply the brake, step on the brake lever,
on the inside of the right rear wheel. To
release the brake, lift the lever up.
3 4
Attach the bumper bar
1. Attaching: slide the pins into the mounts on
the seat until they lock into place.
2. Removing: push the release button on the
bottom of the mounts and pull arm bar out
NOTE: Front bumper bar must always be
used to avoid finger entrapment in the open
connectors
Attach the seat
1. Pull the seat recline post upwards on both
sides.
2. Now adjust the posts to a 45 degree angle
towards the front of the stroller.
3. When attaching the seat, align the connec-
tors on each side of the stroller seat above the
recline posts. Once aligned, simultaneously
push the connectors onto the recline posts
until you hear a “click” from both sides.
NOTE: Seat attaches forward or rear facing.
▲WARNING: Please make sure that both
sides have been attached properly. Try lifting
the seat off the chassis; if either side moves,
you need to push down until you hear a “click”.
4. Detaching the Seat: Lift both release levers
on the seat locking latch at the same time, Lift
upward .
IMPORTANT: Always remove child before
detaching the seat

Folding the stroller
1. Always remove the secondary seat (if in
use).
2. Always have the primary seat in the forward
facing position.
3. Always apply brake and remove children
before folding the stroller.
4. Push down on the secondary folding lock
located just above the Release Lever on the
right hand side.
5. Pull up both frame release levers located just
below the stroller handle, and step back while
guiding stroller downward. Continue folding until
the chassis lock engages.
USING YOUR STROLLER
Swivel wheels
1. To make the wheels swivel or lock, lift the
tab on the front of the wheel housing.
Footrest
1. Depress buttons on both sides of the leg
rest hinge and hold while raising or lowering
the footrest to the desired position.
Handle adjustment
1. Depress and hold the two release buttons
on the outside of the handle assembly while
raising or lowering the handle to the desired
position.
Reclining the seat
1. To recline the seat push the buttons on
both sides of the stroller seat, and position the
seat at the desired angle.
2. There are 3 positions for the seat, fully
reclined, fully upright, and a middle position.
Using the safety harness
The G+G 1+1 Stroller is equipped with a
5-point adjustable harness system. The
shoulder harness is adjustable in height
and can be changed by unthreading the
metal from its current position and
rethreading it through the shoulder belt
positioning loop at the desired height.
The length of the shoulder straps can
also be changed by sliding the buckle on
each shoulder strap. The waist belts are
adjustable on either the right or left by
using the adjustment buckles on the
waist strap.
To use the 5-point harness, insert the 2
waist strap tongues into the center
crotch strap buckle from the right and
left. The shoulder straps do not need to
be detached each time the child is
removed or seated in the stroller.
▲WARNING: Always fasten the 5-point
harness securely and properly around
the child’s body whenever the child is
seated in the stroller.
▲WARNING: Never leave the child
unattended when seated in the stroller
5 6

Using the rain cover
1. Fully extend the canopy.
2. Place the rain cover over the canopy.
3. Attach the left and right buckles to the
corresponding rivets on each side of the
stroller seat.
4. Place the elastic strap around the
footrest to secure the rain cover.
▲WARNING:Never use the rain without
having your child properly restrained in
stroller.
▲WARNING: The rain cover is designed
to be used with this guzzie+Guss stroller.
Not for use with other accessories.
Universal carseat adaptor
guzzie+Guss has developed a “truly”
universal carseat adaptor that will work
with every infant carseat that we have
seen yet. Just adjust it to fit your seat
and the included safety belt will keep
baby in a secure position.
Universal cup holder
guzzie+Guss has developed a “truly”
universal cup holder will work with both
your new G+G051 or any other stroller
you own. Auto adjusts to fit bottles or
large cups. Flexible hinge keeps your
cup from tipping over.
OPTIONAL EQUIPMENT
G+G1+1 second seat
Have 2 kids? Add the guzzie+Guss
second seat to the already impressive
G+G1+1 Gabriola to instantly convert it
to a double stroller. It can fit in either the
primary or secundary seat locations.
With three recline positions and includes
a rain cover.
PLEASE NOTE:Secondary seat
position can hold a child up to 20 kgs
(45 lbs).
Operating the canopy
1. To recline the seat push the buttons on
both sides of the stroller seat, and position the
seat at the desired angle.
2. There are 3 positions for the seat, fully
reclined, fully upright, and a middle position.
7 8

STROLLER CONFIGURATIONS WARNINGS
Please note the following to ensure safe use of your stroller
▲WARNING: Using this stroller for purposes other than intended use may:
• Void the warranty
• Damage the stroller
• Cause harm or injury to the child
• Cause harm or injury to others
▲WARNING: The G+G 1+1 is NOT designed as a jogging or running stroller and should never be
pushed while wearing inline skates or roller blades.
▲WARNING: Always fasten the 5-point harness securely and properly around the child’s body whenever
the child is seated in the stroller.
▲WARNING: Never use the rain cover without having the Canopy/Hood in place and properly attached
to the seat frame.
▲WARNING: Never leave the child unattended.
▲WARNING: Do not use stroller with a child who weighs more than 55 lbs (25kg).
▲WARNING: Do not use stroller with a child taller than 44 inches (111.8 cm).
▲WARNING: Never allow the child to stand while in the stroller.
▲WARNING: Do not allow children to climb on or play with the stroller.
▲WARNING: Never use stroller on stairs or escalators
▲WARNING: To avoid entrapment or pinching, do not fold or unfold stroller when child is in or within
reach of the stroller.
▲WARNING: Always set the parking brake when stroller is not moving.
▲WARNING: Make sure child’s arms are clear when adjusting the seat recline position.
▲WARNING: Only use this stroller on even surfaces such as sidewalks and roads, and at walking speed.
▲WARNING: Avoid using the stroller on uneven surfaces.
▲WARNING: Keep away from high temperatures and other dangerous places.
▲WARNING: When the stroller is not in use, please fold and store in a dry, shady place, away from
children. This stroller is not a toy.
▲WARNING: Do not place parcels or accessory items anywhere except in the storage basket and
pockets provided - Do not overload basket - Maximum weight in basket is 10 lbs (4.5kg). Overloading
the basket may cause the stroller to become unstable.
▲WARNING: Any load attached to the handle may affect the stability of the stroller. Do not overload
stroller.
▲WARNING: Avoid serious injury from falling or sliding out. Always use harness to secure child.
▲WARNING: Do not use stroller for an infant younger than 6 months without an infant car seat or
bassinet.
▲WARNING: Do not lift the stroller by the front bumper bar of the seat.
▲WARNING: To ensure proper use, store this user guide in a convenient place so it can be consulted
often. Failure to follow all warnings and instructions could result in serious injury or death.
▲WARNING: When using an infant car seat with this product, refer to the infant car seat’s user guide for
maximum weights and other instructions.
▲WARNING: Do not use this stroller if there are any broken or missing parts.
▲WARNING: Do not exceed the manufacturer’s maximum weight limit when using an infant car seat with
the guzzie+Guss universal car seat adapter.
▲WARNING: Primary seat position can hold a child up to 25kgs (55 lbs). Secondary seat position can
hold a child up to 20 kgs (45 lbs).
9 10
