GVA GVAOR11FT User manual

Instruction Manual
11 Fin Oil Filled Heater
/ GVAOR11FT

2
Important Safety Instructions 3
Parts List 5
Getting Started 6
Operations 8
Care and Maintenance 11
Responsible Disposal 12
Contents

3
Read this manual thoroughly before rst use, even if you are familiar with this type of product.
The safety precautions enclosed herein reduce the risk of re, electric shock and injury
when correctly adhered to.
Keep the manual in a safe place for future reference, along with the warranty card, purchase
receipt and carton.
Electrical safety and cord handling
• Connect the appliance to a single-phase AC supply of the voltage specied on the rating
plate; the socket must stand a minimum 10A load, use a safe socket with an earthed
connection.
• Always plug this heater into a separate power point. Do not use it with an extension cord
as this may overheat and cause a risk of re.
• Do not place the heater immediately below an electrical outlet.
• To ensure you do not overload the electrical circuit, make sure that no other appliance is
in use on the same electrical circuit as the heater.
• Protect the heater from moisture. Never touch the heater with wet or damp hands or
feet. Never expose it to water (including rain) or other liquids. Never use the heater in the
immediate surroundings of a bath, shower or swimming pool, or anywhere it may fall into
a bathtub or any other water container.
• Always place the heater in an upright position and on a stable surface.
• Do not operate the heater with a damaged cord or plug, or after the heater malfunctions,
has been dropped, or damaged in any manner.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent
or similarly qualied persons in order to avoid a hazard. In case of damage, contact the
after sales support line for advice on return or repair.
• Protect the power cord. Do not put it on top of the heater, or expose it to hot surfaces.
Do not put any stress on the power cord where it connects to the product, as the power
cord could fray and break.
• Do not run the cord under carpeting or cover it with throw rugs, runners etc. Arrange the
cord away from trac areas and where it will not be tripped over.
• Never leave the heater unattended while it is in use. Always switch it o and unplug it
from the power point when not in use and before moving it.
• To disconnect the heater, turn it o and then remove the plug from the electrical outlet.
Grip the plug when disconnecting, do not pull on the cord.
Important Safety Instructions

4
Usage conditions and restrictions
• This product is intended for indoor, non-commercial, non-industrial, household use only.
Do not use it outdoors.
• Do not use the product for anything other than its intended purpose, and only use it as
described in this manual. Any other use is not recommended and may cause re, electric
shock or injury to persons.
• Do not use the heater to dry or heat clothing, shoes or any other item.
• This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
• Supervise young children to ensure they do not play with the heater. Close supervision is
necessary when any appliance is used by or near children.
• Do not use the heater in a room with a oor area of less than 5m2.
• To avoid any risk of re, do not place this heater near ammable materials, surfaces or
substances and keep such materials at least 1m from the front of the heater and away
from its sides and back.
• Do not use the heater in any areas where petrol, paint or other ammable liquids are
stored, such as in a garage or workshop.
• Use this heater in a well ventilated area.
• Use the heater on at, dry surfaces only. Do not use it on soft surfaces such as bedding or
soft carpeting, where openings may become blocked.
• Do not insert or allow objects to enter any openings. To prevent a possible re, do not
block air intakes or exhaust openings in any manner.
• In order to avoid overheating, do not cover the heater.
• CAUTION: HOT! This heater is hot when in use. To avoid burns and personal injury, do
not allow bare skin to touch hot surfaces. Only use the handles when moving the heater
during use.
• Contact the after sales support line if your heater is not working properly or if there is
an oil leakage. Repairs requiring opening of the oil container are only to be made by the
manufacturer or its service agent.
• NOTE: Unless your home is already tted with a residual current device (safety switch),
we recommend installing an RCD with a rated residual operating current not exceeding
30mA to provide additional safety protection when using electrical appliances. See your
electrician for professional advice.
Important Safety Instructions (Cont.)

5
Parts List
1
2
3
4
5
6
7
1. Handle
2. Power setting switch and indicator light
3. Thermostat control knob
4. Oil lled ns
5. 24 hour timer
6. Power cord storage
7. Castor wheels
8. Power cord
8

6
Getting Started
Before First Use
• Thank you for purchasing our oil lled heater. Each unit has been manufactured to
ensure safety and reliability. Please read the instructions carefully and keep them for
future reference.
• Unpack the appliance but keep all packaging materials until you have made sure
your new heater is undamaged and in good working order. Plastic wrapping can be a
suocation hazard for babies and young children, so ensure all packaging materials are
out of their reach.
• Inspect the power cord and plug for damage. Do not use the heater if the appliance or
its cord have been damaged or are not working properly. In such case, contact the after
sales support line for advice.
Assembly
The heater is packaged with the feet (castor wheels) unattached. You must attach them
before using or turning on the heater.
1. Remove the heater and all accessories from carton.
2. Place the heater body upside down on a scratch-free surface, make sure it is stable and
will not fall.
3. Screw o the wing nuts from the U-shaped bolt provided. Attach the U-shaped bolt to
the U-facing ange between the rst and second ns (near the front cover).
4. To attach the castor mounting plate to the heater body, you should insert the threaded
ends of the U-shaped bolt in the holes on the castor mounting place.

7
Getting Started (Cont.)
5. Screw the wing nuts back to the U-shaped bolt and fasten the wing nut properly.
NOTE: Do not over tighten, which may cause damage to the heater ange.
6. Screw o spherical nut from the castor, align the shaft to the hole of the castor
mounting plate, insert in and screw on the spherical nut.
7. Repeat step 3, 4, 5, 6 on the rear of heater ns for mounting the rear castors.
NOTE: The rear castors must be mounted between the end two ns.

8
Operations
Using The Heater
NOTE: The heater is packaged with castor wheels unattached. You must attach them before
using the heater, see opposite for instructions.
1. Choosing a safe location
• Always place the heater on a at and stable surface. Using it on an uneven or sloping
surface may cause damage to the heater.
• Make sure you have read all safety instructions on pages 3 to 4, which will help you
choose a safe location for your new heater.
2. Switching on
• Set the power setting switch to the OFF (0) position.
• Set the thermostat knob to LOW (the thin end of the circle).
• Then insert the plug into a well earthed wall socket.
3. Selecting a heat setting
• Rotate the thermostat knob clockwise to HIGH (the thick end of the circle).
• Switch the heater to desired heat setting:
Switch (I) for 800W, Switch (II) for 1200W, Switch (I) & (II) for 2000W
• The power light indicator will light up.
4. Setting the thermostat
When your room has reached the desired temperature:
• Slowly rotate the thermostat knob counterclockwise until the pilot light goes out. The
thermostat can now be left at this setting.
• As soon as the room temperature drops below the set temperature, the unit will
switch itself on automatically until the set temperature has been reached again. This
way the room temperature remains consistent with the most economical use of
electricity.
5. Changing the temperature
If you want to change the room temperature setting:
• Rotate the thermostat knob clockwise to raise the temperature or counterclockwise
to lower it.
6. Switching o
Once you have nished using your heater:
• Turn the heat settings switch to the OFF (0) position.
• Turn the thermostat knob to LOW (the thin circle shape).
• Then unplug the heater from the mains supply outlet.

9
Operations (Cont.)
7. Setting the timer
The heater features a timer you can set to start the heater, or switch it o, automatically at
a certain, pre-set time. The timer has a small switch. If this switch is set to [ I ], the heater is
always on, set to [ ], the timer function is on.
NOTE: To set the current time on the timer, always turn the timer clockwise.
Do not turn it counterclockwise!
h) First of all, you must activate the timer: set the small switch to [ ].
i) Turn the timer clockwise until the arrow points on the current time. Then set the on/
o time by pushing the appropriate pins outward or inwards. Each of the 96 small
plastic pins on the timer corresponds to a 15 minute interval. Push outward the pins
corresponding to the time you want the heater to turn ON. Push inward the pins
corresponding to the time you want the heater to turn OFF.
NOTE: Make sure you have selected a heat and temperature setting (see
page 8) prior to setting the timer. This will ensure the heater cycles
on and o to maintain the set temperature.

10
CAUTION!
• Do not use the timer function unattended.
• The heater will not operate if the timer is set to the position and the pins are not
activated according to the times required.
• If the heater loses its electricity supply, e.g. is switched o at the mains socket or in the
event of a power failure, the timer should be reset after the power comes on again.
Safety Features
This heater includes two safety features to prevent an accidental re should the heater
overheat or be tipped over.
• An overheat protection system shuts o the heater when parts of the heater are getting
excessively hot.
• A built-in tip over switch shuts o the heater automatically when it is accidently tipped
forward or backward. When the heater returns to the normal upright position, it will
resume normal operation.
Operations (Cont.)

11
Care and Maintenance
Care and Maintenance
WARNING!
• Always set all controls to the OFF position, remove the plug from the socket outlet and
allow the heater to cool down completely before cleaning it.
• Never immerse the heater in water. Never allow the interior to get wet.
• Do not use any chemical cleaners such as detergents or solvents, or abrasives, on any
part of the heater.
1. To clean dust and dirt o the heater, only wipe it with a soft cloth, moistened, if
necessary, but not wet.
2. When the heater is not in use, make sure it is unplugged from the wall socket.
3. To store the heater, we recommend removing the castor wheels and packing it in its
original carton. Storing it in a cool and dry place, out of children’s reach, until later use.
4. In case of a malfunction or if in doubt, do not try to repair the heater yourself, it may
result in a re hazard or an electric shock. Call the after sales support line for advice.
NOTE: Unless your home is already tted with a residual current device (safety switch), we
recommend installing an RCD with a rated residual operating current not exceeding 30mA to
provide additional safety protection when using electrical appliances. See your electrician for
professional advice.

12
Responsible Disposal
Responsible Disposal
At the end of its working life, do not throw this appliance out with your household
rubbish. Electrical and electronic products contain substances that can have a detrimental
eect on the environment and human health if disposed of inappropriately. Observe any
local regulations regarding the disposal of electrical consumer goods and dispose of it
appropriately for recycling. Contact your local authorities for advice on recycling facilities in
your area.
