GV-NC-102D/DO
GV-NC-102D/DO
H.264 High Denition Network Mini-dome Camera
Summary
autoIP™ mini dome network cameras are designed to provide cost effective, High Denition
video surveillance in a discrete, low prole enclosure. A 1/3” CMOS progressive scan image
sensor delivers High Denition video that is compressed with H.264 to retain high video
quality at a low data rate. Power over Ethernet (PoE) reduces installation time and costs. The
IP66 rugged model (GV-NC-102DO) is ideal for environments that require dust and humidity
resistance. The camera is compatible with the user-friendly autoIP™ open platform video
management software for quick plug and play installation.
Features
• 1/3” Progressive Scan CMOS
• Resolution: 1280x720
• Flat Design Mini-dome
•
Plastic Housing (IP66 Rugged Housing - GV-NC-102DO)
• Multiple Codec (H.264, MJPEG)
• Simultaneous Dual Codec Support
• F1.8 / f=4.3mm Fixed Lens
• Privacy Masks
• Flip, Mirror, Rotate Functions
• Micro SD Card Support
• Power over Ethernet (PoE) Support
High Denition
The high resolution of the GV-NC-102D/DO
provides a level of detail that is not possible
with analog cameras.
Discrete, Low Prole Design
The GV-NC-102D/DO cameras can be installed
simply and discretely. The low prole design
blends easily into any wall space or ceiling in
any indoor location.
Plug and Play Installation
The camera is instantly discovered and
congured for recording when deployed with
autoIP™ software.
VGA (640x480) High Denition (1280x720)

GVI Security | Toll Free: 888-595-2288 | Fax: [phone]
This product specications and manual are also available in pdf format at www.gviss.com
The information is subject to change without notice - v7.14.10
GV-NC-102D/DO
GV-NC-102D/DO
H.264 High Denition Network Mini-dome Camera
Specications
Dimensions (unit : in) Side/Rear Panel
Certications
Item GV-NC-102D/DO
Camera
Image Sensor 1/3” Progressive CMOS
Picture Elements 1280(H) x 1024(V)
Resolution >700 TVL
Minimum Illumunation Color: 0.04 lux @ F 1.8
Shutter Speed 1~ 1/10000 sec.
White Balance Manual / ATW (1500 ~ 15000K)
Lens Fixed Lens F 1.8 / f = 4.3mm
Operation
Video Compression H.264 / MJPEG
Video Streaming Simultaneously H.264 + MJPEG
H.264 + H.264
Resolution H.264 HD 720p (1280x720)
MJPEG HD 720p / D1 / CIF
Frame Rate 30fps
Image Setting Brightness Manual
Exposure Auto / Manual
Sharpness Manual
Contrast Manual
White Balance Auto / Manual
Digital Zoom Zoom In / Zoom Out
Image Rotation Flip, Mirror, and 180˚Rotate
Motion detection On/Off
Privacy Mask On/Off
Privacy Mask Type Transparent, Color
Audio One-way Audio Microphone (GV-NC-102D only)
Compression G.711 / G.726
Network
Interface 10/100Mb Ethernet (RJ-45)
Protocol TCP/IP, UDP, RTP, RTSP, HTTP, ICMP,FTP, SMTP, DHCP and IGMP
Password Levels User and Administrator
Internet Browser Internet Explorer (6.0+)
User Account 20
Mechanical
Lens Mounting M12 Board Lens
Connectors Ethernet RJ-45
Micro SD SDHC support
General
Operating Temperature
32°F ~ 122°F (0°C ~ 50°C) Humidity: 10% to 90%, No Condensation
IP66 Yes (GV-NC-102DO only)
Power Source PoE
Power Consumption 3W
Dimension Ø4.3 x 2.0 in. (Ø110 x 50mm)
Weight 0.40lbs (180g)
Ø4.3
1.9
