GW Instek GSP-8000 Series User manual

Spectrum Analyzer
GSP-8000 Series
QUICK START GUIDE
ISO-9001 CERTIFIED MANUFACTURER

October 2023
This manual contains proprietary information, which is protected by
copyright. All rights are reserved. No part of this manual may be
photocopied, reproduced or translated to another language without
prior written consent of the Good Will company.
The information in this manual was correct at the time of printing.
However, Good Will continues to improve products and reserves the
right to change specification, equipment, and maintenance procedures
at any time without notice.
Good Will Instrument Co., Ltd.
No. 7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan.

Table of Contents
3
Table of Contents
USER NOTICE ............................................................. 5
General Inspection ...................................................5
Safety Precaution before Operation ...........................6
Electro-static Discharge (ESD) Protection ..................8
First Time to Power on..............................................9
GETTING STARTED .....................................................10
Front Panel Overview .............................................. 11
Rear Panel .............................................................. 13
Front Panel Function Key......................................... 15
Parameter Input ..................................................... 18
User Interface......................................................... 20
MENU INTEPRETATION...............................................22
Frequency............................................................... 23
Span ...................................................................... 23
Amplitude .............................................................. 23
Autoset .................................................................. 23
Bandwidth .............................................................. 24
Trace ...................................................................... 24
Detector ................................................................. 24
Display................................................................... 25
Sweep .................................................................... 25
Trigger ................................................................... 25
Tracking Generator ................................................. 25
Mode ..................................................................... 25
Peak Search ............................................................ 26
Marker ................................................................... 26
Measurement ......................................................... 27
Measure Setup ....................................................... 27
System ................................................................... 27

GSP-8000 series Quick Start Guide
4
File ........................................................................ 27
Quick Save ............................................................. 27
Save ....................................................................... 27
APPENDIX ................................................................. 28
Specifications ......................................................... 28

USER NOTICE
5
USER NOTICE
This chapter helps you in preparing the spectrum
analyzer for use and provides the information to
start using the spectrum analyzer correctly.
General Inspection
When you receive your new instrument, it is recommended that
you check the instrument following these steps:
Steps
1. Check for transportation damage.
If it is found that the packaging carton or the
foamed plastic protection cushion has suffered
serious damage, do not throw it away until the
complete device and its accessories have been
electrically and mechanically checked.
2. Check the Accessories
Please ensure that all the listed accessories are
present and undamaged, if any problems are
found please contact your distributor.
3. Check the Complete Instrument
If there is any physical damage, operational
fault, or performance issue please contact your
distributor or GW Instek’s local office. If there
is any damage to the instrument please ensure
you keep the original packaging. Ideally you
should always keep the original packaging if
the instrument must be returned for repair.

GSP-8000 series Quick Start Guide
6
Safety Precaution before Operation
Check Power Supply
The analyzer is equipped with a three-wire power cord in
accordance with international safety standards. The product must
be grounded properly before being powered on, as floating or
improper ground may cause damage to the instrument or personal
injury.
Make sure the grounding conductor of the spectrum analyzer is
grounded before turning on the instrument. After which the AC
power cord can be connected. Do not use a non-ground power cord.
Allowed Variation Range of Supply Power Parameters
The spectrum analyzer is compatible with 100V~240V, 50Hz-60Hz
AC power. The table below lists the power requirement to run the
spectrum analyzer.
Power Supply Parameter
Compatible Range
Voltage
100 - 240 VAC
Frequency
50 - 60 Hz ±10％
Power
28W
To prevent or lower the risk of damage to the spectrum analyzer
from power interference between instruments, especially from peak
pulses produced by large power consumption instruments, a
220V/110V AC regulated power supply is recommended.
Power Cord Selection
The analyzer is equipped with a three-wire power cord in
accordance with international safety standards. This cable grounds
the analyzer cabinet when connected to an appropriate power line
outlet. The cable must be rated greater than 250Vac and 2A.

USER NOTICE
7
WARNING
Improper grounding may cause damage to the
instrument, or result in personal injury. Make sure the
grounding conductor of the spectrum analyzer is
grounded before turning on the instrument.
Always use a well-grounded power source. Do not use
an external power cable, power cord or an auto
transformer without grounded protection. If this
product is to be powered via an external auto
transformer for voltage reduction, ensure that its
common terminal is connected to a neutral (earthed
pole) of the power supply.
Make sure the supply power is stable before turning
on the analyzer to protect it from damage. Refer to
“First Time to Power on”on page 9

GSP-8000 series Quick Start Guide
8
Electro-static Discharge (ESD) Protection
ESD is an issue often ignored by users. Damage from ESD on the
instrument is unlikely to occur immediately but will significantly
reduce the reliability of it. Therefore, ESD precautions should be
implemented in the work environment, and applied daily.
Generally, there are two steps to manage ESD protection:
1. Conductive table mats to connect hands via
wrist bands
2. Conductive ground mat to connect feet via
ankle straps
Implement both protection methods will provide a good level of
anti-static protection. If used alone, the protection will not be as
reliable. To ensure user’s safety, anti-static components should
offer at least 1MΩ isolation resistance.
WARNING
The above ESD protections measures cannot be used
when working with over 500V!
Make good use of anti-static technology to protect components
from damage:
1. Quickly ground the internal and external
conductor of the coaxial cable before it is
connected with the spectrum analyzer.
2. Staff must wear anti-static gloves before
touching the connector cord or doing any
assemble work.
3. Assure all the instruments are grounded
properly to avoid static storage.

USER NOTICE
9
First Time to Power on
Connect the three-pin AC power cord into the instrument. Insert
the plug into a power socket provided with a protective ground.
WARNING
Check the power source before turning on the
spectrum analyzer, to protect the device from damage.
Steps
1. Press the power switch on the bottom left
of the front panel.
2. Self-initialization takes about 30 seconds, after
the boot screen the spectrum analyzer will
default to the scanning curve.
3. After power on, let the spectrum analyzer warm
up for 60 minutes for stabilization to obtain the
most accurate results.

GSP-8000 series Quick Start Guide
10
GETTING STARTED
This chapter introduces the front / rear panel, the
user interface and explains how to use the
instrument with a measurement example
demonstration.
Front Panel Overview .............................................. 11
Rear Panel .............................................................. 13
Front Panel Function Key ........................................ 15
Parameter Input ..................................................... 18
Numeric Keypad............................................................... 18
User Interface......................................................... 20

GETTING STARTED
11
Front Panel Overview
123
4
5
67891011
12
13
1.
LCD
1024x768 color LCD display. The display
shows the soft keys for the current
function, frequency, amplitude and
marker information.
2.
Menu soft
keys
The F1 to F7 function keys directly
correspond to the soft keys on the right-
hand side of display.
3.
Function
keys
See page 15 for details.
4.
Knob
During parameter editing, turn the knob
clockwise to increase, or
counterclockwise to decrease the
parameter values at specified steps.
5.
Arrow keys
(1) Increase or decrease the parameter
value at specific steps while editing a
parameter.
(2) Move the cursor though the directory

GSP-8000 series Quick Start Guide
12
tree in the File function
6.
RF Input
connector
The RF input may be connected to a
device via a N type connector.
Note
When input attenuator is higher than 10 dB, the RF port
input signal must be less than +30 dBm.
Input voltage at RF input port must not be higher than
50 V DC to avoid damage to the attenuator and input
mixer tracking generator.
7.
Unit keys
Unit keys include GHz/dBm/s,
MHz/dB/ms, kHz/dBmV/μs and
Hz/mV/ns. After entering the desired
numbers, choose an appropriate unit to
complete the input. The specific meaning of
unit is decided by the type of input parameter
(“frequency”, “amplitude”or “time”).
8.
Numeric
keypad
See page 18 for details.
9.
TG output
connector
The output of the tracking generator can
be connected to a receiver through an N
type male connector, users can purchase
this option if required.
10.
TG output
On/Off
button
When the TG function is enabled, the
backlight of button turns on and turns off
when the function is disabled.
11.
Earphone
interface
3.5mm stereo headphone jack (wired for
mono operation)
12.
USB Host
port
The analyzer may serve as a "host" device
to connect to external USB devices. This
interface is available for USB storage
devices.
13.
Power key
Push to turn on, long push to turn off

GETTING STARTED
13
Rear Panel
1
74
653
2
8
1.
Handle
Stow the handle for mobile use.
2
AC power
connector
AC: frequency 50Hz/60Hz ±10％, single-
phase alternative 220V±15％or 110V±15％
3.
Stool
To adjust the angle of the device
4.
LAN
interface
Through this interface, the analyzer can be
connected to your local network for remote
control. An integrated testing system can be
built quickly, as the analyzer conforms to the
LXI C Device class instrument standards.
5.
USB Device
interface
This configurable USB port permits external
USB devices. It supports PictBridge printer
and remote-control connection.
6.
Ref In/Out
The BNC input or output of the 10 MHz
reference clock
7.
Trig-In
Input an external signal (TTL signal) for
external trigger function.

GSP-8000 series Quick Start Guide
14
8.
Lock hole
You can lock the spectrum analyzer to a fixed
location using the security lock (please buy it
yourself) to secure the spectrum analyzer.

GETTING STARTED
15
Front Panel Function Key
Basic keys
Marker function measure
Utility keys
Control keys
Mode
BW
Basic keys
Activates the center-frequency function, and accesses
the frequency function menu.
Activates the frequency sweep span function, and set
Full Span\Zero Span\Last Span.
Activates the reference level function, and accesses
the amplitude softkeys, with which you set functions
that affect data on the vertical axis.
Searches the signal automatically within the full
frequency range.
Control keys
BW
Activates the RBW (resolution bandwidth), VBW
(video bandwidth) function, and accesses the
softkeys that control the bandwidth.
Accesses the softkeys that allow you to store and
manipulate trace information.

GSP-8000 series Quick Start Guide
16
Accesses the softkeys that allow you to configure
detector functions.
Accesses the softkeys that allow you to control what
is displayed on the analyzer, including the display
line, graticule, Label, Menu Hide, Brightness and
Screen Sleep.
Accesses the softkeys that allow you to set the sweep
time, select the sweep mode of the analyzer.
Accesses the softkeys that allow you to select the
trigger mode of the analyzer.
Accesses the softkeys that allow you to set the
tracking generator.
Mode
Accesses the softkeys that allow you to set the
Spectrum and demodulation mode.
Marker function keys
Places a marker on the highest/lowest peak, and
accesses the Peak functions menu.
Accesses the marker control keys that select the type
and number of markers and turns them on and off.
Accesses the marker function soft keys that allow you
to set other system parameters based on the current
marker’s value.
Accesses the menu of other marker functions, such as
N-dB bandwidth measure, marker noise, and
frequency counting.
Advanced measure keys
Accesses the softkeys that let you make transmitter
power measurements such as Time Spec, ACPR
(adjacent channel power), channel power, and OBW
(occupied bandwidth), etc.

GETTING STARTED
17
Sets the parameters for the selected measurement
function.
Utility keys
Accesses the softkeys that allow you to get the system
information, or set the system parameters.
Accesses the softkeys that allow you to configure the
file system of the analyzer.
Resets the analyzer to the factory settings or user
state. This state can be specified in 【System】→
[PowerOn/Preset►] →[Preset►].
Save the contents of the current screen quickly.
Accesses the soft keys that allow you to save current
screen, trace data, user state or limit line data.
Press the Help key to activate the help system. Press
the Help key again to exit.

GSP-8000 series Quick Start Guide
18
Parameter Input
Specific parameter values are able to be entered using the numeric
keypad, knob, and directional keys.
Numeric Keypad
Numeric keys
Numbers 0-9 are available to be used.
Decimal
point
A decimal point “.”will be inserted at the
cursor position when this key is pressed.
Sign key
Sign key “+/-“is to toggle the sign of a
parameter. When pressed the first time, a
“-“will be inserted and changed into “+”
following the second press.
Cancel key
(1) During the editing process this key will
clear the inputs in the active area and exit
editing mode at the same time.
(2) Turn off the display in the active area.
(3) Exit current test mode while in keyboard
test.
Back key
(1) During the process of parameter editing,
this key will delete the characters on the left
side of the cursor.
(2) While in the process of file name editing,
pressing this key will delete characters that
have been entered.

GETTING STARTED
19
Enter key
When pressed, the system will complete the
input process and insert a default
measurement unit for the parameter
automatically.
Unit keys
Unit keys include GHz/dBm/Sec,
MHz/dB/mSec, kHz/dBmV/μSec and
Hz/mV/nSec. After entering the desired
numbers, choose an appropriate unit to
complete the input. The specific meaning of
unit is decided by the type of input parameter
(“frequency”, “amplitude”or “time”).

GSP-8000 series Quick Start Guide
20
User Interface
Marker function
2 5
9
378
11
6
1213
1415
1617
18
19
20
4
1
10
No.
Name
Description
Related Key
1.
Reference level
Reference level
→ [Ref Level]
2
Attenuation
Display input
attenuation setting
→ [Attenuation]
3.
Amplitude
Division Type
Can choose
logarithmic or
linear
→ [Scale Type]
4.
Amplitude
Division
Display Division
scale
→ [Scale/ Div]
5.
Marker
Display current
activated marker
6.
Marker
readout
Display frequency
and amplitude of
current marker
