GSP-810 User Manual
1
Table of Contents
1.0 GENERAL DESCRIPTION AND FEATURES...............................................................................2
2.0 USAGE PRECAUTIONS AND RECOMMENDATIONS ...............................................................3
3.0 PANEL DESCRIPTIONS ...............................................................................................................7
4.0 SETUP AND USE ........................................................................................................................11
5.0 QUICK USE INDEX .....................................................................................................................27
6.0 SPECIFICATIONS .......................................................................................................................28
APPENDIX 1 - REMOTE OPERATION (STANDARD AND OPTION) .............................................32
Due to continuous improvements in the GSP-810 Spectrum Analyzer, information
contained in this Manual is subject to change without notice.
Contact GW, for revisions and corrections.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

GSP-810 User Manual
2
Declaration of Conformity
We
GOOD WILL INSTRUMENT CO., LTD.
No. 7-1, Jhongsing Rd, Tucheng City, Taipei County 236. Taiwan.
GOOD WILL INSTRUMENT (SUZHOU) CO., LTD.
No. 69 Lushan Road, Suzhou New District Jiangsu, China.
declare that the below mentioned product
Type of Product: Spectrum Analyzer
Model Number : GSP-810
is herewith confirmed to comply with the requirements set out in the Council
Directive on the Approximation of the Law of Member States relating to
Electromagnetic Compatibility (2004/108/EC) and Low Voltage Equipment
Directive (73/23/EEC & 93/68/EEC).
For the evaluation regarding the Electromagnetic Compatibility and Low Voltage
Equipment Directive, the following standards were applied:
◎EMC
EN 61326-1 :
EN 61326-2-1: Electrical equipment for measurement, control and laboratory use－
EMC requirements (2006)
Conducted & Radiated Emission
CISPR 11: 2003+A1: 2004 +A2: 2006
Electrostatic Discharge
IEC 1000-4-2: 2001
Current Harmonics
EN 61000-3-2: 2006
Radiated Immunity
IEC 1000-4-3: 2006+A1: 2007
Voltage Fluctuations
EN 61000-3-3:1995+A1:2001+A2:2005
Electrical Fast Transients
IEC 1000-4-4: 2004+Corr.1: 2006+Corr.2:
2007
==================== Surge Immunity
IEC 1000-4-5: 2005
==================== Conducted Susceptibility
IEC 61000-4-6: 2003+A1: 2004+A2: 2006
==================== Power Frequency Magnetic field
IEC 61000-4-8: 1993+A1: 2001
==================== Voltage Dip/Interruption
IEC 61000-4-11: 2004
Low Voltage Equipment Directive 73/23/EEC & amended by 93/68/EEC
Safety Requirements IEC/EN 61010-1: 2001
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

GSP-810 User Manual
3
1.0 General Description and Features
The GSP-810 is designed for minimal set-up and adjustment. The user interface
allows fast and accurate measurements. The fully synthesized design of the GSP-
810 permits stable operation down to 2 kHz / division.
2.0 Usage Precautions and Recommendations
The following precautions are recommended to insure your safety and to provide the
best condition of the GSP-810.
Safety Terms and Symbols
These terms may appear in this manual or on the product:
WARNING: Warning statements identify condition or practices that could
result in injury or loss of life.
CAUTION: Caution statements identify conditions or practices that could result
in damage to this product or other property.
The following symbols may appear in this manual or on the product:
DANGER ATTENTION Protective Earth (ground)
High Voltage refer to Manual Conductor Terminal
Terminal
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

GSP-810 User Manual
4
FOR UNITED KINGDOM ONLY
NOTE: This lead / appliance must only be wired by competent persons
WARNING: THIS APPLIANCE MUST BE EARTHED
IMPORTANT: The wires in this lead are coloured in accordance with the following code:
Green/ Yellow: Earth
Blue: Neutral
Brown: Live (Phase)
As the colours of the wires in main leads may not correspond with the colours
marking identified in your plug/appliance, proceed as follows:
The wire which is coloured Green & Yellow must be connected to the Earth
terminal marked with the letter E or by the earth symbol or coloured Green or
Green & Yellow.
The wire which is coloured Blue must be connected to the terminal which is
marked with the letter N or coloured Blue or Black.
The wire which is coloured Brown must be connected to the terminal marked with
the letter L or P or coloured Brown or Red.
If in doubt, consult the instructions provided with the equipment or contact the
supplier.
This cable/appliance should be protected by a suitably rated and approved HBC
mains fuse: refer to the rating information on the equipment and/or user
instructions for details. As a guide, cable of 0.75mm2should be protected by a 3A
or 5A fuse. Larger conductors would normally require 13A types, depending on the
connection method used.
Any moulded mains connector that requires removal /replacement must be
destroyed by removal of any fuse & fuse carrier and disposed of immediately, as a
plug with bared wires is hazardous if a engaged in live socket. Any re-wiring must
be carried out in accordance with the information detailed on this lable.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

GSP-810 User Manual
5
Use and Wear
CAUTION
•Do not exceed +30 dBm into the RF INPUT or +30 dBm reverse power into the
TG OUTPUT.
•Do not place any heavy object on the instrument.
•Avoid severe impacts or rough handling that could damage the GSP-810.
•Use electrostatic discharge precautions while handling and making
connections to the GSP-810.
•Do not place wires into the connectors of the GSP-810, only mating connectors
and adapters.
•Do not block or obstruct cooling fan vent opening on side panels or on the rear
panel of unit.
1) Disassembly of the Instrument
•Do not disassemble the instrument; refer the instrument to a factory approved
service facility only.
2) AC Power Input
CAUTION
•AC input should be within the range of selected line voltage +/- 10%.
•Insure the correct fuse is installed prior to applying voltage for the first time -
90 V ~ 132 VAC input : T 1A / 250V
198 ~ 250 VAC input : T0.5A / 250V
•Check the line voltage setting on the rear panel. If the line voltage does not
match input voltage, change as follows:
a) Remove AC Power Cord;
b) Open cover of AC socket with flat blade screwdriver;
c) Remove selector Cam Drum and rotate to the correct voltage selection
d) Replace Cam Drum.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

GSP-810 User Manual
6
3) Grounding
WARNING
•To avoid electrical shock, the power cord protective grounding conductor must
be connected to earth ground.
4) Fuse Replacement
WARNING
•For continued fire protection, replace the fuse with the specified type and rating
only.
•Disconnect power cord before replacing fuse.
•If the fuse is blown, there is something wrong with the instrument. Repair the
cause of fault before replacing fuse.
5) Cleaning
•Disconnect AC Power Cord from the instrument before cleaning.
•Use a soft cloth dampened in a solution of mild detergent and water. Do not
spray any liquid into the unit.
•Do not use chemicals or cleaners containing benzene, toluene, xylene,
acetone or other harsh chemicals.
6) Operating Environment
•The following conditions are recommended for optimum use of the instrument -
Indoor Use Altitude < 2000 m Temperature 18° to 28° C Relative Humidity < 90%
Dust Free No direct sunlight No strong magnetic fields
•Installation Category: II
CAT ⅣFor measurements performed at the source of the low-voltage installation.
CAT ⅢFor measurements performed in the building installation.
CAT ⅡFor measurements performed on circuits directly connected to the low-
voltage installation.
CAT ⅠFor measurements performed on circuits not directly connected to Mains.
•Pollution degree: 2
7) Storage Environment
•The following conditions are recommended for optimum storage of the instrument -
Indoor Temperature 0° to 40° C Relative Humidity < 85%
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

GSP-810 User Manual
7
3.0 Panel Descriptions
Front Panel
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

GSP-810 User Manual
8
Item Description
1 Cathode Ray Tube (CRT) Display, 8 x 10 graticule, 5 inch
2 Liquid Crystal Display (LCD), 4 line x 20 character
3 Keypad, field selection and data entry
4 Spinner, field selection and data change
5 RF Input, Coaxial, Type N Female
6 Tracking Generator Output, Coaxial, Type N Female (optional)
7 Switch, Power ON / OFF
8 Adjustment, CRT Trace Rotation, potentiometer
9 Control Knob, Volume (optional demod receiver)
10 Phone Jack, head set output, (optional demod receiver)
11 Control Knob, CRT Focus
12 Adjustment, CRT Y-axis position, potentiometer
13 Control Knob, CRT Intensity
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

GSP-810 User Manual
9
Rear Panel
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

GSP-810 User Manual
10
Item Description
14 Panel Label, Usage Warning
15 External Frequency Reference Input, BNC (optional)
16 Connector, DB9, Female, RS-232
17 Panel Label, Serial Number
18 Cooling Fan Vent
19 Adjustment, CRT Trace Rotation, potentiometer
20 Adjustment, Internal Frequency Reference , potentiometer
21 Adjustment, LCD Contrast, potentiometer
22 Panel Label, Input Voltage
23 AC Input, Connector, Voltage Select and Fuse
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

GSP-810 User Manual
11
4.0 Setup and Use
4.1 General Description
The RF input is used to connect to the device under test, or to an external circuit or
antenna. The characteristic frequency and level of the signals received are
detected displayed on the CRT.
4.2 Use
The settings and control for the GSP-810 are easily accessed from the keypad.
The left column of keys are the field selections for Center Frequency (CENTER),
Span (SPAN) and Reference Level (REF LVL). Pressing one of these keys selects
the corresponding setting and screen edit field. The BLUE alternate function key is
used to access the functions identified by the blue text above the respective key.
For instance, pressing BLUE followed by MEMORY selects the TRACE functions.
The following table contains a list of the various data fields that may be controlled
within the GSP-810, the selection for the field and the means to change or enter
data into the field.
Field Selection Key Data Entry
Center Frequency CENTER 0-9, "." to directly enter a value; Í
and ÎSPINNER to scroll ENTER or
MHz to complete
Frequency Span SPAN SPINNER to scroll
Reference Level REF LVL SPINNER to scroll
Markers MKR SPINNER to select #1 or #2; Îto edit
selected marker; ENTER or MHz to
complete
Delta Marker ΔMKR ΔMARK to select Delta mode; MARK
to end Delta Mode
Memory Storage /
Recall MEMORY SPINNER select Recall or Save; Îto
edit Recall / Save number; SPINNER
scrolls numbers; ENTER to complete
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

GSP-810 User Manual
12
Field Selection Key Data Entry
Resolution Bandwidth RBW SPINNER to scroll
(SPAN OF 0 Hz / div ONLY)
Demodulation (Optional
Receiver) SHIFT , DEMOD SPINNER to select demod type
Power Meter (Optional) SHIFT , PWR MTR SPINNER selects change line;
Íor Îto select an item; SPINNER
to scroll
Tracking Generator
(Optional) SHIFT , TRK GEN SPINNER selects change line;
Íor Îto select an item; SPINNER
to scroll
Marker to Peak SHIFT , PK ÎMKR No data to enter
Marker to Center
Frequency SHIFT , MKR ÎCF No data to enter
Trace Functions SHIFT , TRACE SPINNER select trace item; Íor Î
change value or turn function ON /
OFF
Setup Functions SHIFT , SETUP SPINNER select setup item; Íor Î
change value or turn function ON /
OFF
Table 1 - Data field selection and entry.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

GSP-810 User Manual
13
CENTER FREQ
This field is the value for the frequency located at the mid-point (center screen) of
the selected span. This frequency value may be changed by entering the digits,
decimal point, followed by the ENTER or MHz key, or the Íand Îkeys can
select a digit to increment or decrement using the SPINNER.
The range of valid entries is 0.010MHz to 1000.000MHz. Setting the Center
Frequency may change the Span field if the span must be lowered to include the
desired frequency. For example, if the Span is set to 100MHz/div and the Center
Frequency is changed to 50MHz, the span will change from 100 MHz/div to 10
MHz/div.
CENTER
SPAN REF LVL
RBW
7
8
.
6
SHIFT
PK->MKR
MKR->CF
SETUP
TRACE
MKR
MKR
E
N
T
E
R
MHz
dBm
4 5
2
1
0
3
9
-
SPAN
CENTER
REF LVL
DEMOD
MEM
TRK GEN
RBW
PWR MTR.
500.000MHz 20 dBm
100 MHz/div 4 MHz
500.000MHz 20 dBm
100MHz/div 4 MHz
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

GSP-810 User Manual
14
SPAN
This field is the value for the frequency range covered by the GSP-810 as it
sweeps its receiver. This span value may be changed by the SPINNER to roll
through the list of valid spans.
The range of valid entries is 2 kHz / division through 100 MHz / division plus zero
span (0 Hz / div). If changing SPAN will cause Center Frequency to change, the
“Limt” message will appear on LCD. It means that the SPAN has exceeded the
frequency range for Center Frequency setting. For example, if the Center
Frequency is 25MHz and the Span is changed from 5MHz to 10MHz, a “Limt” will
appear because the start frequency of span has exceeded the frequency range of
GSP810.
CENTER
SPAN RBW
7
8
.
6
SHIFT
PK->MKR
MKR->CF
SETUP
TRACE
MKR
MKR
E
N
T
E
R
MHz
dBm
4 5
2
1
0
3
9
-
SPAN
CENTER
REF LVL
DEMOD
MEM
TRK GEN
RBW
PWR MTR.
500.000MHz 20 dBm
100MHz/div 4 MHz
500.000MHz 20 dBm
100MHz/div 4 MHz
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

GSP-810 User Manual
15
CENTER
SPAN REF LVL
RBW
7
8
.
6
SHIFT
PK->MKR
MKR->CF
SETUP
TRACE
MKR
MKR
E
N
T
E
R
MHz
dBm
4 5
2
1
0
3
9
-
SPAN
CENTER
REF LVL
DEMOD
MEM
TRK GEN
RBW
PWR MTR.
500.000MHz 20 dBm
0MHz/div 4 MHz
500.000MHz 20dBm
0MHz/div 4 MHz
REF LVL
This field is the value (on the top of screen) for the received input signal. This
reference level value may be changed by the rotating the SPINNER to scroll
through the list of valid reference levels.
The range of valid entries is +20 dBm to -30 dBm in 10 dB steps.
RBW
This field sets the Resolution Bandwidth. The RBW will be set to the optimum
automatically every time when SPAN selection is changed. Afterward RBW can be
set by rotating the SPINNER to scroll through the list of valid RBWs. It has been
under “Amplitude Uncalibrated” status when the “ * ” sign is appeared in front of the
RBW range.
CENTER
SPAN REF LVL
RBW
7
8
.
6
SHIFT
PK->MKR
MKR->CF
SETUP
TRACE
MKR
MKR
E
N
T
E
R
MHz
dBm
4 5
2
1
0
3
9
-
SPAN
CENTER
REF LVL
DEMOD
MEM
TRK GEN
RBW
PWR MTR.
500.000MHz 20 dBm
100MHz/div 4 MHz
500.000MHz 20 dBm
100MHz/div 4 MHz
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

GSP-810 User Manual
16
MARKERS
The GSP-810 supports 2 markers. To access the marker screen, press the MRK
key. Displayed will be 2 marker frequencies. Accessing the marker frequency
fields is performed through the left column of numbers. Cursor to the left most
position, then use the SPINNER to switch between marker 1 and marker 2.
Pressing ENTER will also switch between the 2 marker fields. The frequency
value may be changed by entering the digits, decimal point, followed by the
ENTER key, or the Íand Îkeys can select a digit within a marker to increment
or decrement by using the SPINNER. The valid range of entries is 0.000 MHz to
1150.000 MHz.
A marker will appear on the CRT when the marker frequency selected falls within
the range of frequencies defined by the main screen Center Frequency and Span.
For example, if the center frequency selected is 100.000 MHz and the span is 1
MHz per division, a marker will appear on the screen if the marker frequency is
anywhere between 95 MHz and 105 MHz. When the marker is displayed on the
CRT, the signal level at the location of the marker will be displayed to the right of
the marker frequency. This level will continuously update while in the marker
screen. If the marker frequency is outside the range of frequencies for a given
Center Frequency and Span, a message will indicate its status. If the marker
frequency is too high to be displayed on the CRT, instead of the marker level, “Off
(high)” will be displayed. If the marker frequency is too low, then “Off (low)” will be
displayed. If the Markers are disabled, then “OFF” is displayed. To disable the
markers, simply press the Marker key while in the markers sub-screen.
If the markers are enabled, their position on the CRT will be updated on each
Center Frequency change and each Span change. If a Center Frequency or Span
is selected such that the marker moves off the CRT screen, they will be off until the
parameter is changed to allow the marker to re-appear.
The resolution of the marker on the screen is based on the span selected. There
are 50 positions between major divisions on the CRT that a marker can be moved
to. In the 100 MHz/div Span, for example, every 2 MHz will move the marker 1
position. On the outside edges of the trace, however, the maximum and minimum
marker positions are considered out of range.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

GSP-810 User Manual
17
PK->MKR
This is a peak search function. Using marker 1, the GSP-810 begins at the current
marker 1 frequency and scans for a peak. When a peak is found in the trace, the
marker frequency is updated to show the frequency of the signal and the level of
the peak is also displayed. If no peak is found (that is greater in frequency than the
current marker position), the marker stops at the end of the trace. Another press of
the PK->MKR key will start a new search from the frequency point at the left-most
edge of the span. If the marker is not active, it will be activated and a new search
will begin from the frequency point at the left-most edge of the span. If the marker
is active but the bottom half of the LCD display does not show the marker, the peak
function will still complete and the marker on the CRT can be viewed.
CENTER
SPAN REF LVL
RBW
7
8
.
6
SHIFT
PK->MKR
MKR->CF
SETUP
TRACE
MKR
MKR
E
N
T
E
R
MHz
dBm
4 5
2
1
0
3
9
-
SPAN
CENTER
REF LVL
DEMOD
MEM
TRK GEN
RBW
PWR MTR.
100.000MHz 20dBm
1 MHz/div 220kHz
1 : 95.000 - 51.7dBm
2 : 105.000 - 51.2dBm
100.000MHz 20dBm
1MHz/div 220kHz
1: 95.000 - 51.7dBm
2: 105.000 - 51.2dBm
CENTER
SPAN REF LVL
RBW
7
8
.
6
SHIFT
PK->MKR
MKR->CF
SETUP
TRACE
MKR
MK
R
E
N
T
E
R
MHz
dBm
4 5
2
1
0
3
9
-
SPAN
CENTER
REF LVL
DEMOD
MEM
TRK GEN
RBW
PWR MTR.
100.000MHz 20dBm
1 MHz/div 220kHz
1 : 95.000 - 51.7dBm
2 : 105.000 - 51.2 dBm
100.000MHz 20dBm
1MHz/div 220kHz
1: 95.000 - 51.7dBm
2: 105.000 - 51.2dBm
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

GSP-810 User Manual
18
DELTA MARKERS
The delta marker function is similar to the marker function. To access the marker
screen, press the ΔMKR key. In this function marker 1 is used as the reference
marker level and the marker 2 level is level difference between marker 1 and
marker 2. In the meantime, a “Δ” symbol will also be displayed on the LCD display.
MKR->CF
This function moves the Center Frequency to the current Marker 1 frequency. This
will occur even if the marker is OFF. The span may be adjusted as required for the
Center Frequency. It has no effect if the current span selection is zero span.
CENTER
SPAN REF LVL
RBW
7
8
.
6
SHIFT
PK->MKR
MKR->CF
SETUP
TRACE
MKR
MKR
E
N
T
E
R
MHz
dBm
4 5
2
1
0
3
9
-
SPAN
CENTER
REF LVL
DEMOD
MEM
TRK GEN
RBW
PWR MTR.
100.000MHz 20dBm
1 MHz/div 220kHz
1 : 95.000 - 51.7dBm
2 : 105.000 - 12.5dBm
100.000MHz 20dBm
1MHz/div 220kHz
1: 95.000 - 51.7dBm
2: 105.000 - 12.0dBm
CENTER
SPAN REF LVL
RBW
7
8
.
6
SHIFT
PK->MKR
MKR->CF
SETUP
TRACE
MKR
MKR
E
N
T
E
R
MHz
dBm
4 5
2
1
0
3
9
-
SPAN
CENTER
REF LVL
DEMOD
MEM
TRK GEN
RBW
PWR MTR.
95.000MHz 20dBm
1 MHz/div 220kHz
1 : 95.000 - 11.7dBm
2 : 105.000 OFF(High)
95.000MHz 20dBm
1MHz/div 220kHz
1: 95.000 - 11.7dBm
2: 105.000 OFF(High)
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]
