GW Instek PSW-Multi Series User manual

Multi-Range DC Power Supply
PSW-Multi Series
USER MANUAL
ISO-9001 CERTIFIED MANUFACTURER

This manual contains proprietary information, which is protected by
copyright. All rights are reserved. No part of this manual may be
photocopied, reproduced or translated to another language without
prior written consent of Good Will company.
The information in this manual was correct at the time of printing.
However, Good Will continues to improve products and reserves the
rights to change specification, equipment, and maintenance
procedures at any time without notice.
Good Will Instrument Co., Ltd.
No. 7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan.

Table of Contents
3
Table of Contents
SAFETY INSTRUCTIONS ....................................................5
GETTING STARTED ............................................................8
PSW-Multi Series Overview....................................... 10
Appearance............................................................... 21
Theory of Operation ................................................. 28
OPERATION.....................................................................42
Set Up ...................................................................... 43
Basic Operation ........................................................ 61
Test Scripts ............................................................... 72
CONFIGURATION ............................................................83
Configuration ........................................................... 84
ANALOG CONTROL ....................................................... 100
Analog Remote Control Overview ........................... 101
Remote Monitoring ................................................ 117
COMMUNICATION INTERFACE ..................................... 122
Interface Configuration ........................................... 123
MAINTENANCE ............................................................. 138
FAQ ............................................................................... 140
APPENDIX ..................................................................... 142
PSW-Multi Web Control Description ....................... 143
PSW-Multi Default Settings .................................... 153
Error Messages & Messages................................... 155
LED Display Format................................................ 155

PSW-Multi Series User Manual
4
Specifications ......................................................... 156
PSW-Multi Dimensions ........................................... 162
Certificate Of Compliance ....................................... 166
INDEX............................................................................ 167

SAFETY INSTRUCTIONS
5
SAFETY INSTRUCTIONS
This chapter contains important safety
instructions that you must follow during
operation and storage. Read the following before
any operation to insure your safety and to keep
the instrument in the best possible condition.
Safety Symbols
These safety symbols may appear in this manual or on the
instrument.
WARNING
Warning: Identifies conditions or practices that
could result in injury or loss of life.
CAUTION
Caution: Identifies conditions or practices that
could result in damage to the PSW-Multi or to
other properties.
DANGER High Voltage
Attention Refer to the Manual
Protective Conductor Terminal
Earth (ground) Terminal

PSW-Multi Series User Manual
6
Do not dispose electronic equipment as unsorted
municipal waste. Please use a separate collection
facility or contact the supplier from which this
instrument was purchased.
Safety Guidelines
General
Guideline
CAUTION
Do not place any heavy object on the PSW-
Multi.
Avoid severe impact or rough handling that
leads to damaging the PSW-Multi.
Do not discharge static electricity to the PSW-
Multi.
Use only mating connectors, not bare wires, for
the terminals.
Do not block the cooling fan opening.
Do not disassemble the PSW-Multi unless you
are qualified.
Power Supply
WARNING
AC Input voltage rating: 100Vac-240Vac +/-10%
Frequency: 47Hz~63Hz
To avoid electrical shock connect the protective
grounding conductor of the AC power cord to
an earth ground.
Cleaning the
PSW-Multi
Disconnect the power cord before cleaning.
Use a soft cloth dampened in a solution of mild
detergent and water. Do not spray any liquid.
Do not use chemicals containing harsh material
such as benzene, toluene, xylene, and acetone.
Operation
Environment
Location: Indoor, no direct sunlight, dust free,
almost non-conductive pollution (Note below)
Relative Humidity: 20%~ 85%
Altitude: < 2000m

SAFETY INSTRUCTIONS
7
Temperature: 0°C to 50°C
Mains supply voltage fluctuations: +/-10 %
Overvoltage category: OVC II
If the equipment is used in a manner not
specified by the manufacturer, the protection
provided by the equipment may be impaired.
LAN, RS232/RS485, USB, and GPIB ports are
only to be connected to the circuits which are
separated from mains supply by double /
reinforce insulation.
(Pollution Degree) EN 61010-1 and EN 61010-2-030 specify the
pollution degrees and their requirements as follows. The PSW falls
under degree 2.
Pollution refers to “addition of foreign matter, solid, liquid, or
gaseous (ionized gases), that may produce a reduction of dielectric
strength or surface resistivity”.
Pollution degree 1: No pollution or only dry, non-conductive
pollution occurs. The pollution has no influence.
Pollution degree 2: Normally only non-conductive pollution
occurs. Occasionally, however, a temporary conductivity caused
by condensation must be expected.
Pollution degree 3: Conductive pollution occurs, or dry, non-
conductive pollution occurs which becomes conductive due to
condensation which is expected. In such conditions, equipment
is normally protected against exposure to direct sunlight,
precipitation, and full wind pressure, but neither temperature
nor humidity is controlled.
Storage
environment
Location: Indoor
Temperature: -25°C to 70°C
Relative Humidity: <90%, no condensation
Disposal
Do not dispose this instrument as unsorted
municipal waste. Please use a separate collection
facility or contact the supplier from which this
instrument was purchased. Please make sure
discarded electrical waste is properly recycled to
reduce environmental impact.
All hazardous wiring must be immediately destroyed and replaced
in accordance to the above standard.

PSW-Multi Series User Manual
8
GETTING STARTED
This chapter describes the power supply in a
nutshell, including its main features and front /
rear panel introduction. After going through the
overview, please read the theory of operation to
become familiar with the operating modes,
protection modes and other safety considerations.
PSW-Multi Series Overview.......................................10
Series lineup .................................................................................... 10
Dual Channel model................................................................ 11
Triple Channel model.............................................................. 12
Main Features ................................................................................. 17
Accessories...................................................................................... 18
PSW 30/40/80/160 Accessories........................................... 18
PSW 250/800 Accessories...................................................... 19
Appearance ...............................................................21
PSW-Multi Front Panel ................................................................. 21
PSW-720 ................................................................................... 21
PSW-1080 ................................................................................. 21
PSW-Multi Rear Panel (low voltage models).............................. 24
PSW-720 ................................................................................... 24
PSW-1080 ................................................................................. 24
PSW-Multi Rear Panel (high voltage models) ............................ 25
PSW-720 ................................................................................... 25
PSW-1080 ................................................................................. 25
Theory of Operation..................................................28
Operating Area Description ......................................................... 28

GETTING STARTED
9
CC and CV Mode........................................................................... 30
Slew Rate ......................................................................................... 32
Bleeder Control .............................................................................. 32
Sink Current Table ......................................................................... 34
Internal Resistance ......................................................................... 36
Alarms.............................................................................................. 37
Considerations ................................................................................ 37
Grounding....................................................................................... 40

PSW-Multi Series User Manual
10
PSW-Multi Series Overview
Series lineup
The PSW-Multi series consists of 37 models divided into 2 output
terminal type (Busbar and connector type) with 2 different size
model types (PSW-720 and PSW-1080). The PSW-720 is 2 channel
output type and PSW-1080 is 3 channel output type. The models of
busbar output type are PSW 30, PSW 40, PSW 80 and PSW160 and
connector type are PSW 250 and PSW 800.
Note
Throughout the user manual, PSW 30, PSW 40, PSW
80, PSW 160, PSW 250, PSW 800 will refer to any of
the PSW models with a maximum voltage rating of
30V, 40V, 80V, 160V, 250V or 800V, respectively.
Each channel of PSW-Multi series doesn't support
serial or parallel operation.

GETTING STARTED
11
Dual Channel model
Model name
Output
Voltage Rating
Current Rating
Output Type
PSW-720L11
CH1
0-30V
0-36A
BusBar
CH2
0-30V
0-36A
PSW-720L12
CH1
0-30V
0-36A
CH2
0-40V
0-27A
PSW-720L14
CH1
0-30V
0-36A
CH2
0-80V
0-13.5A
PSW-720L15
CH1
0-30V
0-36A
CH2
0-160V
0-7.2A
PSW-720L22
CH1
0-40V
0-27A
CH2
0-40V
0-27A
PSW-720L24
CH1
0-40V
0-27A
CH2
0-80V
0-13.5A
PSW-720L25
CH1
0-40V
0-27A
CH2
0-160V
0-7.2A
PSW-720L44
CH1
0-80V
0-13.5A
CH2
0-80V
0-13.5A
PSW-720L45
CH1
0-80V
0-13.5A
CH2
0-160V
0-7.2A
PSW-720L55
CH1
0-160V
0-7.2A
CH2
0-160V
0-7.2A
PSW-720H66
CH1
0-250V
0-4.5A
Connector
CH2
0-250V
0-4.5A
PSW-720H68
CH1
0-250V
0-4.5A
CH2
0-800V
0-1.44A
PSW-720H88
CH1
0-800V
0-1.44A
CH2
0-800V
0-1.44A

PSW-Multi Series User Manual
12
Triple Channel model
Model name
Output
Voltage Rating
Current Rating
Output Type
PSW-1080L111
CH1
0-30V
0-36A
BusBar
CH2
0-30V
0-36A
CH3
0-30V
0-36A
PSW-1080L112
CH1
0-30V
0-36A
CH2
0-30V
0-36A
CH3
0-40V
0-27A
PSW-1080L114
CH1
0-30V
0-36A
CH2
0-30V
0-36A
CH3
0-80V
0-13.5A
PSW-1080L115
CH1
0-30V
0-36A
CH2
0-30V
0-36A
CH3
0-160V
0-7.2A
PSW-1080L122
CH1
0-30V
0-36A
CH2
0-40V
0-27A
CH3
0-40V
0-27A
PSW-1080L124
CH1
0-30V
0-36A
CH2
0-40V
0-27A
CH3
0-80V
0-13.5A
PSW-1080L125
CH1
0-30V
0-36A
CH2
0-40V
0-27A
CH3
0-160V
0-7.2A
PSW-1080L144
CH1
0-30V
0-36A
CH2
0-80V
0-13.5A
CH3
0-80V
0-13.5A
PSW-1080L145
CH1
0-30V
0-36A
CH2
0-80V
0-13.5A
CH3
0-160V
0-7.2A
PSW-1080L155
CH1
0-30V
0-36A
CH2
0-160V
0-7.2A
CH3
0-160V
0-7.2A

GETTING STARTED
13
PSW-1080L222
CH1
0-40V
0-27A
BusBar
CH2
0-40V
0-27A
CH3
0-40V
0-27A
PSW-1080L224
CH1
0-40V
0-27A
CH2
0-40V
0-27A
CH3
0-80V
0-13.5A
PSW-1080L225
CH1
0-40V
0-27A
CH2
0-40V
0-27A
CH3
0-160V
0-7.2A
PSW-1080L244
CH1
0-40V
0-27A
CH2
0-80V
0-13.5A
CH3
0-80V
0-13.5A
PSW-1080L245
CH1
0-40V
0-27A
CH2
0-80V
0-13.5A
CH3
0-160V
0-7.2A
PSW-1080L255
CH1
0-40V
0-27A
CH2
0-160V
0-7.2A
CH3
0-160V
0-7.2A
PSW-1080L444
CH1
0-80V
0-13.5A
CH2
0-80V
0-13.5A
CH3
0-80V
0-13.5A
PSW-1080L445
CH1
0-80V
0-13.5A
CH2
0-80V
0-13.5A
CH3
0-160V
0-7.2A
PSW-1080L455
CH1
0-80V
0-13.5A
CH2
0-160V
0-7.2A
CH3
0-160V
0-7.2A
PSW-1080L555
CH1
0-160V
0-7.2A
CH2
0-160V
0-7.2A
CH3
0-160V
0-7.2A

PSW-Multi Series User Manual
14
PSW-1080H666
CH1
0-250V
0-4.5A
Connector
CH2
0-250V
0-4.5A
CH3
0-250V
0-4.5A
PSW-1080H668
CH1
0-250V
0-4.5A
CH2
0-250V
0-4.5A
CH3
0-800V
0-1.44A
PSW-1080H688
CH1
0-250V
0-4.5A
CH2
0-800V
0-1.44A
CH3
0-800V
0-1.44A
PSW-1080H888
CH1
0-800V
0-1.44A
CH2
0-800V
0-1.44A
CH3
0-800V
0-1.44A
Apart from the differences in output type, each unit differs at
output channels and voltage. The PSW-720 is two channel output
and PSW-1080 is three channel output.

GETTING STARTED
15
PSW-Multi 2-channel modules with low voltage models.
A
W
V
W
%W10080604020
ISR
C C
DLY
ALM
RMT
C V
VSR
Function OVP/OCP Set Output
PWR DSPLLock/LocalTest
PS W 30-3 6 360W
Voltage
Current
Multi-Range DC Power Supply
A
W
V
W
%W10080604020
ISR
C C
DLY
ALM
RMT
C V
VSR
Function OVP/OCP Set Output
PWR DSPLLock/LocalTest
PS W 80-1 3.5 360W
Voltage
Current
Multi-Range DC Power Supply
LAN 240VAC 100
63Hz 1000VA MAX.47
LAN 240VAC 100
63Hz 1000VA MAX.47
PSW-Multi 2-channel modules with high voltage models.
A
W
V
W
%W10080604020
ISR
C C
DLY
ALM
RMT
C V
VSR
Function OVP/OCP Set Output
PWR DSPLLock/LocalTest
PS W 250- 4.5 360W
Voltage
Current
Multi-Range DC Power Supply
A
W
V
W
%W10080604020
ISR
C C
DLY
ALM
RMT
C V
VSR
Function OVP/OCP Set Output
PWR DSPLLock/LocalTest
PS W 800- 1.44 360W
Voltage
Current
Multi-Range DC Power Supply
V
V
S N.C. SV
VS N.C. SV
LAN 240VAC 100
63Hz 1000VA MAX.47
LAN 240VAC 100
63Hz 1000VA MAX.47

PSW-Multi Series User Manual
16
PSW-Multi 3-channel modules with low voltage models.
A
W
V
W
%W10080604020
ISR
C C
DLY
ALM
RMT
C V
VSR
Function OVP/OCP Set Output
PWR DSPLLock/LocalTest
PSW 3 0-3 6 360W
Voltage
Current
Multi-Range DC Power Supply
A
W
V
W
%W10080604020
ISR
C C
DLY
ALM
RMT
C V
VSR
Function OVP/OCP Set Output
PWR DSPLLock/LocalTest
PSW 8 0-1 3.5 360W
Voltage
Current
A
W
V
W
%W10080604020
ISR
C C
DLY
ALM
RMT
C V
VSR
Function OVP/OCP Set Output
PWR DSPLLock/LocalTest
PSW 8 0-1 3.5 360W
Voltage
Current
Multi-Range DC Power SupplyMulti-Range DC Power Supply
LAN
240VAC 10063Hz47
1500VA MAX.
LAN
240VAC 10063Hz47
1500VA MAX.
NL
PSW-Multi 3-channel modules with high voltage models.
A
W
V
W
%W10080604020
ISR
C C
DLY
ALM
RMT
C V
VSR
Function OVP/OCP Set Output
PWR DSPLLock/LocalTest
PSW 2 50- 4.5 360W
Voltage
Current
Multi-Range DC Power Supply
A
W
V
W
%W10080604020
ISR
C C
DLY
ALM
RMT
C V
VSR
Function OVP/OCP Set Output
PWR DSPLLock/LocalTest
PSW 8 00- 1.44 360W
Voltage
Current
A
W
V
W
%W10080604020
ISR
C C
DLY
ALM
RMT
C V
VSR
Function OVP/OCP Set Output
PWR DSPLLock/LocalTest
PSW 8 00- 1.44 360W
Voltage
Current
Multi-Range DC Power SupplyMulti-Range DC Power Supply
LAN
240VAC 10063Hz47
1500VA MAX.
LAN
240VAC 10063Hz47
1500VA MAX.
NL
VS N.C. SV VS N.C. SV
VS N.C. SV

GETTING STARTED
17
Main Features
Performance
High performance/power
Power efficient switching type power supply
Low impact on load devices
Fast transient recovery time of 1ms
Fast output response time
Features
OVP, OCP and OHP (OTP) protection
Adjustable voltage and current slew rates
User adjustable bleeder control to quickly
dissipate the power after shutdown to safe
levels.
Extensive remote monitoring and control
options
Power on configuration settings.
Supports test scripts
Web server monitoring and control
Interface
Ethernet port
Analog connector for analog voltage and current
monitoring
USB host and device port

PSW-Multi Series User Manual
18
Accessories
Please check the contents before using the PSW-Multi.
PSW 30/40/80/160 Accessories
Standard Accessories
Part number
Description
Power cord (PSW-720)
Power cord (PSW-1080)
Output terminal Cover (per channel)
GTL-123
Test leads: 1x red, 1x black (per
channel)
GTL-240
USB Cable
PSW-004
Basic Accessory Kit (per channel):
M4 terminal screws and washers x2,
M8 terminal bolts, nuts and washers
x2, Air filter x1, Analog control
protection dummy x1, Analog control
lock level x1
Optional Accessories
Part number
Description
GET-001
Extended terminal with max. 30A
GET-005
Extended European terminal with
max. 20A
PSW-001
Accessory Kit:
Pin contact x10, Socket x1, Protection
cover x1
PSW-002
Simple IDC Tool
PSW-003
Contact Removal Tool
GRA-410-J
Rack mount adapter (JIS)

GETTING STARTED
19
GRA-410-E
Rack mount adapter (EIA)
GUG-001
GPIB to USB adapter
GTL-240
USB Cable
GUR-001A
RS-232 to USB adapter with M3 rivet
nut
GUR-001B
RS-232 to USB adapter with #4-40
UNC rivet nut
Download
Name
Description
PSW-Multi_cdc.inf
USB driver
PSW 250/800 Accessories
Standard Accessories
Part number
Description
Power cord (PSW-720)
Power cord (PSW-1080)
High voltage output terminal
(per channel)
GTL-240
USB Cable
High voltage output terminal
(per channel)
PSW-008
Basic Accessory Kit (per channel):
(Air filter x1, Analog control
protection dummy x1, Analog control
lock level x1
Optional Accessories
Part number
Description
GET-002
Extended terminal with max. 10A
PSW-001
Accessory Kit:
Pin contact x10, Socket x1, Protection
cover x1
PSW-002
Simple IDC Tool

PSW-Multi Series User Manual
20
PSW-003
Contact Removal Tool
GRA-410-J
Rack mount adapter (JIS)
GRA-410-E
Rack mount adapter (EIA)
GTL-130
Test leads: 2x red, 2x black
GUG-001
GPIB to USB adapter
GTL-240
USB Cable
GUR-001A
RS-232 to USB adapter with M3 rivet
nut
GUR-001B
RS-232 to USB adapter with #4-40
UNC rivet nut
Download
Name
Description
PSW-Multi_cdc.inf
USB driver
