Habitat 792/3616 User manual

Issue 1 - 16/09/20
Spare Parts
www.argos-support.co.uk
[e-mail]
0370 112 1928
Customer Support
0345 640 2020

1
Safety and Care Advice
Product Details
GV Sideboard
792/3616 Oak
759/8089 Black
759/7987 White
Keep children and animals
away from the work area, small
parts could choke if swallowed.
Make sure you have enough space
to layout the parts before
starting.
Care and maintenance
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY.
Only clean using a damp cloth
and mild detergent. Do not use
abrasive cleaners.
Use a dry cloth to clean the
product, furniture polish is
not recommended.
•From time to time check that there
are no loose screws, nuts or bolts.
If there are please re-tighten.
This product should not be
discarded with household
waste. Take to your local
authority waste disposal
centre.
Additional Guidance
●Assemble all parts and bolts loosely during assembly, only once the product is complete should you
fully tighten the bolts.
●Regularly check and ensure that all bolts and fittings are tighten properly.
●This product is compliant BS4875-7 level 3
•This product has been
constructed to be used in the
domestic environment only and
not for commercial purposes.
Assemble on a soft level
surface to avoid damaging the
Assemble the item as close
room) as possible.
Sainsbury's Argos is a trading name of both: Argos Limited, Registered office: 489-499 Avebury Boulevard, Milton Keynes, United
Kingdom, MK9 2NW, registered number: 01081551 (England and Wales); and Sainsbury's Supermarkets Limited, Registered
office: 33 Holborn, London, EC1N 2HT, registered number: 03261722 (England and Wales). Both companies are subsidiaries of J
We do not
recommend the
use of power
drill/drivers for
inserting screws
as this could damage the unit.
Only use hand screwdrivers.
Parts of the assembly will be
easier with 2 people.
Dispose of all packaging
carefully and responsibly.
WARNING
In order to prevent overturning this product must be used with the wall attachment device provided.

2
Fittings (Shown to scale)
Bag 1
E
4 x 14.5mm Screw x 8
G
15 x 12mm Locking Nut x 8
D
3.5 x 15mm Screw x 16
F
Plastic Support x 3
I
4 x 18mm Shelf Support x 4
B
6 x 30mm Dowel x 4
A
7 x 39mm Locking Pin x 8
C
4 x 33mm Screw x 2
M
7 x 1.5mm Door Pad x 2
J
4 x 12mm Support Cover x 4
L
Handle x 2
O
Wall Strap x 2
H
1.2 x 20mm Nail x 16
K
4 x 30mm Screw x 2
N
Wall Plug x 2
Hardware
R
Door Hinge x 4
SCR07039
SCR03015
FIT1512000
PGP0412
PAD0701501 CAP070350 ELSRING10015
SCR04030 HRP24239
ELSNAIL PGM0418
SCR04014 TRI
PGW0630 SCR04033
HIG0900048354F

3
Phillips screwdriver
(small & medium)
Phillips screwdriver
(small & medium) Eye protection
(when using a
hammer or glue)
Small
hammer
Large hammer
Pencil
Mallet
Set Square
Spirit Level
Ruler/tape
measure
Power Drill
Drill Heads
Tools required

4
Back Panel (794 x 686mm)
9
Shelf (768 x 378mm)
8
Panels
1Top (800 x400mm)
7Bottom Panel (768 x 378mm)
2Left (399 x 732mm)
3Right (399 x 732mm)
4Left Door
(379 x 666mm)
6Bottom support (768 x 60mm)
5Right Door
(379 x 666mm)

5
B
DD
R
DD
D
R
B
A
A
A
A
B
R
R
R
D
DD
DD
D
D
R
A
A
R
Door Hinge x 4
1
2
E
4 x 14.5mm Screw x 8
G
7 x 39mm Locking Pin x 15
D
3.5 x 15mm Screw x 16
F
Plastic Support x 3
I
4 x 18mm Shelf Support x 4
B
6 x 30mm Dowel x 4
A
7 x 39mm Locking Pin x 8
C
4 x 33mm Screw x 2
M
7 x 1.5mm Door Pad x 2
J
4 x 12mm Support Cover x 4
L
Handle x 4
O
Wall Strap x 2
H
1.2 x 20mm Nail x 16
K
4 x 30mm Screw x 2
N
Wall Plug x 2
A
7 x 39mm Locking Pin x 4
B
6 x 30mm Dowel x 2
D
3.5 x 15mm Screw x 8
2
3
2
3

6
3
4
E
E
B
B
E
F
F
FF
F
F
E
E
E
F
E
4 x 14.5mm Screw x 6
F
Plastic Support x 3
B
6 x 30mm Dowel x 2
A
A
A
A
A
A
A
7 x 39mm Locking Pin x 4
E
F
E
7
6
6
1

5
6
G
15 x 12mm Locking Nut x 4
G
15 x 12mm Locking Nut x 4
G
G
Unfinished edge
G
G
G
G
G
G
G
Unfinished edge
2
2
3
3
1
7

7H
1.2 x 20mm Nail x 16
8I
4 x 18mm Shelf Support x 4
J
4 x 12mm Support cover x 4
I
J
M
7 x 1.5mm Door Pad x 2
J
M
MM
M
I
IJ
H
Unfinished surface
JI
3
9
7
3
2
8
Rotate
Product

9
10
C
D
3.5 x 15mm Screw x 8
L
Handle x 2
K
4 x 30mm Screw x 2
R
Door Hinge x 4
Press to Unclip
If need be,
rotating screw
clockwise while
hard to mount
on plate
Mount on plate
A
B
C
DD
DD
DDD
D
R
R
R
L
L
K
K
R
R
DD
4
5
3
2
4
5
