Habitat Radius RADI-ED-AW18-B User manual

Assembly Instructions - Please keep for future reference
Dimensions
Important – Please read these instructions before assembly
If you need help or have damaged or missing parts, email:
customer[email protected]o.uk or call: 0344 499 4686
Radius Extending Dining Table
Width - 160 / 260cm
Depth- 90cm
Height - 74cm
1 2 1
RADI-ED-AW18-B

Safety and Care Advice
Important – Please read these instructions fully before starting assembly
If for any reason you should have
problems with your Habitat product,
please contact the store from which
you purchased it.
Please retain your receipt as proof of
purchase.
If you have any comments or
suggestions regarding this product,
assembly instructions or service
received, please contact the store or
Habitat Head Office via its website:
www.habitat.co.uk
or write directly to: Habitat Retail Ltd.
489-499 Avebury Boulevard,
Milton Keynes MK9 2NW
General information
Check you have all the
components and tools listed on the
front cover and pages 3 - 4.
Remove all fittings from the plastic
bags and separate them into their
groups.
Keep children and animals away
from the work area, small parts
could choke if swallowed.
Make sure you have enough space
to layout the parts before starting.
Do not stand or put weight on the
product, this could cause damage.
Assemble the item as close to its
final position (in the same room) as
possible.
Do not place furniture directly in
front of radiators, fires or any other
source of heat.
Parts of the assembl y
will be easier with 2
people.
Assemble on a soft level surface
to avoid damaging the unit or your
floor.
We do not
recommend the
use of power drill/
drivers for inserting
screws, as this c ould
damage the unit. Only use hand
screwdrivers.
Dispose of all packaging carefully
and responsibly.
Take care when moving furniture -
dragging it across the oor will
loosen and damage the joints.
Always lift and move.
General care and maintenance
Cleaning and care
1 2
Important: Recommended
maximum load shown below
Maximum weight limit
2
From time to time check that there
are no loose ttings.
Tighten as necessary.
Avoid exposing your furniture to direct
and prolonged periods of sunlight and
heat sources as fading and
cracking may occur.
Take care to prevent sharp objects
e.g. toys, buckles and heels from
coming into contact with your
furniture, and avoid contact with
chemicals e.g. cosmetics or hair
products which may permanently
mark the surface.
Dust regularly with a clean dry cloth.
Wipe up any spills immediately with a damp cloth and then dry
the surface with a clean dry duster.
Repeat this procedure for periodic cleaning.
Remove stubborn stains with a weak washing up liquid solution
and a damp cloth and dry after with a clean cloth.
The use of furniture polish or spray is not necessary or recommended.
Never use abrasive or corrosive cleaning agents.
Always use place mats and coasters to protect the surface
from moisture and heat.
Max.
50kg
Max.
30kg

BC Note: There are ‘Batch Code’ lables where shown on the indicated items, these should be retained.
Components - Panels
Please check you have all the panels listed below
If you need help or have damaged or missing parts, email:
customerservic [email protected] o.uk or call:
0344 499 4686
3
1/1
1
2
3
4

Please check you have all the fixings listed below
Note: The quantities below are the correct amount to complete the assembly. In some
cases more fittings may be supplied than are required.
Components - Fittings
A
Ruler - To help correctly identify thefixings
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 11 0 115 120
105
If you need help or have damaged or missing parts, email:
customerservic [email protected] o.uk or call:0344 499 4686
4
B
x 6 moon washer 6
C
metric hex nut xx 6
D
x 1wrench
threaded bolt
x 4metric feet
E
Fittings pack contained in pack 1/1
F
x 8wooden dowel

5
Assembly Instructions
Step 1
1
Ax6
Dx4
3
4
Step 2
Ex8
11
1
2

6
Assembly Instructions
Step 3
1 2 1
1
1
2
2
4Step
RELEASE
ROTATE
STEP 1 STEP 2
2 2
PLEASE NOTE!
Caution when taking out extension to avoid damaging runner
catches.

7
Assembly Instructions
Step 5
Bx6
Cx6
1 2 1
1
4
3
Fx1

8
Assembly Instructions
Step 6
Step 7
1 2 1
TAKE CARE!
NEVER DRAG THE LEGS OF THIS TABLE ON THE FLOOR!
Always extend this table with the help of 2 people - one at each end.
One should hold the non-extending end of the table steadily in place
while the person at the extending end should rst lift the legs o the
oor so they are not dragging, and then gently pull the extending section
of the table out fully.
1 2 1
TAKE CARE!
Carefully line up the guide pins on the extension leaf with the table top.
Then with 1 person holding the stationary end of the table, the person
should lift the legs o the oor and push the extending mechanism in
to lock the extension leaf securely in place.
1
3
4
1
2
3
4
2
1
2
1
PLEASE NOTE!
Before you can slide the extending table top open or closed you
will need to ensure that the locking mechanism is in the open
position.

9
Assembly Instructions
Step 8
LOCK
Step 9
RELEASE
1
2
1
2
PLEASE NOTE!
Don't forget to lock the sliding mechanism after the extension
leaf has been tted.

10
Assembly Instructions
Step 10
LOCK
1
2
2
2
