Habitat Enzo Desk ENZO-DK-AW17-A User manual

Assembly Instructions - Please keep for future reference
Dimensions
Important – Please read these instructions before assembly
If you need help or have damaged or missing parts, email:
customer[email protected]o.uk or call: 0344 499 4686
Enzo Desk
Width - 130cm
Depth - 57cm
Height - 77cm
1 2 1
ENZO-DK-AW17-A

Safety and Care Advice
Important – Please read these instructions fully before starting assembly
If for any reason you should have
problems with your Habitat product,
please contact the store from which
you purchased it.
Please retain your receipt as proof of
purchase.
If you have any comments or
suggestions regarding this product,
assembly instructions or service
received, please contact the store or
Habitat Head Office via its web site:
www.habitat.co.uk
or write directly to: Habitat Retail Ltd.
489-499 Avebury Boulevard,
Milton Keynes MK9 2NW
General information
Check you have all the
components and tools listed on the
front cover and pages 2 - 3.
Remove all fittings from the plastic
bags and separate them into their
groups.
Keep children and animals away
from the work area, small parts
could choke if swallowed.
Make sure you have enough space
to layout the parts before starting.
Do not stand or put weight on the
product, this could cause damage.
Assemble the item as close to its
final position (in the same room) as
possible.
Do not place furniture directly in
front of radiators, fires or any other
source of heat.
Parts of the assembly
will be easier with 2
people.
Assemble on a soft level surface
to avoid damaging the unit or your
floor.
We do not
recommend the
use of power drill/
drivers for inserting
screws, as this could
damage the unit. Only use hand
screwdrivers.
Dispose of all packaging carefully
and responsibly.
Take care when moving furniture - dragging
it across the floor will loosen and damage
the joints.Always lift and move.
General care and maintenance
Dust regularly with a clean dry cloth.
Wipe up any spills immediately with a damp cloth and then
dry the surface with a clean dry duster.
Repeat this procedure for periodic cleaning.
Remove stubborn stains with a weak washing up liquid solution
and a damp cloth and dry after with a clean cloth.
The use of furniture polish or spray is not necessary or recommended.
Never use abrasive or corrosive cleaning agents.
Cleaning of solid wood and wood veneers
1 2
Important:
Maximum weight limit
2
Max.
15kg
30kg
MAX
Recommended maximum
evenly dispersed load is shown below.
5kg
MAX
5kg
MAX
5kg
MAX
From time to time check that there
are no loose fittings. Tighten as necessary.
Avoid exposing your furniture to direct
and prolonged periods of sunlight and
heat sources as fading and cracking
may occur.
Take care to prevent sharp objects e.g. toys,
buckles and heels from coming into contact
with your furniture, and avoid contact with
chemicals e.g. cosmetics or hair products
which may permanently mark the surface.
Always use place mats and coasters to protect the surface
from moisture and heat. Illustration above for information only.
Do not open more than 1 drawer at
a time as this could destabilise the
desk.
Important:

BC Note: There are ‘Batch Code’ lables where shown on the indicated items, these should be retained.
Components - Panels
Please check you have all the panels listed below
If you need help or have damaged or missing parts, email:
customerservic [email protected] o.uk or call: 0844 499 4686
3
1. Box
2. Legs
3. Connector
1 of 1
BC

Please check you have all thefixings listed below
Note: The quantities below are the correct amount to complete the assembly. In some
cases more fittings may be supplied than are required.
Components - Fittings
A
Ruler - To help correctly identify the fixings
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 11 0 115 120
105
If you need help or have damaged or missing parts, email:
customerservic [email protected] o.uk or call: 0844 499 4686
4
B
1 of 1
Allen key x 1 M6x30 Screws x 6
C
Feet xx 4
268341
268342
Wooden dowels 8mm x 4
DE
F
GHI
Cover cap x 2x Locking cams x 3x
Metal dowels x 3x Cover cap x 3x Wall Mounting & Fixing Fittings x 2x

5
Assembly Instructions
Step 1
1
Dx4
Fx3
Connector
Step 2
1
12
180
Gx3
Box
G
1
1

6
Assembly Instructions
Step 3
1
12
Ax1
Bx2
Step 4
B
A
1
12
Ax1
Bx4
B
A
1
2
2
2
2
2
2
3
3
3
Legs

7
Assembly Instructions
Step 5
1
30mm
==
Step 6
Cx4
Ex2
Hx3
Ex2
Cx4
Hx3
1
Ix2
640
635
WARNING!
In order to prevent overturning this product must be used with the wall attachment device provided.
Serious or fatal crushing injuries can occur from furniture tipping over. To help prevent topple over :-
• Use the wall attachment devices provided
• Never allow children to climb or hang on drawers
• Do not overload the drawers beyond maximum recommended loading.
• Place heaviest items in the lower drawers or shelves.
• Unless specifically designed to accommodate, do not set TV's or other heavy objects on top of this product
• Never open more than one drawer at a time
Attachment devices are provided with your product, however you will need to source suitable fixings for your wall type.
If in doubt consult a qualified trades person.
Always ensure that the wall to be drilled into is free from hidden electrical wires, water and gas pipes.
1
2
2
2
3
Ix2

8
Assembly Instructions
Step 7
11
12
180
Step 8
Ix2
Ix2
1
1
2
2
2
2
3

Important note:
Types of walls
Care &
Maintenance
No.1“General Purpose” wall plug
No.6 “Shield Anchor” wall plug Heavy
loads
No.3 “Cavity Fixing” wall plug
No.4 “Cavity Fixing-Heavy Duty” wall
plug
No.5 “Hammer Fixing” wall plug
No.2 “Plasterboard” wall plug
Generally aerated blocks should not
be used to support heavy loads, use
a specialist fitting in this case. For light
loads, general purpose wall plugs can be
used.
For use with heavier loads such as TV &
HiFi speakers and satelite dishes etc.
For use with plasterboard partitions or
hollow wooden doors.
For use when fitting or supporting heavy
loads such as shelving, wall cabinets and
coat racks.
For use with walls stuck with plasterboard.
The hammer fixing allows it to be fixed
to the wall rather than the plasterboard.
Always check the fixing is secure to the
retaining wall.
For use when attaching light loads on to
plasterboard partitions.
Safety: Always check the fitting and
location to ensure your safety in and
around the home.
Fitting: From time to time check
the fitting to ensure the wall plugs
or screws do not become loose.
You can use one of the following types of wall plug if your walls are made
of brick, breeze block, concrete, stone or wood.
Important: When drilling into walls always
check that there are no hidden wires or pipes etc.
Hints:
1: General rule: Always use a larger screw and wall plug
if you are not sure.
2: Ensure you use the recommended drill bit to match the wall
plug and hole size.
3: Ensure you drill the hole horizontally, do not force the drill or
enlarge the hole.
4: Take extra care when drilling high walls, ceilings and ceramic tiles.
Ensure wall plugs are inserted beyond the thickness of the ceramic
tiles to avoid the tiles splitting or cracking.
5: Ensure wall plugs are well fitted and are a tight fit in the
drilled hole.
Wall Fixings: Make sure that the screws and wall plugs being used are suitable
for supporting your unit. Consult a qualified tradesperson if you are
unsure.
- because of the variety of
different wall types, Habitat
cannot provide you with the
exact fixings you will need to
fix this product to the wall.
You must first identify the
type of wall you intend to fix
product onto and then contact
your local hardware store to
get the appropriate fixings.
A Guide to- Wall Mounting & Fixings
