HADEF 28/06 AP-EX Assembly instructions

5.52.132.01.01.08 Rev.08
HADEF Pneumatic Chain Hoist
Type 28/06AP-EX
low headroom configuration
with monorail push travel trolley APR
with monorail hand geared trolley APH
with monorail pneumatic trolley APP
Explosion proof design
II 2G IIB c T4 or II 2D c 135°C
II 2G IIB c T3 or II 2D c 200°C
DANGER!
Not to be used with IIC gases and IIB gases hydrogen sulphide and ethylene oxide and
light metal and shock sensitive dusts.
It is not allowed to use the equipment in area at risk from explosion where gas AND
dust does both exist at the same time!
o
Installation,- Operating and
Maintenance Instructions

2 5.52.132.01.01.08
©by Heinrich de Fries GmbH
Heinrich de Fries GmbH, Gauss Str. 20, D-40235 Düsseldorf
Heinrich De Fries GmbH will be named HADEF in the following text.
Original operating- and maintenance instructions in German language.
Translation in other languages is made of the German original.
A copy may be requested in writing or is available for download on www.hadef.com
Subject to changes.
Table of Contents
1Information..........................................................................................3
1.1Indications to determine the used part of the theoretical usage life............................4
2Safety...................................................................................................4
2.1Warning notice and symbols............................................................................................4
2.2Duty of care of the owner..................................................................................................4
2.3Requirements for the operating personnel.....................................................................5
2.4Appropriate use.................................................................................................................5
2.5Basic safety measures......................................................................................................6
2.6Explosion protection.........................................................................................................8
3Transport and Storage.....................................................................11
3.1Transport..........................................................................................................................11
3.2Safety device for transport.............................................................................................11
3.3Storage .............................................................................................................................11
4Description........................................................................................11
4.1Areas of application ........................................................................................................11
4.2Design...............................................................................................................................11
4.3Functions..........................................................................................................................12
4.4Important components....................................................................................................12
5Technical data...................................................................................14
6Installation.........................................................................................14
6.1Trolley...............................................................................................................................14
6.2Adjusting the gauge........................................................................................................15
6.3Installation on the beam..................................................................................................15
6.4Pressure roller .................................................................................................................16
6.5Chain container installation............................................................................................16
6.6Tools.................................................................................................................................17
7Operation...........................................................................................17
8Operation...........................................................................................18
9Commissioning.................................................................................19
9.1General .............................................................................................................................19
9.2Compressed air connection ...........................................................................................19
9.3Gear...................................................................................................................................20
9.4Load chain........................................................................................................................20
9.5Power operated hoists with chain container:...............................................................20
10Safety check......................................................................................21

5.52.132.01.01.08 3
11Functional test.................................................................................. 21
11.1Checks before the initial start-up...................................................................................21
11.2Functional test.................................................................................................................21
12Maintenance...................................................................................... 21
12.1General.............................................................................................................................21
12.2Monitoring........................................................................................................................22
12.3Replacing the load chain................................................................................................22
12.4Pneumatic motor.............................................................................................................22
12.5Overload protection ........................................................................................................ 23
13Inspection ......................................................................................... 23
13.1General Overhaul for motor-driven units......................................................................23
13.2Periodic checks...............................................................................................................24
13.3Checking the load chain.................................................................................................24
13.4Checking the load hook..................................................................................................25
13.5Inspection – Gear – Oil level ..........................................................................................26
14Service............................................................................................... 26
14.1Load chain .......................................................................................................................26
14.2Pulleys..............................................................................................................................26
14.3Load hook ........................................................................................................................26
14.4Hoist gear.........................................................................................................................27
14.5Trolley...............................................................................................................................28
14.6Pneumatic motor.............................................................................................................28
14.7Lubricant selection .........................................................................................................28
14.8Lubricant for food industry – selection (as option*).................................................... 29
15Trouble .............................................................................................. 29
16Remedy ............................................................................................. 30
17Decommissioning ............................................................................ 31
17.1Temporary decommissioning ........................................................................................ 31
17.2Final decommissioning/disposal...................................................................................31
18Additional documents...................................................................... 31
18.1Pneumatic connections diagram...................................................................................31
1 Information
The products meet European Union requirements, in particular the valided EU Machine Directive.
The entire company works acc. to a certified quality assurance system as per EN ISO 9001.
The production of components at our work is subject to strict, intermediate checks.
After assembly, the products are subject to a final test with overload.
For the operation of hoists, the national accident prevention apply in Germany, amongst others.
Lifting equipment for use in areas prone to explosion complies with current legislation, standards and
regulations and is classified in the applicable Ex-protection class.
The stated performance of the devices and meeting any warranty claims require adherence to all instructions
in this manual.
Before delivery, all products are packed properly. Check the goods after receipt for any damage caused
during transport. Report any damage immediately to the forwarding agent.
This manual serves for safe and efficient use of this hoist. Illustrations serve to explain something and may
differ from the illustration of the existing unit as they only serve as an example.
Documentation of component manufacturers that may be supplied additionally, must be observed, in case of
differences between these documentation and our manuals, the specification of the our manual must be
observed.

4 5.52.132.01.01.08
NOTICE!
We refer to the prescribed equipment tests before initial start-up, before putting back into operation and the
regular periodic inspections.
In other countries any additional national regulations must be observed.
1.1 Indications to determine the used part of the theoretical usage life.
For motor driven units.
The equipment (rope hoists, chain hoists, winches as well as crane hoisting units) are classified in drive
groups (duty classification) according to their intended mode of operation, running times and load collectives
and dimensioned according to the requirements derived from these.
They are thus only designed for a limited period of use with regard to the overall dimensioning and
certification.
After the total period of use as elapsed, measures must be taken where parts are checked and exchanged
as per indication by the manufacturer. After that a new maximum usage period is determined. See also the
valued accident prevention regulations, “winches, lifting and pulling devices”.
NOTICE!
Commitment
A general overhaul may only be performed by HADEF or by a specialized company, authorized by HADEF.
2 Safety
DANGER!
To assess the intended use of the devices correctly, the user must carry out an Ex-zone
classification.
The classification must be carried out in accordance with all current legislation, standards and
regulations for areas prone to explosion!
2.1 Warning notice and symbols
Warnings and notice are shown as follows in these instructions:
DANGER! This means that there is a high risk that leads, if it is not avoided, to death or severe injury.
WARNING! This means that there is a risk that could lead, if it is not avoided, to death or severe injury.
CAUTION! This means that there is little risk that could lead, if it is not avoided, to slight injury or damage to the device or its
surrounding.
NOTICE! Gives advice for use and other useful information.
Danger from electricity.
Danger from explosive area.
2.2 Duty of care of the owner
DANGER!
Failure to follow the instructions of this manual can lead to unpredictable hazards.
For any resulting damage or personal injury, HADEF assumes no liability.
The unit was designed and built following a risk analysis and careful selection of the harmonized standards
that are to be complied with, as well as other technical specifications. It therefore represents state-of-the-art
technology and provides the highest degree of safety.

5.52.132.01.01.08 5
Our delivery includes the hoist supplied beginning at its suspension and ending at the load hook and if
supplied with control, the control line/hose that leads to the hoist. Further operating material, tools, load
attaching devices as well as main energy supply lines must be assembled according to the valid rules and
regulations. For explosion-proof equipment, all these parts must be approved for use in area prone to
explosion, or they must be suitable for use in area prone to explosion. The owner is responsible for this.
However, in everyday operation this degree of safety can only be achieved if all measures required are
taken. It falls within the duty of care of the owner/user of the devices to plan these measures and to check
that they are being complied with.
Complete the operating and installation instructions by any instructions (regarding supervision or
notifications)that are important for the special kind of use of the equipment, i.e. regarding organization of
work, work flow and human resources.
In particular, the owner/user must ensure that:
The unit is only used appropriately.
The device is only operated in a fault-free, fully functional condition, and the safety components, in
particular, are checked regularly to ensure that it is functioning properly.
The required personal protective equipment for the operators, service and repair personnel is available
and is used.
The operating instructions are always available at the location where the equipment is used and that they
are legible and complete.
The unit is only operated, serviced and repaired by qualified and authorized personnel.
This personnel is regularly trained in all applicable matters regarding safety at work and environmental
protection, and that they are familiar with the operating manual and, in particular, the safety instructions it
contains.
Any safety and warning signs on the devices are not removed and remain legible.
Devices for use in area prone to explosion must (from customer's side) be earthed with a shunting
resistor of < 106Ωagainst earth.
WARNING!
It is not allowed to make constructive changes of the equipment!
2.3 Requirements for the operating personnel
The units may only be operated by qualified persons that are appropriately trained and that are familiar with
it. They must have their employer’s authorization for operation of the units.
Before starting work, the operating personnel must have read the operating and installation instructions,
especially the chapter "Safety Instructions".
This is especially important for operating personnel that rarely uses the equipment, i.e. for installation or
maintenance work.
DANGER!
In order to avoid severe injury, please pay attention to the following when using the equipment:
Use protective clothes/equipment.
Do not wear long hair hanging down open.
Do not wear rings or other jewelry.
Do not wear clothes that are too big/wide.
Do not reach into ropes, chains, drive parts or other moving parts with your hands
2.4 Appropriate use
The permitted safe working load of the devices must not be exceeded! An exception can be made during the
load test before initial operation, carried out by a licensed qualified person.
The permissible ambient temperature during operation of manual driven devices is -20 ° C / + 50 ° C and
at all power driven devices -20 ° C / + 40 ° C!
Defective devices and load suspension devices must not be used until they have been repaired! Only
original spare parts must be used. Non-compliance will result in any warranty claims becoming void.
Liability and warranty will become void if unauthorized modifications of the units are made by the user!

6 5.52.132.01.01.08
The appropriate use of the hoists is vertical lifting and lowering of unguided loads. In combination with
trolleys, loads can also be moved horizontally.
DANGER!
It’s only allowed to use the unit in the EX-classification which is named on the type plate; or in lower
classes
EX II 2G IIB c T4 or EX II 2D c 135°C
or
EX II 2G IIB c T3 or EX II 2D c 200°C
DANGER!
It is not allowed:
pulling loose of stuck loads, dragging of loads and inclined pulling is not allowed.
in explosive atmosphere, except the unit is especially modified for it and marked by an indication label
In reactor containment vessels.
to transport people
The device is not suitable for use on stages and in studios
persons must not stand under a suspended load
NOTICE!
If the units are not used appropriately, it is not possible to ensure safe operation.
The owner and operator have sole liability for all personal injury and damage to property arising from
inappropriate use.
2.5 Basic safety measures
Observe installation-, operation and maintenance instruction.
Take notice of caution notes at units and in the manual
Observe safety distances.
Take care for a free view on the load.
Only use the hoists appropriately.
The equipment is to be used exclusively for movement of goods. Under no circumstances my persons be
moved.
Never load the devices beyond their working load limit.
Pay attention to the accident prevention regulations (UVV).
Should the hoist be used outside of Germany, please pay attention to the national regulations that apply.
Supporting structures and load-attached devices used in conjunction with this equipment must provide an
adequate safety factor to handle the rated load plus the weight of the equipment. In case of doubt, consult
a structural engineer.
If the equipment has not been used for a period of time, carry out visual checks of all main components
such as chains, load hooks etc. and replace any damaged parts with new, original spare parts before
putting the equipment back into operation!
Do not use a hoist that is defective, pay attention to any abnormal noise it makes during operation.
Stop working immediately in case of disturbances and remedy failures.
Any damage and faults must be reported to a responsible supervisor immediately.
If the unit is put into motion, any persons in the immediate vicinity must be informed by calling to them!
Please pay attention to the regulations for load carrying devices UVV for both positive and non-positive
methods of attaching loads.
The lifting tackle or the load must be securely attached to the hook and be seated at the bottom of the
hook.
The safety catch of hooks must be closed.
When charged, the housing may not be in contact somewhere.

5.52.132.01.01.08 7
Stop lowering the load when the bottom block or the load is being set down or is prevented from being
lowered further.
The load chain must not be twisted.
Twisted chains must be aligned before attaching the load.
The correct alignment of the chain links can be seen from the weld seams.
The chain links must always be aligned in one direction.
Don't bump against something with load or hook
Illustration 1
NOTICE!
Pneumatic air motors are capable of operating at continuous duty up to 100% and 360 cycles per hour and
can be used in accordance with their device classification (mechanism class). The remaining service life of
the devices in accordance with mechanism group and usage (see calculation of remaining service life)
must be followed.
WARNING!
The following is not allowed:
to lift another load than the nominal safe working load
to manipulate the sliding clutch if units are equipped with
The use of elongated or damaged chains or wire ropes. Replace them immediately by new, original
parts.
Never loop the load chain around a load nor place or pull the chain over edges.
Never repair damaged load hooks (e.g. by hammering), but replace them by original hooks.
DANGER!
Special safety measures for use in areas prone to explosion.
Not to be used with IIC gases and IIB gases hydrogen sulphide, ethylene oxide and light metal and shock
sensitive dusts!
No use in temperature class T5 or T6.
It is not allowed to use the equipment in area at risk from explosion where gas AND dust does both exist
at the same time!
During assembly and operation of explosion-proof equipment, the relevant regulations of i.e. BG-Chemie
about the use of equipment in area at risk from explosion, must be adhered to by the user/owner.
Please make sure that external ventilation is sufficient.
Please wear conductive shoes. Gloves should have a shunt resistance of < 108Ω.
It is not allowed to take off clothes.
The surface temperature of the devices could increase by a variety of external circumstances. For this
reason, the surface temperature is to be monitored.
Avoid ignitable dust deposits.
Remove dust deposits daily before commencing work and ensure that dust cannot settle between moving
parts.
Never remove dust with compressed air - remove it with a wet bolt of cloth.
Defective units or units that show abrasion of its surface rust on chains, hooks, or suspension devices,
must be taken out of service.
Please observe the prescribed intervals.
Assembly and maintenance work must only be carried out in an atmosphere not prone to explosion.
Check the grease level of the bearings regularly
Exchange friction surfaces in time and (an exception to this are electric units - maintenance of the brakes
must only be effected by HADEF).
Protect the device from impact, friction, rough handling and moisture.

8 5.52.132.01.01.08
Special scope
Use of different EX-zones is depended from the EX-classification of the unit. Find the EX-classification on its
type plate.
Unit classified
in EX-classification No use in EX-zone
3G/D 0,20,1,21
2G/D 0,20
3G 0,20,1,21,22
3D 0,20,1,21,2
2G 0,20,21,22
2D 0,20,1,2
2.6 Explosion protection
The EX classification of the unit is indicated on a
separate plate, situated on the unit.
Illustration 2
Example of ATEX classification:
II 2GIIB cT4
CE-marking European Union
explosion-proof operating
material
II device group / application I
II danger of mine damp other areas prone to explosion
2device category 1
2
3
Use in zone 0
Use in zone 1
Use in zone 2
GEX atmosphere G
D....caused by gas, steam, fog ...caused by dust
IIB explosion group IIA
IIB
IIC
limit gap widths (MESG) > 0,9 mm
limit gap widths (MESG) 0,9 >= 0,5 mm
limit gap widths (MESG) < 0,5 mm
ctype of protection c
kconstruction safety encapsulation of liquids
T4 Temperature class - gas-
es
(for dust only the temper-
ature in °C is stated)
T1
T2
T3
T4
T5
T6
limit temperature 450 °C
limit temperature 300 °C
limit temperature 200 °C
limit temperature 135 °C
limit temperature 100 °C
limit temperature 85 °C

5.52.132.01.01.08 9
2.6.1 EX-Category
EX- Zone 1+21
2+22
1+21
2+22
Device category 2 2
Expl.-group of gases IIB IIB
Temperature class - gases
Temperature class - dust
T4
135°C
T3
200°C
DANGER!
The classification for the device can be found on the EX-type plate on the unit.
The device must only be used in the classification stated or in a lower classification.
2.6.2 Surface temperature of the devices
DANGER!
The temperature class mentioned on the EX-type plate on the unit must be observed, - make sure
that the max. surface temperature is even fallen short of.
DANGER!
The maximum surface temperature of the equipment must always be lower than the ignition
temperature of the gas/vapour/dust/air mixture. Equipment which has been classified in higher
temperature classes is, of course, also approved for use in applications with lower temperature
classes. As gas/air mixtures for T5 do not occur with normal use, and only very rarely occur for T6,
for specific gas/air mixtures such as carbon disulphide (IIC), our hoists are not rated for these
temperature classes and must not be used for these classes.
Temperature
class
Ignition tem-
perature of gas
°C
max. surface
temperature of the
operating material in
°C
T1 >450 450
T2 >300 <450 300
T3 >200 <300 200
T4 >135 <200 135
T5 >100 <135 100
T6 >85 <100 85
2.6.3 EX zone classification
Areas that are prone to explosion are classified into zones. The owner must determine the zone that exists.
Information on the zone classification can be found in IEC 60079-10 and in national standards. The following
table contains an overview of the zone classification in combination with the device category.
Gases
Vapours
Mist
device category
(Gases) Dust device category
(dust)
explosive
atmosphere
is present
Zone 0 1G Zone 20 1D continuously, long-term or
frequently
Zone 1 2G Zone 21 2D occasionally
Zone 2 3G Zone 22 3D rarely or short-term

10 5.52.132.01.01.08
2.6.4 Explosion hazards … recognizing and preventing!

5.52.132.01.01.08 11
3 Transport and Storage
CAUTION!
Transport may only be done by qualified personnel. No liability for any damage resulting from improper
transport or improper storage.
3.1 Transport
The devices are checked and if so adequately packed before delivery.
Do not throw or drop the equipment.
Use adequate means of transport.
Transport and means of transport must be suitable for the local conditions.
3.2 Safety device for transport
NOTICE!
Should a safety device for transport exist, please remove it before commissioning.
3.3 Storage
Store the equipment at a clean and dry place.
Protect the equipment against dirt, humidity and damage by an appropriate cover.
Protect hooks, wire ropes, chains and brakes against corrosion.
DANGER!
Units that show corrosion must be taken out of service!
4 Description
4.1 Areas of application
The devices must be as far as possible installed in a covered room.
If they are used in the open, protect the units against the effects of weather such as rain, hail, snow, direct
sunshine, dust, etc. - we recommend to use a cover in parking position. If the device is set up in a
continuously humid environment with strong temperature fluctuations, the correct functionings are
endangered by the forming of condensation.
Ambient temperature -20°C up to +50°C. Power-operated units -20 up to +40°C. Humidity 100 % or less but
not under water
During longer periods of standstill, corrosion may reduce the function of the brake.
Depending on the type of device, it is suitable for use in area at risk from explosion in the EX-classification
stated.
The EX-classification is mentioned on the EX-type plate on the hoist. The use of the unit is only allowed for
the EX-classification mentioned on the EX-type plate or lower EX classification.
4.2 Design
HADEF pneumatic chain hoists, with low
headroom design and pneumatic trolley Type
28/06APP, with hand-geared trolley Type
28/06APH and push travel trolley Type 28/06 APR
are monorail trolleys with integrated hoisting gear.
The hoisting gear is driven by compressed air
motors and, the trolleys by hand via chains or also
by compressed air motors.
Type 28/06APR - Table 1 - 0,5t

12 5.52.132.01.01.08
Type 28/06APP - Table 2-10t
Type 28/06APP - Table 2-15t
4.3 Functions
The lifting gear and motor-driven trolleys are moved by pressing the buttons on the control switch. The
spring-operated brake which is integrated in the lifting motor prevents the load from being lowered
automatically after releasing the control keys.
Hand geared trolleys are moved to the left or right by pulling one of the two stands of the endless hand
chain.
NOTICE!
The best protection against functional failures in case of extreme environmental impact is the regular use of
the equipment.
If the hoist is not used very often, we recommend to carry out a test run at least once a week and to switch
on the motor several times during this test run.
In our experience, this will prevent the brake from sticking.
4.4 Important components
NOTICE!
All hoists are fitted with high-quality lifting gears of the reliable AK series.
4.4.1 Motor
Type of chain hoist
Pneumatic motor
70/06AP, 70/06AP-EX
28/06AP, 28/06 AP-EX
29/06AP, 29/06AP-EX
29/06APL Big Bag, 29/06APL Big Bag-EX
4.4.2 Gear
Lifting gear with ventilation screw
AK 4-8 Precision Spur Gear
AK9+10 Precision Planetary Gear

5.52.13
2
Trolley
g
Combin
a
Closed
d
4.4.3
Control
s
Classifi
c
Kind of c
o
Direct con
t
Indirect co
4.4.4
Type
70/06AP+
E
28/06AP+
E
29/06AP+
E
4.4.5
acc. to
E
4.4.6
Hook in
4.4.7
A
ccordi
n
4.4.8
automat
(only ap
p
4.4.9
for prep
a
4.4.10
Manual
e
(A) to lo
w
pressur
e
4.4.11
operatio
(only for
4.4.12
only for
h
2
.01.01.08
g
ea
r
a
tion of wor
m
d
esign - ven
t
Control
s
witch with
e
c
ation of con
t
o
ntrol
t
rol
o
ntrol
Overload
p
Sl
i
E
X
E
X
E
X
Load chai
n
E
N 818-7-T
h
Load hoo
k
ball bearing
Chain con
n
g to hoist ty
Safety en
d
ic stop whe
n
p
licable for
h
Maintena
n
a
ration of th
e
Emergen
c
e
mergency
o
w
er the load
e
Operation
nal driving i
n
indirect con
t
Special c
o
h
oists that a
r
m
gear and
m
t
ilation not n
e
e
mergency s
t
t
rol accordin
g
Standard
AK 4
AK 6-10
p
rotection
i
pping clutch
AK 4-8
AK 4-8
AK 4-8
n
h
igh quality
c
k
with safety
c
taine
r
pe made of
c
d
switch (lif
t
n
the load ch
a
h
oists with t
e
n
ce unit (op
t
e
operation
a
c
y ventilatio
n
o
pening for t
in case of d
limit switc
h
n
to upper an
d
t
rol)
o
mponents
r
e used in a
r
m
otor
e
cessary.
t
op
g
to lifting g
e
mechanical
as
s
Standard
AK 9+10
c
hain
c
atch.
c
oated fabri
c
t
ing/lowerin
a
in does not
nsioning de
v
t
ion)
a
ir
n
- hoisting
h
e brake via
r
op of air
h
d
lower hoo
k
r
ea at risk of
e
ar sizes
Option
AK 4
stop by sprin
g
s
embly
Option
AK 4-10
AK 4-10
c
, plastic of
s
g)
t
run correctl
y
v
ice)
motor (opt
i
lever
k
position
explosion
g
Pressure
Standar
d
AK 9+10
AK 9+10
s
teel plate.
y
i
on)
Illustration
reducing valv
e
d
Option
AK 4-10
3
e
13

14 5.52.132.01.01.08
5 Technical data
Table 1
Capacity kg 500 1000 1600 2000 3200 5000
hoisting unit AK4 AK6 AK7 AK6 AK7 AK8
Number of chain falls 1 1 1 2 2 2
FEM 9.511/EN 818-7 2m 2m 2m 2m 2m 2m
Load chain mm 5x15 7x21 9x27 7x21 9x27 11,3x31
load bar size 1N
for beam flange width 2N
from - to
mm
mm
82-185
186-310 76-196 197-310 125-192 193-310 76-196 197-310 125-192 193-310 140-215 216-312
Lifting speed approx. m/min 7 8 8 4 4 3
Lowering speed approx. m/min 16 15 16 7 8 6
Hoist motor output kW 0,75 1,5 2,5 1,5 2,5 *)
Travel speed approx m/min 8/4
Trolley motor output kW 0,55
Travel path when reeling off 30 m
of hand chain
m 9,8 9,8 6,5 9,8 6,5 4,5
Hand chain pull for travel approx N 40 50 55 100 110 90
Travel resistance (if equipped with
push trolley) approx N 155 240 320 360 420 630
Noise emission at 1m distance
tolerance +2 dB(A) dB(A) 84 84 84 84 84 84
max. wheel load approx..
at 3m track height kg 185 370 580 895 1500 *)
Weight at 3 m track height approx. kg 67 98 148 139 166 *)
Table 2
Capacity kg 6300 12000 15000 20000 25000 30000 40000
hoisting unit AK9 AK9 AK9 AK9 AK9 AK9 AK9
Number of chain falls 1 2 3 4 5 6 2x4
FEM 9.511/EN 818-7 1Bm 2m 2m 2m 2m 2m 2m
Load chain mm 16x45
Lastbolzengrößen 1N
bei Trägerflansch- 2N
breite von- bis
mm
155-164
165-310 140-189 190-310 140-189 190-310 220-310 220-310 180-310 180-310
Lifting speed approx. m/min 2 1,2 0,9 0,7 0,6 0,45 0,7
Lowering speed approx. m/min 3,6 2,2 2,2 1,1 0,7 0,6 1,1
hoist motor output kW 2,5 2,5 2,5 2,5 2,5 2,5 2,5
Travel speed approx m/min 8/4 8/4 8/4 8/4 8/4 8/4 8/4
Trolley motor output kW 0,55 0,55 0,75 0,75 2x0,55 2x0,55 2x0,75
Travel resistance (if equipped with
push trolley) approx m 4,5 4 3,7 3,7 4 4 4,5
Hand chain pull for travel approx N 110 170 140 170 280 2x190 2x110
Noise emission at 1m distance
tolerance +2 dB(A) dB(A) 84 84 84 84 84 84 84
max. wheel load approx..
at 3m track height kg 2030 6460 4400 5500 6950 8300 *)
Weight at 3 m track height approx. kg 910 920 970 1170 1590 1740 *)
*) at the time of going to print this data had not been finalised.
6 Installation
DANGER!
Assembly, disassembly and maintenance operations must only be carried out in an atmosphere not
prone to explosion!
The assembly and installation depends on the local environment. The hoist must be suspended in a way that
it can position itself freely.
6.1 Trolley
For assembly on a beam a travel limit must be placed at either end of the track.
This must be attached so that any elastic limitation buffer or the trolley wheels are driven against them in
their end position when moving.
Generally, additional lifting gear (e.g. fork lift, lifting platforms) will be required for the assembly. These must
take the weight of the devices securely.

5.52.132.01.01.08 15
6.2 Adjusting the gauge
The trolley can be adjusted to various beam flange widths. Adjustment to the relevant beam flange width “B”
depends on the type and size and is to be made as follows:
There are distance tubes (5) and/or washers
(6) situated on the load bars (2) of the trolley.
Dimension "X" is set by placing washers (6)
from the outer to the inner side ("X" increases)
or from the inner to the outer side ("X"
decreases).
Washers (6) and rubber discs (depended on
type) leave a distance for the load hook. It is
important that the load hangs in the middle
under the beam so that the two side plates are
equally loaded.
The suspension eye (9) (if existent) for bigger
load bolts must still be swivelling after it has
been secured.
Tighten the hexagon nut (3) and safety nuts (4)
again.
Check correct flange width "B" and dimension
"X". Adjustment must be repeated if necessary.
1 side plates
2 load bars
3 hexagon nut
4 safety nuts
5 distance tubes
6 washers
7 ---
8 rubber disc (depended on type)
9 suspension eye
6.3 Installation on the beam
1 Tighten the hexagon nut (3) and safety nuts (4).
2 Push on the trolley at the face of the beam flange.
3 If this is not possible, the trolley can also be mounted
on the beam from below.
4 Therefore, remove the hexagon nut (3) and the safety
nut (4) on the side without gear.
5 Pull apart the side plates (1) as far until it is possible to
push the trolley onto the beam flange from below.
Afterwards, push the trolley together to correct gauge.
6 Secure the washers (6) and distance tubes (5) by
tightening the hexagon nuts (3) and the safety nuts (4).
Illustration 4
6.3.1 Bolt securing with collar
Securing the load bolts with set collars (1) and safety
screws (3).
In order to adjust the beam flange width dismantle
the safety screws (3) at one trolley side.
After adjustment of dimension "X" and installation on
the beam, install the safety screws (3) again and
secure them with a nut (4).
When pulling apart the side plates, the trolley drive
shaft will also be moved.
To do this, loosen the safety screws at the stern tube
bearing and secure them again after the side plates
have been pushed together.
Illustration 5
1 set collar
2 load bar
3 safety screw
4 hexagon nut
5 washer

16 5.52.132.01.01.08
CAUTION!
The distance “X” between the wheel flanges of the trolley wheels must be
for trolleys up to 3,2 t: 2-3 mm (1-1,5 mm each side) bigger and
for trolleys from 4 t up: 3-5 mm (1,5-2,5 mm each side) bigger than the flange width "B" of the beam
6.4 Pressure roller
6.4.1 Units with a load capacity of up to 6,3 t
These units are fitted with adjustable pressure
rollers (1).
After assembly on the beam, adjust the
pressure roller (1).
The air gap between beam and pressure roller
(1) must be approx. 1-2 mm.
Tighten the screw and nut (2).
Illustration 6
1 Pressure roller
2 Screw with nut.
6.5 Chain container installation
The chain container is supplied as a complete
unit. For the installation of the chain container, the
following must be observed:
Mount chain container (1) with screws (2) in
the position provided (3).
Let the load chain run smoothly into the chain
container (1).
The holding chain (4) which is already fixed to
the chain container must be fastened with
screw (6) at the position provided therefore at
the hoist (5) in such a way that the chain
container (1) hangs as horizontally as possible,
to achieve this, either shorten the holding chain
(4) or another chain link must be added to the
holding chain (4).
Re-check the fastening screws.
Check whether the load chain of the device
can enter the chain container freely by carrying
out a functional test without load.
Illustration 7
i The chain container should hang horizontally or
as horizontally as possible
1 chain container
2 screws
3 position for screws
4 holding chain
5 position of holding chain
6 screw

5.52.132.01.01.08 17
6.6 Tools
7 Operation
Only people that are familiar with the operation of the lifting devices and cranes may be entrusted with their
operation. They must be authorized by the employer for the operation of the equipment. The employer must
ensure that the operating instructions are available near the equipment and that they are accessible for the
operating personnel.
The shown control switches are only for the optical information. They can be different acc. the delivery.
Direct control
1 Emergency-Stop
2 Lifting
3 Lowering
Illustration 8
Capacity Size Tool Use
0,5t
1t
1,5t + 2t
2,5t + 3,2t + 4,0t
5t + 6,3t
7,5t + 10t
SW27
SW36
SW46
SW55
SW60
SW75
Load bar
12,5t
16t – 60t
SW22
SW24
Load bar
with fixing ring
only if pneumatic
drive exist div. Pneumatic connections
div.
div.
div. Electric
div.

18 5.52.132.01.01.08
Indirect pneumatic control
1 Emergency stop
2 lifting
3 lowering
Hoists combined with trolleys have control
switches where push buttons for trolley movement
are added.
Special design units can be supplied upon
request.
Illustration 9
Push button functions
Relieved push button = stand still
push button pushed = respective movement
Illustration 10
Red Emergency-Stop button
button pushed = stand still
turn the button clockwise = free functions
Illustration 11
Emergency release – Hoist (as option)
To drain the load at pressure drop in an emergency
case, a manual brake release is possible by lever (A).
Illustration 12
NOTE!
A minimum weight of approx. 20% of the rated load is necessary for lowering. This value depends on
application and ambient conditions!
CAUTION!
Run in of chain into the chain container for hoist with double lifting mechanism
For a correct run in of chain into both chain containers, the lowering operation must be carried out, without
load, at certain intervals, until both chain container are empty.
For motorized devices with operating limit switches "lowering"
Lower until the operating limit switch is released.
Non-observance can lead to device damages!
8 Operation
The following, important points must be observed when operating the equipment:
Read the safety instructions.
Never load the devices beyond their working load limit.
The prescribed maintenance intervals must be adhered to.
The lifting tackle or the load must be securely attached to the hook and be seated at the bottom of the
hook. The safety catch must always be closed.

5.52.132.01.01.08 19
DANGER!
It is not allowed:
pulling loose of stuck loads, dragging of loads and inclined pulling is not allowed.
in explosive atmosphere, except the unit is especially modified for it and marked by an indication label
In reactor containment vessels.
to transport people
The device is not suitable for use on stages and in studios
persons must not stand under a suspended load
9 Commissioning
9.1 General
Should the unit be used in Germany:
Please observe the validated, national accident prevention regulations.
For other countries:
Inspections as above. Please observe the national rules and regulations and the instructions in this manual!
NOTICE!
Hoists up to 1000 kg capacity and without motor-driven trolleys of hoisting unit must be tested by a “qualified
person” before putting into operation for the first time.
Hoists of 1000 kg capacity and up or with more than one motor-driven hoist movement; i.e. lifting and trolley
movement, must be tested by a “licensed qualified person” before putting in operation.
An exception is “hoists ready for operation” acc. validated national regulations with EU-declaration of
conformity.
Definition “qualified person” (former expert)
A “qualified person” has learned, due to occupational training and experience and the job that the person has
done, the skills needed to tests the material for one’s work.
Definition “licensed qualified person” (former approved expert)
A “licensed qualified person” has, due through special occupational training, knowledge about testing of the
material for one’s work and knows the national accident prevention regulations and other prescriptions and
technical regulations. This person must test the material for one’s work regularly with regard to design and
kind of use. The license will be given to qualified person be the approved supervision authorities (ZÜS).
9.2 Compressed air connection
Before commencing work on the equipment, the main air supply line must be closed and secured against
inadvertent opening!
9.2.1 Main connection
The connections must be made according to the pneumatic connection diagram.
Connect to the existent hose nozzle.
The hose must be secured with a hose clamp.
Nominal width of the air connection hose
0,52-0,75 kW - NW 13 mm
1,5 kW - NW 19 mm
2,5 kW - NW 25 mm
If hose length exceeds 15 m, a larger cross section must be selected.
9.2.2 Control hose connection
Control switches with hoses are connected at the factory, unless otherwise agreed.

20 5.52.132.01.01.08
9.2.3 Maintenance unit
It is important that an automatic maintenance unit, consisting of oiler, filter ,water separator and air pressure
reducer is installed in the main air supply - if not assembled by the manufacturer this must be assembled by
the customer.
It serves for the necessary preparation of the operation air so that the pneumatic motor can work trouble-
free. Installation must be as close as possible to the motor; - in no cases should the distance to the motor
exceed 10 m.
Should higher pressure occur in the supply net, it will be reduced to the operating pressure of 6 bar by the
pressure reducing valve. The oiler enriches the air with oil. Setting of oil addition: approx. 2 drops of oil must
be added per minute.
NOTICE!
HADEF does not assume any responsibility for damage caused by non-observance of the instructions.
CAUTION!
Should the unit be assembled at the customer, the maintenance unit is supplied without oil.
Before putting the unit into operation, the main air supply line must be cleaned and the oiler of the
maintenance unit must be filled with oil. Should this not be done the unit may be severely damaged.
CAUTION!
The maintenance units are not approved for use with synthetic oil.
They must not be connected to compressed air systems which are supplied by compressors with synthetic
lubricants.
9.3 Gear
NOTICE!
For transport, some gear types are fitted with a plug screw. Replace the plug screw by a ventilation screw
(attached) before putting the unit into operation.
9.4 Load chain
Before commissioning the load chain must be aligned and oiled.
For the first commissioning of motorized hoists, chain oil is supplied with the delivery.
Move safety note and fixing wire away from the chain.
9.5 Power operated hoists with chain container:
Due to the transport and / or installation of the hoist on the beam, the position of the load chain in
the chain container can change unfavorably.
WARNING!
It is mandatory before the first commissioning:
that the complete load chain without load with the utmost care from the chain
container is driven
i.e. when lowering, pay special attention to the load chain on the chain container side,
so that the load chain can run properly through the hoist without being twisted
only after the chain container is completely empty, the load chain without load, can
be returned to the chain container
during the running in of the load chain, lubricate it over its entire length
