PRODUCT CODE: 206978
DUAL BASKET AIR FRYER
INSTRUCTION MANUAL

www.haden.com
3
How Can We Help?
The Haden team is always interested in
what you have to say, so why not get in touch?
Call us
01909 544 570
Email us
[email protected]
Write to us
Team Haden, Sabichi Homewares Ltd,
Priorswell Rd, Worksop, S80 2BY
Visit us
www.haden.com
COMPONENTS
A. Grill trays
B. 4.5L Basket x2
C. Basket handles
D. Air Inlet
E. Control Panel
F. Air Outlet vents
G. Cord storage
H. Power cord

www.haden.com www.haden.com
4 5
SAFETY INSTRUCTIONS
When using this appliance, the following basic safety precautions
should always be taken.
• Read all instructions.
• Never immerse the housing, which contains electrical
components and the heating elements, in water nor rinse it
under the tap.
• Do not let any water or other liquid enter the appliance to
prevent electric shock.
• Always put the ingredients to be fried in the tray, to prevent it
from coming into contact with the heating elements.
• Do not cover the air inlet and the air exhaust openings while the
appliance is operating.
• Do not fill the frying tray with oil as this may cause a fire hazard.
• Never touch the inside of the appliance while it is operating.
• Check whether the voltage indicated on the appliance
corresponds to the local mains voltage in your country before
you connect the appliance.
• Do not use the appliance if the plug, the power cord or the
appliance itself is damaged.
• If the power cord is damaged, you must have it replaced at a
service centre or similarly qualified persons in order to avoid a
hazard.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children should not play with the appliance. Cleaning and user
maintenance should not be made by children unless they are
older than 8 and supervised.
• Keep the appliance and its mains cord out of the reach of
children when the appliance is switched on or is cooling down.
• Keep the mains cord away from hot surfaces.
• Do not plug in the appliance or operate the control panel with
wet hands.
• Only connect the appliance to an earthed wall socket. Always
make sure that the plug is inserted into the wall socket properly.
• Never connect this appliance to an external timer switch.
• Do not place the appliance on or near combustible materials
such as a tablecloth or curtains.
• Do not place the appliance against a wall or against other
appliances. Leave at least 10cm free space at the back and sides
and 10cm free space above the appliance. Do not place anything
on top of the appliance.
• Do not use the appliance for any purpose other than described
in this manual.
• Do not let the appliance operate unattended.
• During hot air frying, hot steam is released through the air
exhaust openings. Keep your hands and face at a safe distance
from the steam and from the air exhaust openings. Also be
careful of hot steam and hot air when you remove the frying tray
from the appliance.
• The surface below the appliance may become hot during use.
• Immediately unplug the appliance if you see dark smoke coming
out of the appliance. Wait for the smoke emission to stop before
you remove the frying tray from the appliance.
• Place the appliance on a horizontal, level and stable surface.
• This appliance is intended for normal household use only. It is
not intended for use in environments such as staff kitchens,
offices, farms or other work environments. Nor is it intended to
be used by clients in hotels or other similar environments.
• Always unplug the appliance after use.
• Let the appliance cool down for approx. 30 minutes before you
handle or clean it.
• If the appliance is used improperly or if it is not used according
to the instructions in the user manual, the warranty becomes
invalid and refuses any liability for any damage that is caused.
SAVE THESE INSTRUCTIONS

www.haden.com www.haden.com
6 7
This Air Fryer provides an easy and healthy way of preparing a wide
assortment of food - with little or no oil! The air fryer uses hot air,
in combination with high-speed air circulation, and a top grill to
prepare your dishes quickly and easily. The ingredients are heated
from all sides, at once, and there is no need to add oil in most cases.
INTRODUCTION
1. Remove all packing material.
2. Remove any stickers or labels from the appliance – other than
the rating label.
3. Thoroughly clean the frying basket and tray with hot soapy water
using a non-abrasive sponge.
Note: You can also clean these parts in the dishwasher.
4. Wipe the inside and outside of the appliance with a moist cloth.
5. Dry all parts thoroughly before use.
6. Do not fill the appliance with oil or frying fat. This appliance
operates using hot air and requires very little to no oil.
BEFORE FIRST USE
CONTROL PANEL
A. Temperature + / - keys
B. LED Screen
C. Time + /- keys
D. Steak
E. Cake
F. Start/Pause
G. Re-heat
H. On/Off button
I. Dehydrate
J. Basket 2
K. Match Cook
L. Vegetables
M. Smart Finish
N. Pizza
O. Fish
P. Basket 1
Q. Prawns
R. French fries
S. Pre-heat
T. Meat
U. Drumsticks

www.haden.com www.haden.com
8 9
1. Place the appliance on a stable, horizontal and level surface that
is also heat resistant.
2. Place the basket in the frying tray.
3. Insert the frying tray into the appliance.
4. Ensure that the cable is clear of obstacles and not hanging off
the edge of the counter.
5. Do not fill the frying tray with oil or any other liquid.
6. Do not put anything on top of the appliance. This disrupts the
airflow and affects the air-frying result.
7. Ensure that nothing is blocking the outlet vent.
PREPARING FOR USE
USING THE AIR FRYER
Turning the Air fryer ON/OFF
1. Plug the into the mains socket. The air fryer will beep and the
control panel will light up, before going into standby mode with
only the the lit up.
2. Touch the button to turn the Air fryer on, the control will light
up at the same time.
3. If you press the button again this will stop the air fryer. It will
beep and go back into standby mode.
Note: If there is a power cut or the air fryer is unplugged during use
the display will go off. Once power is back or plugged back in, the air
fryer will continue the program previously set.
Start / pause
1. After selecting a cooking function, time and temperature press
the button.
2. The will start to flash, followed by a beep and the Air fryer
will start to work.
3. To pause the air fryer, press . The will stop flashing and it
will beep before stopping. To restart press the again.
Setting the Temperature
The temperature control range is 50-200°C*.
1. Each press of the Temperature +/-keys will increase/decrease
the temperature in increments of 10°C. The temperature will
flash 3 times in the display to confirm the setting chosen.
Note: When 200°C is reached, if the temperature key is touched
again the display will loop back to 50°C.
2. Short press the button to adjust gradually or press and hold to
change the temperature more quickly.
*Dehydrate function operates between 30-80°C.

www.haden.com www.haden.com
10 11
Setting the Timer
The time range is 1 to 60 mins*.
1. Each press of the Timer +/- buttons will increase/decrease the
time by 1 minute. The time will flash 3 times in the display to
confirm the setting chosen.
Note: At 60 minutes, if the button is touched again the display will
loop back to 1 minute.
2. Short press the keys to adjust gradually or press and hold to
change the time more quickly.
*Dehydrate function operates between 30-1440 minutes (24hours).
Auto Cook Functions
Once plugged in and in standby:
1. Place food in the baskets.
2. Press the button to turn on the air fryer.
3. Press the or button, to select basket 1 or 2.
4. Select the icon of the auto cooking function required.
5. The default temperature and timer will show in the displayed.
Alternately, you can adjust these setting by pressing the
Temperature +/- and / or the Time +/- button to meet your
liking.
6. If cooking with both baskets touch the other basket button and
repeat steps 3 and 4.
7. Press the button to begin cooking.
8. When the timer has elapsed, the motor will continue to operate
for approximately 1 min to cool the air fryer. The display will
show ‘00’ and the heating element will stop working. The air
fryer will beep before the air fryer enters standby mode.
9. Remove the drawer from the air fryer and place it on a heat-
resistant surface.
10. Check if the food is ready:
• If the food is not ready yet, return the basket to the air fryer, and
turn back on for a couple of minutes until ready.
• If the food is ready empty the drawer into a bowl or onto a plate.
Take care if tilting the basket as any excess oil that has collected
on the bottom will leak onto the food.
CAUTION: Take care when tilting the basket as the grill tray
may move or fall out of the basket.
CAUTION: DO NOT touch the basket during and for some time after
use, as it gets very hot. Only hold the drawer by the handle.
When a batch of food is ready, the air fryer is instantly ready for
preparing another batch. However, if the air fryer is not required
for further cooking, turn it off and unplug it from the mains socket.
Leave the baskets open to allow the unit to cool down.

www.haden.com www.haden.com
12 13
Smart Finish
Cook different foods in each compartment with different times and
temperatures, use the ‘Smart Finish’ function to ensure that both
compartments finish cooking at the same time.
1. Press and set the cooking program.
2. Press and set the cooking program.
3. Press the SMART FINISH button.
4. Press the to start cooking.
Match Cook
Use the ‘Match Cook’ function when using both compartments
to cook the foods, cooking will finish at the same time for both
compartments.
1. Press the MATCH COOK button
2. Set the cooking program.
3. Press the to start cooking.
Pre-Heat
To pre-heat the Air fryer before cooking:
1. Select the required basket or both.
2. Select Pre-Heat function button. This will pre-heat the drawer at
180ºC for 3 minutes.
3. Press the button to start.
Note: Pre-heating the grill plate helps achieve a chargrill effect
when cooking food or add extra crispness to chips and other coated
ingredients.
Air Fryer Basket Safety Switch
The air fryer has a safety switch in the basket, designed to stop
the unit from accidentally turning on whenever the basket is not
properly situated inside the air fryer or the timer is not set.
Before using your air fryer, please ensure that the grill plate is
inside the basket and the basket is fully closed.
Removing the basket
The drawer can be removed fully from the air fryer. Pull on the
handle to slide the drawer out of the air fryer.
Auto Off Function
The Air fryer is fitted with an automatic switch off function. This will
activate when the timer has elapsed, the air fryer will beep and go in
Standby automatically.
Note: To turn the unit back on press the button.

www.haden.com www.haden.com
14 15
PRE-SET COOKING FUNCTIONS
ICON FUNCTION DEFAULT TIME (MIN) DEFAULT
TEMPERATURE (°C)
Pre-heat 3 180
French fries 18 200
Meat 12 200
Drumsticks 20 200
Steak 12 180
Cake 25 160
Prawns 8 180
Fish 10 180
Pizza 20 180
Vegetables 10 160
Reheat 15 150
Dehydrate
360 (6 hours)
Adjustable time:
30 - 1440
60
• Try cooking food ingredients of similar sizes together. Large
food will require more cooking time than smaller food.
• Smaller ingredients usually require a slightly shorter
preparation time than larger ingredients.
• A larger amount of ingredients only requires a slightly longer
preparation time, a smaller amount of ingredients only requires
a slightly shorter preparation time.
• Shaking smaller ingredients halfway through the preparation
time optimises the end result and can help prevent unevenly
fried ingredients.
• You can coat fresh potatoes with a little oil for a crispy result.
• Fry your ingredients in the air fryer within a few minutes after
you have added the oil.
• Do not prepare extremely greasy ingredients such as sausages
in the air fryer.
• Snacks that can be prepared in an oven can also be prepared in
the air fryer.
• The optimal amount for preparing crispy fries is 500 grams.
• Use pre-made dough to prepare filled snacks quickly and easily.
Pre-made dough also requires a shorter preparation time than
home-made dough.
• You can also use the air fryer to reheat ingredients by setting the
temperature to 150°C and the timer to about 15 minutes.
COOKING TIPS

www.haden.com www.haden.com
16 17
TIMING SUGGESTIONS
Time
(min)
Temp (oC) Shake Extra
information
Potatoes & fries
Thin frozen fries 12-16 200 Shake
Thick frozen fries 12-20 200 Shake
Home-made fries 18-25 180 Shake Add 1/2 tbsp
of oil
Home-made wedges 18-22 180 Shake
Home-made cubes 12-18 200 Shake
Rosti 15-18 180
Potato gratin 18-22 180
Meat & Poultry
Steak 8-22 180
Pork Chop 10-14 180
Hamburger 7-14 180
Sausage roll 13-15 200
Drumsticks 18-22 180
Chicken breast 10-15 180
Snacks
Spring rolls 8-10 200 Shake
Use oven
ready
Frozen chicken nuggets 6-10 200 Shake
Frozen fish fingers 6-10 200
Frozen bread crumbed
cheese snacks 10 200
Stuffed vegetable 10 160
Note: Keep in mind that these settings are only for reference. As
ingredients differ in origin, size, shape as well as brand, we cannot
guarantee the best setting for your ingredients.
For the best results, we advise to use pre-baked fries. If you want to
make home-made fries, follow the steps below:
1. Peel the potatoes and cut them into fries.
2. Soak the fries in a bowl of water for at least 30 minutes, take
them out and dry them with kitchen paper.
3. Pour 1/2 tablespoon of olive oil in a bowl, put the fries on top
and mix until they are lightly coated with oil.
4. Remove the fries from the bowl with tongs so that excess oil
stays behind in the bowl. Place the fries in the basket.
Note: Do not tilt the bowl to place all the fries in the basket, to
prevent excess oil from collecting at the bottom of the basket.
5. Air fry the fries according to the timing suggestions (page 16).
MAKING HOME-MADE FRIES

www.haden.com www.haden.com
18 19
Clean the appliance after every use.
The frying tray, basket and the inside of the appliance has a non-
stick coating. Do not use metal kitchen utensils or abrasive cleaning
materials to clean them, as this may damage the non-stick coating.
1 Remove the mains plug from the wall socket and let the appliance
cool down.
Note: Remove the grill tray to let the air fryer cool down quickly.
2 Wipe the outside of the appliance with a moist cloth.
3 Clean the grill tray and basket with hot soapy water and a
non-abrasive sponge.
Note: The grill tray and basket are dishwasher-proof.
Tip: If dirt is stuck to the basket, or at the bottom of the grill tray,
fill the grill tray with hot water and with some washing up liquid.
Put the basket in the grill tray and let it soak for approx. 10 minutes.
1 Clean the inside of the appliance with moist cloth
2 Clean the heating element with a cleaning brush to remove any
food residues.
3 Do not submerge the air fryer in water!
CLEANING AND MAINTENANCE
STORAGE
1. Unplug the appliance and let it cool down.
2. Make sure all parts are clean and dry.
3. Store in a cool and dry place.
TROUBLESHOOTING
Problem Cause Solution
The air fryer
does not work.
The appliance is not plugged
into the mains.
You have not set the timer.
Put the mains plug in an
earthed wall socket.
Turn the timer knob to the
required Preparation time to
switch on the appliance.
The ingredients
fried with the air
fryer are not done.
The amount of the ingredients
in the pot is too much.
Put smaller batches of
ingredients in the pot. Smaller
batches are fried more evenly.
The set temperature is too low.
The preparation time is too
short.
Turn the temperature
control knob to the required
temperature setting
(see page 10).
Turn the timer knob to the
required preparation time
(see page 10).
The ingredients
are fried unevenly
in the air fryer.
Certain types of ingredients
need to be shaken halfway
through the cooking time.
Ingredients that lie on top of or
across each other (e.g. fries)
need to be shaken halfway
through the cooking time.
Fried snacks are
not crispy when
they come out of
the air fryer.
I cannot slide
the pot into the
appliance properly.
You used a type of snack meant
to be prepared in a traditional
deep fryer.
There is too much food
in the tray.
The pot is not placed in the pan
correctly.
Use oven snacks or lightly
brush some oil onto the snacks
for a crispier result.
Do not fill the tray beyond the
Max amount indicated on the
product.
Push the pot down into the pan
until you hear a click.

www.haden.com www.haden.com
20 21
TROUBLESHOOTING
Problem Cause Solution
White smoke
comes out of the
appliance.
You are preparing greasy
ingredients.
The pan still contains greasy
residues from previous use.
Pay attention that the
temperature is well-controlled
to be under 180ºC when you fry
greasy ingredients in the air fryer.
White smoke is caused by
grease heating up in the pan.
Make sure you clean the pan
properly after each use.
Fresh potato fries
are fried unevenly
in the air fryer.
You did not soak the potato
sticks properly before you
fried them.
Soak the potato sticks in a bowl
of water for at least 30 minutes;
take them out and dry them
with kitchen paper.
You did not use the right
potato type.
Use fresh potatoes and make
sure they stay firm during frying.
Fresh potato fries
are not crispy when
they come out of
the air fryer.
The crispiness of the fries
depends on the amount of oil
and water in the fries.
Make sure you dry the potato
sticks properly before you coat
them with oil.
Cut the potato into thinner
sticks for a crispier result.
Add slightly more oil for a
crispier result.
Note: When using the Air fryer for the first time, a slight smoke or
odour may be emitted. This is normal and will soon subside. Ensure
that there is sufficient ventilation around the fryer
This symbol indicates the product is classed as Electrical or
Electronic Equipment and should not be disposed of with other
household waste.
The Waste Electrical and Electronic (WEEE)
Directive has been introduced across the EU:
• To recycle waste electrical products using
the best available recovery and recycling
techniques.
• To minimise the impact to on the
environment
• To treat any hazardous substances
• To avoid increasing landfill
WEEE product should be disposed of by
handing it over at a designated collection point.
For more information about where to drop off
your waste product for recycling please contact
you local authority.
Product Code 206978
Rated Voltage 220-240V 50/60Hz
Rated Power 2200-2600W
Pot Capacity 9 Litre
Basket Capacity 2 x 4.5 Litre
TECHNICAL DETAILS
WASTE ELECTRICAL RECYCLING

www.haden.com
22
This product is guaranteed for 2 years from the date of original purchase.
If the product fails within this period due to faulty materials or workmanship, it
will be repaired, replaced or refunded at our discretion. Proof of purchase will be
required.
This warranty applies only to:
• Product installed and used in accordance with the instructions contained
in this manual.
• Product used for domestic purposes only.
• Product purchased in the UK and Ireland.
This warranty does not cover:
• Cosmetic damage.
• Normal wear and tear of consumable parts.
• Incorrect voltage supply or power surges.
• Customer misuse, modifications or adjustments.
• Products with unreadable or removed serial numbers.
Haden disclaims any liability for incidental or consequential loss or damages.
In the event of a problem:
• Please refer to the troubleshooting tips section within your user guide
for help and guidance.
• If you are still unable to resolve the problem, please contact our
technical support team for assistance.
When contacting Haden please provide:
• Product model number. Model & serial numbers can be found on the product
rating label.
• Date of purchase.
• Complete description of the problem.
This information will help our team assist you more quickly.
Help Line: 01909 544 570
Opening Hours: Monday - Friday 9am – 5pm
Email: [email protected]
WARRANTY (UK & IRELAND ONLY)
