Haier 10571570 User manual

No. *
Please read this manual carefully before using
Please keep this manual for future use
AB212BCBAA
0010571570
Haier Network Air Conditioner
Two by One Room Air Conditioner
CONTENTS
Before Use
Name of Parts ************* 3-4
Safety Precautions ********** 5-6
Operation Instruction
Fan Operation ************** 7
Auto, Cooling, Dehumidifying,
Heating operation ************ 8
Timer On/Off Function ******** 11
Timer On-Off Function ******** 12
Maintenance
Maintenance *************14-18
Usersí Attention ************ 13
Installation of Indoor Unit
Installation Instruction ****** 21 22
Installation Procedure ****** 23*36
*
Operation Points *********** 1-2
Troubleshooting *********** 19-20
Sleep Function ************* 10
Swing Operation ************ 9

Characteristics of Products
Far distance monitoring
There is a pre-set far distance control communication interface on the control
panel of indoor unit. After installing the peripheral equipment according to the
manual attached with the Haier made far distance control detector, the computer
management or other place monitoring can be achieved to the air conditioner.
Characteristics of Products
1.Free combination multi-split.
2.Four-direction air sending, more even temperature adjustment.
3.Inner hidden type installation, space-saving; harmonized with the ceiling, exquisite
and beautiful.
4.Powerful circular air volume, quick temperature adjustment.
5.This air conditioner has POWER FAILURE RESUME FUNCTION.
6.Anti-bacteria mildew resistant air filter, fresher air creates more healthy.
This unit has the function of far distance monitoring. Through the telephone
network, it can be effectively controlled in any other far-distance place. (Only
after equipped with the ìfar distance detectorî made by our company can this
function be fulfilled.)
7.This unit has the function of far distance monitoring. Through the telephone network,
it can be effectively controlled in any other far-distance place. (Only after equipped
with the ìfar distance detectorî made by our company can this function be fulfilled.)

Operation points
1
Operation of air conditioner
When the ambient humidity is too high,
in COOLING or DEHUMIDIFYING
mode, there may be water dropped
in the air outlet.
Far distance monitoring
There is a pre-set far distance control communication interface on the
control panel of indoor unit. After installing the peripheral equipment
according to the manual attached with the Haier made far distance
control detector, the computer management or other place monitoring
can be achieved to the air conditioner.
If start the unit immediately only after
it is turned off, the compressor will start
after 3 minutes have elapsed to protect the
compressor.
3-minute protection function
Change of fan speed
In COOLING mode, the air sending is set at AUTO, when the indoor
temperature is near the set temperature,
the fan speed will lower automatically.
In HEATING mode, when room
temperature reaches the set temperature,
the compressor will stop running, and
the fan will change to LOW FAN or stop.
In DEHUMIDIFYING mode, the fan speed
will change automatically.

Operation points
Anti-cold air blowing out
Defrosting function
During Heating operation, after
starting the unit, the indoor fan
motor will not rotate immediately
to prevent cold air from blowing out.
During Heating operation, when frost formed
on the heat exchanger of outdoor unit, the air
conditioner will defrost automatically for
several minutes. During defrosting, both
the fan of indoor and outdoor unit do not
run. After finishing defrosting, the air
conditioner will automatically resume operation.
Hint
When the air conditioner is in Heating mode,
it absorbs heat from outside and release to
indoors. So the outdoor temperature may
affect the Heating effect.
Power failure resume function
(please set and use this function according to actual condition)
After setting power failure resume function, if there is a sudden power
failure during unit operation, when power on for again, the unit will
resume the previous state.
Setting method: when the wire controller is in ON state (except for
TIMER and FAN mode), press the SLEEP button for 10 times in 5
seconds, after the buzzer sounds 4 times, the unit will change to
POWER FAILURE RESUME function.
Cancellation method: press the SLEEP button 10 times in 5 seconds, after
the buzzer 2 times, the POWER FAILURE RESUME function is cancelled.
Note: After the unit is set POWER FAILURE RESUME function, if there
is a sudden power failure in using, during this period of time if there is no
need to use the unit for a long time, please cut off power to prevent the air
conditioner from automatically resuming to the previous setting if power
failure resumes, or press the ON/OFF button to turn off the unit after power
failure resumes.
2
?
Please wait

Connection pipes
and electric wire
Drain hose Louver
Louver
Air filter
(inside of air outlet)
(inside of air inlet grille)
Air inlet grille
Air outlet
Name of Parts
Indoor Unit
Wire Controller
** ** **
**
**
**
**
**
** ****
AUTO
**
**
**
**/**
3

Name of Parts Wire Controller
14.Network control display
Used to adjust the
time of timer and
clock
When the wire
controller appears
abnormal condition,
use a sharp-pointed
article to press this
button to make the
wire controller
resume normal
After cleaning the
air inlet, press this
button, the unit
can start to operate
12.Humidifying state display
Used to turn on/off unit
1.ON/OFF button
6.Air filter cleaning display
*
7.Super/Soft operation display
13.Sleep state display
2.Temperature display
24.Time Adjusting
button
23.Sleep button
Used to set Sleep
state or Power
Failure Resume
Function
When there is too much dust
collected on the air inlet, the
wire controller will show
this display to remind the
user to clean the air inlet.
After cleaning and installation,
just press the air filter reset button.
8.Fan speed display
9.Auto Swing display
11.Fresh air state display
25.Reset button
26.Air Filter Reset
button
27.Timer button
Used to set the
mode of timer
28.Lock state display
29.Electric heating button
4.Timer ON/OFF display
3.Clock display
17.Operation mode button
5.Humidity display
22.Setting button
Used to confirm
the time of timer
and clock
15.Working mode display
21.Clock button
Used to calibrate the time of
timer and clock
16.Electric heating display
Used to set working mode:
Auto, Cooling, Dehumidifying,
Heating, Fan
18.Fan speed button
Used to set fan speed: Low
Fan, Med Fan, High Fan, Auto
20.Temperature Setting button
29
** ** **
**
**
**
**
**
** ****
**
**
**
**/**
1
2
3
4
5
6
7
8
9
11
12
13 14 15 16 17 18
20
21
22
23
24
25
26
27
28
AUTO
10.Health state display Used to set temperature,
temperature range: 16*~30*
10
19
19.Swing button
Used to set Auto Swing or
Fixed air sending direction
4
Calibration of clock
When turning on the unit for the first time, the clock should be calibrated. The
method of calibration is:
1.Press “Clock” button, the Clock display “AM” “PM” will flash.
2.Press *or *to adjust time. For each press, the time will increase or*decrease 1
*minute. If depressing the button, the time will increase or decrease*rapidly.
3.After confirming the time, press “Set” button, “AM” or “PM” will stop flashing,
*the clock will begin to work.
Note:1.This model does not have the following related display and function
2.Non-electric heating type, there is no electric heating button and electric heating
display
* * 10 11 12 28
16 29
Auto
Low Fan Med Fan High Fan Auto
Working
mode Auto operationCooling operationDehumidifying operation Heating operationFan operation
Wire
controller

When repair is needed, please ask
the after-sales service worker for
help.
Improper repair and maintenance
may cause water leakage,
electric shock
and fire.
If finding abnormal phenomenon
(e.g. smell of firing), please cut off
the power first, and contact the
after-sales service worker
for treatment.
Under this
circumstance,
if continue using
the air conditioner,it may be
damaged, it may also cause electric
shock or fire accident.
During unit operation, do not insert
fingers or other objects into air inlet,
air outlet and louver.
Because high
rotation speed
fan is dangerous,
it may cause injury.
Ask after-sales service worker to take
measure to prevent refrigerant from
leaking.
If the leaked refrigerant exceeds a
certain density, it will cause
lack of oxygen. If the room
installed with air conditioner
is too small, do take enough
measure in order to avoid lack of
oxygen even if refrigerant leaks.
When have to dismantle and reinstall
the air conditioner, please ask the
after-sales service worker to perform
the work.
Improper installation may
cause water leakage,
electric shock or fire.
Cut off
power
Safety Precautions
The following lists four kinds of safety precaution items and suggestions:
Warning: Improper use may cause death or serious injury.
* Those contents marked with “Forced” are definitely forced action,
otherwise, it may cause unit damage or risk to users’ safety.
Notice: Improper use may cause body hurt or unit damage; in some
circumstance, it may cause serious results.
Those contents marked with “Prohibition” are definitely prohibited
action, otherwise, it may cause unit damage or risk to users’ safety.
The following safety precautions must be observed.
This safety precautions should keep in hand for reference.
If the air conditioner is given to a new user, this manual should be attached with
unit to the new user.
!
!
Warning
!
*
Please read the following Safety Precautions carefully and use the
air conditioner properly.
5

Safety Precautions
6
Notice
Do not use wet hands to operate the
air conditioner.
Otherwise, it may
cause electric shock.
Only use the proper specified fuse.
Do not use cable or
other materials to
replace the fuse,
otherwise it may
cause fire and
other trouble.
Do not use water to
clean air conditioner,
otherwise
may cause
electric shock.
Connected with the grounding wire.
The grounding wire shouldn’t be
connected with gas pipe, tap water pipe,
lightning rod or
telephone line.
Improper grounding
may cause electric shock accident.
The drain hose should be
arranged properly to have a
smooth drainage.
If the drain hose is
not arranged properly, the leaked
drain water may damage the
furniture or other articles alike.
Do not install the air conditioner
in a place where the inflammable
gas maybe exists.
The inflammable gas around the
air conditioner may cause fire
accident.
The Creepage breaker should
be equipped.
If not equipped
with Creepage breaker, it may
cause Creepage.
When using indoor smoky type
pesticide, do not use air
conditioner.
Otherwise, it
may cause the
chemicals
accumulate
in the unit, result in
doing harm to the people’s health
who is extremely sensitive to
these chemicals.
Do not put the fire devices in the
places, which the air from the air
conditioner can directly blow.
It may cause the
fire devices
cannot burn
completely.
Only after cutting off the power, can
the cleaning of the air conditioner be
performed to
avoid leading
to electric
shock or
injury.
Do not put or use any spray near the
air conditioner,
otherwise it
may cause
fire.
Not in
operation

Fan operation
About FAN operation:
FAN operation refers the air conditioner does not perform COOLING and
HEATING operation, but FAN operation. In this mode, the air conditioner
cannot perform AUOT FAN operation, and does show the temperature
value on the wire controller.
Turn on the unit
Press the ON/OFF button to turn on the
unit The LCD display of the wire controller
will show the previous working state
(except for Timer, Sleep, Swing mode), the
operation indicator light on the wire controller
will light up.
2Choose of working mode
Press MODE button, each press the
working mode will change as the
following sequence:
.
choose FAN operation
Adjusting FAN SPEED
Press the FAN SPEED button to change fan
speed:
3
4Turn off the unit
Press the ON/OFF button to turn off the
unit.
The wire controller only shows the clock and
room temperature.
Choose the desired fan speed
7
COOLING DEHU
AUTO HEATING FAN
1
LOW FAN MED FAN HIGH FAN
Operation instruction
** ** **
**
**
**
**
**
**** **
**/**
**
1
4
3
2

Operation instruction Auto/Cooling/Dehumidifying/Heating operation
Hints:
The wire controller can memorize the working condition of each time. When
start the unit for the second time, just need to press ON/OFF button, the air
conditioner will work according to the previous working mode. (except for
Timer, Sleep and Swing)
Turn on the unit
Press the ON/OFF button to turn on the
unit The LCD display of the wire
controller will show the previous
working state (except for TIMER,
SWING, SLEEP mode). The operation
indicator light on the wire controller
will light up.
3
1
Choose of working mode
Press MODE button, each press the
working mode will change as the
following sequence:
then choose AUTO, COOLING,
DEHUMIDIFYING, HEATING operation.
Set temperature
*Each press , the set temperature will
increase 1 degree.
*Each press, the set temperature will
decrease 1 degree.
Set the desired temperature.
Press the TEMP. SET button
Adjusting FAN SPEED
Press the FAN SPEED button, for each
press, the fan speed will change as the
following sequence:
Choose the desired fan speed.
In Heating operation, after start
the unit, the air conditioner will
sending warm air a moment
later to prevent the cold air
blowing out. In Dehumidifying,
when the room temperature drops
2*higher than the set
temperature, regardless the set fan
speed, the air conditioner will
intermittently operate in low fan
speed.
4
** ** **
**
**
**
**
**
** ****
**
**
**/** 5
1
4
3
2
3
5Turn off the unit
Press the ON/OFF button to turn off
the unit.
The wire controller only shows the clock
and room temperature.
2
8
AUTO COOLING DEHUMIDIFYING HEATING FAN
AUTO
LOW FAN MED FAN HIGH FAN AUTO
Set temperature + 2*
Set temperature
When room temperature
reaches set temperature
+ 2*, the unit will
operate in mild
dehumidifying
operation.
Ultra-low air flow
When room temperature
is higher than set
temperature, unit in
COOLING operation.
