CASSETTE TYPE AIR CONDITIONER
Operation & Installation
Manual
AB092ACBJA
AB122ACBJA
AB142ACBJA
AB182ACBJA
AB142ACBFA
AB182ACBFA
Please read this operation manual before using the air conditioner.
Please keep this manual carefully and safely.
051220***,*AB092/122ACBIA***
**AB092/122ACBJA*******

CASSETTE TYPE AIR CONDITIONER
Contents
Cautions .............................................................................................
Main Points of Operation...................................................................
Part Name...........................................................................................
Safety Precautions..............................................................................
Maintenance ......................................................................................
When Trouble Happens .....................................................................
Customer Need-to-know ...................................................................
Installation Tools ...............................................................................
Installation Procedures ......................................................................
Troubleshooting ................................................................................
Failure code .........................................................................................
Check and Test Run ..........................................................................
1-2
3-4
5
6-7
8-9
10
11
12
13-20
21-22
23
24

Cautions
1
For the purpose of safety, the air
conditioner must be properly grounded in
accordance with specifications.
Always remember to unplug the air
conditioner before opening inlet grill. Never
unplug your air conditioner by pulling on the
power cord. Always grip plug firmly and
pull straight out from the outlet.
Damaged air conditioners are not to be
put into operation. In case of doubt, consult
your supplier.
Use of the air conditioner is to be carried
out in strict compliance with the relative
instructions set forth in the User's Guide.
Installation shall be done by professional
people, don't install unit by yourself.
All electrical repairs must be carried out by
qualified electricians. Inadequate repairs may
result in a major source of danger for the user
of the air conditoiner.
Do not damage any parts of the air
conditioner that carry refrigerant by piercing
or perforating the air conditioner's tubes with
sharp or pointed items, crushing or twisting
any tubes, or scraping the coatings off the
surfaces. If the refrigerant spurts out and gets
into eyes, it may result in serious eye injuries.
Disposal of the old air conditioner
Before disposing an old air conditioner
that goes out of use, please make sure it's
inoperative and safe. Unplug the air
conditioner in order to avoid the risk of
child entrapment.
It must be noticed that air conditioner
system contains refrigerants, which require
specialized waste disposal. The valuable
materials contained in a air conditioner can
be recycled. Contact your local waste
disposal center for proper disposal of an
old air conditioner and contact your local
authority or your dealer if you have any
question. Please ensure that the pipework
of your air conditioner does not get
damaged prior to being picked up by the
relevant waste disposal center, and
contribute to environmental awareness by
insisting on an appropriate, anti-pollution
method of disposal.
Disposal of the packaging of your new
air conditioner
All the packaging materials employed in
the package of your new air conditioner
may be disposed without any danger to the
environment.
The cardboard box may be broken or cut
into smaller pieces and given to a waste
paper disposal service. The wrapping bag
made of polyethylene and the polyethylene
foam pads contain no fluorochloric
hydrocarbon.
Safety Instructions and Warnings
Before starting the air conditioner, read the
information given in the User's Guide
carefully. The User's Guide contains very
important observations relating to the
assembly, operation and maintenance of the
air conditioner.
The manufacturer does not accept
responsibility for any damages that may
arise due to non-observation of the following
instruction.
All these valuable materials may be taken to a
waste collecting center and used again after
adequate recycling.
Consult your local authorities for the name and
address of the waste materials collecting
centers and waste paper disposal services
nearest to your house.

2
Do not obstruct or cover the ventilation
grille of the air conditioner. Do not put
fingers or any other things into the
inlet/outlet and swing louver.
Do not allow children to play with the air
conditioner. In no case should children be
allowed to sit on the outdoor unit.
Specifications
The refrigerating circuit is leak-proof.
1. Applicable ambient temperature range:
The machine is adaptive in following
situation
Cautions
Cooling
Heating
Indoor
outdoor
Rated Maximum Minimum
27 32 18
19 23 14
35 43 -5
24 26 --
20 27 15
14.5 -- --
7 24 -7
6 18 --
DB C
WB C
DB C
WB C
Indoor
outdoor DB C
WB C
DB C
WB C
Cooling
Heating
Indoor
outdoor
Rated Maximum Minimum
27 32 18
19 23 14
35 43 10
24 26 --
20 27 15
14.5 -- --
7 24 -7
6 18 --
DB C
WB C
DB C
WB C
Indoor
outdoor DB C
WB C
DB C
WB C
AB142/182ACBFA:
Other Instructions
*****
2.Ifthesupply cordis damaged,it mustbe
replacedby themanufacturer orits service
agent ora similarqualified person.
3.If thefuse onPC boardis broken,please
changeit withthe typeof T3.15A/250VAC.
4. Use copper wire only.The connecting cable
should be H05RN-F 3G(2.5mm2+H05RN-F
1x 0.75mm2. The power cable should be
H05RN-F 3G 2.5mm2.All the cables shall
have got the European authentication certificate.
***************
AB092/122ACBJA AB142/182ACBJA:
051220*********
1. The waste battery should be disposed properly.
When throw away the waste batteries, please
perform in accordance with the local regulation.
2. The indoor unit installation height is at least
2.5m.certificate.
5. The power cord should be self-provided and
it should have got the Local authentication
certificate.
6. The air breaker should be all-pole switch.
and the distance between it's two
connecters should no less than 3mm.
7. Air conditioner must use special power supply
system (above 20A), and qualified electrician
makes wiring and fixing according to wiring
regulations specified in national standard.
8. In socket, exactly distinguish earth wire with
neutral wire and it is wrong to connect them
together.
9.Aleakage breaker must be installed.
10. Connection method is Y-connection .If the
power cord is damaged, it must be replaced
by professional people of manufacturer or its
maintenance department or similar to avoid
dangers.
11. The air breaker and the power switch should
installed the conveniently reachable place for
user.
AB142ACBFA AB182ACBFA:
Attention:
As a result of poor conditions of the electrical
MAINS, shortly voltage drops can appear
when starting the EQUIPMENT. This can
influence other equipment (et.Blinking of a
lamp). If the MAIN-IMPEDANCE Zmax<
0.3970617HM, such disturbance are not
expected. In case of need , you may contact
your local supply authority for further
information.

3
Main Points of Operation
Operation of Air Conditioner
When the environmental humidity is heavy,
water will be dripped from the air outlet in
cooling or drying mode.
3-minute Protection Function
If restarting the unit immediately after unit stops,
the compressor will start only 3 minutes later
to protect the machine.
Diferent Fan Speed
If fan speed is in auto mode, it will automatically
lower when the room temperature is close to the
setting temperature in cooling mode.
In heating mode,the compressor stops when the
room temperature is at setting temperature and fan
turns into low speed or stops.
In Dry mode,fan speed will be automatically adjusted.
Remote Control:
There is a telecommunication interface for remote control on the operation
panel of the indoor unit. After the peripheral equipment have been installed
in accordance with the instruction manual of the selected remote control
detector, the air conditioner will be computerized and controlled from a distant
away place.

4
Main Points of Operation
Anti-cold Blowing Off
In heating mode,the indoor fan will not run
immediately after the unit starts up, which will the
cold air being blow out.
Defrosting Function
In heating mode, when frost is formed on the outdoor heat
exchanger, the air conditioner will automatically defrost for
few minutes. During defrosting, both indoor fan and outdoor
fan will stop running. When defrosting finishes, air condi-
tioner will automatically be back to running.
Hints
The air conditioner absorbs heat form outdoor and
releases to indoor when in heating mode, therefore the
outdoor environmental temperature will affect heating
efficiency.
Auto-restant function(to be applied for a necessary situation):
After the auto-restant function is set, if power failure suddenly occurs while the air
conditioner is working,it will resume the previous working state when the power is supplied
again.
Setting Method: When the remote controller is on (excluding timer mode and fan mode),press
the ìSLEEPî button on the remote controller 10 times within 5 seconds,and
after the buzzer sounds 4 times, the air conditioner will enter the state of auto-
restant function
Cancel Method:Press the ìSLEEPî button on the remote controller 10 times within 5 seconds,
and after the buzzer sounds 2 times, the auto-restant function will be
cancelled.
Note: When a power failure suddenly occurs during the air conditioner is working after the
auto-restant function is set,if the air conditioner will not be used for a long
time, please shut off the power supply to prevent its operation from being resumed
after the power is supplied again, or press the ì ON/OFF î button after the power come
again.
Defrosting Running
Wait a
minute

5
Indoor unit
Part Name
outdoor unit
Swing louver
(Air flow direction can be adjusted by using
the SWING button on the remote controller)
Air Inlet Grille
Air Filter
(Inside of the Inlet Grille)
Operating Control Panel
Air inlet
Air outlet
Drain hose
Connecting piping
and electrical wiring
Remote receiver
Compressor Lamp
TIMER Lamp
OPERATION Lamp
Power Lamp
Emergency switch
1
2
3
4
5
COMP TIMER OPER POWER
1 2 3 4 5
Operating Control Panel
6
6
051220**********

6
Below are listed four kinds of Safety Precautions and Suggestions:
Be sure to conform with the following important Safety Precautions.
The Safety Precautions should be at hand so that they can be checked at any time when necessary.
If the air conditoner is transferred to the new user, this manual should be as well transferred to the new
user.
Safety Precautions
Incorrect operations may result in severe consequences of death or serious injures.
WARNING:
Incorrect operations may result in injures or machine damages; in some cases may
cause serious consequences.
CAUTION :
: It must be strictly prohibited where being marked with ì Prohibited î, otherwise may
result in machine damages or endanger the usersípersonal safety.
This information can ensure the correct operation of the machine.
INSTRUCTION:
Carefully read the following information in order to operate the air conditioner correctly.
WARNING
If any abnormal phenomena are found (e.g.
smell of firing),please cut off the power supply
immediately, and contact the dealer to find outí
the handling method.
When the unit needs maintenance
and repair,call dealer to handle it.
Donít put figures or any other
things into the inlet/outlet and
swing louver while the conditi-
oner is in operation
Call the dealer to take measures to prevent the
refrigerant from leaking.
Switch
off
In such case,to continue using
the air conditioner will damage
the conditioner,and may cause
electrical shock or fire hazard.
Incorrect maintenance and repair
may cause water leak,
electrical shock or fire hazard.
Because the high-speed fan
is very dangerous and may cause
injures.
The leaked refrigerant over certain density may
cause oxygen deficient.If the air conditioner is
installed in a small room be sure to take measure
in order to prevent suffocation accident even in
case of refrigerant leakage
When air conditioner is removed and reinstalled
dealer should be responsible for them.
Incorrect installation may cause water leaking,
electrical shock and fire hazard.
Donít dismantle the outlet of the outdoor unit.
The exposure of fan is very
dangerous witch may harm
human beings.
After air conditioner has been used for a long time,
the base should be checked for any damages.
If the damaged base is not
repaired, the unit may fall
down and cause accidents.

7
WARNING
No goods or nobody is permitted
to be placed on or stand on
outdoor unit.
Donít clean air conditioner
with water.
The falling of goods and
people may cause accidents.
Don't operate the air conditioner with
damp hands.
Otherwise will be shocked.
Don't use incorrect type fuse.
May not use wire or any other
materials replacing fuse,othe-
rwise may cause faults or fire
accidents.
Donít place any burning
unit in the airflow of air
conditioner,which may
cause incomplete
combustion
No inflammable spray fluid
should be permitted to be
placed or used near air
conditioner,otherwise may
cause fire accident.
Air conditioner should be
cleaned only after power
supply is cut off to keep
from shock or hurt.
Otherwise may cause shock.
Connect earthing wire.
Earthing wire should not be
connected to the gas pipe,
liquid pipe,lightning rod or
phone line,incorrect earthing
may cause shock.
Use discharge pipe correctly to
ensure efficient discharge.
Incorrect pipe usage may cause water
leaking.
Air conditioner canít be be installed in
the environment with inflammable gas.
The inflammable gas near air conditioner
may cause fire hazard.
Installed electrical-leaking circuit breaker.
When useing the fumigating insecticide
donít operate air conditioner.
Otherwise the poisonous chemicals
may damage air conditioner,
and will harm the health of
chemical-allergic people.
It easily causes electrical shock without
circuit breaker.
Not permitted
when running
Safety Precautions

8
Maintenance
Clean the unit
Turn off the power supply switch Do not touch with wet hand. Do not use hot water or volatile liquid
Take down air inlet grille
Clean the air filter
Clean the air filter with water or vacuum cleaner.
Use the detergent or neutral soapy water if the
air filter is too dirty. Then rinse the air filter with
water,and reinstall after it isdry.
Caution:
Do not clean the air filter with hot water over 40 C,
otherwise may damage the filter.
Sweep the filter carefully.
Clean indoor/outdoor unit
Clean with hot wet cloth and neutral detergent, then wipe with
dry cloth.Do not use too hot water (over 40 C) which may result
in fading and deforming. Do not use insecticide and chemical
washing agent.
Fixing nolt
lock
filter corner
grille edge
take out the grille
press the locks
As the figure, press the two locks on air inlet grille
vertically, and make it move to grille, then rise
it up 45 degree gently to take out the grille.
Take down the filter
Press the outside two edges of inlet grille with
the thumbs, and pull out the filter corner with the
forefingers, to rise the filter up after it moves
away from the locks, then take out the filter.
ON
OFF
