Haier AB094FAAHA Manual

Please read this operation manual before using the air conditioner.
No.0010576722A
Indoor Unit Operation & Installation
Manual
CASSETTE TYPE AIR CONDITIONER
Please keep this manual carefull and safel .
AB094FAAHA
AB124FAAHA
AB184FCAHA
AB244FCAHA
AB424FCAHA
AB484FCAHA

Contents
Cautions ...........................................................................................
Part name of the unit........................................................................
Maintenance......................................................................................
Trouble Shooting ..........................................................................
When Trouble Happens..................................................................
Customer Need-to-know.....................................................................
Installation Procedure ....................................................................
1-5
6
7-9
10-11
12-13
14
15-25
Electrical Wiring..............................................................................
Technical Specification....................................................................
26-28
29

Cautions
1
Disposal of the old air conditioner
Before disposing an old air conditioner
that goes out of use, please make sure it's
inoperative and safe. Unplug the air
conditioner in order to avoid the risk of
child entrapment.
It must be noticed that air conditioner
s stem contains refrigerants, which require
specialized waste disposal. The valuable
materials contained in a air conditioner can
be rec cled. Contact our local waste
disposal center for proper disposal of an
old air conditioner and contact our local
authorit or our dealer if ou have an
question. Please ensure that the pipework
of our air conditioner does not get
damaged prior to being picked up b the
relevant waste disposal center, and
contribute to environmental awareness b
insisting on an appropriate, anti-pollution
method of disposal.
Disposal of the packaging of your new
air conditioner
All the packaging materials emplo ed in
the package of our new air conditioner
ma be disposed without an danger to the
environment.
The cardboard box ma be broken or cut
into smaller pieces and given to a waste
paper disposal service. The wrapping bag
made of pol eth lene and the pol eth lene
foam pads contain no fluorochloric
h drocarbon.
Consult our local authorities for the name and
address of the waste materials collecting
centers and waste paper disposal services
nearest to our house.
Safety Instructions and Warnings
Before starting the air conditioner, read the
information given in the User's Guide
carefull . The User's Guide contains ver
important observations relating to the
assembl , operation and maintenance of the
air conditioner.
The manufacturer does not accept
responsibilit for an damages that ma
arise due to non-observation of the following
instruction.
Damaged air conditioners are not to be
put into operation. In case of doubt, consult
our supplier.
Use of the air conditioner is to be carried
out in strict compliance with the relative
instructions set forth in the User's Guide.
Installation shall be done b professional
people, don't install unit b ourself.
All these valuable materials ma be taken to a
waste collecting center and used again after
adequate rec cling.
For the purpose of safet , the air
conditioner must be properl grounded in
accordance with specifications.
Alwa s remember to unplug the air
conditioner before opening inlet grill. Never
unplug our air conditioner b pulling on the
power cord. Alwa s grip plug firml and
pull straight out from the outlet.

4. The wiring method should be in line with the
local wiring standard.
5. The power cable and connecting cable are
self-provided. The requirement of the power
cable:H05RN-F 3G 1.5mm2
The requirement of the connecting cable:
All the cables shall have got the European
authentication certificate.
6. The breaker of the air conditioner should be
all-pole switch; and the distance between its two
contacts should be no less 3mm. Such means for
disconnection must be incorporation in the fixed
wiring.
7. The waste batter shall be disposed properl .
8. The indoor unit installation height is at least
2.5m.
2
All electrical repairs must be carried out
b qualified electricians. Inadequate repairs
ma result in a major source of danger for
the user of the air conditoiner.
Do not damage an parts of the air
conditioner that carr refrigerant b
piercing or perforating the air conditioner's
tubes with sharp or pointed items, crushing
or twisting an tubes, or scraping the
coatings off the surfaces. If the refrigerant
spurts out and gets into e es, it ma result
in serious e e injuries.
Do not obstruct or cover the ventilation
grille of the air conditioner. Do not put
fingers or an other things into the
inlet/outlet and swing louver.
Do not allow children to pla with the air
conditioner. In no case should children be
allowed to sit on the outdoor unit.
Specifications
The refrigerating circuit is leak-proof.
1. Applicable ambient temperature range:
The ma hine is adaptive in following
situation
2. If the suppl cord is damaged, it must be
replaced b the manufacturer or its service
agentor a similar qualified person.
3. If the fuse on PC board is broken please
change it with the t pe of T 3.15A /250VAC.
Cooling
Heating
Indoor
outdoor
DB C
WB C
DB C
WB C
Indoor
outdoor DB C
WB C
DB C
WB C
Cautions
H05RN-F 2¡`(1.0~1.5)mm2
Rated Maximum Minimum
27 32 21
19.5 23 15
35 43 21
24 26 15
20 27 20
15 15 15
7 21 -10
6 15 --

3
WARNING!
Carefully read the following information in order to operate the air onditioner orre tly.
Below are listed three kinds of Safet Cautions and Suggestions.
WARNING!
CAUTION! Incorrect operations ma result in injuries or machine damages; in some cases ma
cause serious consequences.
Incorrect operations ma result in severe consequences of death or serious injuries.
INSTRUCTIONS: These information can ensure the correct operation of the machine.
Be sure to conform with the following important Safet Cautions.
The Safety Cautions should be at hand so that they an be he ked at any time when needed.
If the conditioner is transferred to the new user, this manual should be as well transferred to the new user.
Otherwise the one
will feel unpleasant
or harm ones' health.
If any abnormal phenomena is found (e. g.
smell of firing), please ut off the power
supply immediately, and onta t the dealer
to find out the handling method.
In such case, to continue
using the conditioner will
damage the conditioner,
and ma cause electrical
shock or fire hazard.
When need maintenan e and repairment,
all dealer to handle it.
Incorrect mainten-
ance and repairment
ma cause water
leak, electrical shock
and fire hazard.
switch
off
Please let the dealer be responsible for installing
the onditioner.
Incorrect installation ma cause water leak, elec-
trical shock and fire hazard.
Don't put fingers or any other things into the
inlet/outlet and swing louver while the ondi-
tioner is in operation.
Because the highspeed
fan is ver dangerous
and ma cause injuries.
Call the dealer to take measures to prevent the
refrigerant from leaking.
If conditioner is installed in a small room be sure
to take ever measure in order to prevent suffoca-
tion accident even in case of refrigerant leakage.
When onditioner is deinstalled or reinstalled
dealer should be responsible for them.
Incorrect installation ma cause water leaking,
electrical shock and fire hazard.
Don't blow the human body with the ooling
air too long, and don't let the room tempera-
ture de rease too low
either.
Safety autions
Cautions

4
CAUTIONS!
Conditioner should not be used for any other
purpose other than air onditioning.
Don't use air-conditioner for an other special
purposes, e.g. the preservation and protection
of food, animals, plants,
pecision apparatus as well
as work of art, otherwise
the qualities of these
stuffs ma be damaged.
Don't dismantle the outlet of the outdoor unit.
The exposure of fan is
ver dangerous which
ma harm human be-
ings.
When air- onditioner is o-used with other
heat-radiator the frequent repla ement of
room atmosphere should be required.
Inefficient venti-
lation ma cause
suffocation.
After a long time use of air- onditioner the
base should be he ked for any damages.
If the damaged base is
not repaired, the unit
ma fall down and
cause accidents.
No goods or nobody is permitted to pla ed on
or stand on outdoor unit.
The falling of goods and
people ma cause acci-
dents.
Pets and plants should not be blowed dire tly
in the air flow.
Otherwise will suffer
damage.
Don't operate the air- on-
ditioner with damp hands.
Otherwise will be shocked.
Only use orre tly-typed fuse.
Ma not use wire or an other
materials replacing fuse, other-
wise ma cause faults or fire
accidents.
Don't pla e any burning unit
in the air flow of air- onditioner,
whi h may ause in omplete
ombustion.
No inflammable spray fluid
should be permitted to be
pla ed or used near to air-
onditioner otherwise may
ause fire a idents.
Air- onditioner should be
leaned only after power
supply is ut off to keep
from sho k or hurt.
Don't lean air- onditioner
with water.
Otherwise ma cause
shock.
Otherwise the poisonous chemicals ma settle
in air-conditioner which harm the health of
chemical-allergic people.
When use the fumigating inse ti ide don't
open air- onditioner.
Cautions

5
WARNING !
CAUTION !
Please ask the dealer or specialist to install, never tr b the users themselves. After the installation please
be sure of the following conditions.
Incorrect installation ma cause water leaking, shock and fire hazard.
Please all dealer to install the air- onditioner.
Air- onditioner an't be installed in the envi-
ronment with inflammable gases be ause the
inflammable gases near to air- onditioner may
ause fire hazard.
Installed ele tri al-leaking ir uit breaker.
Conne t earthing wire.
Use dis harge pipe orre tly to ensure effi ient
dis harge.
[Lo ation]
[Wiring]
[Operating noise]
It easil cause electrical shock without circuit
breaker.
Air-conditioner should be located in well-vented
and easil -accessible place.
Air-conditioner should not be located in the
following places:
(a) Places with machine oils or other oil vapours.
(b) Seaside with high salt content in the air.
(c) Near to hot spring with high content of sulfide
gases.
(d) Area with frequent fluctuation of voltage e.g.
factor , etc.
(e) In vehicles or ships.
(f) Kitchen with heav oil vapour or humidit .
(g) Near to the machine emitting electric-magnetic
waves.
(h) Places with acid, alkali vapuor.
TV, radio, acoustic appliances etc are at least 1 m
far awa to the indoor unit, outdoor unit, power
suppl wire, connecting wire, pipes, otherwise
images ma be disturbed or noises be created.
Earthing wire should not be con-
nected to the gas pipe, water pipe,
lightning rod or phone line, in-
correct earthing ma cause shock.
Incorrect pipe use ma cause water leaking.
As required, take measures against heav snow.
Air-conditioner should be equipped with special
power suppl wire.
Choose the following locations:
(a) Capable of supporting air-conditioner weight,
don't increase operating noise and vibration.
(b) Hot vapour from outdoor unit outlet and ope-
rating noise don't disturb neighbour.
No obstacles around the outdoor unit outlet.
Earthing
Installation
Cautions

Introdu tion to Spare Parts
6
Drain Hose
Swing fender
Refrigerant pipe
Cable line
Earthing line
Air filter
Outlet
Suction grill
(located in the suction grill)
In cooling operation,
to discharge the
water from inside the
room.
Discharge unit (built in)
(located in the outlet)
Anti-bacteria filter
Air intakeAir Outlet

7
3. Dismantle air filter
CAUTION!
4. Clean
6. Close inlet grill
(A) Remove dust with vacuum filter.
5. Install air filter
(1) Put filter into protruding parts at the top of
the inlet grill.
(2) Connect the two pothooks with inlet grill
See 2
[Clean inlet grill]
1. Open inlet grill
See 1.
Connect the two pothooks with inlet grill
PUSH
Press the elliptical knob
the inlet grill will
automaticall drop
Open two
pothooks
Pothook
Press the elliptical "PUSH" knob, the inlet
grill will automaticall drop. (the inlet grill
is catched with two pothooks)
Drag the knob of
the grill back lift
the filter and take
down.
Air filter
Maintenan e
[Clean air filter]
NOTE
1. Open inlet grill
Press the elliptical "PUSH" knob, the inlet
grill will automaticall drop. (the inlet grill
is catched with two pothooks)
When having to clean, don't dismantle
air-filter,otherwise ma cause faults.
In the environment where there is too
much dust, air filter should be cleaned
for more times.
(about half a ear one time)
2. Open two othooks
(B) Wash with water.
With too much dust, use soft brush and neutral
detergent.
Swing off the water, and then place in cool place.
PUSH
Press the elliptical knob
the inlet grill will
automaticall drop
Open two
pothooks
Pothook

8
3. Take of inlet grill
4. Clean
CAUTION!
NOTE
When the filter too mu h dust
To spra the special detergent for vent fan or
utensils.
5. Install inlet grill
6. Install air filter
7. Close inlet grill
[Clean outlet and shell]
see 3
see "Clean air filter"
see 1
CAUTION!
Don't use gasoline, benzene, dilutant,
polishing powder, or liquid inseticide.
[Dismantle and install swing
plate ]
1. Fix the swing plate at the bottom.
2. Dismantle the swing plate.
CAUTION!
Use water to clean the plate and don't heavil
scrub, otherwise the fine hair ma fall off.
Unscrew the screw at both ends of the swing
plate.
[Dismantle and install swing
plate ]
3. Install swing plate
Lightl rotate swing plate to insert the ridge
at both ends of the outlet into the groove
and then screw up.
Maintenan e
2. Take off airfilter

9
NOTE
The inner part of indoor unit must be leaned. Consult dealer, be ause lean must be done by
te hni ian.
In ooling operation, dis harging system dis harge water in room.
2.
1.
Seasonal Reserve
Operate the unit with FAN mode on a fair da for about half
a da to dr the inside of the unit well.
Stop operation and turn off the power suppl switch .Electric
power is consumed even the air conditioner is in stop.
Clean the air filter, indoor unit and outdoor unit,and cover
the unit with dustcoat.
Pre-season Care
See that there is no obstacles blocking the air
inlet and air outlet of both indoor and outdoor
unit to avoid reduce the working efficienc .
Be sure to install the air filter, ensure that the air filter is not dirt . Otherwise ma result in
machine damages or cause malfunciton due to dust inside the unit
To prevent compressor when start in HEAT mode,
please cut in the power suppl switch 12 hours
before starting run,furthermore, alwa s keep the
power suppl switch on during the using senson.
Post-season Care
Maintenan e

10
The followings are not malfuncition
Hua
Hua
Trouble Shooting
Water flowing sound is heard When the air conditoner is started, when the
compressor starts or stops during operation
or when the air conditioner is stopped,it som-
etimes sounds  Bi- Bi- or Godo-Godo. It is
the flowing sound of the refrigerant , not a
malfunction.
Cracking sound is heard
It smells.
This is caused b heat expansion or contra-
ction of plastics
Air blown out from the indoor unit sometimes
smells. The smell results from smells of
furniture, paint , tobacco absorbed b indoor
unit.
During operation, white fog comes out of
indoor unit.
When in COOL or DRY mode, a thin water
fog can be seen blown out of unit ,this is the
condensed fog because the suddenl cooled
indoor air is blown out.
Automaticall switch into FAN mode during
cooling.
To prevent frost from being accumulated on the
indoor unit heat exchanger, it sometimes auto-
maticall switched into the FAN mode,but it will
soon back to the cooling mode.
The air conditioner cannot be restarted soon
after it stops.
Air conditioner does not start?
This is because of the self-protection function
of the s stem, therefore,it cannot be restarted
for about three minutes after it stops.
Please wait for
three minutes

11
**?
ON
OFF
Trouble Shooting
Air does not blow or the fan speed cannot be
changed during dr ing.
In DRY mode, when room temperature
becomes 2 C higher than temperature setting,
unit rill run intermittentl at LO speed regardless
of FAN setting
During heating,indoor fan is still running even
unit is stopped.
To get ride of the excess heat, indoor fan will
continue running for a while after unit autom-
aticall stops.
Water or vapor generated from the outdoor
unit during heating.
This happens when the frost accumulated on
the outdoor unit is removed (during defrosting
operation).
Defrosting operation
Please check the following things about our air conditioner before making a
service call.
Unit fails to start.
Is the power suppl switch on ?
Power suppl switch is not in
ON position.
Is cit suppl power normal ? Is the earth leakage breaker
in action ?
Be sure to turn off the power
suppl switch immediatel and
contact the sales dealer.

12
When Trouble Happens
Insufficient cooling or heating
The operation controller
adjusted as required
Air filter too dirt ? Horizontal swing louver
upward ? (in HEAT mode)
An obstacle exists at the air
inlet or outlet?
Door or window left opened ?
Insufficient cooling
An other heat sources in the
room?
Sunlight direct into the
room ?
Too crowed in the room ?
Cooled air blown out ( when heating)
When the air conditioner does not operate properl after
ou have checked the above-mentioned items or when
following phenomenon is observed,stop the operation of
the air conditioner and contact our sales dealer.
1)The fuse or breaker often shuts down.
2)Water drops off during cooling or dr ing operation.
3)There is an irregularit in operation or abnormal sound that
is audible.

13
When Trouble Happens
1. Error display
Indoor unit malfun tion display ode
Please keep this manual carefull and safel .
Outdoor unit malfun tion display ode
When the wire remote controller displa E1,Can check the outdoor unit control board LED1 or outdoor
unit malfunction displa code to sure outdoor unit malfunction.
Indoor unit malfunction Displa code
Float switch or water motor abnormal E0
Outdoor unit abnormal E1
Liquid temperature sensor is abnormal E3
Gas temperature sensor is abnormal E4
Indoor unit adress abnormal
(Firstl ou saw E5 in controller LCD,
and then the failure code is changed
from E5 to E9)
E5
The communication with electronic
expansion box is abnormal
E7
The communication between the
wire remote controller and indoor
unit control board is abnormal
E8
The communication between indoor
and outdoor unit is abnormal
E9
Water temp. sensor is abnormal (Onl
used for the twin energ source function) E0
Displa codeIndoor unit malfunction
Remote ontroller Timer and Operation indi ator malfun tion ode
When the unit running, Timer indicator flash stand for indoor unit malfunction
When the operation indicator flashing stand for outdoor unit malfunction,Operation indicator flashing
times can't determinant outdoor unit malfunction ,You must check the outdoor unit control board LED1
flashing times or outdoor unit malfunction displa code to sure outdoor unit malfunction.
Others malfunction manual plese read the outdoor unit manual.
E6
Indoor unit EEPROM data is abnormal
Timer indicator
Flashing times Indoor unit malfunction
Flashing once The liquid tube temperature sensor is abnormal
Flashing twice The gas tube temperature sensor is abnormal
Flashing 3 times The environment temperature sensor is abnormal
Flashing 4 times The communication with outdoor unit is abnormal
Flashing 5 times The ommunication with the electronic expansion valve control board is abnormal
Flashing 10 times Indoor unit PG fan motor is abnormal
Flashing 11 times Indoor unit water overflow or float switch is abnormal
Flashing 12 times Indoor unit EEPROM data is abnormal
Flashing 15 times Water temp. sensor is abnormal£¤Onl used for the twin energ source function£'

14
Customer Need-to-know
Customer Need-to-know
Please install the air conditioner according to the requirements specified in this manual to ensure
the air conditioner work well.
Be careful not to scratch the surface of the case during moving the air conditioner.
Please keep the installation manual for future reference when maintenance and changing installation place.
After installation ,please use the air conditioner according to the specification in the operation
manual.
Using Directions
Adjust suitable airflow direction Avoid direct sunlight and airflow
Keep the proper indoor temperature.
Too cool or hot is not good for our health.
Furthermore,it will result in excessive
consumption of electric power.
Optimal
temper-
ature
Effectivel use timer.
Using TIMER mode, ou can make the room
temperature reach a suitable temperature when
ou wake up or go back home.
ATTENTION: after finishing installation,confirm no refrigerant leakage.

15
A
B
C
D
E
F
Installation tools
Standard accessories
1. Screw driver
2. Hacksaw
3. Drill with a diameter of 60mm
4. Inner hexagon spanner,shifting
spanner
5. Spanner (14, 17, 19,24,27mm)
6. Pipe cutter
7. Pipe expander
8. Knife
9. Pincers
10. Leakage detector or soap water
11. Band tape
12. Scraper
13. Refrigerant oil
The installation tools listed in the
following sheet can be used as required.
The following parts mentioned in this
manual are the installation accessories
we prepared.
S mbol Parts Name
Adhesive tape
Pipe clamp
Connecting hose
Drainage hose
Non-h droscopic
heat insulating material
G psum powder
Following in the list are the accessories
supplied with the unit,which can be used
as required
1
2
3
4
5
6
7
1
2
4
No. Accessor parts Qt .
Remote controller
Batter
Wire clamp
Heat
insulation
sheathing
Accesories
Screw cap
1+1
1+1
1
Remote
controller
bracket
1
Installation Pro edure

16
Unit shall be grounded. But grounding shall not be connected to gas pipe
water pipe, telephone line. Poor grounding will cause electric shock.
Be sure to install a leakage breaker to avoid electric shock.
Arrange water drainage according to this Manual. Cover pipe with insulation materials in case
dew ma occur. Unproper installation of water drainage will cause water leakage and wet our furniture.
To maintain good picture or reduce noise, keep at least 1 m from T.V. radio, when install indoor and ou-
tdoor unit, connecting wire and power cable. (If the radio wave is relativel strong, 1 m is not enough
to reduce noise).
Don't install unit in following places:
(a) Oil mist or oil gas exists, such as kitchen, or, plastic parts ma get aged, or water leakage.
(b) Where there is corrosive gas. Copper tube and welded part ma be damaged due to corrosion,
causing leakage.
(c) Where there is strong radiation. This will affect unit's control s stem, causing malfunction of the unit
(d) Where flamable gas, dirt, and volatile matter (thinner, gasoline) exist, These matter
might cause fire accident.
Meanings of Warning and Cautions:
Warning! Serious injury or even death might happen, if it is not observed.
Caution! Injury to people of damages to ma hine might happen, if it is not observed.
CAUTION!
CAUTIONS:
To ensure proper installation, read "Cautions" arefully before working. After
installation, start the unit orre tly and show
ustomers how to operate and
maintain the unit.
Installation shall be done b professional people, don't install unit b ourself. Incorrect installation will
cause water leakage, electric shock or fire.
Install unit as per the Manual. Incorrect installation will cause water leakage, electric shock or fire
accident.
Be sure to use specified accessaries and parts. Otherwise, water leakage, electric shock, fire accident or
unit falling down ma happen.
Unit should be placed on a place strong enough to hold the unit. Or, unit will fall down causing injuries.
When install the unit, take in consideration of storms, t phoom, earthquake. Incorrect installation ma
cause unit to fall down.
All electric work shall be done b experienced people as per eocal code, regulations and this Manual.
Use exclusive wire for the unit. Incorrect installation or undersized electric wire ma cause electric
shock or fire accident.
All the wires and circuit shall be safe. Use exclusive wire firml fixed. Be sure that external force
will not affect terminal bolck and electric wire. Poor contact and installation ma cause fire accident.
Arrange wire correctl when connectin indoor and outdoor power suppl . Fix terminal cover firml to
avoid overheat, electric shock or even fire accident.
In case retrigerant leakage occurred during unit installation, keep a good ventilation in the room.
Poisonous gas will occur when meet with fire.
Check the unit upon installation. Be sure there is no leakage. Refrigerant will induce poisonous gas
when meet heat source as heater, oven, etc.
Cut power suppl before touching terminal bolck.
WARNING!
Earthing
Don't fail to show customers how to operate unit.
Refer to paper pattern when installing unit.
Cautions for the installation personnel
Installation Pro edure

(2) Ceiling height
Indoor unit can be installed on ceiling of 2.5-3m in height. (Refer to Field setting and Installation Manual of
ornament panel.)
(3) Install suspending bolt. Check if the installation place is strong enough to hold weight. Take necessar
measures in case it is not safe. (Distance between holes are marked on paper pattern. Refer to paper pattern
for place which need be reinforced)
Installation space
(1) Installation place shall meet the following and agreed b customers:
Place where proper air flow can be ensured.
No block to air flow.
Water drainage is smooth.
Place strong enough to support unit .
Place where inclination is not evident on ceiling.
Enough space for maintenance.
Indoor and outdoor unit piping length is within limit. (Refer to Installation Manual for outdoor unit.)
Indoor and outdoor unit, power cable, inter unit cable are at least 1 m awa fromT.V. radio. This is helpful
to avoid picture disturbance and noise. (Even if 1 m is kept, noise can still appear if radio wave is strong)
<Don't dis ard any a essories until ompleted>
1. BEFORE INSTALLATION
2. SELECTION OF INSTALLATION PLACE
Determine the wa to carr unit to installation place.
Don't remove packing until unit reaches installation place.
If unpacking is unavoidable, protect unit properl .
Air inlet Air outlet
2500 Over
Air outlet
1500 Over
1500 Over
310
1
2
17
Air inlet Air outlet
2500 Over
Air outlet
1500 Over
1500 Over
260
AB184FCAHA
AB094FAAHA AB124FAAHA
AB244FCAHA
AB424FCAHA AB484FCAHA
Installation Pro edure

3. PREPARATION FOR THE INSTALLATION
(1) Position of ceiling opening between unit and suspending bolt.
3
18
AB424FCAHA AB484FCAHA
(2) Cut an opening in ceiling for installation if necessar . (when ceiling alread exists.)
(3) Install a suspending bolt.
(Use a M10 bolt)
To support the unit weight, anchor bolt shall be used in the case of alread exists ceiling. For new
ceiling, use built-in t pe bolt or parts prepared in the field.
Before going on installing adjust space between ceiling.
<Installation example>
Note: All the above mentioned parts shall be prepared in field.
Ceiling
50~100
Roof
Anchor bolt
Long nut
Suspending bolt
Refer to paper pattern for dimension of ceiling hole.
Connect all pipings (refrigerant, water drainage), wirings (inter unit cable) to indoor unit, before installation.
Cut a hole in ceiling, ma be a frame should be used to ensure a smooth surface and to prevent vibration.
Contact our real estate dealer
AB184FCAHA AB244FCAHA
950(Ornament panel) 890(Ceiling opening)
840(Indoor unit)
680
(Distance between suspending bolts)
(Distance between suspending bolts)
950(Ornament panel)
890(Ceiling opening)
840(Indoor unit)
Suspending bolts
Refrigerant pipe
*
*
680
A
Note:
Dimension of ceiling opening marked with * can be as
large as 910mm, but the matching part of ceiling with
ornament panel shall be over 20mm.
20 Over
(160)
Suspending bracket
Ceiling
A
780
(Distance between suspending bolts)
620
(Distance between suspending bolts)
860-890
860-890
(Ceiling opening)
AB094FAAHA AB124FAAHA
807.6
761
700
350
438
500(GRILLE)
460
712.6
831
860(GRILLE)
£¤Ceiling opening)
Installation Pro edure
