Test power plug before each use:
1. Press ìreset ìbutton.
2 . Press ìtest ìbutton, unit should trip.
3. Press ìresetî button again for use .
Do not use if above test fail.
In the event this device trips , the cause of the malfunction is to
be corrected before further use of the device .
Important:

MODEL: HWR08XC5
ESA3065, ESA3085
1. Thermostat
This allows you to adjust the temperature of the air.
The lower the setting the cooler the air temperature
With this you can set the temperature to your
desired comfort level You can set the temperature
between 61oF and 86oF.
2. fan Speed
You have 2 levels of Fan speed to set at your
desired comfort level.
3. Function.
Your air conditioner has 2 Functions.
a) COOL
Here the air conditioner will operate the compressor
and the desired fan speed set to give you chilled
cold air for your comfort.
b) Fan
You can run the fan only on not so hot days. The
fan can be set to run at 2 speeds as desired by you.
4. Timer
Your air conditioner can be set to go on or off at
your desire. This can be done up to 24 hours in
advance.
5. 4 Way Air Flow
These air directional louvers let you control the direction
of the airflow in your required direction.
The airflow can be directed
up - down - right side -left side.
10. How The Unit Drains

10. How The Unit Drains
MODEL: HWF08XC5

Remote control and control panel operations
MODEL: HWR08XC5, ESA3065, ESA3085

Every time you press the MODE button, it will change between FAN, COOL . (See
Fig. # 3)
Having set the temperature you will set the function of the air conditioner.

Once the function mode is decided you will have to set the fan speed.(See fig. #4)
Every time you press the SPEED button, fan speed will change between LOW, HIGH.
1) If you choose the COOL mode you can run the fan in one of the 2speeds HIGH,
LOW.
2) For cool days you may want to run the "FAN" function. Here the fan runs at one
of 2 speeds, HIGH or LOW.

Fig. # 5
MODEL: HWF08XC5

Also when you shut off the air conditioner wait for 3 minutes
before turning it on again.

13) Be careful of exposed sharp edges of the cabinet and sharp coils(fins)on the
back of the unit that could cut and cause serious injury.

Model: HWF08XC5
ìCR2025ìbattery
Remote
control
Model: HWR08XC5, ESA3065,ESA3085
