Haier AP242ACAAA User manual

HAIER
Machine Model No.:
1. Product coding explanation and product series brief instruction
2. Product technical parameter
3. Product specification
4. Name, dimension and function of primary component and accessory
5. Explosion illustration and structure details
6. Usage and setting of remote controller
7. Electric control instruction
8. Diagram circuit
9. Fault diagnosis
10. System flowchart
11. Mounting and maintenance
Contents
Cabinet air conditioner
Technical manual
AP242ACAAA/AU242AHAAA (HPU-24H03)
AP42NACAAA/AU42NAIAAA (HPU-42H03)
AP44NACAAA/AU44NAIAAA (HPU-44H03)
AP42NACABA/AU42NAIABA (HPU-42HB03)

1. Product coding explanation and product series instruction
a. Model coding rule explanation
H
AAAAACPN42
P42H0 3U Power type: triphase
Functional code: heatingand cooling dual-purposemachine
Nominal cooling output(BTU/h) The firsttwo numbers basedon thousand unit
Structured code ofindoor and outdoorunit: Cabinet airconditioner
H-Abbreviation of Haier
Climatic type: T1
Design serial number
Class of product: heat pump
Appearance characteristic:
Series of product: one wall-mounted split type
Appropriate voltage: 380V/50Hz
Specifications of products: The first two numbers
based on thousand unit
Type of product: cabinet air conditioner
Air conditioner
C. Brief instruction of series
Serialization of product:
Now our company has the following cabinet air conditioner:
HPU-24H03(AP242ACAAA+AU242AIAAA) HPU-42H03(AP42NACAAA+AU42NAIAAA)
HPU-44H03(AP44NACAAA+AU44NAIAAA HPU-42HB03(AP42NACABA+AU42NAIABA)
Product characteristics:
Heat and cool rapidly and sharply
With powerful motion function, forceful and high cyclical air volume, heating and
cooling of product is rapid and sharp. Temperature control is homogeneous, rapid,
correct and soft, which can rapidly satisfy client and make them more comfortable.
Muting function and low noise
Adopting large diameter centrifugal fan unit and optimum turbine air duct design , air
supply is stronger and farther; internationally advanced and reliable compressor
reduces the vibration and noise of outdoor unit.
b.Table 1
Running condition
Indoor condition Outdoor condition
Nominal cooling
Nominal heating
Temperature Temperature
Humidity Humidity
DB:27 WB:19 DB:35
DB:7 WB:6
WB:24
DB:20 WB:15
Serial
number
1
2
1

2
Model:
Outline dimension of indoor unit
Packing dimension of indoor unit:
Noise of indoor unit (cooling):
Noise of indoor unit (heating):
Net/gross weight of indoor unit:
Working voltage range
Working temperature range
Temperature regulating difference:
Maximum mounting drop height:
Maximum length of connecting pipe:
Filtering efficiency:
Model of compressor:
Performance curve of compressor
Flow figure of two units :
Type of stop valve:
Cooling coefficient
Cooling power :
Outdoor temperature-dependent performance curve of cooling /heating
capacity
Louver size of inlet grill
Quantity/spacing of grill louver
Total area of evaporator:
Total area of condenser:
Total /row number of fin:
Evaporating temperature range:
Type of drain pipe:
Length/diameter of drain pipe:
Size of mounting bottom plate:
Air supplying angle/distance
New air capacity:
Real-time regulating range:
All attachments type of computer plate
Fan speed :
Type /quantity of fan
Type of capillary tube:
Diameter/length of capillary tube:
Swinging frequency of outlet grill louver
Maximum working pressure of heat side:
Indoor wet and dry bulb temperature:
Dynamic ratio:
Certificate
Function of product:
Popularity of product:
HPU-24H03
1820x530x300mm
1952x660x417mm
upper/lower 50/38dB(A)
upper/lower 50/38dB(A)
45/47kg
187-242
-7-43
15
30
ZR34K4-PFJ-552
enclosed hereafter
10/8
9.52; 15.88
2.73
2600
PVC
15m
-
enclosed hereafter
Indoor :centrifugal;
outdoor : tubeaxial
TP2Y
2.8MPa
2.73
CE
Enclosed hereafter
1. Low noise;
2. Easy of mounting and
simplicity of operator
Beautiful and natural
25(internal);
25(interanl)
WHITE
948x340x1225mm
1050x440x1375mm
upper/lower 58/50 dB(A)
upper/lower 58/50dB(A)
74kg
50Hz
R22
3520g
Copeland compressor
plant
enclosed hereafter
9.52; 15.88
3.14
2700
enclosed
hereafter
Light foil
0.35/1.9
43-60
3.15A
R25
Power sprayed
Electric zinc plate
1/month
XPE
Daub
Resin net
I
2.8MPa
4/2
Appearance color (internal/external):
Outline dimension of outer unit:
Packing dimension of outer unit:
Noise of outer unit (cooling):
Noise of outer unit (heating):
Net/gross weight of outer unit:
Working current range
Workable frequency:
Type of refrigerant
Refrigerant charge:
Type of filter:
Dimension of filter:
Manufacturer of compressor:
Performance variation curve of fan motor
Type/diameter of pipe of two units:
Type of 4-way valve:
Heating coefficient:
Heating power:
Anion quantity of anionic unit
Variety of fin material
Coefficient of fin
Total length of cooling pipeline (liquid/vapor):
Thickness/pitch of fins
Condensing temperature range:
Protector model of control panel:
Protector model of compressor:
Temperature transducer model:
Sheathing material :
Cleaning frequency of filter:
Type of quieter material:
Model of gas-liquid separator:
Model of dryer:
Power consumption:
Model of quieter:
Type of vibrating material:
Type/dimension of sterilizing net
Class of electrostatic prevention:
Maximum working pressure of cold side:
Outdoor wet and dry bulb temperature:
Piling layer of inner and outer units:
Filling capacity of compressor:
Appearance characteristics of product's
inner and outer unit:
2. Technical parameter of product

3
Model:
Outline dimension of indoor unit:
Packing dimension of indoor unit:
Noise of indoor unit (cooling):
Noise of indoor unit (heating):
Net/gross weight of indoor unit:
Working voltage range
Working temperature range
Temperature regulating difference:
Maximum mounting drop height:
Maximum length of connecting pipe:
Filtering efficiency:
Model of compressor:
Performance curve of compressor
Flow figure of two units :
Type of stop valve:
Cooling coefficient
Cooling power :
Outdoor temperature-dependent performance curve of cooling /heating
capacity
Louver size of inlet grill
Quantity/spacing of grill louver
Total area of evaporator:
Total area of condenser:
Total /row number of fin:
Evaporating temperature range:
Type of drain pipe:
Length/diameter of drain pipe:
Size of mounting bottom plate:
Air supplying angle/distance
New air capacity:
Real-time regulating range:
All attachments type of computer plate
Fan speed :
Type /quantity of fan
Type of capillary tube:
Diameter/length of capillary tube:
Swinging frequency of outlet grill louver
Maximum working pressure of heat side:
Indoor wet and dry bulb temperature:
Dynamic ratio:
Certificate
Function of product:
Popularity of product:
HPU-42H03
1820x530x300mm
1952x660x417mm
upper/lower 50/38dB(A)
upper/lower 50/38dB(A)
45/47kg
187-242
-7-43
30
50
CRNQ-0500-TFD-522
enclosed hereafter
10/8
9.52; 19.05
2.73
2600
PVC
15m
-
enclosed hereafter
Indoor :centrifugal;
outdoor : tubeaxial
TP2Y
2.8MPa
2.73
CE
Enclosed hereafter
1. Low noise;
2. Easy of mounting and
simple of operator
Beautiful and natural
25(internal);
Indoor :130W
Outdoor:60X20
40X2
see table 1
25(internal)
WHITE
948x340x1225mm
1050x440x1375mm
upper/lower 58/50 dB(A)
64/-/-
85kg
50Hz
R22
3520g
enclosed hereafter
9.52; 19.05
3.14
2700
enclosed
hereafter
Light foil
0.35/1.9
43-60
3.15A
R25
1/month
XPE
2.0L
-
Plaster
Resin net
I
2.94MP
4/2
2070cc
Appearance color (internal/external):
Outline dimension of outer unit:
Packing dimension of outer unit:
Noise of outer unit (cooling):
Noise of outer unit (heating):
Net/gross weight of outer unit:
Working current range
Workable frequency:
Type of refrigerant
Refrigerant charge:
Type of filter:
Dimension of filter:
Manufacturer of compressor:
Performance variation curve of fan motor
Type/diameter of pipe of two units:
Type of 4-way valve:
Heating coefficient:
Heating power:
Anion quantity of anionic unit
Variety of fin material
Coefficient of fin
Total length of cooling pipeline (liquid/vapor):
Thickness/pitch of fins
Condensing temperature range:
Protector model of control panel:
Protector model of compressor:
Temperature transducer model:
Refrigerant charge:
Cleaning frequency of filter:
Type of quieter material:
Model of gas-liquid separator:
Model of dryer:
Power consumption:
Model of quieter:
Type of vibrating material:
Type/dimension of sterilizing net
Class of electrostatic prevention:
Maximum working pressure of cold side:
Outdoor wet and dry bulb temperature:
Piling layer of inner and outer units:
Filling capacity of compressor:
Appearance characteristics of product's
inner and outer unit:

4
Model:
Outline dimension of indoor unit:
Packing dimension of indoor unit:
Noise of indoor unit (cooling):
Noise of indoor unit (heating):
Net/gross weight of indoor unit:
Working voltage range
Working temperature range
Temperature regulating difference:
Maximum mounting drop height:
Maximum length of connecting pipe:
Filtering efficiency:
Model of compressor:
Performance curve of compressor
Flow figure of two units :
Type of stop valve:
Cooling coefficient
Cooling power :
Outdoor temperature-dependent performance curve of cooling /heating
capacity
Louver size of inlet grill
Quantity/spacing of grill louver
Total area of evaporator:
Total area of condenser:
Total /row number of fin:
Evaporating temperature range:
Type of drain pipe:
Length/diameter of drain pipe:
Size of mounting bottom plate:
Air supplying angle/distance
New air capacity:
Real-time regulating range:
All attachments type of computer plate
Fan speed :
Type /quantity of fan
Type of capillary tube:
Diameter/length of capillary tube:
Swinging frequency of outlet grill louver
Maximum working pressure of heat side:
Indoor wet and dry bulb temperature:
Dynamic ratio:
Certificate
Function of product:
Popularity of product:
HPU-42HB03
1820x530x300mm
1952x660x417mm
52/46/40dB(A)
50/44/38dB(A)
60/64kg
380-400
-7-43
30
50
C-SB373H8F
10/8
9.52; 19.05
2.06
4800
PVC
15m
-
enclosed hereafter
Indoor :centrifugal;
outdoor : tubeaxial
TP2Y
2.8MPa
2.73
CE
Enclosed hereafter
1. Low noise;
2. Easy of mounting and
simple of operator
Beautiful and natural
25(internal);
Indoor :130W
Outdoor:60X20
40X2
see table 1
25(internal)
WHITE
948x340x1225mm
1050x440x1375mm
upper/lower 58/50 dB(A)
64/-/-
91/116kg
50Hz
R22
4000g
9.52; 19.05
2.5
5100
Light foil
0.35/1.9
43-60
3.15A
R25
1/month
XPE
2.0L
-
Plaster
Resin net
I
2.94MP
4/2
2070cc
Appearance color (internal/external):
Outline dimension of outer unit:
Packing dimension of outer unit:
Noise of outer unit (cooling):
Noise of outer unit (heating):
Net/gross weight of outdoor unit:
Working current range
Workable frequency:
Type of refrigerant
Refrigerant charge:
Type of filter:
Dimension of filter:
Manufacturer of compressor: SANYO
Performance variation curve of fan motor
Type/diameter of pipe of two units:
Type of 4-way valve:
Heating coefficient:
Heating power:
Anion quantity of anionic unit
Variety of fin material
Coefficient of fin
Total length of cooling pipeline (liquid/vapor):
Thickness/pitch of fins
Condensing temperature range:
Protector model of control panel:
Protector model of compressor:
Temperature transducer model:
Refrigerant charge:
Cleaning frequency of filter:
Type of quieter material:
Model of gas-liquid separator:
Model of dryer:
Power consumption:
Model of quieter:
Type of vibrating material:
Type/dimension of sterilizing net
Class of electrostatic prevention:
Maximum working pressure of cold side:
Outdoor wet and dry bulb temperature:
Piling layer of inner and outer units:
Filling capacity of compressor:
Appearance characteristics of product's
inner and outer unit:

5
Model:
Outline dimension of indoor unit:
Packing dimension of indoor unit:
Noise of indoor unit (cooling):
Noise of indoor unit (heating):
Net/gross weight of indoor unit:
Working voltage range
Working temperature range
Temperature regulating difference:
Maximum mounting drop height:
Maximum length of connecting pipe:
Filtering efficiency:
Model of compressor:
Performance curve of compressor
Flow figure of two units :
Type of stop valve:
Cooling coefficient
Cooling power :
Outdoor temperature-dependent performance curve of cooling /heating
capacity
Louver size of inlet grill
Quantity/spacing of grill louver
Total area of evaporator:
Total area of condenser:
Total /row number of fin:
Evaporating temperature range:
Type of drain pipe:
Length/diameter of drain pipe:
Size of mounting bottom plate:
Air supplying angle/distance
New air capacity:
Real-time regulating range:
All attachments type of computer plate
Fan speed :
Type /quantity of fan
Type of capillary tube:
Diameter/length of capillary tube:
Swinging frequency of outlet grill louver
Maximum working pressure of heat side:
Indoor wet and dry bulb temperature:
Dynamic ratio:
Certificate
Function of product:
Popularity of product:
HPU-44H03
1820x530x310mm
1952x660x455mm
52/46/40dB(A)
50/44/38dB(A)
60/64kg
380-400
-7-43
30
50
C-SB373H8F
10/8
9.52; 19.05
2.06
4800
PVC
15m
-
enclosed hereafter
Indoor :centrifugal;
outdoor : tubeaxial
TP2Y
2.8MPa
2.73
CE
Enclosed hereafter
1. Low noise;
2. Easy of mounting and
simple of operator
Beautiful and natural
25(internal);
Indoor :130W
Outdoor:60X20
40X2
see table 1
25(internal)
WHITE
1225x960x380mm
1370x1080x440mm
upper/lower 58/50 dB(A)
64/-/-
91/116kg
50Hz
R22
4000g
9.52; 19.05
2.5
4000
Light foil
0.35/1.9
43-60
3.15A
R25
1/month
XPE
2.0L
-
Plaster
Resin net
I
2.94MP
4/2
2070cc
Appearance color (internal/external):
Outline dimension of outer unit:
Packing dimension of outer unit:
Noise of outer unit (cooling):
Noise of outer unit (heating):
Net/gross weight of outdoor unit:
Working current range
Workable frequency:
Type of refrigerant
Refrigerant charge:
Type of filter:
Dimension of filter:
Manufacturer of compressor: SANYO
Performance variation curve of fan motor
Type/diameter of pipe of two units:
Type of 4-way valve:
Heating coefficient:
Heating power:
Anion quantity of anionic unit
Variety of fin material
Coefficient of fin
Total length of cooling pipeline (liquid/vapor):
Thickness/pitch of fins
Condensing temperature range:
Protector model of control panel:
Protector model of compressor:
Temperature transducer model:
Refrigerant charge:
Cleaning frequency of filter:
Type of quieter material:
Model of gas-liquid separator:
Model of dryer:
Power consumption:
Model of quieter:
Type of vibrating material:
Type/dimension of sterilizing net
Class of electrostatic prevention:
Maximum working pressure of cold side:
Outdoor wet and dry bulb temperature:
Piling layer of inner and outer units:
Filling capacity of compressor:
Appearance characteristics of product's
inner and outer unit:

50000
100000
(ZR3K4-PFJ-552)
(CRNQ-0500-TFD)
40000
80000
30000
60000
20000
40000
(BTU)
(BTU)
0
0
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
60.0
60.0
48.9
48.9
37.9
37.9
14
14
()
()
6

Model of product
Structural characteristic
Cooling capacity
Voltage
Series of product
Appearance characteristics
Certificate
Remote controller
Refrigerant
Climatic type
Dimension of indoor unit
Dimension of outdoor unit
Packing dimension of indoor unit
Packing dimension of outdoor unit
Packing list
AP242ACAAA/AU242AHAAA
Split type
24000BTU/h
220V
Cabinet type
CE
Imitation Sharpen
R22
T1
1820x530x300
1952x660x417
Circular are panel, telephone push
key and control panel
Picture of product 1 Picture of product 2
Circular are panel, telephone push
key and control panel
AP42NACAAA/AC42NAIAAA
Split type
42000BTH/h
380V
Cabinet type
CE
Imitation Sharpen
R22
T1
1820x530x340
1225X948X340
1952X660X455
1375X1110X445
3. Product specification
Specification form of split air conditioner:
7

Parts
Indoor unit
Outdoor unit
Outlet grill
Operation panel
Inlet grill
Air filter
Remote-controller
Air inlet
[ At side and rear]
Compressor
[Inside the unit ]
Air outlet
Piping and electric wire
Drain pipe
C
AM
TEMP
SWING
MODE
CLOCK
TIMER
SLEEP
SET
RESETLOCK
FAN
ON
OFF
5
8

AM
TIMER TIME TEMP
TEMP
TIME
CLOCK
SET SLEEP SWING
FANSPEED
MODE
ON
OFF
1
2
3
Outlet grill
Operation panel
Inlet grill
Air filter[Inside the unit]
Remote-controller
Air inlet
[At side and rear]
Air outlet
Indoor unit
HPU-42H03 HPU-44H03 HPU-42HB03
Outdoor unit
C
ON OFF
AM
PM
AM
PM
AM
PM
AUTO
TEMP
SWING
MODE
CLOCK
TIMER
SLEEP
SET
RESETLOCK
FAN
ON
OFF
9
ROOM
TEMP
C
LOW MID HIGH
5

No.
Spare parts
number
Spare parts description
in english Qty. Model Price list
Failure
rate
the proportion
of the spare-
part stock Remark
1 001A1236028 Front grille 1 HPU-24H03 0.00% 0.000% ×
2 001A1436160 handle 2 HPU-24H03 0.00% 0.000% ×
3 001A0100261 Front panel 1 HPU-24H03 0.00% 0.000% ×
4 001A5402022 Axial fan 1 HPU-24H03 0.02% 0.024% *
5 0010450280 Fan motor 1 HPU-24H03 0.02% 0.024% *
6 001A0100266 Bracket for fan motor 1 HPU-24H03 0.00% 0.000% ×
7 001A0400119 Condenser assy. 1 HPU-24H03 0.01% 0.012%
8 001A1301453 Electric box 1 HPU-24H03 0.00% 0.000% ×
9 001A5745009 cable clamp 1 HPU-24H03 0.00% 0.000% ×
10 001A3600018 Capacitor for fan motor 1 HPU-24H03 0.04% 0.048% *
11 001A3800141 Resumable transformer 1 HPU-24H03 0.01% 0.012%
12 001A5736055 clip for sensor 1 HPU-24H03 0.00% 0.000% ×
13 001A3900153
temp. Sensor （Pipe ＆
environment）1HPU-24H03 0.00% 0.000% ×
14 001A3600030
Capacitor for
compressor 1 HPU-24H03 0.00% 0.000% ×
15 0010100001 Capacitor clamp 1 HPU-24H03 0.00% 0.000% ×
16 001A3300270 outdoor PCB 1 HPU-24H03 0.02% 0.024% *
17 001A3900161 AC contactor 1 HPU-24H03 0.03% 0.036% *
18 001A4000151 Terminal block 1 HPU-24H03 0.00% 0.000% ×
19 001A4000110
electrical source
connection block 1 HPU-24H03 0.00% 0.000% ×
20 001A2500081 4-way valve 1 HPU-24H03 0.00% 0.000% ×
21 001A2500076 coil of 4-way valve 1 HPU-24H03 0.00% 0.000% ×
22 001A3400138 High pressure switch 1 HPU-24H03 0.00% 0.000% ×
23 001A2611223 capillary 1 HPU-24H03 0.00% 0.000% ×
24 001A3900153
temp. Sensor （Pipe ＆
environment）1HPU-24H03 0.00% 0.000% ×
25 001A2411024 filter 1 HPU-24H03 0.00% 0.000% ×
26 001A0500461 Tube assy. 1 HPU-24H03 0.00% 0.000% ×
27 001A2500083 3-way stop valve 1 HPU-24H03 0.00% 0.000% ×
28 001A2500082 2-way stop valve 1 HPU-24H03 0.00% 0.000% ×
29 001A2111912 muffle 1 HPU-24H03 0.00% 0.000% ×
30 0010700774 Compressor 1 HPU-24H03 0.06% 0.072% *
31 001A2101857 Accumulator 1 HPU-24H03 0.00% 0.000% ×
32 001A0100350 Partition plate 1 HPU-24H03 0.00% 0.000% ×
33 001A0100524 Front panel 1 HPU-24H03 0.00% 0.000% ×
34 001A0100351 Bottom cover assy. 1 HPU-24H03 0.00% 0.000% ×
35 001A1301117 branch triby 1 HPU-24H03 0.00% 0.000% ×
36 001A1301506 Valve pedestal 1 HPU-24H03 0.00% 0.000% ×
37 001A0100264 Top cover assy. 1 HPU-24H03 0.00% 0.000% ×
38 001A0100109 Back grille 1 HPU-24H03 0.00% 0.000% ×
39 001A0100394 Junction box 1 HPU-24H03 0.00% 0.000% ×
40 001A0100390 Slide plate(right) 1 HPU-24H03 0.00% 0.000% ×
Parts list

41 001A4400511 wire assy. 1 HPU-24H03 0.00% 0.000% ×
4,not need provided :The spare-part which is seldom damaged or the maintenance man could not
maitmains.The spare parts may be air freighted by the factory if they were damaged.The customer
nees not stock in the spare-part warehouse,should be marked with " x ".
5,Above should be improved accord with the reply of the market half a year per time.
6.The s
p
are
p
arts
p
rice on net is FOB Qin
g
dao term.
1,The failer rate and the proportion of the spare-part stock are regarded as the reference of the stock
for spare-parts;The first time should be stocked accroded with the proportion of the spare-parts,and it
should be adjusted with the actual quantity 3 months later.
2,easy-damaged;The spare-part which is often damaged and the customer must stock in the spare-
parts warehouse,and should be marked with"*"
3
,poss
ibl
e
d
amage
d
:
Th
e spare-par
t
w
hi
c
h
i
s no
t
o
ft
en
d
amage
d
lik
e
th
e easy
d
amage
d
one an
d
th
e
customer may stock in the spare-part warehouse accord with the actual case,should be marked with "
".

9
414243
1
2 3
4
5
6
7
8
910
13 14
15 16 17 18
19
20 21 22 23 24
25 26
27 28 29
30 31 32 33 34
35
36
37383940
11
12

10
Bristol Compressor
Detailed statement of explosion figure
Model No. AP42NACAAA/AU42NAIAAA outdo r unito
No. Specific
number Name Single
consumption Type of material Weight of material
580
6040
1245
2550
255
1810
2330
3740
1610
6
19
7.5
250
400
1920
19
4
2
5
1
2
2
2
1
1
1
1
1
1
1
1
1
1
1
1
6
1
2
1
2
1
1
1
1
1
1
1
4
1
1
1
1
1
1
3
1
1
1
1
Stainless steel
Weather resisting PP
Nick treatment
Electro-zinced plate
M10
ABS-fiber glass
1.5 Heating zinc plate
PU
0.8 Heating zinc plate
PE
0.8 Heating zinc plate
Weather resisting PP
Rubber
0.8 electro zinc plate
Stainless steel
0.8 electro zinc plate
Glass wool
Steel wire
Chloroprene rubber
RE610
Weather resisting PP
1.0 Heating zinc plate
Composite thermal
insulation cotton
1.5 electric zinc plate
Heat-resisting ABS
Stainless steel
Stainless steel
Electric zinc plate
Electric zinc plate 0.8
Weather resisting PP
5002108
1236028
5002005
1301640
5102027
5402022
3000244
1001645
17421215
1301469
17341207
0400164
Screw
Front guard web
Screw
Left front panel
Cap nut
Tubeaxial fan
Motor
Motor bracket
Vertical strip foam
Vertical strip
Damping cushion
Upper heat exchanger
assembly
Partition plate
Ambient temperature
thermistor clamp
Partition pad
Electrical box assembly
Discharge piping assembly
Upper discharge piping
assembly
Cover
Specific screw
Right side plate
Right side liner
Heat exchanger guard web
Rubber block
Upper feed pipe assembly
Handle
Dead plate
4-way valve
Accumulator
Suction piping assembly
2-way stop valve
Flaring nut
3-way stop valve
Damping cushion sleeve
Valve base
Bottom plate assembly
Bracket
Screw
Screw
Lower heat
exchanger group
Little cover
Servicing plate
Handle
1301468
5736055
17561212
0600566
0500528
0500521
1101034
5002152
1101197
17621214
1303642
1752285
0500522
1436160
1301465
2500117
2000175
0500520
2500115
5102050
2500116
17621208
1301762
0100735
1431952
5002 03
5002 03
0400164
1301464
1301707
1436160
1
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
35
36
37
38
39
40
41
42
43
25
26
27
28
29
30
31
32
33
34

No.
Spare parts
number
Spare parts description
in english Qty. Model Price list
Failure
rate
the proportion
of the spare-
part stock Remark
1 001A5002108 Screw 4 HPU-42HB03 0.00% 0.000% ×
2 001A1236028 Front guard web 2 HPU-42HB03 0.00% 0.000% ×
3 001A5002005 Screw 1 HPU-42HB03 0.00% 0.000% ×
4 001A1301640 Left front panel 1 HPU-42HB03 0.00% 0.000% ×
5 001A5102027 Cap nut 1 HPU-42HB03 0.00% 0.000% ×
6 001A5402022 Axial fan 1 HPU-42HB03 0.02% 0.024% *
7 001A3000244 Motor 1 HPU-42HB03 0.02% 0.024% *
8 001A1301645 Motor bracket 1 HPU-42HB03 0.00% 0.000% ×
9 001A17421215 Vertical strip foam 1 HPU-42HB03 0.00% 0.000% ×
10 001A1301469 Vertical strip 1 HPU-42HB03 0.00% 0.000% ×
11 001A17341207 Damping cushion 1 HPU-42HB03 0.00% 0.000% ×
12 0010400164 sensor 1 HPU-42HB03 0.01% 0.012%
13 001A1301468 Partition plate 1 HPU-42HB03 0.00% 0.000% ×
14 001A5736055
Ambient temperature
thermistor clamp 1 HPU-42HB03 0.00% 0.000% ×
15 001A17561212 Partition pad 1 HPU-42HB03 0.00% 0.000% ×
16 001A0600566 Electrical box assembly 1 HPU-42HB03 0.00% 0.000% *
17 001A0500528 assembly 1 HPU-42HB03 0.00% 0.000% *
18 001A0500521
Upper discharge piping
assembly 1 HPU-42HB03 0.00% 0.000% ×
19 001A1101034 Cover 1 HPU-42HB03 0.00% 0.000% ×
20 001A5002152 Specific screw 1 HPU-42HB03 0.00% 0.000% ×
21 001A1101197 Right side plate 1 HPU-42HB03 0.00% 0.000% ×
22 001A17621214 Right side liner 1 HPU-42HB03 0.00% 0.000% ×
23 001A0100767 web 1 HPU-42HB03 0.00% 0.000% ×
24 001A1752289 Rubber block 1 HPU-42HB03 0.00% 0.000% ×
25 001A0500522 assembly 1 HPU-42HB03 0.00% 0.000% ×
26 001A1436160 Handle 1 HPU-42HB03 0.00% 0.000% ×
27 001A1301465 Dead plate 1 HPU-42HB03 0.00% 0.000% ×
28 001A2500117 4-way valve 1 HPU-42HB03 0.00% 0.000% ×
29 001A2000175 Accumulator 1 HPU-42HB03 0.00% 0.000% ×
30 0010750042 assembly 1 HPU-42HB03 0.06% 0.072% *
31 001A2500115 2-way stop valve 1 HPU-42HB03 0.00% 0.000% ×
32 001A5102050 Flaring nut 1 HPU-42HB03 0.00% 0.000% ×
33 001A2500116 3-way stop valve 1 HPU-42HB03 0.00% 0.000% ×
34 001A17621208 sleeve 1 HPU-42HB03 0.00% 0.000% ×
35 001A1301762 Valve base 1 HPU-42HB03 0.00% 0.000% ×
36 001A0100735 Bottom plate assembly 1 HPU-42HB03 0.00% 0.000% ×
37 001A1431952 Bracket 1 HPU-42HB03 0.00% 0.000% ×
38 001A5002103 Screw 1 HPU-42HB03 0.00% 0.000% ×
39 001A5002103 Screw 1 HPU-42HB03 0.00% 0.000% ×
40 0010751095 Heat exchanger group 1 HPU-42HB03 0.01% 0.012%
41 001A1301464 Little cover 1 HPU-42HB03 0.00% 0.000% ×
42 001A1301707 Servicing plate 1 HPU-42HB03 0.00% 0.000% ×
Parts list

43 001A1436160 Handle 1 HPU-42HB03 0.00% 0.000% ×
5,Above should be improved accord with the reply of the market half a year per time.
6.The s
p
are
p
arts
p
rice on net is FOB Qin
g
dao term.
1,The failer rate and the proportion of the spare-part stock are regarded as the reference of the stock for
spare-parts;The first time should be stocked accroded with the proportion of the spare-parts,and it
should be adjusted with the actual quantity 3 months later.
2,easy-damaged;The spare-part which is often damaged and the customer must stock in the spare-parts
warehouse,and should be marked with"*"
3,possible damaged:The spare-part which is not often damaged like the easy damaged one and the
customer may stock in the spare-part warehouse accord with the actual case,should be marked with " ".
4,not need provided :The spare-part which is seldom damaged or the maintenance man could not
maitmains.The spare parts may be air freighted by the factory if they were damaged.The customer nees
not stock in the spare-part warehouse,should be marked with " x ".

No.
Spare parts
number
Spare parts description
in english Qty. Model Price list
Failure
rate
the proportion
of the spare-
part stock Remark
1 001A5002108 Screw 4 HPU-44H03 0.00% 0.000% ×
2 001A1236028 Front guard web 2 HPU-44H03 0.00% 0.000% ×
3 001A5002005 Screw 1 HPU-44H03 0.00% 0.000% ×
4 001A1301640 Left front panel 1 HPU-44H03 0.00% 0.000% ×
5 001A5102027 Cap nut 1 HPU-44H03 0.00% 0.000% ×
6 001A5402022 Axial fan 1 HPU-44H03 0.02% 0.024% *
7 001A3000244 Motor 1 HPU-44H03 0.02% 0.024% *
8 001A1301645 Motor bracket 1 HPU-44H03 0.00% 0.000% ×
9 001A17421215 Vertical strip foam 1 HPU-44H03 0.00% 0.000% ×
10 001A1301469 Vertical strip 1 HPU-44H03 0.00% 0.000% ×
11 001A17341207 Damping cushion 1 HPU-44H03 0.00% 0.000% ×
12 0010400164 assembly 1 HPU-44H03 0.01% 0.012%
13 001A1301468 Partition plate 1 HPU-44H03 0.00% 0.000% ×
14 001A5736055
Ambient temperature
thermistor clamp 1 HPU-44H03 0.00% 0.000% ×
15 001A17561212 Partition pad 1 HPU-44H03 0.00% 0.000% ×
16 001A0600566 assembly 1 HPU-44H03 0.00% 0.000% *
17 001A0500528 assembly 1 HPU-44H03 0.00% 0.000% *
18 001A0500521
Upper discharge piping
assembly 1 HPU-44H03 0.00% 0.000% ×
19 001A1101034 Cover 1 HPU-44H03 0.00% 0.000% ×
20 001A5002152 Specific screw 1 HPU-44H03 0.00% 0.000% ×
21 001A1101197 Right side plate 1 HPU-44H03 0.00% 0.000% ×
22 001A17621214 Right side liner 1 HPU-44H03 0.00% 0.000% ×
23 001A0100767 web 1 HPU-44H03 0.00% 0.000% ×
24 001A1752289 Rubber block 1 HPU-44H03 0.00% 0.000% ×
25 001A0500522 assembly 1 HPU-44H03 0.00% 0.000% ×
26 001A1436160 Handle 1 HPU-44H03 0.00% 0.000% ×
27 001A1301465 Dead plate 1 HPU-44H03 0.00% 0.000% ×
28 001A2500117 4-way valve 1 HPU-44H03 0.00% 0.000% ×
29 001A2000175 Accumulator 1 HPU-44H03 0.00% 0.000% ×
30 0010750042 assembly 1 HPU-44H03 0.06% 0.072% *
31 001A2500115 2-way stop valve 1 HPU-44H03 0.00% 0.000% ×
32 001A5102050 Flaring nut 1 HPU-44H03 0.00% 0.000% ×
33 001A2500116 3-way stop valve 1 HPU-44H03 0.00% 0.000% ×
34 001A17621208 sleeve 1 HPU-44H03 0.00% 0.000% ×
35 001A1301762 Valve base 1 HPU-44H03 0.00% 0.000% ×
36 001A0100735 Bottom plate assembly 1 HPU-44H03 0.00% 0.000% ×
37 001A1431952 Bracket 1 HPU-44H03 0.00% 0.000% ×
38 001A5002103 Screw 1 HPU-44H03 0.00% 0.000% ×
39 001A5002103 Screw 1 HPU-44H03 0.00% 0.000% ×
40 0010751095 group 1 HPU-44H03 0.01% 0.012%
41 001A1301464 Little cover 1 HPU-44H03 0.00% 0.000% ×
42 001A1301707 Servicing plate 1 HPU-44H03 0.00% 0.000% ×
Parts list

43 001A1436160 Handle 1 HPU-44H03 0.00% 0.000% ×
5,Above should be improved accord with the reply of the market half a year per time.
6.The s
p
are
p
arts
p
rice on net is FOB Qin
g
dao term.
1,The failer rate and the proportion of the spare-part stock are regarded as the reference of the stock
for spare-parts;The first time should be stocked accroded with the proportion of the spare-parts,and it
should be adjusted with the actual quantity 3 months later.
2,easy-damaged;The spare-part which is often damaged and the customer must stock in the spare-
parts warehouse,and should be marked with"*"
3,possible damaged:The spare-part which is not often damaged like the easy damaged one and the
customer may stock in the spare-part warehouse accord with the actual case,should be marked with "
".
4,not need provided :The spare-part which is seldom damaged or the maintenance man could not
maitmains.The spare parts may be air freighted by the factory if they were damaged.The customer
nees not stock in the spare-part warehouse,should be marked with " x ".

10
26
34
3536
37 38
40 39
41 42
43
44
45 46
47
48
49
50
51 52
10
987
6
5 4
3
2 1
11 12 13 14 15 16
25 24 23
53 54 55 56 57 58 59
30 29 28 27
21
17 18
19 20
22
33 32
31
