SERVICE MANUAL
Models
AS072XVERA
AS092XVERA
AS122XVERA
AU182XFERA
AU222XFERA
 Features
 High energy efficiency
 Newly designed V-appearance for wall mounted unit, step or stepless air flow
control
 New outdoor unit with valve cover plate, also the grille is changed from metal
one to plastic one
 Adjustable heating temperature compenstation
 Free combination, multiple connection types with different types of indoor
unit, total indoor load can be up to 135% than the standard match
 Infrared control type
 Central control and full automation, if connected with a central controller
 New friendly refrigerant R410a, zero ODP, environment protection
 Advanced technology, DC inverter control function
 Health airflow and sterilize function for wall mounted unit, more healthy
 Weekly timer (standard)
 Group control function
 Auto restart function
 Low ambient temperature heating (-15 degree) function
 Room card function
Manual code: SYJS-013-05REV.3Edition: 2007-04-14

Commercial Air Conditioner Model: AU18/222XFERA
AS072/092/122XVERA
CONTENTS
Contents………………………………………………………....2
1. Description of products& features………………………...3
2. Specification………………………………………………….6
3. Safety precaution……………………………………………10
4. Net dimension of indoor and outdoor……………………..12
5. Installation instructions………..……………………………13
6. Parts and functions………………………….………………36
7. Remote controller YR-H65...……………………………….37
8. Refrigerant diagram…………………………………………45
9. Electrical control functions………………………………….47
10. Diagnostic information and trouble shooting...………….59
11. Electrical data………………………………………………65
12. Performance curves.......................................................71
13. Noise level.....................................................................75
14. Air velocity distribution...................................................78
-2-

Commercial Air Conditioner Model: AU18/222XFERA
AS072/092/122XVERA
1.Description of products & features
1.1. Products code explanation
AU 18 2 X F E R A
Climate type: T1 (see table 1)
Design number (R stands for design sequence, DC inverter
type)
Product type: A stands for heat pump type, refrigerant is R22
B stands for heat pump type, refrigerant is R407C
E stands for heat pump type, refrigerant is R410A
N stands for cool only type, refrigerant is R407C
Appearance character
Product series: X stands for multi-split series
Applicable voltage: 2 stands for 220-230V/50Hz,
4 stands for 220V/60Hz，N stand for 380-400V/50Hz
Cooling / Heating capacity,18=18000BTU/h
Product type : “B” stands for cassette type, “C” stands for
convertible type, ”D” stands for duct, “S” stands for wall
mounted type, "E" stands for ceiling concealed type, “U”
stands for outdoor unit
Air Conditioner
1.2 Brief Introduction for T1、T2、T3 working condition
1.3 Operating Range of Air Conditioners
Working temperature range
Rated Maximum Minimum
Indoor DB℃27 32 18
WB℃19 23 14
outdoor DB℃35 43 10
Cooling
WB℃24 26 6
Indoor DB℃20 27 15
WB℃14.5 -- --
outdoor DB℃7 24 -15
Heating
WB℃6 18 --
Climate type
Type of Air
Conditioner T1 T2 T3
Cooling Only 18 ℃~43℃10℃~35℃21℃~52℃
Heat pump -7℃~43℃-7℃~35℃-7℃~52℃
Electricity Heating ~43℃~35℃~52℃
-3-

Commercial Air Conditioner Model: AU18/222XFERA
AS072/092/122XVERA
1.4 Product features
High efficienct, universal outdoor unit
The outdoor unit can match with wall mounted type, duct and cassette type indoor unit. One set
outdoor can match with multiple indoor units, up to 3 sets. Even when you have already installed
the air conditioner, if you want to add or reduce one unit, go ahead freely as long as your operation
complies with our design. Greatly convenient for designer and installer.
Total indoor load can be up to 135% than the standard match
The total capacity of all indoor units can be 135% more than the mominal cooling capacity, but the
total indoor cooling capacity will not be increased.
Newly designed V- appearance indoor unit
The wall mounted type indoor unit adopts the newly designed V appearance, more fashion, more
beautiful. The unit is designed with the health airflow and sterilize function, which will make the air
more healthy. Also the air blow direction can be set as step or stepless control, much convenient to
control.
Newly designed guarding plate of valve
In order to protect the valve against the dust, the rain or the snow, etc. we add a
guarding plate to the valve.
Adopt the much friendlier refrigerant R410a
The air conditioner system adopts the greatly friendly refrigerant R410a, which is protective for the
ozone layer and is good to avoid the earth getting warmer. Benefit for the environment.
Adopt the advanced DC inverter technology
The system adopts the advanced DC inverter technology, which can consume less power energy to
realize the equal efficiency, saving money for you.
With air inlet filter, enhance the air quality
The high efficiency filter can collect the dirt and remove the bacterium, which can be installed on the
easy-to-unload place, convenient to be cleaned.
Convenient infrared remote controller
This remote controller YR-H65 can realize the healthy air flow and sterilize function, it is mobile type
appearance, so smart and compact.
And the infrared controller can be equipped with the controller holder, convenient to fix
the remote controller.
-4-

Auto–restart function (optional)
All indoor units have auto-restart function. When the power supply cut off suddenly, the unit will
automatically recover the previous running mode once the power supply is on.
Self-diagnostic function
In the course of operation, if the failure occurs, the failure code will display on the wired controller or
on the operation panel. Then according to the failure code chart, you can eliminate the failure soon.
Central control function, if connected with a detector and a central controller
That is convenient for building management.
Weekly timing function, if connected with a detector and a weekly timer
Adjustable heating temperature compensation
In heating mode, the temperature compensation can be adjusted by the remote controller. If you do
not want the compensation, you can set the compensation as 0 degree.
-5-
Commercial Air Conditioner Model: AU18/222XFERA
AS072/092/122XVERA
ON
OFF
OFF
ON
When room card function is available,indoor will be controlled as below figure:
When room card is disconnected When room card is connected

2. Specification
-6-
—— Cooling Heating
W 5300 7000
W 1650 1800
W/W 3.21 3.88
W 1500 1800
W 500 500
W5800 7400
W2300 2300
——
A / A 10.2 10.2
—— 99% 99%
A
Model / Manufacture ——
Oil charge and type ——
Type ——
Number ——
Type × Number ——
Speed r/min
Motor output power W
Air-flows (H/M/L) m³/h
Type / Diameter mm
Face area m²
External mm
Package mm
——
——
W
Noise level H/M/L dB(A)
Weight Net / Shipping kg / kg
Type / Charge kg
No need to recharge m
Recharge g/m
Liquid mm
Gas mm
——
Drop between IU & OU m
Piping length between IU & OU m
Total liquid piping length m
Drop between indoor units m
Max.Drop between IU & OU m
Max.Drop between IU & OU m
Max.Drop between indoor units m
Max.Piping length between IU & m
Max.Total liquid piping length m
Power input
Minimum capacity
Power input
Power facor(under rating power input)
Max.Running current
Fan
Item Model AU182XFERA
Function
Power source 1PH, 220-230V~, 50Hz
Rating capacity
Maximum capacity
Power input
EER / COP
Fuse size (recommended size)
TNB175FLBM1 / MISTUBISHI ELEC.
Twin Rotary (DC inverter)
1
25
Outdoor unit
Compressor
Dimension
(L×W×H)
Heat exchanger
Crankcase heater power
Axial × 1
670CC, MEL 56
928/288/680
1015/405/760
850/ 700/ 500
35
about 3000
TP2M / 7.0
about 0.52
35
Refrigerant control method PMV
Defrosting method Automatic by reversible cycle
Pipe 3* Φ6.35
3* Φ9.52
≤10
≤5
45
30
20
≤30
10(indoor unit lower than outdoor unit)
25
15 (indoor unit higher than outdoor unit)
≤1
5
2. Large drop and long piping installation will obviously reduce the totao capacity.
1. The above performance data are from the combination of AU182XFERA+2*AS092XVERA+AS122XVERA.
51/-/-
54 / 60
Piping
Refrigerant R410A / 2.0
Connecting method Flared
Between I.D &O.D
Commercial Air Conditioner Model: AU18/222XFERA
AS072/092/122XVERA

—— Cooling Heating
W 6400 7300
W 2100 2000
A 9.3 8.9
W/W 3.04 3.65
W 1500 1800
W 500 500
W6800 7500
W2900 2900
——
A / A 12.9 12.9
—— 99% 99%
A
Model / Manufacture ——
Oil charge and type ——
Type ——
Number ——
Type × Number ——
Speed r/min
Motor output power W
Air-flows (H/M/L) m³/h
Type / Diameter mm
Face area m²
External mm
Package mm
——
——
W
Noise level H/M/L dB(A)
Weight Net / Shipping kg / kg
Type / Charge kg
No need to recharge m
Recharge g/m
Liquid mm
Gas mm
——
Drop between IU & OU m
Piping length between IU & OU m
Total liquid piping length m
Drop between indoor units m
Max.Drop between IU & OU m
Max.Drop between IU & OU m
Max.Drop between indoor units m
Max.Piping length between IU & m
Max.Total liquid piping length m
25
45
1. The above performance data are from the combination of AU222XFERA+AS092XVERA+2*AS122XVERA.
2. Large drop and long piping installation will obviously reduce the total capacity.
Connecting method Flared
Between I.D &O.D ≤5
≤10
≤30
≤1
10(indoor unit lower than outdoor unit)
15 (indoor unit higher than outdoor
5
55/-/-
54 / 60
Piping
Refrigerant R410A / 2.0
30
20
Pipe 3* Φ6.35
3* Φ9.52
Defrosting method Automatic by reversible cycle
Crankcase heater power 35
Dimension
(L×W×H)
928/288/680
1015/405/760
Refrigerant control method PMV
about 3200
Heat exchanger TP2M / 7.0
about 0.52
Outdoor unit
Compressor TNB175FLBM1 / MISTUBISHI
670CC, MEL 56
Twin Rotary (DC inverter)
1
Fan Axial × 1
960/ 700/ 500
35
Max.Running current
Power facor(under rating power input)
Fuse size (recommended size) 25
Maximum capacity
Power input
Power source 1PH, 220-230V~, 50Hz
Power input
EER / COP
Minimum capacity
Power input
Current input
Item Model AU222XFERA
Function
Rating capacity
Commercial Air Conditioner Model: AU18/222XFERA
AS072/092/122XVERA
-7-

-8-
—— Cooling Heating Cooling Heating
BTU/h 7000 8000 9000 10000
W2000 2300 2500 2900
——
——
10‐³×m³/h 1.0 / 1.0 /
N, V, Hz
A / A 0.15 0.15 0.15 0.15
Type × Number ——
Speed r/min
Motor output power W
Air-flows (H/M/L) m³/h
Type / Diameter mm
Total area m²
External mm
Package mm
Drainage pipe material, diameter mm
——
——
Noise level H/M/L dB(A)
Weight Net / Shipping kg / kg
Refrigerant Type ——
Liquid mm
Gas mm
——
——
BTU/h
W
10‐³×m³/h
——
——
N, V, Hz
A / A
Type × Number ——
Speed r/min
Motor output power W
Air-flows (H-M-L) m³/h
Type / Diameter mm
Total area m²
External mm
Package mm
Drainage pipe material, diameter mm
——
——
Noise level H/M/L dB(A)
Weight Net / Shipping kg / kg
Refrigerant Type ——
Liquid mm
Gas mm
——
R410A
6.35
9.52
Flared
1250/1150/1050
27
550/480/430
about 0.20
/
0.15 0.15
CROSS×1
AS122XVERA
Cooling
11000
3200
1.6
Heating
13000
3800
Piping
Pipe
Connecting method
39/36/33
7.6/10.6
PVC, 11.4/16.4
Controller type Infrared (YR-H65)
Refrigerant control PMV on outdoor unit
Dimension
(L×W×H)
795×197×265
880×315×330
Heat exchanger TP2M / 7×0.35
Power source 1, 220~230, 50
Running current
Fan
Power cable 3 × (1.0~1.5mm2)
Communication cable 2x(0.75~1.25mm2
), must be shielded
Function
Capacity
Capacity
Dehumidifying capacity
Flared
Item
Piping
R410A R410A
Pipe 6.35 6.35
9.52 9.52
Connecting method Flared
PMV on outdoor unit
36/33/30 38/34/31
7.6/10.6 7.6/10.6
795×197×265
880×315×330 880×315×330
PVC, 11.4/16.4
520/450/390
Heat exchanger TP2M / 7×0.35
about 0.15 about 0.15
CROSS×1
1150/1050/950 1200/1100/1000
27 27
Running current
Fan CROSS×1
480/430/380
Dimension
(L×W×H)
795*197*265
Controller type Infrared (YR-H65)
Refrigerant control
Communication cable 2x(0.75~1.25mm2
), must be shielded
Dehumidifying capacity
Power source 1,220-230~, 50
Capacity
Capacity
Power cable 3 × (1.0~1.5mm2)
Item Model AS072XVERA AS092XVERA
Function
Commercial Air Conditioner Model: AU18/222XFERA
AS072/092/122XVERA

Norminal condition: indoor temperature (cooling): 27℃DB/19℃WB, indoor temperature (heating): 20℃
DB
Outdoor temperature(cooling): 35℃DB/24℃WB, outdoor temperature(heating): 7℃DB/6℃WB
The noise level will be measured in the third octave band limited values, using a Real Time Analyser
calibrated sound intensity meter. It is a sound pressure noise level. The detailed method please refer to
the following information:
Installation state: the unit should be placed on the flat floor or be mounted in horizontal direction.
Testing method:
outdoor unit:
1.air outlet from side: the noise level is the average sound pressure level measured from front, left, right
directions.
2.air outlet from top: the noise level is the average sound pressure level measured from front, back, left, right
directions.
measured point:
H ( height to the ground) = (h (unit height) + 1m) /2
and, it is 1m to each side.
mounting-on-wall unit:
Note: ⊙is the real time analyser position
0.8m
1m
h
1m
1m
1m
1m
-9-
Commercial Air Conditioner Model: AU18/222XFERA
AS072/092/122XVERA

3. Safety precaution
Carefully read the following information in order to operate the airconditioner correctly .
Below are listed three kinds of Safety Cautions and Suggestions.
WARNING!
CAUTION! Incorrect operations may result in injuries or machine damages; in some cases may
cause serious consequences.
Incorrect operations may result in severe consequences of death or serious injuries.
INSTRUCTIONS: These information can ensure the correct operation of the machine.
Be sure to conform with the following important Safety Cautions.
The Safety Cautions should be at hand so that they can be checked at any time when needed.
If the conditioner is transferred to the new user, this manual should be as well transferred to the new user.
WARNING!
If any abnormal phenomena is found
(e. g.smell of firing), please cut off the
power supply immediately , and contact
the dealer to find out the handling
method.
Don't dismantle the outlet of the
outdoor unit.
The exposed fan is very dangerous
which may harm human beings.
switch
off
In such case, to continue using the
conditioner will damage the conditioner,
and may cause electrical shock or fire
hazard.
Incorrect maintenance and repairment
may cause water leak, electrical shock
and fire hazard.
When the unit needs maintenance and
repairment, please call dealer to handle it.
After the unit being used for a long time,
the base should be checked for any
damages.
If the damaged base is not repaired, the
unit may fall down and cause accidents.
-10-
Commercial Air Conditioner Model: AU18/222XFERA
AS072/092/122XVERA
