Haier HBU-42CH03 User manual

Please read this operation manual before using the air conditioner.
No.0150500604
C
Operation & Installation Manual
HBU 28CH03
HBU 28HH03
HBU 36HH03
HBU 42CI03
HBU 42CH03
HBU 42HI03
HBU 48CH03
HBU 48HJ03
HBU 48CK03
CASSETTE TYPE AIR CONDITIONER
Please keep this manual carefully and safely.
Indoor Unit

Contents
Cautions ...........................................................................................
Introduction to Spare Parts................................................................
Maintenance...................................................................................
Trouble Shooting ..........................................................................
When Trouble Happens..................................................................
Customer Need to know.....................................................................
Installation Procedure ....................................................................
1 5
6
7 8
9 10
11 12
13
14 24

Cautions
1
Disposal of the old air conditioner
Before disposing an old air conditioner
that goes out of use, please make sure it's
inoperative and safe. Unplug the air
conditioner in order to avoid the risk of
child entrapment.
It must be noticed that air conditioner
system contains refrigerants, which require
specialized waste disposal. The valuable
materials contained in a air conditioner can
be recycled. Contact your local waste
disposal center for proper disposal of an
old air conditioner and contact your local
authority or your dealer if you have any
question. Please ensure that the pipework
of your air conditioner does not get
damaged prior to being picked up by the
relevant waste disposal center, and
contribute to environmental awareness by
insisting on an appropriate, anti pollution
method of disposal.
Disposal of the packaging of your new
air conditioner
All the packaging materials employed in
the package of your new air conditioner
may be disposed without any danger to the
environment.
The cardboard box may be broken or cut
into smaller pieces and given to a waste
paper disposal service. The wrapping bag
made of polyethylene and the polyethylene
foam pads contain no fluorochloric
hydrocarbon.
Consult your local authorities for the name and
address of the waste materials collecting
centers and waste paper disposal services
nearest to your house.
Safety Instructions and Warnings
Before starting the air conditioner, read the
information given in the User's Guide
carefully. The User's Guide contains very
important observations relating to the
assembly, operation and maintenance of the
air conditioner.
The manufacturer does not accept
responsibility for any damages that may
arise due to non observation of the following
instruction.
Damaged air conditioners are not to be
put into operation. In case of doubt, consult
your supplier.
Use of the air conditioner is to be carried
out in strict compliance with the relative
instructions set forth in the User's Guide.
Installation shall be done by professional
people, don't install unit by yourself.
All these valuable materials may be taken to a
waste collecting center and used again after
adequate recycling.
For the purpose of safety, the air
conditioner must be properly grounded in
accordance with specifications.
Always remember to unplug the air
conditioner before opening inlet grill. Never
unplug your air conditioner by pulling on the
power cord. Always grip plug firmly and
pull straight out from the outlet.

All the cables shall have got the European
authentication certificate.
5. The breaker of the air conditioner should
be all pole switch; and the distance
between its two contacts should be no less
3mm. Such means for disconnection must
be incorporation in the fixed wiring.
6. The waste battery shall be disposed
properly.
7. The indoor unit installation height is at
least 2.5m.
All electrical repairs must be carried out
by qualified electricians. Inadequate repairs
may result in a major source of danger for
the user of the air conditoiner.
Do not damage any parts of the air
conditioner that carry refrigerant by
piercing or perforating the air conditioner's
tubes with sharp or pointed items, crushing
or twisting any tubes, or scraping the
coatings off the surfaces. If the refrigerant
spurts out and gets into eyes, it may result
in serious eye injuries.
Do not obstruct or cover the ventilation
grille of the air conditioner. Do not put
fingers or any other things into the
inlet/outlet and swing louver.
Do not allow children to play with the air
conditioner. In no case should children be
allowed to sit on the outdoor unit.
Specifications
The refrigerating circuit is leak proof.
1. Applicable ambient temperature range:
The machine is adapti e in following
situation
Model
2. If the supply cord is damaged, it must be
replaced by the manufacturer or its service
agentor a similar qualified person.
Cautions
HBU 36HH03 HBU 42CH03
HBU 42CI03 HBU 42HI03
HBU 48CH03 HBU 48HJ03
HBU 48CK03
HBU 28CH03 HBU 28HH03
Power Cable
3. The wiring method should be in line with
the local wiring standard.
4. The power cable and connecting cable
are self provided.
The requirement of the power cable:
The requirement of the connecting cable:
Model Connecting cable
HBU 28CH03 HBU 36HH03
HBU 42CH03 HBU 42CI03
HBU 42HI03 HBU 48CH03
HBU 48HJ03 HBU 48CK03
3G 4.0mm2
5G 2.5mm2
HBU 28HH03
4G 0.75mm2
6G 0.75mm2
Cooling
Heating
Indoor
outdoor
DB
WB
Indoor
outdoor
Rated
27
19
35
24
20
14.5
7
6
Maximum
32
23
43
26
27
24
18
Minimum
18
14
10
6
15
7
2
DB
WB
DB
WB
DB
WB

WARNING!
Carefully read the following information in order to operate the airconditioner correctly.
Below are listed three kinds of Safety Cautions and Suggestions.
WARNING!
CAUTION! Incorrect operations may result in injuries or machine damages; in some cases may
cause serious consequences.
Incorrect operations may result in severe consequences of death or serious injuries.
INSTRUCTIONS: These information can ensure the correct operation of the machine.
Be sure to conform with the following important Safety Cautions.
The Safety Cautions should be at hand so that they can be checked at any time when needed.
If the conditioner is transferred to the new user, this manual should be as well transferred to the new user.
Otherwise the one
will feel unpleasant
or harm ones' health.
If any abnormal phenomena is found (e. g.
smell of firing), please cut off the power
supply immediately, and contact the dealer
to find out the handling method.
In such case, to continue
using the conditioner will
damage the conditioner,
and may cause electrical
shock or fire hazard.
When need maintenance and repairment,
call dealer to handle it.
Incorrect mainten
ance and repairment
may cause water
leak, electrical shock
and fire hazard.
switch
off
Please let the dealer be responsible for installing
the conditioner.
Incorrect installation may cause water leak, elec
trical shock and fire hazard.
Don't put fingers or any other things into the
inlet/outlet and swing lou er while the condi-
tioner is in operation.
Because the highspeed
fan is very dangerous
and may cause injuries.
Call the dealer to take measures to pre ent the
refrigerant from leaking.
If conditioner is installed in a small room be sure
to take every measure in order to prevent suffoca
tion accident even in case of refrigerant leakage.
When conditioner is deinstalled or reinstalled
dealer should be responsible for them.
Incorrect installation may cause water leaking,
electrical shock and fire hazard.
Don't blow the human body with the cooling
air too long, and don't let the room tempera-
ture decrease too low
either.
Cautions
Safety cautions
3

CAUTIONS!
Conditioner should not be used for any other
purpose other than airconditioning.
Don't use air conditioner for any other special
purposes, e.g. the preservation and protection
of food, animals, plants,
pecision apparatus as well
as work of art, otherwise
the qualities of these
stuffs may be damaged.
Don't dismantle the outlet of the outdoor unit.
The exposure of fan is
very dangerous which
may harm human be
ings.
When air-conditioner is co-used with other
heat-radiator the frequent replacement of
room atmosphere should be required.
Inefficient venti
lation may cause
suffocation.
After a long time use of air-conditioner the
base should be checked for any damages.
If the damaged base is
not repaired, the unit
may fall down and
cause accidents.
No goods or nobody is permitted to placed on
or stand on outdoor unit.
The falling of goods and
people may cause acci
dents.
Pets and plants should not be blowed directly
in the air flow.
Otherwise will suffer
damage.
Don't operate the air-con-
ditioner with damp hands.
Otherwise will be shocked.
Only use correctly-typed fuse.
May not use wire or any other
materials replacing fuse, other
wise may cause faults or fire
accidents.
Don't place any burning unit
in the air flow of air-conditioner,
which may cause incomplete
combustion.
No inflammable spray fluid
should be permitted to be
placed or used near to air-
conditioner otherwise may
cause fire accidents.
Air-conditioner should be
cleaned only after power
supply is cut off to keep
from shock or hurt.
Don't clean air-conditioner
with water.
Otherwise may cause
shock.
Otherwise the poisonous chemicals may settle
in air conditioner which harm the health of
chemical allergic people.
When use the fumigating insecticide don't
open air-conditioner.
Cautions
4

WARNING !
CAUTION !
Please ask the dealer or specialist to install, never try by the users themselves. After the
installation please be sure of the following conditions.
Incorrect installation may cause water leaking, shock and fire hazard.
Please call dealer to install the air-conditioner.
Air-conditioner can't be installed in the
en ironment with inflammable gases
because the inflammable gases near to air-
conditioner may cause fire hazard.
Installed electrical-leaking circuit breaker.
Connect earthing wire.
Use discharge pipe correctly to ensure
efficient discharge.
[Location]
[Wiring]
[Operating noise]
It easily cause electrical shock without circuit
breaker.
Air conditioner should be located in well vented
and easily accessible place.
Air conditioner should not be located in the
following places:
(a) Places with machine oils or other oil vapours.
(b) Seaside with high salt content in the air.
(c) Near to hot spring with high content of sulfide
gases.
(d) Area with frequent fluctuation of voltage e.g.
factory, etc.
(e) In vehicles or ships.
(f) Kitchen with heavy oil vapour or humidity.
(g) Near to the machine emitting electric magnetic
waves.
(h) Places with acid, alkali vapuor.
TV, radio, acoustic appliances etc are at least 1 m
far away to the indoor unit, outdoor unit, power
supply wire, connecting wire, pipes, otherwise
images may be disturbed or noises be created.
Earthing wire should not be con
nected to the gas pipe, water pipe,
lightning rod or phone line, in
correct earthing may cause shock.
Incorrect pipe use may cause water leaking.
As required, take measures against heavy snow.
Air conditioner should be equipped with special
power supply wire.
Chose the following locations:
(a) Capable of supporting air conditioner weight,
don't increase operating noise and vibration.
(b) Hot vapour from outdoor unit outlet and ope
rating noise don't disturb neighbour.
No obstacles around the outdoor unit outlet.
Earthing
Installation
Cautions
5

Introduction to Spare Parts
6
( adjust air outlet direction
by the air direction adjusting
button on remote controller)
Air ourlet blade
Suction grill
Air filter
(located in the suction grill)

5. Close inlet grill
4. Install air filter
Put filter into protruding parts at the top of the
inlet grill.
[Clean outlet and shell]
CAUTION!
Don't use gasoline, benzene, dilutant, polishing
powder, or liquid inseticide.
CAUTION!
3. Clean
(A) Remove dust with vacuum filter.
Maintenance
[Clean air filter]
NOTE
1. Open inlet grill
When having to clean, don't dismantle air filter,otherwise may cause faults.
In the environment where there is too much dust, air filter should be cleaned for
more times.
(about half a year one time)
(B) Wash with water.
Swing off the water,
and then place in cool
place.
Pull the two handles at the same
time, slowly draw them out.
2. Dismantle air filter
Clip cpening
Bottom of filter
Frame of air inlet grill
the reverse sequance of 1.
Don't wash with water over 50 , to prevent
discoloring or deforming.
Don't dry over fire. Filter maybe burn.
7
With too much dust, use soft brush and neutral
detergent.
Don't wash with water over 50 , otherwise may
cause discoloring or deforming.
Use soft dry cloth to scrub.
If duse not removed,can use water or neutral
detergent.
If ceiling built in conditioner's swing plate too
dirty, it can be dimantled(as described below)
and cleaned.
Remove the air inlet grill

8
NOTE
1.The inner part of indoor unit must be cleaned. Consult dealer, because clean must be
done by technician.
2.In cooling operation, discharging system discharge water in room.
Seasonal Reser e
Operate the unit with FAN mode on a fair day for about half
a day to dry the inside of the unit well.
Stop operation and turn off the power supply switch .Electric
power is consumed even the air conditioner is in stop.
Clean the air filter, indoor unit and outdoor unit,and cover
the unit with dustcoat.
Pre-season Care
See that there is no obstacles blocking the air inlet and
air outlet of both indoor and outdoor unit to avoid reduce
the working efficiency.
Be sure to install the air filter, ensure that the air filter is not dirty. Otherwise may
result in machine damages or cause malfunciton due th dust inside the unit
To prevent compressor when start in HEAT mode, please
cut in the power supply switch 12 hours before starting
run,furthermore, always keep the power supply switch
on during the using senson.
Post-season Care
Maintenance

The followings are not malfunction
Hua
Hua
Trouble Shooting
Water flowing sound is heard When the air conditoner is started, when
the compressor starts or stops during
operation or when the air conditioner is
stopped,it sometimes sounds "Bi Bi "or
"Godo Godo". It is the flowing sound of
the refrigerant , not a malfunction.
Cracking sound is heard
It smells.
This is caused by heat expansion or
contraction of plastics
Air blown out from the indoor unit
sometimes smells. The smell results from
smells of furniture, paint , tobacco
absorbed by indoor unit.
During operation, white fog comes out of
indoor unit.
When in COOL or DRY mode, a thin water
fog can be seen blown out of unit ,this is
the condensed fog because the suddenly
cooled indoor air is blown out.
Automatically switch into FAN mode during
cooling.
To prevent frost from being accumulated
on the indoor unit heat exchanger, it
sometimes automatically switched into the
FAN mode,but it will soon back to the
cooling mode.
The air conditioner cannot be restarted soon
after it stops.
Air conditioner does not start?
This is because of the self protection
function of the system, therefore,it cannot
be restarted for about three minutes after
it stops.
Please wait for three minutes.
9

**?
ON
OFF
Trouble Shooting
Air does not blow or the fan speed cannot
be changed during drying.
In DRY mode, when room temperature
becomes 2 higher than temperature
setting, unit rill run intermittently at LO
speed regardless of FAN setting
During heating,indoor fan is still running
even unit is stopped.
To get ride of the excess heat, indoor fan
will continue running for a while after unit
autom atically stops.
Water or vapor generated from the outdoor
unit during heating.
Please check the following things about your air conditioner before making a service call.
Unit fails to start.
Is the power supply switch on?
Power supply switch is not in
ON position.
Is city supply power normal? Is the earth leakage
breaker in action ?
Be sure to turn off the
power supply switch
immediately and
contact the sales dealer.
10

When Trouble Happens
Insufficient cooling or heating
The operation controller
adjusted as required
Air filter too dirty ? Horizontal swing louver
upward ? (in HEAT mode)
Any obstacle exists at the air
inlet or outlet?
Door or window left opened ?
Insufficient cooling
Any other heat sources in the
room?
Sunlight direct into the
room ?
Too crowed in the room ?
Cooled air blown out ( when heating)
When the air conditioner does not operate properly after
you have checked the above mentioned items or when
following phenomenon is observed,stop the operation
of the air conditioner and contact your sales dealer.
1)The fuse or breaker often shuts down.
2)Water drops off during cooling or drying operation.
3)There is an irregularity in operation or abnormal sound
that is audible.
11

When Trouble Happens
Power lamp flash
times/LED on
PCB flash times
failure description Reasons
E0 10 Fault in drain system Float switch is open
E1 1 Indoor ambient
temp. sensor failure
Sensor broken down or short circuit for
more than 2m continuously
E2 2 Indoor pipe
temp. sensor failure
Sensor broken down or short circuit for more
than 2m continuously
E3 3 Outdoor ambient
temp. sensor failure
Sensor broken down or short circuit for more
than 2m continuously
E4 4
Outdoor pipe or
discharge temp.
sensor failure
Sensor broken down or short circuit for more
than 2m continuously or outdoor discharge
temp. over 120 for 3 times continuously in
30m
E5 5 overcurrent
Indicate phase failure when been electrified
for the first time, indicate overcurrent
protection during working procedure
E6
6
16
High pressure
malfunction
Outdoor high pressure switch acts
Low pressure
malfunction
Outdoor low pressure switch acts or the
proctector on the top of compressor breaks
for protection
E8 8
Communication
failure between
indoor PCB and panel
or wired controller
Communication abnormal for more than 4m
continuously
E9 9
Communication
failure between
indoor and outdoor
unit
Communication between indoor PCB and
outdoor PCB open for more than 4m
E7 13 Temperature cutoff
protection
System failure. System cooling or heating
function abnormal
12
Failure code list
Failure code
on wired
controller

Customer Need-to-know
Customer Need-to-know
Please install the air conditioner according to the requirements specified in this manual
to ensure the air conditioner work well.
Be careful not to scratch the surface of the case during moving the air conditioner.
Please keep the installation manual for future reference when maintenance and changing
installation place.
After installation ,please use the air conditioner according to the specification in the
operation manual.
Using Directions
Adjust suitable airflow direction Avoid direct sunlight and airflow
Keep the proper indoor temperature.
Too cool or hot is not good for your health.
Furthermore,it will result in excessive
consumption of electric power.
Optimal
temper
ature
Effectively use timer.
Using TIMER mode, you can make the
room temperature reach a suitable
temperature when you wake up or go back
home.
ATTENTION: after finishing installation,confirm no refrigerant leakage.
13

A
B
C
D
E
F
Installation tools
Standard accessories
1. Screw driver
2. Hacksaw
3. Drill with a diameter of 60mm
4. Inner hexagon spanner,shifting spanner
5. Spanner (14, 17, 19, 24, 27mm)
6. Pipe cutter
7. Pipe expander
8. Knife
9. Pincers
10. Leakage detector or soapy water
11. Band tape
12. Scraper
13. Refrigerant oil
The installation tools listed in the following sheet can be used as required.
The following parts mentioned in this manual are the installation accessories we prepared.
Symbol Parts Name
Adhesive tape
Pipe clamp
Connecting hose
Drainage hose
Non hydroscopicheat insulating material
Gypsum powder
14
Installation Procedure

Unit shall be grounded. But grounding shall not be connected to gas pipe water pipe,
telephone line. Poor grounding will cause electric shock.
Be sure to install a leakage breaker to avoid electric shock.
Arrange water drainage according to this Manual. Cover pipe with insulation materials in case dew may
occur. Unproper installation of water drainage will cause water leakage and wet your furniture.
To maintain good picture or reduce noise, keep at least 1 m from T.V. radio, when install indoor and outdoor
unit, connecting wire and power cable. (If the radio wave is relatively strong, 1 m is not enough to reduce
noise).
Don't install unit in following places:
(a) Oil mist or oil gas exists, such as kitchen, or, plastic parts may get aged, or water leakage.
(b) Where there is corrosive gas. Copper tube and welded part may be damaged due to corrosion,causing
leakage.
(c) Where there is strong radiation. This will affect unit's control system, causing malfunction of the unit.
(d) Where flamable gas, dirt, and volatile matter (thinner, gasoline) exist, These mattermight cause fire
accident.
Meanings of Warning and Cautions:
CAUTION!
Installation shall be done by professional people, don't install unit by yourself. Incorrect installation
will cause water leakage, electric shock or fire.
Install unit as per the Manual. Incorrect installation will cause water leakage, electric shock or fire
accident.
Be sure to use specified accessaries and parts. Otherwise, water leakage, electric shock, fire accident
or unit falling down may happen.
Unit should be placed on a place strong enough to hold the unit. Or, unit will fall down causing injuries.
When install the unit, take in consideration of storms, typhoom, earthquake. Incorrect installation
may cause unit to fall down.
All electric work shall be done by experienced people as per eocal code, regulations and this Manual.
Use exclusive wire for the unit. Incorrect installation or undersized electric wire may cause electric
shock or fire accident.
All the wires and circuit shall be safe. Use exclusive wire firmly fixed. Be sure that external force
will not affect terminal bolck and electric wire. Poor contact and installation may cause fire accident.
Arrange wire correctly when connectin indoor and outdoor power supply. Fix terminal cover firmly
to avoid overheat, electric shock or even fire accident.
In case retrigerant leakage occurred during unit installation, keep a good ventilation in the room.
Poisonous gas will occur when meet with fire.
Check the unit upon installation. Be sure there is no leakage. Refrigerant will induce poisonous gas
when meet heat source as heater, oven, etc.
Cut power supply before touching terminal bolck.
WARNING!
Earthing
Don't fail to show customers how to operate unit.
Refer to paper pattern when installing unit.
Cautions for the installation personnel
15
Warning! Serious injury or even death might happen,if it is not observed.
Caution! Injury to people of damages to machine might happen, if it is not observed.
To ensure proper installation,read
" Cautions " carefully before working.After installation,start
the unit correctly and show customers how to operate and maintain the unit.
CAUTIONS:
Installation Procedure

(2) Ceiling height
Indoor unit can be installed on ceiling of 2.5 3m in height. (Refer to Field setting and Installation
Manual of ornament panel.)
(3) Install suspending bolt. Check if the installation place is strong enough to hold weight. Take
necessary measures in case it is not safe. (Distance between holes are marked on paper pattern.
Refer to paper pattern for place which need be reinforced)
Installation space
(1) Installation place shall meet the following and agreed by customers:
Place where proper air flow can be ensured.
No block to air flow.
Water drainage is smooth.
Place strong enough to support unit .
Place where inclination is not evident on ceiling.
Enough space for maintenance.
Indoor and outdoor unit piping length is within limit. (Refer to Installation Manual for outdoor
unit.)
Indoor and outdoor unit, power cable, inter unit cable are at least 1 m away fromT.V. radio.
This is helpful to avoid picture disturbance and noise. (Even if 1 m is kept, noise can still appear
if radio wave is strong)
<Don't discard any accessories until completed>
Determine the way to carry unit to installation place.
Don't remove packing until unit reaches installation place.
If unpacking is unavoidable, protect unit properly.
1
HBU 28CH03 HBU 28HH03
HBU 36HH03 HBU 42CH03
HBU 42CI03 HBU 42HI03
HBU 48CH03
16
2
Before installation
Selection of installation place
Air inlet
Air outlet
2500 Over
Air outlet
1500 Over
1500 Over
Air inlet Air outlet
1500 Over
Model H
Unit:mm
310
Model H
290HBU 48HJ03 HBU 48CK03
260
H
1500 Over
Air outlet
H
2500 Over
Installation Procedure

17
3Preparation for the installation
(1) Position of ceiling opening between unit and suspending bolt.
Unit:mm
Note:
Dimension of ceiling opening marked with * can be
aslarge as 910mm, but the matching part of ceiling
with ornament panel shall be over 20mm.
HBU 28CH03
HBU 28HH03
HBU 36HH03
HBU 42CH03
HBU 42CI03
HBU 42HI03
HBU 48CH03
HBU 48HJ03
HBU 48CK03
160
Suspending bracket
Ceiling
A
690
(Distance between
suspending bolts)
790
(Distance between suspending bolts)
890
890
Ceiling opening)
(Ceiling opening)
A
20 Over
drain pipe
950(Ornament panel)
890(Ceiling opening)
840(Indoor unit)
780
(Distance between suspending bolts)
950(Ornament panel)
890(Ceiling opening)
840(Indoor unit)
Suspending bolts
Refrigerant pipe
*
*
680
(Distance between
suspending bolts)
340
150mm
60mm
Ornament panel
25mm
Ceiling Suspending bracket
Installation Procedure
Distance between
suspending bolts 790mm
Distance between
suspending bolts 690mm
840mm(Indoor unit)
890mm(Ceiling opening)
950mm(Ornament panel)
950mm(Ornament panel)
890mm(Ceiling opening)
840mm(Indoor unit)

< After installation on the ceiling >
(3) Adjust unit to its right position. (Refer to preparation for the installation (1))
(4) Check unit's horizontal level.
Watert pump and flating switch is installed inside indoor unit, check four corners of the unit for its level
using horizontal compartor or PVC tube with water. (If unit is tilting against the direction of water
drainage, problem may occur on floating switch, causing water leakage.)
(5) Remove the washer mounlting , and tighten the nut above.
(6) Remove the paper pattern.
As for the dimensions of ceiling hole, see paper pattern. Ask your real estate dealer for details.
Center of the hole is marked on the paper pattern.
Center of the unit is marked on the card in the unit and on the paper pattern.
Mount paper pattern onto unit using 3 screws . Fix the corner of the drain pan at piping outlet.
(1) Install unit temporarily
Put suspending bracket on the suspending bolt. Be sure to use nut and washer at both ends of the bracket.
In the case of ceiling already exists
(1) Install unit temporarily
Put suspending bracket on the suspending
bolt. Be sure to use nut and washer at both ends
of the bracket. Fix the bracket firmly.
(2) Adjust the height and position of the unit.
(Refer to preparation for the installation (1) ).
(3) Proceed with (3) and (4) of "In the case of
new ceiling".
Nut (Prepare in field)
Washer (Prepared in field)
Suspending bolts
Fasten (double nuts)
Insert
Washer fixing pad
(prepared in feild)
[ secure the washer firmly]
(2) Cut an opening in ceiling for installation if necessary. (when ceiling already exists.)
(3) Install a suspending bolt.(Use a M10 bolt)
To support the unit weight, anchor bolt shall be used
in the case of already exists ceiling. For new ceiling,
use built in type bolt or parts prepared in the field.
Before going on installing adjust space between ceiling.
Note: All the above mentioned parts shall be
prepared in field.
Refer to paper pattern for dimension of ceiling hole.
Connect all pipings (refrigerant, water drainage), wirings (inter unit cable) to indoor unit, before installation.
Cut a hole in ceiling, may be a frame should be used to ensure a smooth surface and to prevent vibration.
Contact your real estate dealer
Installation of indoor unit
4
(2)
In the case of new ceiling
18
Level Polythene pipe
5
6
<Installation example>
Ceiling
Roof
Anchor bolt
Long nut
Suspending bolt
50~150
2
2
Installation Procedure
