Haier HI50IB User manual
InstallationandUserManual
Instructionsd’installationet
Guidedel’utilisateur
Instruccionesdeinstalacióny
Manualdelusuario
HI50IB
AutomaticUndercounterIceMachine
Machineàglaçonsautomatiquesousplan
detravail
MáquinadeHieloAutomaticParaDebajo
delaEncimera
49-60811 01-18 GEA
49-60811
2
3
49-60811
TABLEOFCONTENTS
ENGLISH
ICEMACHINESAFETY ......................................................4
PARTSANDFEATURES......................................................6
INSTALLATIONREQUIREMENTS.............................................7
LocationRequirements .....................................................7
InstallationClearances ......................................................8
WaterSupplyRequirements .................................................8
ConnectingElectricity ......................................................9
INSTALLATIONINSTRUCTIONS ............................................10
Unpacking.................................................................10
ReversingtheDoorSwing(Optional)........................................10
ConnecttheWater........................................................ 11
ConnecttheElectricalSupply ..............................................14
InstalltheIceMachine......................................................14
LevelingtheIceMachine ...................................................15
ICEMACHINEUSE.. .......... ... ............. ... .......... ... .............16
Operation .................................................................16
IceMakingCycles ..........................................................17
Controls. ..................................................................18
ICEMACHINECARE .......................................................20
Cleaning...................................................................20
VacationandMoving .......................................................24
Reinstalling/UsingIceMachineAgain .......................................24
TROUBLESHOOTING......................................................25
LIMITEDWARRANTY ......................................................27
RECORDKEEPING ........................................................28
49-60811
4
ENGLISH
ŶUsethisapplianceonlyforitsintendedpurposeasdescribedinthis
usermanual.
ŶThisappliancemustbeproperlyinstalledinaccordancewiththe
installationinstructionsbeforeitisused.Seegroundinginstructionsin
theinstallationsection.
ŶPlugintoagrounded3prongoutlet.
ŶDonotremovegroundprong.
ŶDonotuseanadapterorextensioncord.
ŶDonotrepairorreplaceanypartoftheapplianceunlessspecifically
recommendedinthemanual.Allotherservicingshouldbereferredtoa
qualifiedtechnician.
ŶDisconnectpowerbeforeservicing.
ŶReplaceallpartsandpanelsbeforeoperating.
ŶUsenonflammablecleaner.
ŶDonotstoreorusegasolineorotherflammablevaporsandliquidsin
thevicinityofthisoranyotherappliance.
ŶDonotstoreexplosivesubstancessuchasaerosolcanswitha
flammablepropellantinthisappliance.
ŶBeforediscardingorremovingfromservice,removethedoor.Thiswill
reducethepossibilityofdangertochildren.
ŶToavoidseriousinjuryordeath,childrenshouldnotstandon,orplayin
orwiththeappliance.
ŶChildrenandpersonswithreducedphysical,sensoryormental
capabilitiesorlackofexperienceandknowledgecanusethisappliance
onlyiftheyaresupervisedorhavebeengiveninstructionsonsafeuse
andunderstandthehazardsinvolved.
ŶThisapplianceisintendedtobeusedinhouseholdandsimilar
applicationssuchas:staffkitchenareasinshops,officesandother
workingenvironments;farmhouses;byclientsinhotels,motels,bed
&breakfastandotherresidentialenvironments;cateringandsimilar
non-retailapplications.
ICEMACHINESAFETY
CAUTION Toreducethe riskofinjury whenusingyour icemachine,
followthesebasic safetyprecautions.
ŶKeepfingersout ofthe“pinch point”areas;clearances betweenthe
doorandcabinet arenecessarilysmall. Becarefulclosing doorwhen
childrenarein thearea.
ŶDonottouchthecoldsurfacesintheicemachinewhenhandsaredampor
wet,skinmaysticktotheseextremelycoldsurfaces.
IMPORTANTSAFETYINSTRUCTIONS
WARNING Toreducetheriskoffire,explosion,electricalshock,
injuryto persons,ordamagewhenusingtheice
machine,followbasicprecautions,includingthefollowing:
5
49-60811
ENGLISH
STATEOFCALIFORNIAPROPOSITION65WARNINGS:
WARNING Thisproductcontains oneormore chemicalsknownto
theStateof Californiatocause cancerandbirth defectsorother
reproductiveharm.
ICEMACHINESAFETY
PROPER DISPOSAL OF YOUR OLD APPLIANCE
WARNING SUFFOCATION AND ENTRAPMENT HAZARD
Failuretofollow thesedisposalinstructions canresultin deathor
seriousinjury.
IMPORTANT: Childentrapmentand suffocationarenot problemsofthe
past.Junkedor abandonedappliancesare stilldangerouseven ifthey
willsitfor “justafew days.”Ifyou aregettingrid ofyourold appliance,
pleasefollowthe instructionsbelowto helppreventaccidents.
Before You Throw Away Your Old Appliance:
ŶTakeoffthe door.
ŶLeavetheshelves inplaceso thatchildrenmay noteasilyclimb inside.
Refrigerant and Foam Disposal:
Disposeofappliance inaccordancewith FederalandLocal Regulations.
Flammableinsulationmaterial usedrequiresspecial disposal
procedures.Contactyour localauthoritiesfor theenvironmentallysafe
disposalofyour appliance.
READANDSAVETHESEINSTRUCTIONS
49-60811
6
ENGLISH
PARTSANDFEATURES
A. Door
B. WaterDistributionTube
C. Evaporator(icemold)
D. WaterTrough
E. Float
F. IceBucket
G. ControlPanel
H. FrontLouverPanel
I. Feet(notshown)
J. WaterSupplyHose
K. PowerCord
L. WaterInlet
M. DrainOutlet
N. IceScoop
O. DrainHose
P. DrainHoseClamp
A
J
K
L
M
N
O
P
B
C
F
H
G
I
D
E
7
49-60811
ENGLISH
INSTALLATIONREQUIREMENTS
LOCATIONREQUIREMENTS
Toensureproperventilationforyouricemachine,thefrontoftheunitmust
becompletelyunobstructed.
Wheninstallingtheicemachineunderacounter,followtherecommended
spacingdimensionsshowninthe“InstallationClearances”section.Allow
atleast3-7/8”(9.8cm)clearanceatrear,and3/8”(1.0cm)attopand3/16”
(0.5cm)atsidesforproperaircirculation.
Theinstallationshouldallowtheicemachinetobepulledforwardfor
servicing,ifnecessary.
Chooseawellventilatedareawithnormaloperatingtemperaturesabove
50°F(10°C)andbelow100°F(38°C).Normaloperatingwatertemperature
shouldbebetween41°F(5°C)and90°F(32°C).Operationoftheicemachine
forextendedperiodsoutsideofthesenormaltemperaturerangesmay
affectproductioncapacity.
Theicemachineshouldnotbelocatednexttoovens,grillsorotherhigh
heatsources.
TheicemachineMUSTbeinstalledinanareaprotectedfromtheelements,
suchaswind,rain,watersprayordrips.
Theicemachineshouldbelocatedonafirmandlevelsurface.Itis
importantfortheicemachinetobeleveledinordertoworkproperly.If
needed,youcanadjusttheheightoftheicemachinebyturningthefeet.
Seethe“LevelingtheIcemachine”section.
• Donotinstall theicemachine wherethetemperature willgobelow
50°F(10°C)because itwillnot runoftenenough tomaintainproper
temperatures.
• Donotinstall theicemachine wherethetemperature willgoabove
100°F(38°C)because itwillnot performproperly.
• Installiton afloorstrong enoughtosupport itfullyloaded.
• Donotinstall theicemachine inalocation exposedtowater (rain,
etc.)ordirect sunlight.
WARNING
ExplosionandFireHazard
Keepflammablematerialsand vapors,suchasgasoline, awayfrom
appliance.
Failuretodosocanresultindeath,explosionorfire.
49-60811
8
INSTALLATIONREQUIREMENTS
ENGLISH
INSTALLATION CLEARANCES
TopView SideView
RearofUnit
FrontofUnit
TopofUnit
Front
Edge
Side Side
q (0.953cm)
A\5:
(0.48cm)
A\5:
(0.48cm)
#s¤)($æð¥
WATERSUPPLYREQUIREMENTS
Installationoftheicemachinerequiresacoldwatersupplyinletof¼”
¤&#%ðð¥öòé÷æòóóèõ÷øåìñêúì÷ëäöëø÷¡òģùäïùè
Theicemachinerequiresacontinuouswatersupplywithaminimum
pressureof15psig(103KPa)andastaticpressurenottoexceed80psig
(552kPa).Thetemperatureofthewaterfeedingintotheicemachineshould
bebetween41°F(5°C)and90°F(32°C)forproperoperation.
Ò÷ìöö÷õòñêïüõèæòððèñçèç÷ëä÷äúä÷èõĤï÷èõåèøöèçÊĤï÷èõìéì÷ìöòé÷ëè
propertype,canremovetasteandodorsaswellasparticles.Somewateris
veryhard,andsoftenedwatermayresultinwhite,mushycubesthatstick
together.Deionizedwaterisnotrecommended.
WARNING Connecttopotable watersupplyonly.
9
49-60811
INSTALLATIONREQUIREMENTS
ENGLISH
Do not, under any circumstances, cut or remove the third (ground)
prong from the power cord. For personal safety, this appliance must
be properly grounded.
Thepowercord ofthisappliance isequippedwith a3-prong(grounding)
plugwhichmates withastandard 3-prong(grounding)wall outletto
minimizethepossibility ofelectricshock hazardfromthis appliance.
Havethewall outletandcircuit checkedbya qualifiedelectricianto make
suretheoutlet isproperlygrounded.
Whereastandard 2-prongwalloutlet isencountered,it isyourpersonal
responsibilityandobligation tohaveit replacedwitha properlygrounded
3-prongwalloutlet.
Theicemachine shouldalwaysbe pluggedintoits ownindividual
electricaloutletwhich hasavoltage ratingthatmatches theratingplate.
A115Volt AC,60Hz, 15-or20-amp fused,groundedelectrical supply
isrequired.This providesthebest performanceandalso prevents
overloadinghousewiring circuitswhichcould causeafire hazardfrom
overheatedwires.
Neverunplugyour icemachineby pullingonthe powercord.Always grip
plugfirmlyand pullstraightout fromtheoutlet.
Immediatelydiscontinueuse ofadamaged supplycord.If thesupply
cordisdamaged, itmustbe replacedbya qualifiedserviceprofessional
withanauthorized servicepartfrom themanufacturer.
Whenmovingthe icemachineaway fromthewall, be carefulnotto roll
overordamage thepowercord.
Theicemachine mustbeinstalled withelectricaland waterconnections
inaccordancewith allstateand localcodes.
Awalloutlet directlybehindthe icemachinewill makeinstallationeasier.
CONNECTING ELECTRICITY
WARNING ELECTRICAL SHOCK HAZARD
Plugintoa grounded3-prongoutlet.
Donotremove thegroundprong.
Donotuse anadapter.
Donotuse anextensioncord.
Failuretofollow theseinstructionscan resultindeath, fire,orelectrical
shock.
49-60811
10
INSTALLATIONINSTRUCTIONS
ENGLISH
REVERSING THE DOOR SWING (Optional)
UNPACKING
1. Removepackagingmaterials.
IMPORTANT:Donotremoveanypermanentinstructionlabelsorthedata
labelonyouricemachine.
2. Removetapeandgluefromyouricemachinebeforeusing.
•Toremoveanyremainingtapeorglue,rubtheareabrisklywithyour
thumb.Tapeorglueresiduecanalsobeeasilyremovedbyrubbinga
smallamountofliquiddishsoapovertheadhesivewithyourfingers.
Wipewithwarmwateranddry.
•Donotusesharpinstruments,rubbingalcohol,flammablefluids,or
abrasivecleanerstoremovetapeorglue.Theseproductscandamage
thesurfaceofyouricemachine.
3. Afteryouremoveallofthepackagingmaterials,cleantheinsideofyour
icemachinebeforeusingit.See“Cleaning.”
4. Properlydisposeof/recycleallpackingmaterial.
ToolsNeeded:
•FlatheadScrewdriver •PhillipsScrewdriver
Toremovethedoor:
1.Unplugtheicemachineordisconnectpower.
2.Usingaflatheadscrewdriver,removethehingepinfromHinge1,andset
itaside.
3.Openthedoorabout20°,andthenliftthedooroffHinge2,andsetthe
dooraside.
WARNING ExcessiveWeightHazard
Usetwoormorepeopletomoveandinstallicemachine.
Failuretodosocanresultindeathorpersonalinjury.
HingePin
Door
Cabinet
Hinge1 Hinge2
WARNING Followallsteps whenreversingthe doorswing.Failure
tofollowthese instructions,leavingoff parts,orovertightening screws,
canleadto thedoorfalling offandresult ininjuryand propertydamage.
11
49-60811
Toreversethedoor:
1.Usingaflatheadscrewdriver,removethecoversfromthescrewholeson
thesideoppositethedoorhinges,topandbottom.Setaside.
2.ReplacethehingepinonHinge1andtightenitfirmly.
3.RemovethescrewsfasteningHinge1tothe
cabinetandreinstallitontheoppositesideof
thecabinetatthebottom.
4.RemovethescrewsfasteningHinge2tothe
cabinetandreinstallitontheoppositesideof
thecabinetatthetop.
5.Usingaflatheadscrewdriver,removethehinge
pinfromHinge2,andsetitaside.
6.Rotatethedoorsothatthehandleisopposite
thehingesideandsetthedoorontothe
bottomhingepin.
7.Completelytightenthebottomhinge.
8.Inserttheholecoversintotheholeswherethe
screwwereoriginallylocated.
ENGLISH
INSTALLATIONINSTRUCTIONS
REVERSING THE DOOR SWING (Optional) (Cont.)
Hinge2
Hinge1
CONNECTTHEWATER
Thewatersupplyshouldbereadyatthepointofinstallation.Thewater
supplypressureshouldbeaminimumof15psig(103KPa)withastatic
pressurenotmorethan80psig(552KPa).(Awalloutletdirectlybehindthe
icemachinew3illmakeinstallationeasier.)
IMPORTANT:
•Allinstallationsmustbeinaccordancewithlocalplumbingcode
requirements.Professionalinstallationisrecommended.
•Makecertainthehosesarenotpinchedorkinkedordamagedduring
installation.
•Checkforleaksafterconnection.
WARNING Followallsteps whenreversingthe doorswing.Failure
tofollowthese instructions,leavingoff parts,orovertightening screws,
canleadto thedoorfalling offandresult ininjuryand propertydamage.
WARNING Connecttopotable watersupplyonly.
49-60811
12
INSTALLATIONINSTRUCTIONS
ENGLISH
ToolsNeeded:
•½”Open-endWrench
•PhillipsScrewdriver
•AdjustablePliers
CONNECTTHEWATERLINE
1.Turnoffthemainwatersupply.Turnonthenearestfaucetlongenoughto
clearlineofwater.
2.Finda½”to¾”verticalcoldwaterpipeneartheinstallationlocation.The
watersupplyhoseisprovidedwiththeicemachine.
3.Ashut-offvalvemustbeinstalledtothemainwatersupply.Ifthewater
pipehasaplainpieceofcoppertubing,attacha¼”outsidediameter
(O.D.)compressionuniontothetubingandremovethenut.
4.Connectthenutfromthewatersupplyhosetothetap,andconnectthe
otherendtothewaterinlet.Tightenfirmlybyhand,andthenusinga
wrenchtightenanadditionalhalfturn.
5.Turnonmainwatersupplyandtap.
6.Checkforwatersupplyconnectionleaks.Tighteneveryconnection
(includingconnectionatthewaterinlet).
IMPORTANT: Whenyouconnectthewatersupplyhoseandthedrainhose,
notethe“Waterinlet”and“Drainoutlet”markedontheicemachine.
CONNECTTHEDRAIN
Youmustconnectthedrainlinebeforeusingtheicemachine.
NOTE:Ifthereisadrainlineneartheicemachine,thebestchoiceistodrain
watertothedrainlinethroughthedrainwaterhoseprovidedwiththeice
machine.
1. Locatethefloordrainneartheicemachine.Thedistanceshouldbeless
than5feetsincethelengthofthelongdrainwaterhoseprovidedwith
theicemachineisabout5feet.
2. Findthedrainoutletonthebackoficemachine.Connectthedrainhose
totheicemachinedrainoutlet,tightendrainhoseclamp,andinsertthe
otherendofthehoseintothedrainline.
CONNECT THE WATER (Cont.)
13
49-60811
ENGLISH
INSTALLATIONINSTRUCTIONS
CONNECTTHEWATER(Cont.)
NOTE:Donotallowthedrainhosetohangorloophigherthanthefloor
oftheicestoragebin.
•Allhorizontalrunsofdrainlinesmusthaveafallof¼”perfoot.An
airgapwilllikelyberequiredbetweentheicemachinedrainhoseand
thedrain/wastereceptacle.Astandpipewithatrapbelowitwouldbe
acceptableforthedrain/wastereceptacle.
•Ifafloororothergravitydrainbelowtheleveloftheicemachinedrain
outletisnotavailable,theuseofanaftermarketsealedicemachine
drainpumpkitwillberequired.
NOTES:
•Connectdrainpumptoyourplumbingdraininaccordancewithall
stateandlocalcodesandordinances.
•Drainpumpmustbeasealeddesigntopreventwateroverflow
duringpoweroutages.
•Minimumratedpumpingrateofdrainpumpshouldbe0.5gal./
minute(1.9L/minute).
•Followallinstallationinstructions,providedwiththedrainpumpkit.
•Drainpumpshouldbelocatedonasurfacethatisatthesamelevel
asthesurfaceunderneaththeicemachine.Thetopofthedrain
pumpreservoirmustbenohigherthantheflooroftheicemachine
storagebin.
•Donotallowthehosefromtheicemachinetothedrainpumpto
hangorloophigherthantheflooroftheicestoragebin.
•Theendofthedrainpumpventhoseshouldbewithin8”(20cm)of
thetopoftheicemachine.
•Plumbingdrainshouldbenomorethan10ft(3m)abovetheoutlet
ofthedrainpump.
•Donotconnecttheoutlethoseofthedrainpumptoaclosedpipe
systemtokeepdrainwaterfrombackingupintotheicemachine.
3.Pour1gallonofwaterintotheicestoragebintocheckforleaksinthe
drainagesystem.Tightenanyconnectionsthatleak.
49-60811
14
INSTALLATIONINSTRUCTIONS
ENGLISH
INSTALLTHEICEMACHINE
Thisicemachinecanbeinstalled,asFree-Standing,orbeEnclosed(as
underthecountertop),orBuilt-in(sealedtothefloor).Inanycase,there
mustbeadequateairspacearoundtheunitforventilation.See“Installation
Clearances”inthe“LocationRequirements”section.
FREE-STANDINGINSTALLATION
Thisicemachinemaybeinstalledinanylocationprovidedthereisaccess
toanelectricalsupply,watersupplyanddrain.Youmustfollowthestated
instructionsforElectricalRequirements,Watersupplyandproperdrainage,
andLevelingtheicemachine.
ENCLOSEDINSTALLATION
Anenclosedinstallationwillallowyoutoinstalltheicemachineundera
countertoporinakitchencabinetprovidedtherequiredclearancespace
aroundtheicemachineisrespected.See“LocationRequirements.”This
installationhasthesamerequirementsasafree-standinginstallation.
ŶPlugintoagrounded3prongoutlet.
CONNECTTHEELECTRICALSUPPLY
WARNING
ElectricalShockHazard
Plugintoagrounded3prongoutlet.
Donotremovethegroundprongfromthepower cordplug.
Donotuseanadapter.
Donotuseanextensioncord.
Failuretodosocanresultindeath,fireor electrical shock.
15
49-60811
ENGLISH
INSTALLATIONINSTRUCTIONS
INSTALLTHEICEMACHINE(Cont.)
BUILT-ININSTALLATION
Ifthismethodofinstallationischosen,itwillstillbenecessarytoallow
adequateventilationspacearoundtheicemachine.
1.Placeicemachineinfrontofinstallationlocation.Placetheicemachine
flatonthefloororonaplatformdependingonyourinstallation
requirements.
2.Thewatersupplylinemustbeplumbedbeforeconnectingtotheice
machine.
3.Turnonmainwatersupplyandtap.
4.Checkforwatersupplyconnectionleaks.Tighteneveryconnection
(includingconnectionatthewaterinlet).
5.Suitabledrainlinemustbeconnectedforthisinstallation.
6.Iftheelectricaloutletfortheicemachineiswithinthecabinetopening,
plugintheicemachine.
7.Pushtheicemachineintoposition.
IMPORTANT: Besuretocheckthatwatersupplyanddrainhosescannot
getpinchedorkinkedordamagedbeforeicemachinemovesintoitsfinal
position.
LEVELINGTHEICEMACHINE
Therollingcastersonthebottomoftheicemachineallowittobemoved
easilytocleanandsanitizethefloorunderneath.
Theicemachinemustbeleveltoworkproperly.Iftheicemachineisnot
levelthewaterwillnotflowproperlythroughtheevaporator(icemold).The
iceproductionwillbelessthannormal,andmaybenoisy.
Theicemachinecanberaisedorloweredbyrotatingtheplasticfeetaround
eachofthefourrollingcastersonthebottomoftheicemachine.
Ifyoufindthatthesurfaceisnotlevel,rotatethefeetuntiltheicemachine
becomeslevel.Youmayneedtomakeseveraladjustmentstolevelit.
Placeacarpenter’slevelontopoftheicemachinetoseeiftheicemachine
islevelfromfronttobackandsidetoside.
Adjusttheheightofthecastersasfollows:
ToLower-Turnthelevelingfeettotheright.
ToRaise-Turnthelevelingfeettotheleft.
IMPORTANT: Whentheicemachineisreadytobeinstalledinacabinetor
directlyonthefloor,youmustlockthecastersafterleveling.Iftheflooris
level,justturnthetwofrontfeettotouchthefloor.
49-60811
16
OPERATION
1.Theoperatingprocedureiscompletelyautomatic.
2.Whentheicestoragebinisfulloficecubes,themachinestopsmakingice
automatically.Itstartsmakingiceagainaftericecubesareremoved.
3.ThedifferentcolorsoftheLEDdisplayindicatevariousworkmodes.
4.Asensitiveprobeandaccuratetimerenhancetheperformanceoftheice
machine.
5.Acompressorprotectionsystemisbuiltin.
HOWTHEICEMACHINEUSESTHEWATER
Theicemachinebeginswithafixedchargeofwaterthatiscontainedinthe
watertrough.Asthewaterflowstothefreezingevaporatorsurface,the
portionofwaterthatdoesnotcontainmineralimpuritiesfreezesandsticks
totheicecubemolds.Thewatercontainingimpuritiesfallsbackintothe
watertrough.Duringtheicemakingprocess,freshwaterentersintothe
watertroughcontinuouslyasthewaterinthetroughfreezescontinuously
intheevaporator.
ENGLISH
ICEMACHINEUSE
A. WaterInlet
B. WaterDistribution
Tube
C. Evaporator
D. WaterPump
E. Compressor
F. Condenser
G. FanMotor
H. HotGasValve
A
BC
D
E
F
H
G
17
49-60811
ENGLISH
ICEMACHINEUSE
OPERATION(Cont.)
1.Turnonthewatertap,letthewatertroughfill.
2.PresstheON/OFFbuttononthecontrolpanel.Theicemachinewillstart
workingautomatically.
3.After3minutes,themachinewillautomaticallygototheice-making
stage,andthesoundofwaterflowingwillbeheard.
4.Whenthebatchoficehasbeenfullyformed,icewillautomaticallybe
harvestedtotheicestoragebin.
5.Whentheicestoragebinisfull,thesheetofcubeswillnotfallcompletely
andwillholdthebin-fullprobeopen.Themachinestopsmakingice
automatically.
6.Theunitwillstartmakingiceagainaftertheicecubesareremoved.Then
thebin-fullprobeswingsbacktooperatingposition.
IMPORTANT:
•Althoughtheicemachinehasbeentestedandcleanedatthefactory,
duetolongtermtransitandstorage,discardthefirstfewbatchesofice
produced.
•Donotturnthewatersupplytapoffwhentheicemachineisworking.
•Donottouchevaporatorwhenunitisrunning!
•Excepttotakeicefromtheunit,keepthedoorclosedtoreducemelting
andinsurepropericeformation.
ICEMAKINGCYCLES
Therearetwodistinctcycles:IceFreezeandHarvest.Thefreezecycle
happenswhenwaterflowstotheevaporatorsurface.Theharvestcycleis
whentheiceisreleasedandwaterentersthemachine.Acompletecycle
takesabout20minutes,butitdependsontemperatureandoperating
conditions.
IceFreezeCycle
Duringthefreezecyclethecompressorispumpingrefrigerant,thefan
motorisblowingair,andthewaterpumpiscirculatingwater.Whenthe
batchoficehasbeenfullyformed,theicemachinestopsthefreezecycle
andtheharvestcyclebegins.
HarvestCycle
Duringtheharvestcyclethecompressorisstilloperating,butthewater
pumphasstopped.Thehotgasvalveopens,divertinghotrefrigerantgas
intotheevaporator.Thehotrefrigerantgaswarmstheevaporator,causing
thecubestoslideasaunitofftheevaporatorandintothestoragebin.The
freezecyclewillrestartwhenallthecubeshavebeenharvested.
49-60811
18
CONTROLS
BinFull(Red)LEDindicatorlight
WhenBinFullislit,theicestoragebinisfulloficeorsomethingisblocking
thebin-fullprobe.Theicemachinewillstopworking.Whenicecubesare
removedfromtheicestoragebin,freeingthebin-fullprobe,theredLEDwill
flashfor3minutes,andthentheicemachinewillrestartandreturntothe
icemakingmode.
IceMaking(Green)LEDindicatorlight
WhenIceMakingislit,theunitisworkingintheicemakingmodecontrolled
byatemperatureprobeontheevaporator.WhenthegreenLEDflashes,the
unitisworkingintheicemakingmodecontrolledbyafixedtimer.
IceHarvest(Yellow)LEDindicatorlight
Whenthisislit,theunitisworkingintheiceharvestmodecontrolledbythe
ice-fullprobe.
Modebutton: MainlyforService
TheMODEbuttonisusedtochangebetweentheIceMakingModeandIce
HarvestMode.Theoperatingmodecanbedeterminedfromthestatusof
thegreen(IceMaking),andyellow(IceHarvest)LEDs.
PressandreleasetheMODE buttontoforcetheicemachinetoswitchfrom
thecurrentstate.
Adjustbutton
Whenthisispressedandheldforlongerthan3seconds,theunitwillenter
theIceSizeAdjustmentmode.Themodecanbejudgedfromthestatusof
theyellowLEDs.
Toadjusttheicesize:
TheADJUSTbuttonisusedtoentertheIceSizeAdjustmentmode.The
HARVESTLEDmustbelitsolidbeforeattemptingtoadjusticesize.Press
andholdtheADJUSTbuttonuntiltheyellowHARVESTLEDbeginsblinking.
Thisusuallyoccursafter3seconds.OncetheyellowLEDstartstoblink,
releasethebutton.TheyellowLEDblinkscontinuouslywhileintheIceSize
Adjustmentmode.
ICEMACHINEUSE
ENGLISH
ICE
ON/OFF CLEAN ADJUST MODE
BIN FULLHARVEST
19
49-60811
ICEMACHINEUSE
ENGLISH
CONTROLS(Cont.)
Todecreasethecubesize,presstheCLEANbutton.TheICEgreenLED
lampwillblinkmomentarilyeachtimetheCLEANbuttonispressed.The
greenLEDwillremainilluminatedwhenthesmallestsizecubeisachieved.
Toincreasethecubesize,presstheMODEbutton.TheBINFULLredLED
lampwillblinkmomentarilyeachtimetheMODEbuttonispressed.Thered
LEDwillremainilluminatedwhenthelargestsizecubeisachieved.
NOTES:
•Whenadjustingtheicecubesize,iftheICE,HARVESTandBINFULLLEDs
allstartblinkingatthesametime,thisindicatesthattheicecubesizeis
settomedium.Mediumistheoriginalfactorysetting.
•IceSizeAdjustmentmodecannotbeenterediftheicemachineisinthe
CleanorBinFullmode.
•After10secondswithoutanyoperation,theicemachinewillreturntothe
previousmode.
49-60811
20
ENGLISH
ICEMACHINECARE
CLEANING
IMPORTANT: Iftheicemachineisleftunusedforalongtime,beforethe
nextuseitmustbethoroughlycleaned.Followcarefullyanyinstructions
providedforcleaningoruseofsanitizingsolutions.Donotleaveany
solutioninsidetheicemachineaftercleaning.
•Periodiccleaningandpropermaintenancewillensureefficiency,top
performance,andlonglife.Themaintenanceintervalslistedarebasedon
normalconditions.Youmaywanttoshortentheintervalsifyouhavepets,
orthereareotherspecialconsiderations.
•Donotplaceorstoreanyitemsotherthaniceintheicestoragebin.Wine
andbeerbottlesarenotonlyunsanitary,butthelabelsmayslipoffand
plugupthedrain.
EXTERIORCLEANING
Paintedmetal:Washpaintedmetalexteriorswithaclean,softclothor
spongeandamilddetergentinwarmwater.Rinsesurfaceswithclean,
warmwateranddryimmediatelytoavoidwaterspots.Donotuseabrasive
cleanersonenamelsurfacesastheymayscratchthefinish.
Stainlesssteel:Stainlesssteeliscorrosionresistantandnotcorrosion-
proof.Tohelpavoidcorrosionofyourstainlesssteel,washstainlesssteel
surfaceswithaclean,softclothorspongeandamilddetergentinwarm
water.Rinsesurfaceswithclean,warmwateranddryimmediatelytoavoid
waterspots.Donotuseabrasiveorharshcleaners.Donotusechlorine
bleachonstainlesssteelsurfaces.
NOTE:Whencleaningstainlesssteel,alwayswipeinthedirectionofthe
graintoavoidcross-grainscratching.
WARNING
ElectricalShockHazard
Unplugyourapplianceordisconnectpowerbeforecleaning.
Failuretodosocanresultindeath,electricshockorpersonalinjury.
Table of contents
Languages:
Other Haier Ice Maker manuals
