Haier HOR54S5CW1 User manual

Cod:0040304154
HOR54S5CW1
User Manual
Free Standing Cooker

DEAR CUSTOMER
The cooker is exceptionally easy to use and extremely efficient. After reading the
instruction manual, operating the cooker will be easy.
Before being packaged and leaving the manufacturer, the cooker was thoroughly checked
with regard to safety and functionality.
Before using the appliance, please read the instruction manual carefully.
By following these instructions carefully you will be able to avoid any problems in using the
appliance.
It is important to keep the instruction manual and store it in a safe place so that it can be
consulted at any time.
It is necessary to follow the instructions in the manual carefully in order to avoid possible
accidents.
Caution!
Do not use the cooker until you have read this instruction manual.
The cooker is intended for household use only.
The manufacturer reserves the right to introduce changes which do not affect the operation
of the appliance.
1
TABLE OF CONTENTS
Safety instructions ......................................................................................................
3
How to save energy .........................................................................................................4
Unpacking.......................................................................................................................... 5
Disposal of the appliance.......................................................................................5
Description of the applianc e...........................................................................................6
Installation ...................................................................................................................... 7
Operation ...................................................................................................................
......9
Before first use............................................................................................................... .... 9
How to use the heating plate .......................................... ..... ..........................................9
Oven functions and operation ..........................................................................................10
Cleaning and maintenance.............................................................................................12
Operation in case of emergency.....................................................................................14
Baking in the oven............................................................................................................15
Technical information.......................................................................................................21
2
Electrical connection ..............
..........................................................................22
..............
...

SAFETY INSTRUCTIONS
3
l The appliance becomes hot during operation. Take care not to touch the hot parts
inside the oven.
l Always keep children away from the cooker. While in operation direct contact with
l Ensure that small items of household equipment, including connection leads, do not
touch the hot oven or the hob as the insulation material of this equipment is usually
not resistant to high temperatures.
l Do not leave the cooker unattended when frying. Oils and fats may catch fire due to
overheating.
l Do not allow the cooktop to get soiled and prevent liquids from boiling over onto the
surface of the cooktop, Any spillages should be cleaned up as they happen.
l Do not place pans with a wet bottom on the warmed up heating zones as this can
cause irreversible changes to the cooktop(irremovable stains).
l Do not switch on the cooktop until a pan has been placed on it.
l Do not put pans weighing over 15kg on the opened door of the oven and pans over
25kg on the cooktop.
l Do not use harsh cleaning agents or sharp metal objects to clean the doors as they
can scratch the surface, which could then result in the glass cracking.
l Do not use the cooker in the event of a technical fault. Any faults must be fixed by an
appropriately qualified and authorized person.
l In the event of any incident caused by a technical fault, disconnect the power and
report the fault to the service centre to be repaired.
l The rules and provisions contained in this instruction manual should be strictly
observed. Do not allow anybody who is not familiar with the contents of this instruction
manual to operate the cooker.
l The cooker should not be cleaned using steam equipment.
WARNING:Accessible parts may become hot during use.Young children should be
kept away.
WARNING:Accessible parts will become hot when the grill is in use .Children shoule be
kept away.
The appliance is not intended to be operated by means of an external timer or separate
remote-control system.
This appliance is not intended for use by persons (including children) with reduced
Children should be supervised to ensure that they do not play with the appliance.
physical, sensory or mental capabilities, or lack of experience and knowledge,unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
If the supply cord is damaged, it must be replaced by the manufacturer or its service
agent or a similarly qualified person in order to avoid a hazard.
WARNING:In order to prevent accidental tipping of the appliance ,for example by a
child climbing onto the open door,the stabilizing means must be installed.
The oven must be switch off before removing the guard and that,after cleaning,the
guard must be replaced in accordance with the instrctions.
Ensure that the appliance is switch off before replacing the lamp to avoid the possibility
of electric shock.
the cooker may cause burns!
HOW TO SAVE ENERGY
Using energy in a
responsible way not only
saves money but also helps
the environment. So let’s
save energy ! And this is how
you can do it:
● Use proper pans for cooking.
Pans with thick, flat b ases can save up to
1/3 on electric energy. Remember to cover
pans if possible otherwise you will use four
times as much energy!.
● Match the size of the saucepan to the
surface of the heating plates.
A saucepan should never be smaller than
a heating plate.
● Ensure heating plates and pan bases
are clean.
Soils can prevent heat transfer-and
repeatedly burnt-onspillages can often only
be removed by products which cause
damage to the environment.
● Do not uncover the pan too often(a
watched pot never boils!).
Do not open the oven door unnecessarily
often.
● Switch off the oven in good time and
make use of residual heat.
For long cooking times,switch off heating
zones 5 to 10 minutes before finishing
cooking.This saves up to 20% on energy.
● Only use the oven when cooking larger
dishes.
Meat of up to 1 kg can be prepared more
economically in a pan on the cooker burner.
●Make use of residual heat from the
oven.
If the cooking time is greater than 40minutes
it is recommended to switch off the oven
10 minutes before the end time.
Caution!
When using the timer set appropriately
shorter cooking times according to the dish
being prepared.
● Only grill with the ultrafan after closing
the oven door.
● Make sure the oven door is properly
closed.
Heat can leak through spillages on the door
seals.Clean up any spillages immediately.
● Do not install the cooker in the direct
vicinity of refrigerators/freezers.
Otherwise energy consumption increases
unnecessarily.
If the appliance used in New Zealand,this
cooking range must be connected to the
supply by a supply cord fitted with an
appropriately rated plug that is compatible
with the socket-outlet fitted to the final
sub-circuit in the fixed wiring that is
intended to supply this cooking range.
4

UNPACKING
After unpacking, please dispose of all
elements of packaging in a way that will
not cause damage to the environment.
All materials used for packaging the
appliance are environmentally friendly;
they are 100% recyclable and are marked
with the appropriate symbol.
DISPOSAL OF THE APPLIANCE
During unpacking, the packaging materials
(polythene bags, polystyrene pieces, etc.)
should be kept out of reach of children.
Caution!
During transportation,
protective packaging was
used to protect the appliance
against any damage.
Old appliances should not
simply be disposed of with
normal household waste, but
should be delivered to a
collection and recycling centre for
electric and electronic equipment.
A symbol shown on t he product,t he
instruction manual or the packaging shows
if it is suitable for recycling.
Materials used inside the appliance are
recyclable and are labelled with information
concerning this. By recycling materials or
other parts from used devices you are
making a significant contribution to the
protection of our environment.
Information on appropriate disposal centers
for used devices can be provided by your
local authority.
5
DESCRIPTION OF THE APPLIANCE
1
3,45,6
7
8
9
10
11
6
3,4,5,6 Hotplate control knobs
1 Temperature control knob
2 Oven function selection knob
7 Cooker operation light orangesignal
10 Drawer
8 Oven temperature signal light orange
9 Oven door handle
11 Hotplate
2

INSTALLATION
7
Installing the cooker
l The kitchen should be dry and airy
and have effective ventilation according
to the existing technical provisions.
l The room should be equipped with a
ventilation system that pipes away
exhaust fumes created during
combustion.This system should consist
of a ventilation grid or hood.
Hoods should be installed according
to the manufacturer’s instructions.
The cooker should be placed so as to
ensure free access to control
elements.
l Coating or veneer used on fitted
furniture must be applied with a heat
resistant adhesive (100℃).This prevents
surface deformation or detachment of
the coating. If you are unsure of your
furniture’s heat resistance,you should
leave approximately 2 cm of free
apace around the cooker. The wall
behind the cooker should be resistant
to high temperatures.During operation,
its back side can warm up to around
50℃ above the ambient temperature.
650mm(min)
2cm2cm 2cm2cm2cm2cm
l The cooker should stand on a hard,
even floor (do not put it on a base.)
Before you start using the cooker it
should be leveled,which is particularly
important for fat distribution in a frying
pan. To this purpose,adjustable feet
are accessible after removal of the
drawer. The adjustment range is +/-5mm.
●
Take the cover and cooker out of the
packaging.
Select a proper place,and steadily level
the cooker.
●
8
INSTALLATION
To fit the rear panel/splashback, slide the lugs on the bottom of the
panel into the matching slots on rear of stove and fix with screws
provided.
Fix the cooker to the back wall
with 2 chains
