Please read this manual carefully
before using this TV set and keep it
for future reference.
HLH15BB/15HL25S/HLE20BB/20AL25S
LCD TV
USER MANUAL
THIS SYMBOL INDICATES THAT HIGH VOLTAGE IS PRESENT
INSIDE. IT IS DANGEROUS TO MAKE ANY KIND OF CONTACT
WITH ANY INSIDE PART OF THIS PRODUCT.
WARNING : To reduce the risk of electric shock do not remove cover or back.
No user-serviceable parts inside refer service to qualified service personnel.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rule. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, use and
can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However ,there is no
guarantee that interference with not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encourage to try to correct the interference by one or
more of the following measures:
*Reorient or relocate the receiving antenna.
*Increase the separation between the equipment and receiver.
*Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
*Consult the dealer or an experienced radio/TV technician for help.
This device compiles with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may be not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
FCC CAUTION:
To assure continued compliance and possible undesirable interference, the provided ferrite
cores must be used when connecting this plasma display to video equipment; and maintain
at least 40cm spacing to other peripheral device.
CANADIAN NOTICE:
This Class B digital apparatus compiles with Canadian ICES-003.
RISK ELECTRIC SHOOK
DO NOT OPEN
WARNING
Safety of operators has been taken into consideration at the design and manufacture
phase, but inappropriate operation may cause electric shock or fire. To prevent the product
from being damaged, the following rules should be observed for the installation, use and
maintenance of the product. Read the following safety instruction before starting the operation.
The User Manual uses the following symbols to ensure a safe operation and prevent
any damage to operators or properties:
THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT
OPERATING AND MAINTENANCE INSTRUCTIONS IN THE
LITERATURE ACCOMPANYING THE APPLIANCE.
FCC STATEMENT
Warning
IMPORTANT SAFETY INSTRUCTIONS
Read all of the instructions before using this appliance. When using this
appliance, always exercise basic safety precautions, including the following:
1)Save these Instructions ---the safety and operating instructions should be
retained for future reference.
2)All warning on the appliance and in the operating instructions should be followed.
3)Cleaning --- Unplug from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use only dry cloth for cleaning.
4)Attachments ---do not use attachments not recommended by the manufacturer
as they may cause hazards.
5)Water and moisture -- do not place this product near water, for example, near a
bathtub, wash bowl, kitchen sink, laundry tub, in a wet basement, or near a
swimming pool.
6)Accessories ---do not place this unit on an unstable cart, stand, tripod, bracket,
or table. Use only with a cart, stand, tripod, bracket, or table recommend by the
manufacture, or sold with the unit.
7)Ventilation ---Slots and openings in the cabinets and the back or bottom are
provided for ventilation. These openings must not be blocked. In a built in
installation such a bookcase or rack do not install product unless proper ventilation
is provided.
8)Power Source ---this LCD TV should be operated only from the type of
power source indicated on the rating label. If you are not sure of the type of power
supply to your home, consult your appliance dealer or local power company.
9)Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet. To prevent electric shock, ensure
the grounding pin on the AC cord power plug is securely connected.
10)Power cord protection ---Power supply cords should be routed so that they are
not likely to be walked on or pinched by items placed upon or against them. Pay
particular attention to cords or plugs, convenience receptacle, and the point where
they exit from the appliance.
11)Lighting precaution ---for added protection for this product during a lighting
storm or when it is left unattended for long period of time, unplug it from the wall
outlet and disconnect the antenna or cable system. This will prevent damage to the
product due to lighting and power line surges.
12)Never push objects of any kind into this product through openings as they may
touch dangerous voltage point or short out parts that could result in a fire or electric
shock. Avoid spilling liquid of any kind on the product.
13)Servicing ---do not attempt to service the product by yourself, as opening or
removing covers may expose you to dangerous voltage or other hazards. Refer all
servicing to authorized service personnel.
14)Unplug this unit from the wall outlet and refer servicing to qualified service
personnel under the following conditions:
a. When the power supply cord or plug is damaged or frayed.
Safety Instructions
b.If liquidhas been spilled,or objects havebeen fallen into the unit.
c.If theunit has been exposed to rainor water.
d.If theunit does not operate normally byfollowing the operating instructions.
Adjust onlythose controls that are covered bythe operating instructions, as
improper adjustment ofother controls may result in damageand will often
require extensive workby a qualified technician to restorethe unit to its normal
operation.
e.If theunit has been dropped or damagedin any way.
f.When theunit exhibits a distinct change inperformance; this indicates a need
for service.
15)Heat ---The product should be situatedaway heat source such as radiators,heat
registers, stoves, orother products (Including amplifiers) that product heat.
16)Overloading ---Do notoverload wall outlets and extension cord as this canresult
in a riskof fire or electric shock.
SAVE THESE INSTRUCTIONS
Thank you for using our Haier product. This easy-to-use manualwill guide you in
getting the bestuse of your product. Remember torecord the modeland serial
number. They are on label in backof the unit.
Model number
serial number
Date of purchase
Staple your receiptto your manual. You will need itto obtain warranty service.
Safety Instructions
To users:
Thank you for our LCD-TV.purchasing
CONTENT
Front Panel Controls..................................................................................
Connection Options...................................................................................
Remote Control Key Functions...................................................................
Remote Control ..................................................................................
Installing Batteries..................................................................................
Connection Instructions.............................................................................
Grounding..............................................................................................
External equipment Connections..............................................................
Antenna Connection.............................................................................
PC Setup.............................................................................................
VCR Setup...........................................................................................
Cable TV Setup....................................................................................
External AV Source Setup......................................................................
Basic Operating Instructions.......................................................................
Turn on the LCD-TV.................................................................................
Audio Control..........................................................................................
Mute......................................................................................................
Select the TV Channel You Want...............................................................
Picture Mode...........................................................................................
Program Scan.........................................................................................
Sleep......................................................................................................
Menu Operations.......................................................................................
Picture Menu Options...............................................................................
Picture Menu Options Continued...............................................................
Sound Menu Options................................................................................
Sound Menu Options Continued................................................................
Function Menu Options.............................................................................
Function Menu Options Continued.............................................................
Adjust Menu Options................................................................................
Tuning Menu Options..............................................................................
Tuning Menu Options Continued..............................................................
Parental Menu Options.............................................................................
Parental Menu Options Continued.............................................................
Troubleshooting Guide...............................................................................
Specifications...........................................................................................
Warranty ..................................................................................................
2
3
4
5
5
6
6
6
6
7
8
9
9
10
10
10
10
11
11
11
11
12
12
13
13
14
15
16
16
17
18
18
19-21
22
23
24
Before connecting the LCD-TV and turning on the power, please
read this book carefully. Please keep this book for later use.
If the unit is disabled by an electrostatic discharge, please turn
the power to the unit and turn it back on to reset.
off
Front Panel Controls
Control Panel Function
1.TV/AV PC/COMPONENT/AV/SV/TV
2. MENU Press to select the main menu
3. VOL-(V-) Volume down/ Left orientation to adjustthe item in the OSD
VOL+ (V+) Volume up / Right orientation to adjust the item/Press to enter
4. CH- TV channel down / to select the item in the menu
CH+ TV channel up / to select the item in the menu
5. Power supplyswitch
6. Power indicator
Illuminates red in standby mode, illuminates green when the display is
turned on
7.Remote Sensor
Selects the input signals:
Receives the signals from the remote control
TV/AV MENU VOL- VOL+ CH- CH+ POWER
12345
67
23145
2314
67
567
HLH15BB
HLE20BB
15HL25S/20AL25S
AV /S-VIDEO/COMPONENT Audio Input
Connect audio
output from an external
device to thesejacks
D-SUB Input
Connect to theVGA
15PIN analog output
connector of thePC
display card forPC
display purpose
S-Video Input
Connect S-Video out
from an S-Video device
to the jacks.
Antenna Input
Connect cable or
antenna signals to
the TV, either direc-
tly or through your
cable box.
Connection Options
Earphone port
PC Audio Input
Connect the PC output
connector from aPC to
the audio inputport
(The figure is just for reference, please see actual unit. )
DVD/DTV Input
Connect a component
device to thesejacks
ANT IN
S-VIDEO
D-SUB IN PC AUDIO IN AUDIO IN
R
L
VIDEO
V
Pb PrY
COMPONENT IN
Video Input
Connect video
output from an external
device to thisjack
DC IN
DC Power Cord Socket
This TV operates on DC
power. The voltage is
indicated on the specifications
page. Never attemptto
operate the TV on ac power
Remote Control Key Functions
When using theremote control, aimit towards the remote sensor onthe TV
2. Power supply switch
9. MENU
To display/exit the main menu
11. CH+/CH-
TV channel up/down or select the item of the menu
12. VOL+
Volume up/ to selectthe main menu/ to adjust theitem/ to
enter the submenu.
VOL- Volume down/ to select the main menu/ to adjust the item
6. 0-9 TV channel numberselect
3. RECALL
Quick TV channel switch(return to the last channel)
10. TV/AV Select PC/COMPONENT/AV/SV/TV
7. MTS/SAP Select MONO,STEREO, SAP in NTSC system
1. MUTE MUTE
8. P.STD Select picture mode: PERSONAL/STANDARD/MILD/FRESH
5. DISPLAY Display current input signal information
4. EXIT Menu exit
Illustration of the keys on the remote control:
MUTE
RECALL DISPLAY EXIT
123
456
789
MTS/SAP P.STD
MENU TV/AV
CH+
CH-
VOL
-
VOL
+
CCD SLEEP SCAN
0
12
34
5
6
78
910
11
12
13 14
15
13. CCD
Closed caption on/off
14. SCAN
Channel scan
15. SLEEP
TV sleep button
Remote Control
Installing Batteries
1.Slide open thecover of thebattery compartment on the back ofthe remote
control.
2.Load two batteries in thecompartment. (plus andminus poles to
respective mark)
3.Replace the coverof the batterycompartment.
AAA alkaline
Precautions
Make sure that there is no
obstacle between theremote
controller and televisionset.
As strong light may interfere with the
signals, change yourposition to
operate the remote control if
the television cannot be turned
on or off as expected.
Keep the remote control
away from heat sources or
humid areas toensure
effective performance of
the remote.
Make sure that two AAA alkaline
batteries are loaded. The batteries
must be of the same type, must be
inserted properly, and must not be
rechargeable.
+
-
Connection Instructions
Ensure that you connect the grounding / earth wire to prevent possible
electric shock. If grounding methods are not possible, have a qualified
electrician install a separate circuit breaker. Do not try to ground the
unit by connectingit to telephone wires, lightening rods, or gaspipes.
Grounding
External Equipment Connections
Antenna Connection
- Antenna or Cable Service with a Cable Box Connections
- For optimum picture quality, adjust antenna direction if needed.
Multi-family Dwellings/Apartments
(Connect to wallantenna socket)
wall antenna
socket
VHF antenna
UHF antenna
outdoor
antenna
Single-family Dwellings /Houses
(Connect to walljack for outdoorantenna)
Bronze Wire
Be careful notto bend thebronze
wire when connectingthe antenna.
Bronze Wire
Turn clockwise to tighten.
RF coaxial wire(75 ohm)
To improve picture quality in a poor
signal area, purchase and install a
signal amplifier.
If the antenna needs to be split for two
TV s, install a 2-Way Signal Splitter
in the connections.
If the antenna is not installed properly,
contact your dealer for assistance.
NOTE: Cables shownare not included with the TV
The connection instructionsshown here are for model HLH15BB for reference only.
May differ with the othermodels mentioned.
