LCD TV
OWNER' S MANUAL
MODEL: L26C300
L32C300
L42C300
Please READ this manual carefully
before operating your TV, and retain
it for future reference
Contents
-1-
1、 Safety and warnings..........................................................................................................2-3
2、 Introduction.....................................................................................................................4
3、 Installation...................................................................................................................... 5-8
4、 Remote Controller........................................................................................................... 9
5、 TV Operation..................................................................................................................10-13
6、 Trouble shooting............................................................................................................. 14
-2-
SAFETY AND WARNINGS
IMPORTANT SAFETY INSTRUCTION
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK).NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
CAUTION
The symbol indicates that dangerous
voltages constituting a risk of electric shock
are present within this unit.
The symbol indicates that there are
important operating and maintenance
instructions in the literaturaccompanying this
unit.
To reduce the risk of fire or electric shock, do
not expose this apparatus to rain or moisture.
WARNING:
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings, install
in accordance with the instructions.
8) Do not install near any heat sources such as
radiations, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9) Do not defeat the safety purpose of the
polarized plug. If the provided plug does not fit
into your outlet, consult an electrician for
replacement of the obsolete outlet.
10) Protected the power cord from being walked
on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
11) Only use attachments/accessories specified
by the manufacturer.
12) Unplug this apparatus during lighting
storms or when unused for long periods of time.
13) Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or
has been dropped.
14) Mains plug is used as the disconnect device,
the disconnect device shall remain readily
operable.
15) The ventilation should not be impeded by
covering the ventilation openings with items,
such as newspapers, table-cloth, curtains, etc.
16) No naked flame sources, such as lighted
candles, should be placed on the apparatus.
17) Attention should be drawn to the
environmental aspects of battery disposal.
18) The use of apparatus in moderate climate.
19) The apparatus shall not be exposed to
dripping or splashing and that no objects filled
with liquids, such as vases, shall be placed on
the apparatus.
This symbol indicates that this product
incorporates double insulation between
hazardous mains voltage and user accessible
parts. When servicing use only
identical replacement parts.
This marking indicates that this product should
not be disposed with other household wastes
throughout the EU. To prevent possible harm to
the environment or human health from
uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of
material resources. To return your used device,
please use the return and collection systems or
contact the retailer where the product was
purchased. They can take this product for
environmental safe recycling.
The batteries shall not be exposed to
excessive heat such as sunshine, fire or the
like.
WARNING:
RISK OF ELECTRIC SHOCK
DO NOT OPEN!
CAUTION
-3-
High voltages are used in the operation of this television
receiver. Do not remove the cabinet back from your set.
Refer servicing to qualified service personnel.
SAFETY AND WARNINGS
To prevent fire or electrical shock hazard, do not expose
the television receiver to rain or moisture.
Do not drop or push objects into the television cabinet
slots or openings. Never spill any kind of liquid on the
television receiver.
Do not block the ventilation holes in the back cover.
Adequate ventilation is essential to prevent failure of
electrical components.
Do not trap the power supply cord under the television
receiver.
Never stand on, lean on, or suddenly push the television or
its stand. You should pay special attention to children.
Serious injury may result if it falls.
Do not place your television on an unstable cart, stand,
shelf or table. Serious injury to an individual , and damage
to the television, may result if it falls.
When the television receiver is not used for an
extended period of time, it is advisable to disconnect
the AC power cord from the AC outlet.
Avoid exposing the television receiver to direct sunlight
and other sources of heat. Do not stand the television
receiver directly on other products which give off heat,
e.g. video cassette players and audio amplifiers. Do not
place naked flame sources, such as lighted candles on
the television.
Dim:515*320mm(不包括底座)
If the television is to be built into a compartment or similar
enclosure, the minimum distances must be maintained. Heat
build-up can reduce the service life of your television, and
can also be dangerous.
INTRODUCTION
-4-
Main features
① Used as Television, display terminal, PC display;
② High luminance, wide viewing angle;
③ Can store 100 TV programs;
④ HDMI interface;
5 Multi-Media player (USB);
Infrared Remote Controller............1
User’sM anual...............................1
Battery(AAA)...............................2
Accessories
Main parameter
1366x768
16 : 9
1-100
100-240V~50/60Hz
2x 5W
Analog RGB(VGA) x 1
High-Definition Multimedia Interface
(HDMI) x 2
Rear Composite Video Input x 1
Audio Input x 3
YCb (Pb )Cr (PR) x 1
Resolution
Aspect Ratio
TV System
Receiving Channel
Input Power Voltage
Signal Input
(THD 7%)
(TV line)
Composite Video
in pu t > =350
Y Cb(Pb ) Cr(Pr)
>=400
Side Composite Video Input x 1
Side USB x 1
RF x 1
26
80W
PAL/BG
PAL/NTSC/SECAM PAL/NTSC/SECAMPAL/NTSC/SECAM
(Diagonal)
1366x768
16 : 9
1-100
2x 8W
32
120W
PAL /B G
1920x1080
16 : 9
1-100
2x 8W
42
200W
PAL /B G
100-240V~50/60Hz 100-240V~50/60Hz
Viewin Picture Sizeg
Video Signal System
Power consumption
Audio Output Power
Horizontal definition
-5-
INSTALLATION
Front panel KEYBOARD
1.SOURCE:Display the input source menu.
2.MENU:Display main MENU.
3.CH+/CH-:In TV mode,press“CH+”or“CH-”to
change the channel up and down.In MENU mode, press
“CH+”or“CH-”to select items .In standby mode,
press“CH+”or“CH-”to turn on the TV.
4.VOL+/VOL-:Adjust sound level.In MENU mode,
press“VOL+”or“VOL-”to adjust the item that you
selected.
5. STANDBY : Press this button to turn the unit ON
from STANDBY mode. Press it again to turn the set
back to STANDBY.
6.USB
7.VIDEO INPUT
8.AUDIO INPUT-L
9.AUDIO INPUT-R
SOURCE
MENU
CH+
CH-
VOL+
VOL-
STANDBY
R
L
VIDEO
USB
1 2 3
4 5 6
7 8 9 0
+
CH
_
+
_
VOL
30 30
3
1
2
4
REAR AV PASTER
All the terminals are(from left to right):
AC POWER SOCKET, HDMI 1, HDMI 2, AV1, YPbPr, AUDIO INPUT, VGA ,PC AUDIO INPUT,
ANTENNA, AV OUTPUT.
Note: 1.AV1 and YPbPr share one audio channel.
2.When HDMI 1 port get DVI signal, the "PC Audio" channel is changed to receive the audio
for HDMI 1 port.
HDMI 1 IN PUT HDMI 2 INPUT L
R
AV1
Pr
Y
Pb
PC
AUDI O INPUT RF IN PUT
AUDIO
OUTPUT
L
RVIDEO
OUTPUT
1: Remote control sensor.
2: Indicator LED: GREEN POWER ON.
RED STANDBY.
3: Key board
4: Power button: Press the Power Button to
turn the unit on or off.
VIDEO
L
R
AV2
USB : DC5V , 500mA
ANTENNA
INSTALLATION
-6-
Note:
Aerial connections:IEC(female).
Input impendance:75 unbalanced.
INSTALLATION
-7-
STEPS:
PC
Be sure both the TV and computer are Power off.
1.Connect VGA and audio cable
2.Connect power cord
3.Power on the TV, switch to PC mode
4.Power on the PC
This sequence is very important.
8
HDMI1 INP UT HDMI2 I NPUT L
R
AV1
Pr
Y
Pb
PC
AUDIO INPUT RF INPUT
AUDIO
OUTPUT
L
RVIDEO
OUTPUT
PRESET MODE (PC)
NOTE: PC V.Freq.(Hz) not more than 60Hz.
1
2
3
800*600
1024*768
60
60
37.88
48.36
RESOLUTION V.Freq.(Hz) H.Freq.(KHz)
1360*768
(Only for 26", 32") 60 47.7
4
1280*768
(Only for 42") 60 47.3
PRESET MODE (HDMI)
1
2
3
800*600
1024*768
60
60
37.88
48.36
RESOLUTION V.Freq.(Hz) H.Freq.(KHz)
1360*768 60 47.7
4
1280*768 60 47.3
5
1920*1080
(Only for 42") 60 67.5
5
1920*1080 60 67.5
INSTALLATION
-8-
AV EQUIPMENT
This TV provides two groups of AV, one group of YPbPr for convenient connection to VCR, DVD or other
video equipment. Please refer to the owner's manual of the equipment to be connected as well.
You can use the input terminals on TV set rear as follows.
VIDEO EQUIPMENT with YPbPr
G B R
GB
HDMI
To au dio
outputs
terminal
VIDEO EQUIPMENT
RWY
output
To video
YR
W
with
HDMI 1 IN PUT HDMI 2 INPUT L
R
AV1
Pr
Y
Pb
PC
AUDIO INPUT RF INPUT
AUDIO
OUTPUT
L
RVIDEO
OUTPUT
From audio outputs
VIDEO EQUIPMENT
From video
output
W R
Y
Y W
R
R
W R
W R
Red (audio R)
White(audio L)
Red(Pr or Cr)
R
W
R
Blue(Pb or Cb)
Green(Y)
B
G
Yellow (video)
Y
It can be connected to the following appliances: VCR, multi disc player, DVD, camcorder, video game
or stereo system, etc.....
YPbPr can support these video fomats: 480i, 576i, 480p, 576p, 720p, 1080i, 1080p.
Note: 1.AV1 and YPbPr share one audio channel.
2.When HDMI 1 port get DVI signal, the "PC Audio" channel is changed to receive the audio for
HDMI1 port.
3.Sometimes it will not support in different device because the device supplys nonstandard signal.
4.When current source is TV, AV OUT signal is TV; when current source is AV, AV OUT signal is
AV; other sources have no AV OUT signal.
VIDEO
L
R
AV2
USB : DC5V , 500mA
REMOTE CONTROLLER
-9-
1:POWER
To set the TV to standby or power on.
2:NUMBER KEY
For direct access to channels.
3:MENU
To display the menu.
4:CURSOR
To move within the menu.
5:CH. LIST
To display the channel list.
6:VOL+/-
To adjust the sound level.
7:PIC
To switch the picture mode.
8:SLEEP
Set
SOURCE HOT KEYS
Switch to the source that you want directly.
13:Be used in programme edit:
Red: delete
Green: rename
Yellow: move
Blue: skip
14:FB
Fast backward key.
15:FF
Fast forward key.
16:Info
Displays or removes the signal information.
17:MUTE
To disable or enable the sound.
18:RECALL
To access the previously viewed programme.
19:SOURCE
To display source menu.
20:OK
In menu mode, use this key to confirm.
21:EXIT
Used to return to the previous menu or exit menu.
22:SOUND
To switch sound mode.
23:CH+/CH-
To access the next or previous TV Program.
24:ASPECT
30:PLAY/PAUSE
Play / Pause key.
the time to turn off the TV.
9,10,11,12,25,26:
To change the picture aspect ratio: 16:9, 4:3, zoom,
zoom2.
27:PREV
Previous key.
28:NEXT
Next key.
29:STOP
Stop key.
Insert Batteries Into the Remote Control
123
Remark:
1. Remove the battery cover.
2. Inserting the 2 AAA 1.5V batteries making sure the
polarity (+ or -) of the batteries matches the polarity
marks inside the unit.
3. Mount the battery cover.
Replace with new batteries when the TV set begins
to show the following symptoms:
Operation is unsteady or erratic. Sometimes the TV
set does not function with Remote Control Unit.
1) Alkaline Battery Recommended.
2) Remove batteries when they are exhausted or if the
remote control is not to be used for long time.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
17
18
19
20
21
22
23
24
25
26
27
28
29
30
15
16
