Haier L26V6-A8K User manual

Please READ thismanual carefully before
operating your TV, and retain it for future
reference.
LCD TV
OWNER`S MANUAL
MODEL :L26V6-A8K
L32V6-A8K
L37V6-A8K
L42V6-A8K
L26V6-A8
L32V6-A8
L37V6-A8
L42V6-A8
S

Safety of operators hasbeen takeninto considerationat thedesign and
manufacture phase, butinappropriate operation maycause electric shock
or fire. To prevent the product from being damaged, the following rules
should be observedfor the installation,use and maintenanceof th product.
Read thefollowing safetyinstruction beforestarting theoperation.
The User Manual uses the following symbols to ensure a safe operation
and prevent anydamage to operatorsor properties:
Warning
This symbol indicatesthat high voltageis present inside.It is
dangerous to makeany kind ofcontact with anyinside part of
this product.
WARNING : To reduce therisk of electric shock do notremove
cover or back.No user-serviceable partsinside refer service
to qualified service personnel.
This symbol indicatesthat there areimportant operating and
maintenance instructions inthe literature accompanyingthe
appliance.
Congratulations on yourpurchase, and welcome to the family !
Dear Haier product owner:
Thank you for your confidence in Haier. You`veselected one of the
best-built, best-backed products available today. We`ll do everything
in our powerto keep you happy with yourpurchase for many years to
come.
As a member of the Haier family, you`re entitled to protection by
one of themost comprehensive warranties and outstanding service
networks in theindustry.
Thanks for investingin a Haier product.
""
""
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING

1. Retain these Instructions ---the safety and operating instructions should be retained for
Future reference.
2. Heed Warnings ---All warning on the appliance and in the operating instructions should be
followed.
3.Cleaning --- Unplug from the wall outlet before cleaning. Do not use liquid cleaners or
Aerosol cleaners. Use only dry cloth for cleaning.
4. Attachments ---do not use attachments
not recommended by the manufacturer as they may cause Hazards.
5. Water and moisture -- do not place this product near water, for example, near a bathtub,
wash bowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.
6. Do not place this unit on an unstable cart, stand, tripod, bracket, or table. Use
only with a cart, stand, tripod, bracket, or table recommend by the manufacture, or sold with
the unit.
7. Ventilation ---Slots and openings in the cabinets and the back or bottom are provided for
Ventilation and to ensure reliable operation of the product and to protect it from overheating,
and these openings must not be blocked or covered. The openings should never be
blocked by placing the product on a bed, sofa, rug, or other similar surface. This product
should not be placed in a built-in installation such as a bookcase or rack unless proper
ventilation is provided or the manufacturer`s instructions have been adhered to.
8. Power Source ---this unit should be operated only from the type of power source indicated on
the rating label. If you are not sure of the type of power supply to your home, consult your
Appliance dealer or local power company.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The wide blade or the third
prong are provided for your safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet. To prevent electric shock, ensure the
Grounding pin on the AC cord power plug is securely connected.
10. Power cord protection ---Power supply cords should be routed so that they are not likely to
Be walked on or pinched by items placed upon or against them. Pay particular attention to
cords or plugs, convenience receptacle, and the point where they exit from the appliance.
11. Lighting precaution ---for added protection for this product during a lighting storm or when
it is left unattended for long period of time, unplug it from the wall outlet and disconnect the
antenna or cable system. This will prevent damage to the product due to lighting and
power line surges.
12. Never push objects of any kind into this product through
openings as they may touch dangerous voltage point or shortout parts
that could result in a fire or electric shock.Avoid spilling liquid of any kind
on the product.
13. Servicing ---do not attempt to service the product by yourself, as opening
or removing covers may expose you to dangerous voltage or other hazards.
Refer all servicing to authorized service personnel.
14.Damage Requiring Service ---Unplug this unit from the wall outlet and
refer servicing to qualified service personnel under the Following conditions:
Grounding or polarization ---
Accessories---
Important safeguards for you and your new product
Your product has been manufactured and tested with your safety in mind. However, improper
use can result in electrical shock or fire hazards. To avoid defeating the safeguards that have
been built into your new product, please read and observe the following safety points when
installing and using your new product, and save them for future reference.
Important Safety Instructions
S3126A
PORTABLE CARTWARNING
(symbol provided by RETAC)

a. When the power supply cord or plug is damaged or frayed.
b. If liquid has been spilled, or objects have been fallen into the unit.
c. If the unit has been exposed to rain or water.
d. If the unit does not operate normally by following the operating instructions. Adjust only
those controls that are covered by the operating instructions, as improper adjustment of
other controls may result in damage and will often require extensive work by a qualified
technician to restore the unit to its normal operation.
e. If the unit has been dropped or damaged in any way.
f. When the unit exhibits a distinct change in performance; this indicates a need for service.
15.Heat --- The product should be situated away heat source such as radiators, heat registers,
stoves, or other products (Including amplifiers) that product heat.
16.Overloading ---Do not overload wall outlets and extension cord as this can result in a risk of
Fire or Electric shock.
17. Outdoor antenna grounding---If an outside antenna or cable system is connected to
the unit, be sure the antenna or cable system is grounded to provide some protection
against voltage surges and built-up static charges, Section 810 of the National Electrical
Code, ANSI/NFPA 70, provides information with respect to proper grounding of the mast and
supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of
grounding conductors, location of antenna discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode.
ANTENNA LEAD IN WIRE
GROUND CLAMP
ELECTRIC SERVICE EQUIPMENT
GROUND CLAMPS
POWER SERVICE GROUNDING ELECTRODE SYSTEM
(NEC ART 250, PART H)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
ANTENNA DISCHARGE UNIT
(NEC SECTION 810-20)
Important Safety Instructions

Table of Contents
Accessories
Remote controller User's manual Alkaline battery(AA) 2 Power cable
STILLSTILL
SLEEPSLEEP PIPPIP
TV/AVTV/AV
P.STDP.STD S.STDS.STD
H.LOCKH.LOCK
CH.LISTCH.LIST EXITEXIT
SCANSCAN
SWAPSWAP
TIMERTIMER ZOOMZOOM
ABC@ABC@ DEFDEF
JKL%JKL%
GHI$GHI$ MNOMNO
STUVSTUVPOR&POR& WXYZWXYZ
*#()*#()
MUTEMUTE
DISPLAYDISPLAY
CH+CH+
CH-CH-
VOL-VOL- VOL+VOL+ MENUMENU
Warning
Important Safety Instructions................
Buttons and interfacelocation..............
............................
.....................
...............................
.....................
Function introduction
Effective range
External Equipment Connections........
Switching ON/OFF theTV set...........
Choose the MenuLanguage.............
Tuning menu
.............
Manual ..............................
AFT(Auto FineTuning).....................
.......................................
Skip
Program swap.................................
.............................................
.......................
................................
Choose the InputSource.................
Program Table ........................
How to selectthe desired program.......
Front control panel
Rear control panel.......
Remote controller
Keys of remotecontroller
Operation
Set up yourTV...................................
......................................
Auto search........................
search..
.......
Edit Name
...............................................
Picture Adjustment
T ............................................
Lock setup..............................................
Teletextfunctions....................................
Maintenance...........................................
.....................
......................................
.................................
AdjustmentSound ...................................
ime setting
Function menu........................................
Adjust menu ...........................................
Other functions.......................................
Specifications and functions
Troubleshooting
1
2
5
5
6
7
8
8
9
10
15
15
15
15
16
16
17
17
18
19
20
20
21
22
23
25
26
27
29
31
32
34
35
36

Front control panel
-This is a simplified representation of front panel.
-Here shown maybe somewhat different from yourTV.
Buttons and interface location
The buttons are on the bottom of the TV set)
MENU TV/AV P-
1.MENU: menu display.
2.TV/AV: all input source display.
3.P-/P+ : program minusand plus,
menu options.
4.V-/V+: volume decrease and increase,
menu reset and entry.
5. POWER: Is used to activate the
display or return to standby
mode.
6.Power indicator: in red when standby
mode, in blue when display.
7.Remote control signal receive window.
P+ V- V+ POWER
1.Remote control signal receive window.
2.Power indicator: in red when standby mode, in blue when display.
3.MENU: menu display.
4.TV/AV: all input source display.
5.P-/P+ : program minusand plus, menuoptions.
6.V-/V+: volume decrease and increase, menureset and entry.
7. POWER: Is used to activate the display or return to standby mode.
1
2
3
4
5
6
7
MENU
VOL-
VOL+
CH-
CH+
TV/AV
Left AUDIO
VIDEO
Right AUDEO
VIDEO
L
AUDIO
R
POWER
Switch
Power jack
Side AV

HDMI/DVI Input
Connect the monitor
output connector from
a DVD player to the
appropriate input port.
ANT IN
HDMI/DVI
IN1 PC IN
Pr/CrPb/Cb
Y
IN2 SCART2 SCART1
DVD/DTV Input
(Component )
Connect a component
video/audiodevice to
these jacks.
Buttons and interface location
Rear Control panel
Earphone jack:
Earphone audio
output terminal.
PC VIDEO Input
Connect the monitor
output connector from
a PC to the jack
Antenna Input
Connect cable orantenna signals
to the TV, either directly or through
your cable box.
SCART2 Input
Connect Scart
out from an Scart
device to the
Scart input.
Audio input
for linking DVI/PC
audio output terminals.
HDMI/DVI
IN2
AC IN
Pr/CrPb/Cb
Y
IN1
HD-AUDIO
HD-AUDIO
PC/DVI
AUDIO IN
Audio input
for linking
YPbPr/YCbCr
audio output
terminals.
Power Cord Socket
This TV operates on AC
power. The voltage is
indicated on the
Specifications page.
Never attempt to operate
the TV on DC power.
SCART1 Input
(Canal+)
Connect Scart
out from an scart
device to the scart
input.
L
R
Speaker
output jack
for linking
loudhailer
only available
42

Remote control
Precautions
3.Replace the coverof the
battery compartment.
Make sure thatthere is noobstacle between
the remote controllerand television set.
As strong lightmay interfere the
signals, change yourposition to
operate the remotecontroller if
the television cannotbe turned
on or off as you expect.
Keep the remotecontroller away from
heat source orhumid area toensure
effective performance of the remote
controller.
Make sure thattwo AAalkaline batteries
are loaded. The batteries mustbe of the
same type. The batteries mustbe located
properly. The batteries are not
rechargeable.
1.Slide open the
cover of thebattery
compartment on the
back of theremote
controller.
2.Load twoAA alkaline
batteries in thecompartment.
(plus and minus
poles to respectivemark)
paying attention tothe polarity
diagram in thebattery
compartment.
Inserting Batteries
7

STILL
SLEEP PIP
TV/AV
P.STD S.STD
H.LOCK
CH.LIST EXIT
SCAN
SWAP
TIMER ZOOM
ABC@ DEF
JKL%
GHI$ MNO
STUVPOR& WXYZ
*#()
MUTE
DISPLAY
CH+
CH-
VOL- VOL+ MENU
Keys of remote control
STILL
Picture static I/II (NICAM)
MUTE
Switches the soundon or off
Power Off/Standby
any other programmed
equipment off.
SCAN
Program scan button DISPLAY
Display ON/OFF
SLEEP
Displaying sleep time,
adjustable
PIP(No available)
Digits
Program direct option(whenedit
program, every presscan set
different sign by turns amongthe
digits and signon top ofthem)
TV/AV
Input source display
SWAP
Switch the currentchannel to the
last channel youhave viewed.
P.STD
(Picture mode option)
S.STD
(Sound mode option)
Program up anddown
or turns yourTV on.
Teletext buttons
buttons which haveletters
on top alsocan use inTV. Lock button
(enter the LockSet menu)
Channel list button
EXIT
clears all on-screendisplays and
returns to TV viewing fromany menu.
TIMER
Time display(only when
there is teletext in TV) ZOOM
Adjust picture aspect ratio
Note:
This User's Manualcovers the functionsof the remotecontroller, includingCH+/-,
VOL-/+, MENU, TV/AV and POWER keysfor control ofprogram up, programdown,
volume decrease, volumeincrease, menu, TV/AV and power ON/OFF.
MENU
main menu entry, menu exitor
return to nexthigher level menu.
sound increase
and decrease
- The remote controller cannotbe operated unlessthe batteries areproperly loaded.
Function introduction
- When usingthe remote control,aim it atthe remote controlsensor on theTV.

Ensure the remote control is pointed toward the remote control window on
the display.
No obstacles shouldbe placed betweenthe remote controland the remote
control window.
The effective receiving scope for the signal is 8 meters to the front of the
OO
remote control window, and45 to the left or right side and 20 above or below
the control window.
Use of remote control:
1. To ensure a normal operation, the remote controller should not be dropped
or damaged in any way .
It should alsobe kept dryand away fromall heat sources.
2. Battery replacementis necessary whenthe remote control acts
inconsistently or stops operating the LCD display.
Remote control
Effective range
above
below
20
20
left right
front 8m
45 45
-Here showns maybe somewhat different from your TV, is only the graphic solution, please
take material objectas.

Generally speaking, to enjoy a clearer picture, we recommend that you use a
CATV system or an outdoor antenna .In different places, the suitable antenna
type and position are different.
Mixer
additional
purchase
Note
* It isrecommended that you'dbetter use 75
* Don't bindantenna cable andelectric wire together.
coaxial cable toremove the
disturbance caused byairwave.
ANT IN
outdoor
antenna
300 twin-lead cable
Antenna adapter
75 coaxial cable
Plug
(additional purchase)
Antenna input
75 standard
coaxial type
External Equipment Connections
If the antennaneeds to besplit for twoTv`s, install a
2-WaySignal Splitter in the connections.
If the antennais not installedproperly, contactyour
dealer for assistance.
Toimprove picture qualityin a poor signal area,
purchase and installa signal amplifier.
Antenna Connection

ANT IN
SCART2 SCART1
HD-AUDIO
HD-AUDIO
PC/DVI
AUDIO IN
External Equipment Connection
- To avoid picturenoise (interference), leavean adequate distancebetween the VCR
And TV.
VCR connection
NOTE: Allcables shown are not included withthe TV.
1. Connect the SCART cables from
the VCR's outputjacks to the TV`s
input jacks, asshown in the figure.
2. Insert a videotape into the VCR and
press PLAY on the VCR. (Referto the VCR
owner`s manual.)
3. Select theinput source
by the TV/AV button
on the remotecontrol.
S-VIDEO
Choose Your Connection
There are severalways to connect your television, depending on the components you
want to connectand the quality of the signal you want to achieve. The following are
examples of someways to connect your TV.
Choose the connectionwhich is best for you.

HDMI/DVI OUTPUT
HDMI/DVI
IN1 PC IN
Pr/CrPb/Cb
Y
IN2
HDMI/DVI
IN2
Pr/CrPb/Cb
Y
IN1
HD-AUDIO
HD-AUDIO
PC/DVI
AUDIO IN
ANT IN
Pr/CrPb/Cb
Y
IN2 SCART2 SCART1
Pr/CrPb/Cb
Y
IN1
HD-AUDIO
HD-AUDIO
PC/DVI
AUDIO IN
RGB-DTV OUTPUT R AUDEO L YPbPr R AUDEO
How to connect
1. Connect theDVD video outputs(Y,
Pb/Cb, Pr/Cr) tothe HDTV INjacks on the
TV and connectthe DVD audiooutputs to
the HD-AUDIO jackson the TV,as shown
in the figure.
2. If yourDVD only hasan SCARToutput
jack, connect thisto the SCARTinput on
the TV. as shown in the figure.
How to use
1. Turnon the DVDplayer, inserta DVD.
2. Use theTV/AV and VOL+/- buttonon
the remote controlto select SCART1 or
SCART2 mode.
3. Press Play buttonon external
equipment for programplay.
4. Refer tothe DVD player'smanual for
operating instructions.
-Towatch digitally broadcastprograms,
purchase and connecta digital set-topbox.
How to connect
Use the TV`s YPbPrIN andAUDIO IN jacks,
PC or HDMI/DVIVIDEO port forvideo
connections, depending onyour set-top
box connections available.Then, make the
corresponding audio connections.
How to use
1. Turnon the digitalset-top box. (Referto
the owner`s manual for the digitalset-top
box.)
2. Use TV/AVon the remotecontrol to
select HDMI mode.
3.Press Play buttonon external equipment
for program play.
DTV connection
DVD connection
External Equipment Connections
DVD
or
Digital Set-top Box
or or

ANT IN
HDMI/DVI
IN1 PC IN
Pr/CrPb/Cb
Y
IN2 SCART2 SCART1
HDMI/DVI
IN2
AC IN
Pr/CrPb/Cb
Y
IN1
HD-AUDIO
HD-AUDIO
PC/DVI
AUDIO IN
How to connect
1. To get thebest picture quality, adjust the PC
graphics card to( 1024x768),60Hz.
2. Use theTV`s PC IN port forvideo
connections, depending onyour PC
connector.
3. Then, make the correspondingaudio
connection. If usinga sound card,adjust the
PC sound asrequired.
How to use
1. Turnon the PCand the TV.
2. Use TV/AV on the remotecontrol to select
PC source.
3. Check theimage on yourTV.There may be
noise associated withthe resolution, vertical
pattern, contrast orbrightness in PCmode. If
noise is present,change the PCmode to
External Equipment Connections
PC connection
another resolution, changethe refresh
rate to anotherrate or adjustthe
brightness and contraston the menu
until the pictureis clear.If the refresh
rate of thePC graphic cardcan not be
changed, change thePC graphic cardor
consult the manufacturerof the PC
graphic card.
NOTES:
1Use a PCcable.
2Avoid keeping a fixedimage on the
TV's screen for a longperiod of time.
The fixed image may become
permanently imprinted onthe screen.
3The synchronization inputform for
Horizontal and Vertical frequencies is
separate.
Resolution
Frame
frequency
(Hz)
Line
frequency
(Khz)
PC
SPC
XGA
640*480 31.5KHz 60Hz
800*600 37.9KHz 60Hz
1024*768 48.4KHz 60Hz
Mode Resolution

Power source
TO USE AC POWER SOURCE
Use theAC polarized linecord provided for
operation onAC. Insert theAC cord plug into
a standard polarizedAC outlet.
NOTES:
Never connect theAC linecord plug toother
than the specifiedvoltage. Use the
attached power cordonly.
If the polarizedAC corddoes not fitinto a non-
polarized ACoutlet, do notattempt to file or cut
the blade. Itis the user`s responsibility to have
an electrician replacethe obsolete outlet.
If you causea static dischargewhen touching
the unit andthe unit fails to function, simply
unplug the unitfrom the AC outlet and plug it
back in. The unit shouldreturn to normal operation.
Polarized AC Cord Plug
AC Outlet
Wider Hole
and Blade
You can connect a set of headphones to your set if you wish to watch a
TV programme withoutdisturbing the other people in theroom.
Connecting Headphones
External Equipment Connections
Note
Prolonged use of headphones at a high volume
may damage yourhearing.
You will not receivesound from the speakers
when you connectheadphones to thesystem.
Plug a setof headphones into the 3.5mm
mini-jack socket onthe rear panel of the set.
ANT IN

Switching ON/OFF the TV set
1first, connect power cord correctly and the powerindicator will light.
2If the indicatoris lighting in red, press the digit buttons or CH+/- button onthe remote
controller again orPOWER or CH+/- button on the TV set.(with the exception 0digit)
3If you wantto exchange to standing by status, please press down button on the remote
controller.
4Disconnect the powersupply or unplug the television if it is intended to completely cease
the television performance.
Set up your TV
Choose the Menu Language
When you startusing your set for the first time, you must selectthe language which
will be usedfor displaying menus and indications.
-There are severaloptions you mightneed to setup in orderfor your TV to work
properly. Read the instructionsthat follow.
-In the manual,the OSD(on screendisplay) may bedifferent from your TV`s,
because it isjust an exampleto help youwith the TV operation.
1 Press MENU button and thenuse CH+/-
button to selectthe Function menu.
2 Press VOL+/- buttonand then useCH+/-
button to selectLanguage.
3 Select your languagewith VOL+/- button and
press the MENUbutton to confirm you selection.
4When you aresatisfied with your choice, press
the EXIT button to returnto normal viewing or press
MENU button to returnto the previous menu.
Choose the Input Source
If you hopeto enjoy the picture from the external input source,
before to selectthe source, you need to connect the devices,
otherwise, when youselect the source, the snowflake,blue
screen will appearson the screen.
Press TV/AV button on televisionor remote
control, the menuappears on the screen.
Then press CH+/-to select the desired option,
and press VOL+/-to ensure it.
Source
MENU
FUNCTION
AUDIO
ADJUST
TUNING
TIMER
West Europe
Language
Menu Timeout
Menu Backgroud
Blue Screen
Calendar
Teletext Language
Restore Default Value
English
15 seconds
Transparent
Off

This TV set has three methods to set channels, which are respectively full automatic,
manual search fine tune.
In this section, how to use the remote control to set channel is explained. You can
also use buttons on the TV set to set channel.
Automatic search
Note :
The TUNING menuwill be only
operated in normal TV, AV and
SCART mode.
Auto Search
AUDIO
ADJUST
FUNCTION
TIMER
MENU
TUNING
Tuning Program
Auto Search
Program Table
Country England
Tuning menu
1 Press MENU button and thenuse CH+/-
button to select the TUNING menu.
2 Press VOL+/- buttonand then use CH+/-
button to select Country, and use VOL+/-
button to set the country.
(
3 Press CH+/- buttonto select Auto Search.
4
first according to where you be)
Press VOL+/- button, at this time, the prompt
will display on the screen, andthen press
VOL+/- button to select the Yesoption, press
MENU button to ensure automatic search
with higher level.
After the search has finished, all channels
now playing program will be automatically
preset in order.
Note:
If you haveset TunerLock as on in Lock Set
menu. there willbe TunerLock display on screen
and you maynot enter theTUNING menu, atthis
time, you mustset Tunerlock as offin Lock Set
menu.
Searching
MENU: Stop
28
Do you wantto start autotuning?
Yes No
VOL+/-:Select
MENU: Confirm
EXIT: Exit

Manual search
If excessive channel signals of unwanted programs are received in local area,
manual search function is recommended.
Tuning menu
AUDIO
ADJUST
FUNCTION
TIMER
MENU
TUNING
Program Number
Edit Name
Color System
Sound System
Manual Search
AFT
Skip OFF
18
C 28
AUTO
D/K
62.25MHz
AUDIO
ADJUST
FUNCTION
TIMER
MENU
TUNING
Tuning Program
Auto Search
Program Table
Country England
1 Press MENU button and thenuse CH+/- buttonto
select the TUNING menu.
2 Press VOL+/- buttonand then useCH+/- button to
select Tuning Program.
3 Press VOL+/- buttonto enter the submenu.
4Press CH+/- buttonto select Manual Search.
5 Press VOL-/+ buttonrepeatedly, till the best picture
and sound areobtained.
If you arefamiliar with the frequency value, press
the desired digitsdirect.
. Or pressVOL+/- button tosurpass for 3seconds,
then become semiautomaticallysearches for
channel, till thechannel is obtained.
AFT(Auto Fine Tuning)
If the pictureand/or sound arepoor, tryusing the Auto Fine Tuning feature. Do not
use this featureunless reception ispoor.
AUDIO
ADJUST
FUNCTION
TIMER
MENU
TUNING
Program Number
Edit Name
Color System
Sound System
Manual Search
AFT
Skip OFF
18
C 28
AUTO
D/K
62.25MHz
AUDIO
ADJUST
FUNCTION
TIMER
MENU
TUNING
Tuning Program
Auto Search
Program Table
Country England
1 Press MENU button and thenuse CH+/- buttonto
select the TUNING menu.
2 Press VOL+/- buttonand then useCH+/- button to
select Tuning Program.
3 Press VOL+/- buttonto enter the submenu.
4Press CH+/- buttonto select AFT.
5 Press VOL-/+ buttonto setAFT as on or off.
6Press the EXIT button to return to normal viewing or
press MENU button to returnto the previousmenu.
Note
If theAFT harmonious effect is notgood, suggested
uses manually searchesfor the adjustmentpicture the
effect
OFF
OFF

Tuning menu
Program Table
Program Table
Red: Del; Green: Copy; Yellow:Name; Blue: Swap
001
002
003
004
005
006
007
008
009
010
Delete name
Copy edit name
Name channel
1 Press CH+/-to select the channel,
2 Press thegreen button on the remote control,
3 Press CH+/-button to select the channel to copy,
4 Press MENU button to ensure.
Swap channel
1 Press CH+/-to select the channel;
2 Press thered button on the remote control to delete;
3 Press MENU button to deletename.
1 Press CH+/-to select the channel;
2 Press theyellow button on the remote control;
3 Press theyellow button to display the digital and letter list;
4 Press Vol+/- or CH+/-to select thedesired digital orletter;
5 Press theyellow button to exit list;
6 Press MENU button to ensure.
1 Press CH+/-to select the channel;
2 Press theblue button on the remote control;
3 Press CH+/-button to select the channel to swap;
4 Press againthe blue button to ensure.
AUDIO
ADJUST
FUNCTION
TIMER
MENU
TUNING
Tuning Program
Auto Search
Program Table
Country England
1 Press MENU button and thenuse CH+/-
button to select the TUNING menu.
2 Press VOL+/- buttonand then use CH+/-
button to select Program Table.
3 Press VOL+/- button to enter the submenu.
You can press CH.LIST button again to enter
the submenu.
4Press CH+/- button to select the edited
channel, and pressbutton corresponding toedit.
Red button: deletechannel name
Green button: copy channel
Yellowbutton: Name channel
Blue button: Swap

If the colour of some channel is abnormal
Usually this shouldbe set inthe auto position.However if thecolour displayed onthe
screen are incorrect,you can manuallyselect the correctcolour system.
Press CH+/- button to select "Sound System", then
press VOL-/+ button to select the correct sound
system.
Press VOL+/- button to selectD/K, I, B/G,L, L' in turn.
If sound is abnormal
Edit Name
Tuning menu
AUDIO
ADJUST
FUNCTION
TIMER
MENU
TUNING
Program Number
Edit Name
Color System
Sound System
Manual Search
AFT
Skip OFF
18
C 28
AUTO
D/K
62.25MHz
AUDIO
ADJUST
FUNCTION
TIMER
MENU
TUNING
Tuning Program
Auto Search
Program Table
Country England
1 Press MENU button and thenuse CH+/-
button to selectthe TUNING menu.
2 Press VOL+/- buttonand then useCH+/-
button to selectTuning Program.
3 Press VOL+/- buttonto enter the submenu.
4Press CH+/- buttonto select Color System.
5 Press VOL-/+ buttonto select the correct color
system (AUTO, NTSC, PAL, SECAM and NT4.43).
6Press the EXIT button to returnto normal viewing
or press MENU button to returnto the previous
menu.
1 Press MENU button and thenuse CH+/-
button to selectthe TUNING menu.
2 Press VOL+/- buttonand then useCH+/-
button to selectTuning Program.
3 Press VOL+/- buttonto enter the submenu.
4Press CH+/- buttonto select Edit Name.
5 Press VOL-/+ buttonto select
6
position you
want to changeand press digitsto change.
Press MENU buttonto ensure it.
AUDIO
ADJUST
FUNCTION
TIMER
MENU
TUNING
Program Number
Edit Name
Color System
Sound System
Manual Search
AFT
Skip OFF
18
C 28
AUTO
D/K
62.25MHz
OFF
OFF
