Haier HBF165W User manual

BAR CHILLER
OPERATING
INSTRUCTIONS
The manufacturer is continuously developing
their products and reserves the right to modify
designs, products and technical data without further
notice.
*
MODEL HBF165W
WARNING - Keep ventilation openings, in the appliance enclosure or in the
built-in structure, clear of obstruction.
WARNING - Do not use mechanical devices or other means to acceler
the defrosting process, other than those recommended b
the manufacturer.
WARNING - Do not damage the refrigerant circuit.
WARNING - Do not use electrical appliances inside the f
compartments of the appliance, unless the
recommended by the manufacturer.
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities
and knowledge, unless they have been given supervision or instr
-cerning use of the appliance by a person responsible f
Children should be supervised to ensure that the
appliance.
If the supply cord is damaged, it must be replaced b
its sernerce agent or similarly qualified persons in order to a
WARNING
ate
y
ood storage
y are of the type
, or lack of experience
uction con
or their safety.
ydonotplaywiththe
y the manufacturer,
void a hazard.

PARTS DESCRIPTION
1
1. Bottle Shelves
3. Vegetable Bin
5. Drip Tray
7. Thermostat
2. Tall Bottle Storage
4. Shelves
6. Ice Box
8. Light Switch
01
2
3
4
5
5
6
4
3
2
1
78

2
LAMP
7
WIRING DIAGRAM
Lamp: 220-240V,15W
Lamp holder: E14 (lamps exceeding 15W must not be used).
When replacing the lamp:
To replace the lamp:
* Unplug the appliance and remove the
water tray from under the ice box.
* Press on the front of the lamp cover
while pulling it down to release it from
the lamp holder.
* To remove the lamp, turn it anti-
clockwise.
* Replace the lamp and cover then refit
the water tray.
LAMP
REPLACEMENT
NOTICE
SETTING UP
The fridge cannot be installed with its
rear panel directly against the wall. For
good air circulation, there should be a
gap of 100mm. Install the machine on a
flat and firm ground to minimize noise.
Avoid installing the appliance
in rooms where it is poorly
ventilated,in direct exposure
sunlight or other similar
sources of heat.
The power supply for
this appliance is
220-240V, 50Hz
Single phase.
It is not
recommended
to use extension
cords.
Connect the appliance to a properly
earthed three pin socket.
Never store anything dangerous
in this unit, such as
combustibles, explosives,
strong acid,or alkali etc.

THERMOSTAT
The thermostat setting are: 0, 1, 2, 3, 4, 5, 6, 7.
The numbers on the thermostat do not stand for the
actual temperature. The greater the number, the colder
the temperature is inside and vice versa.
Usually, it is best to start the thermostat in position
1 - 3 then turn it to a higher setting if required.
Position ‘0’ is off.
STORING FOOD
Different sections within the applia e
will vary in temperature. Thus select
the appropriate se tio he stori g your foo .
The coldest position is ‘1’ and the
armest is ‘5’.
(Please refer to the image o the right)
ICE BOX˄7KLVLVQRWDIUHH]HU
When making ice, add water to the ice tray
until 4/5 full and place it on the bottom of
the icebox. Twist the tray or place it briefly
in warm water to remove the ice cubes.
NOTE
This chilller section will operate at the lowest temperature of
minus 12 degrees if the thermostat is set o 7
Do not use a knife or sharp instrument when removing the ice tray
if it is stu k.
3
1
2
5
4
3
6
In the event of a fault occurring during operation, check below to see if
the fault is due to an operator error. You can repair the following faults
yourself.
The appliance does
not run.
1. It is not switched on properly,
or the plug is not inserted properly
into the socket.
2. The thermostat knob is set on “0”.
3. The supply voltage is too low.
The temperature inside
the appliance is not
cool enough.
1. The appliance is too full of food.
2. The appliance is located too close
to a source of heat.
3. The door is not properly closed or
is opened too frequently.
Excessive noise
from the appliance. The appliance is not standing
securely on the ground.
If none of these circumstances applies and you are not able to repair
the fault, please contact a service agent:-
PHONE [phone]

4
DEFROSTING
Remove ayfood from the ice box, wrap it
and store in a esky or similar applia e.
Switch off the appliance at the wall and
leave the ice box door open. It will defrost
automatically. When the defrosting process
has finished, empty the drip-tray under the
ice box and wipe the ice box dry. Replace
the food and switch on the appliance.
NOTES
5
4~6mm
DO NOT USEA KNIFE OR SHARP
INSTRUMENT TO ASSIST WITH ICE
REMOVAL.
If the appliance is going to be out of use for any length of
time , unplug and clean the interior as
described in the previous page.
Dry thoroughly and store with the door open.
To reduce energy consumption, do not leave the door open
for too long and dont’t open it too often.
In the event of a power failure, try to keep the door closed to
keep the cool air inside for as long as possible.
NOTES ON STORAGE
CLEANING
Where necessary, food should be
packed in bags to avoid giving off
strong odours or getting freezer
burn.
Do not overstock the appliance with
food. Allow space among the
packages of food for air circulation
and better cooling.
Hot food or liquid must be allowed to
cool to room temperature
before placing in the applia e.
Always remove the plug before cleaning.
Clean with lukewarm water containing a little detergent.
Do not use hot water, corrosive scouring agent or anything rough.
