Haier RF-8888-279 User manual

1
HAIER
REFRIGERATOR
Service Manual
PART # RF-8888-279
HAIER AMERICA TRADING, LLC
www.haieramerica.com

2
Table Of Contents
Contents 2
Features 3
Product Code Explanation And Series Introduction 4
Specifications 5
Safety Precaution 6
Parts And Functions 10
Function Schedule 11
System Flow Chart 12
Circuit Diagram 13
Maintenance Service And Troubleshooting 14
Troubleshooting And Repairs 16

3
Features
 Flat-Back Design
 Freezer Compartment With Ice Cube Tray

4
Product code Explanation and Series Introduction

5
Specifications
Model HSP03WNAWW
Capacity (Cu.Ft) 2.7
Color White
Power Supply (V/Hz) 115V/60Hz
Rated Input Power (W) 161
Power Consumption (kW·h/year) 307
Net Weight (lbs) 61.7
Gross Weight (lbs) 70.5
Unit Dimension (WXDXH inches) 19 23/32”X19 23/32”X26 5/16”
Packing Dimension (DXHXW inches) 20 1/4”X23 1/2”X27”
Container Quantity (40’) 331
Container Quantity (40’HC) 331

6
Safety Precautions
WARNING!
This appliance uses 115V~/60Hz AC for
power supply.
Voltage has excessive variations, which is likely
to prevent malfunctions like abnormal noise by
processor. It is advisable to use a 750-voltage
regulator or a higher power
voltage.
WARNING!
It is advisable to use a separate, dedicated and
secured grounding outlet.
Power cable is filed with three core (grounding) plugs
complying with three core grounding outlet. In no case
should the third plug pin (grounding) of the power cable be
removed.
WARNING!
Do not damage power cable.
Be sure not to unplug unit by power cable.
Hold plug firmly to unplug
Do not let the body of the unit have contact or
press power cable. Take care of power cables to
avoid damage when moving unit.
WARNING!
In case the power cable is damaged.
Worn out cables should not be used.
Replace such damaged cables.

7
In the case of the leakage of an
inflammable gas
1. Access leaking area and close leaking gas
valve
2. Open door and windows.
3. Do not temper with unit plug any electrical
device such as refrigerator.
Unplug power in these situations
1. Unplug unit prior to cleaning or repairing.
2. Unplug unit before replacing damaged
lamp to prevent electrical shock.
WARNING!
It is not advisable or prohibited to keep
hazardous, inflammable or explosive items like
acid or alkali into refrigerators.
WARNING!
Do not keep medicine, vaccines or chemical reagents in
refrigerator.
This refrigerator is for household use and cannot store
items with strict temperature requirements.

8
Do not store or use gasoline or other flammable
substances in the vicinity of the refrigerator to
avoid fire outbreak.
Do not place any electrical plugs, regulators or microwaves
on top of the refrigerator. Do not use any other electric
appliance (except the one the manufacturer has stated)
inside the refrigerator.
WARNING!
Do not play with the door to avoid damage.
WARNING!
Do not keep heavy objects on Refrigerator
WARNING!
Do not touch refrigerator with your wet hands when it
is in operation to avoid your hand form getting stuck
to the freezer.
WARNING!
Do not spray water onto the unit or install
Unit at a wet place to avoid interferences with the
power source.

9
WARNING!
Do not temper with refrigerator when you do not
have any technical know how. Seek professional
advice in case of the refrigerator gets damaged.
WARNING!
Do not keep bottled items in the freezer compartment
to avoid frost crack.
WARNING!
Unplug power supply when carrying out cleaning.
Switch power on 5 minutes after to prevent any
damage.
WARNING!
Dismantle door and door gasket before disposing off a
refrigerator to avoid damage to unsuspecting persons
or children.

10
Parts and Functions
