Haier DTA-1486 User manual
.
2
Edition:2005-5-6
CONTENTS
1.Safetyprecautions .. 3
2.TVblock diagram .. .4
3.ReplacementofmemoryIC .5
4.Service adjustment .. ...5
5.ICsfunctionaldescription 8
6.Testpointwaveform 10
7.All ICsvoltages .. .10
8.Purity/convergence adjustment 11
9.DVDmaintenance 13
10.ListofParts ..14
11.Circuitdiagram 28
12.Explodedview 29
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
.
3
1. SAFETY PRECAUTIONS
1.Thedesignofthisproductcontainsspecial hardware,many
circuitsandcomponentsespeciallyforsafetypurposes.For
continued protection,nochangesshouldbemadetothe
originaldesignunless authorizedinwritingbythe
manufacturer.Replacementpartsmustbeidenticaltothose
usedintheoriginal circuits.Serviceshouldbeperformed by
qualified personnel only.
2.Alterationsofthedesignorcircuitryoftheproductsshould
notbemade.Anydesignalterationsoradditionswill voidthe
manufacturer swarrantyandwill furtherrelievethe
manufacturerofresponsibilityforpersonal injuryorproperty
damageresultingtherefrom.
3.Manyelectrical andmechanical partsintheproductshave
special safety-related characteristics.Thesecharacteristics
areoften notevidentfromvisual inspectionnorcan the
protectionaffordedbythemnecessarilybeobtained byusing
replacementcomponentsrated forhighervoltage,wattage,
etc.Replacementpartswhichhavethesespecialsafety
characteristics areidentifiedinthepartslistofService
manual.Electrical componentshavingsuchfeaturesare
identifiedbyshadingon theschematics andby( )on
thepartslistinServicemanual.Theuseofasubstitute
replacementwhichdoesnothavethesamesafety
characteristics astherecommendedreplacementpart
showninthepartslistofServicemanual maycauseshock,
fire,orotherhazards
4. Don’tshortbetweentheLIVE sideground and
ISOLATED(NEUTRAL)sidegroundorEARTHside
groundwhenrepairing.Somemodel spowercircuitis
partlydifferentintheGND.ThedifferenceoftheGNDis
shownbytheLIVE:()sideGND,ISOLATED
(NEUTRAL): ()sideGNDandEARTH: ()sideGND.
Don tshortbetweentheLIVEsideGNDandISOLATED
(NEUTRAL)sideGND orEARTHsideGND andnever
measurewithameasuringapparatus(oscilloscopeetc.)the
LIVEsideGND andISOLATED(NEUTRAL)sideGNDor
EARTHsideGND atthesametime.If abovenotewillnotbe
kept, afuseoranypartswill bebroken.
5.Ifanyrepairhasbeenmadetothechassis,itis
recommended thattheB1settingshouldbecheckedor
adjusted (See ADJUSTMENT OFB1POWERSUPPLY).
6.The highvoltageapplied tothepicturetubemustconformto
that specifiedinServicemanual. Excessivehighvoltagecan
causean increasein X-Rayemission,arcingand possible
componentdamage,thereforeoperationunderexcessive
highvoltageconditionsshouldbekepttoaminimum,or
shouldbeprevented.Ifseverearcingoccurs,removetheAC
powerimmediatelyanddeterminethecausebyvisual
inspection (incorrectinstallation,cracked ormelted high
voltageharness,poorsoldering,etc.).Tomaintain theproper
minimumlevel ofsoftX-Rayemission,componentsin the
highvoltagecircuitryincluding thepicturetubemustbethe
exactreplacementsoralternativesapproved bythe
manufacturerofthecompleteproduct.
7.Donotcheckhighvoltagebydrawinganarc.Useahigh
voltagemeterorahighvoltageprobewithaVTVM.
Dischargethepicturetubebeforeattemptingmeter
connection,byconnectingacliplead tothegroundframe
andconnectingtheotherendofthelead through a10kΩ2W
resistortotheanodebutton.
8.Whenserviceisrequired,observetheoriginal leaddress.
Extraprecautionshould begiventoassurecorrectlead
dress in thehighvoltagecircuitarea.Whereashortcircuit
hasoccurred,thosecomponentsthatindicateevidenceof
overheatingshouldbereplaced.Alwaysusethe
manufacturer sreplacement components.
9.Isolation Check
(SafetyforElectricalShockHazard)
Afterre-assemblingtheproduct, alwaysperformanisolation
checkon theexposed metal partsofthecabinet(antenna
terminals,video/audioinputandoutputterminals,Control
knobs,metal cabinet, screwheads,earphonejack,control
shafts,etc.)tobesuretheproductissafetooperatewithout
dangerof electrical shock.
10.The surfaceoftheTVscreeniscoatedwithathinfilmwhich
can easilybedamaged. Beverycarefulwithitwhen handle
theTV. ShouldtheTVscreen becomesoiled, wipeitwitha
softdrycloth.Neverrubitforcefully.Neveruseanycleaner
ordetergenton it.
(1)DielectricStrengthTest
Theisolation between theACprimarycircuitandallmetal
partsexposed totheuser,particularlyanyexposed metal
parthavingareturnpathtothechassisshouldwithstanda
voltageof 3000VAC(r.m.s.)foraperiod of onesecond.
(…Withstandavoltageof 1100VAC(r.m.s.)toanappliance
ratedupto120V,and 3000VAC(r.m.s.)toanappliance
rated 200Vormore,foraperiodof onesecond.)
Thismethodoftestrequirestestequipmentnotgenerally
foundintheservicetrade.
(2)LeakageCurrentCheck
PlugtheAClinecorddirectlyintotheACoutlet(donotuse
lineisolation transformersduring thischeck).Using a
“LeakageCurrent Tester”,measuretheleakagecurrentfrom
eachexposedmetal partofthecabinet, particularlyany
exposedmetal parthavingareturnpathtothechassis,toa
knowngood earthground(waterpipe,etc.).Anyleakage
currentmustnotexceed0.5mAAC(r.m.s.).
However,intropical area,thismustnotexceed0.2mAAC
(r.m.s.).
●AlternateCheck Method
PlugtheAClinecorddirectlyintotheACoutlet (donotuse
alineisolationtransformerduringthischeck.).UseanAC
voltmeterhaving 1000 ohmspervoltormoresensitivityin
thefollowingmanner.Connecta1500Ω10Wresistor
paralleled bya0.15μFAC-typecapacitorbetween an
exposed metal partand aknowngoodearthground(water
pipe,etc.).MeasuretheACvoltageacross theresistorwith
theACvoltmeter.Movetheresistorconnection toeach
exposed metal part, particularlyanyexposed metal part
having areturnpathtothechassis,and measuretheAC
voltageacross theresistor.Now,reversetheplug intheAC
outletand repeateachmeasurement.Anyvoltagemeasured
mustnotexceed0.75VAC(r.m.s.).Thiscorrespondsto
0.5mAAC(r.m.s.).
However,intropical area,thismustnotexceed0.3VAC
(r.m.s.).
Thiscorrespondsto0.2mAAC(r.m.s.)
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
5
3. REPLACEMENTOFMEMORYIC
1.MEMORYIC.
ThisTVusesmemory IC.Inthe memoryICarememorized dataforcorrectlyoperating the video and deflection
circuits.
2.PROCEDUREFORREPLACINGMEMORYIC
(1)Poweroff
Switchthe poweroff and unplug the powercordfromACoutlet.
(2)ReplaceIC
BesuretousememoryICwritten withthe initial datavalues.
(3)PowerOn
Plug thepowercordintothe ACoutlet and switchthe poweron.
(4)Check and set SYSTEM default value:
1)Press “MUTE”à“CALL”à“-\--“à“CALL”à“MUTE”buttonsinsequencetoenterintofactory
status.
2)Ifthe memoryIChaven t been written withthe initial data, press [Program+]/[Program-]toselectitem
INITand press [VOLUME+] /[VOLUME-]tostartinitializememory IC.
3)Check the setting value ofthe SYSTEMdefaultvalue ofTablebelow.Ifthe value isdifferent, select
itemsby[Program+]/ [Program-] keysand setvalue by[VOLUME+]/[VOLUME-]keys.
4)Press “EXIT”button toreturntothe normalscreen.
4. SERVICE ADJUSTMENT
Specificoperation:useremotecontroller
Press “MUTE”à“CALL”à“-\--“à“CALL”à“MUTE”buttonsinsequencetoenterintofactory mode.
Press [Program+]/[Program-]toselectitemsand press [VOLUME+]/[VOLUME-] key,tomakedataadjustment
of corresponding factory menus.
Press “EXIT”keytoexit factory mode.
Focusadjustment
1.Receiveacrosshatchsignal.
2.Whilewatching the screen,adjustthe FOCUSVRon the FBTtomakethe verticaland horizontallinesas
fine and sharpaspossible.
Geometrical adjustment
ReceivePALstandardcompletepatternsignal.
Adjustment steps：
a)Adjust VSL,tothe centrehorizontallinejust appearsfromhalf bottomshadow.
b)Adjust VAM,toget 92%ofvertical picturecontentswouldbe displayed on CRT.
c) Adjust VSH,the centrehorizontalline correspondstoCRT vertical centre.
d)Adjust SCL,tothe linearityofPcardfieldisinpropercondition.
e)Adjust HSH,togetthe picturehorizontal centrecorrespond toCRThorizontalcentre.
ReceiveNTSCsignaland repeataboveadjustment.
AGCAdjustment
Receive60dBμ(1mV) VHcolourbarpatternsignal.
SelectTOPitem.
Adjust value, tonoisereducegraduallyandjust disappeared point.
CRTcutoffandwhitebalance adjustment
a)CRTcut off adjustment
1.SelectitemVG2B, then adjustvalue to32.
2.PRESS “0”key,when the screen shows”VG2”adjustthe SCREENcontrolon Flyback transformerto
makethe screen showalternating flashing charactersof “INSIDEHIGHINSIDELOW”.
b)Whitebalanceadjustment
1.ReceiveaBlackand Whitepattern.
2.AdjustWRP, WRG,WRBitemstogetcolourtemperature9300K ±3JND.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
6
AdjustableItems
DirectaccesskeyItems Description Preset Remark
“0”VG2 Adjust VG2voltage
“1”5/6HSH Horizontalshift ON A
“2”5/6VSL Verticalslop 21 A
5/6VAM Verticalamplitude 45 A
5/6SCL S-correction 20 A
5/6VSH Verticalshift 38 A
5/6VOF OSDVerticaloffset 38 A
HOF* OSDHorizontaloffset 20 A
“3”RED Blackleveloffset R 32 A
GRN BlackleveloffsetG 32 A
WPR WhitepointR 31 A
WPG Whitepoint G 31 A
WPB WhitepointB 31 A
YDFP Y-DelayforPAL
YDFN Y-DelayforNTSC
YDFS Y-DelayforSECAM
YDAV Y-DelayforAV
COOL
WARM
LCT OSDgainreduction
TLCT Teletext gainreduction
“4”TOP AGCTake-overpoint 27 A
VOL Volume 36
9874 GaincontrolforTDA9874 59
AVLT 5
9860 1
IFFS VisionIF 32
HDOL Cathodedrivelevel 31
AGC IFAGCspeed
VG2B VG2Brightness
PF Peaking centerfrequency
“5”Picturepreset 1
0CON Listen: Contrast 0 A
0BRI Listen: Brightness 0 A
0COL Listen: Colour 50 A
0SHP Listen: Sharpness 50 A
1CON Soft:Contrast 45 A
1BRI Soft:Brightness 45 A
1COL Soft:Colour 50 A
1SHP Soft:Sharpness 50 A
“6”Picturepreset 2
2CON Standard: Contrast 70 A
2BRI Standard: Brightness 50 A
2COL Standard: Colour 50 A
2SHP Standard: Sharpness 60 A
3CON Dynamic: Contrast 85 A
3BRI Dynamic: Brightness 60 A
3COL Dynamic: Colour 60 A
3SHP Dynamic: Sharpness 80 A
“7”OP1-OP9
“8”INIT InitializeEEPROM
“9”XMIN “no signal”osdthehorizon
leftmostposition
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
7
XMAX “no signal”osdthehorizon
rightmostposition
YMIN “nosignal”osdthevertical
leftmostposition
YMAX “nosignal”osdthevertical
rightmostposition
NOTE: THEITEMSWITHREMARK “A”ISADJUSTABLEDATA.
Optional data
1.OP1
Bit Function Description Preset Remark
Bit7 OP_RGB 1=Enable 0 EA
Bit6 OP_DVD 1=Enable 1 EA
Bit5 OP_SVHS 1=Enable(CanonlybeselectedeitherSVHSand
DVD) 1 EA
Bit4 OP_AV2 1=Enable0 EA
Bit3 OP_WOOFER_VOL 1=Enable 0 EA
Bit2 OP_SUPERWOOFER1=Enable 0 EA
Bit1 OP_YPRPB 1=Enable 0 EA
Bit0 OP_VG2_MODE 1=Enable 1 EA
2.OP2
Bit Function Description Preset Remark
Bit7 OP_FSL 1=21dBμV0=26dBμV 0 EA
Bit6 OP_SOY 1=Enable 0 EA
Bit5 OP_ARABIC_SET 1=Enable 1 EA
Bit4 OP_FARSI_SET 1=Enable0 EA
Bit3 OP_CYRILLIC_SET 1=Enable 1 EA
Bit2 OP_EUROUP_SET 1=Enable 1 EA
Bit1 OP_AUTO_SOUND 1=Enable 1 EA
Bit0 OP_AVL 1=Enable 1 EA
3.OP3
Bit Function Description Preset Remark
Bit7 OP_RUSSIA 1=Enable 1 EA
Bit6 OP_ITALY 1=Enable 0 EA
Bit5 OP_GERMANY 1=Enable 0 EA
Bit4 OP_FRANCE 1=Enable 0 EA
Bit3 OP_TURKISH 1=Enable 1 EA
Bit2 OP_ARABIC 1=Enable 1 EA
Bit1 OP_FARSI 1=Enable 0 EA
Bit0 OP_ENGLISH 1=Enable 0 EA
4.OP4
Bit Function Description Preset Remark
Bit7 Reserved 0 EA
Bit6 OP_HALFTONE 1=Enable 1 EA
Bit5 OP_IDENT-SENSITIVE
1:21dbuv0:26dbuv 0 EA
Bit4 OP_HCO 0 EA
Bit3 OP_LOGO 1=Enable 0 EA
Bit2 OP_DUTCH 1=Enable 0 EA
Bit1 OP_SPANISH 1=Enable 0 EA
Bit0 OP_ROMANIA 1=Enable 0 EA
5.OP5
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
8
Bit Function Description Preset Remark
Bit7 OP_STORE_AV 1= Enable 1 EA
Bit6 OP_OSO 1= Enable 0 EA
Bit5 OP_SOFT_CHANGE
1=Enable 0 EA
Bit4 OP_FADE 1=Enable 0 EA
Bit3 OP_SOUND_M 1= Enable 1 EA
Bit2 OP_SOUND_I 1= Enable 1 EA
Bit1 OP_SOUND_BG 1=Enable 1 EA
Bit0 OP_SOUND_DK 1=Enable 1 EA
6.OP6
Bit Function Description Preset Remark
Bit7 RESERVED 1=Enable 0 EA
Bit6 OP_POR_WHEN_BLUE
1=Enable 0 EA
Bit5 OP_MENU_MIDLINE 1=Enable 0 EA
Bit4 OP_MENU_BLUE 1=Enable 1 EA
Bit3 OP_CHILDLOCK 1=Enable 1 EA
Bit2 OP_TINT 1=Enable 0 EA
Bit1 OP_BLUE_SCREEN 1=Enable 0 EA
Bit0 OP_LOGO_LISTEN 1=Enable 1 EA
7.OP7
Bit Function Description Preset Remark
Bit7 OP_FMWS 1= Enable 1 EA
Bit6 OP_HOTEL 1= Enable 0 EA
Bit5 OP_PROG-ID 1=Enable 0 EA
Bit4 OP_LED 1=Enable 0 EA
Bit3 OP_TWIST 1= Enable 1 EA
Bit2 OP_BYELORUSSIAN
1= Enable 1 EA
Bit1 OP_UKRANIAN 1=Enable 1 EA
Bit0 OP_AV1 1=Enable 1 EA
8.OP8
Bit Function Description Preset Remark
Bit7 OP_TILT 1= Enable 1 EA
Bit6 OP_DIRECT_WITCH-ON
1= Enable 0 EA
Bit5 OP_INEER-DVD 1=Enable 0 EA
Bit4 OP_PROG-FREQ 1=Enable 0 EA
Bit3 OP_FAST_BAR 1= Enable 1 EA
Bit2 OP_AUSTALIA 1= Enable 1 EA
Bit1 OP_FREQ 1=Enable 1 EA
Bit0 OP_9860 1=Enable 1 EA
9.OP9
Bit Function Description Preset Remark
Bit7 OP_YGN 1= Enable 1 EA
Bit6 OP_OPC 1= Enable 0 EA
Bit5 OP_BSD 1=Enable 0 EA
Bit4 OP_AAS 1=Enable 0 EA
Bit3 OP_FMWS1 1= Enable 1 EA
Bit2 OP_MVK 1= Enable 1 EA
Bit1 OP_CMSS 1=Enable 1 EA
Bit0 OP_OSVE 1=Enable 1 EA
Note：Don t adjustanyOPTIONitems,pleaseinformtheengineeraboutanychange.
5. ICsfunctionaldescription
1.N501 UOCTDA9351
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
9
SYMBOL PIN DESCRIPTION
STAND BYoutput. 1 InSTANDBYmode,lowlevel(PowerOFF).
ForPowerONthispinwillbehigh.
SCL 2 I2C-busclock line
SDA 3 I2C-busdataline
TUNING 4 tuning Voltage(Vt)PWMoutput
KEY 5 Controlkeys input
SYSTEM 6 TVsystemcontrol
VOL 7 Sound VolumecontrolPWMoutput
MUTE 8 Sound muteoutput
VSSC/P 9 Digitground for μ-controllercoreandperiphery
CTL 10 DVDpowercontrol
STANDBY 11 STANDBYcontrol
VSSA 12 AnaloggroundofdigitalgroundofTV-processor
SECPLL 13 Internallyconnected
VP2 14 2nd supplyvoltageTV-processor(+8V)
DECDIG 15 decouplingdigitalsupplyof TV-processor
PH2LF 16 Phase-2filter
PH1LF 17 Phase-1filter
GND3 18 Ground3forTV-processor
DECBG 19 Band gapdecoupling
AVL/EWD 20 Automaticvolumelevelling
VDRB 21 VerticaldriveBoutput
VDRA 22 VerticaldriveAoutput
IFIN1 23 IFinput1
IFIN2 24 IFinput2
IREF 25 Referencecurrentinput
VSC 26 Verticalsawtoothcapacitor
TUNERAGC 27 TunerAGCoutput
AUDEEM/SIFIN1*1 28 AudiodeemphasizeorSIFinput
DECSDEM/SIFIN229 Decouplingsound demodulator
GND2 30 Ground2forTVprocessor
SNDPLL/SIFAGC*1 31 NarrowbandPLL filter
AVL 32 AutomaticVolumeLevelling
HOUT 33 Horizontaloutput
FBISO 34 Flyback input/sandcastleoutput
AUDEXT 35 Externalaudiooutput
EHTO 36 EHT/overvoltageprotection input
PLLIF 37 IF-PLL loopfilter
IFVO/SVO 38 IFvideooutput/selectedCVBS output
VP1 39 supplyvoltageTVprocessor
CVBS INT 40 internalCVBS input
GND1 41 groundforTVprocessor
CVBS/Y 42 CVBS/SVHS(Y)input
CHROMA 43 SVHS(C)input
AUDOUT 44 Audiooutput
INSSW2 45 YUVinsertion input
R2/VIN 46 Rinput/V(R-Y)input/PRinput
G2/YIN 47 Ginput/ Yinput
B2/UIN 48 Binput/U(B-Y)input/PBinput
BCLIN 49 Beamcurrentlimiterinput
BLKIN 50 Blackcurrentinput
RO 51 Redoutput
GO 52 Greenoutput
BO 53 Blueoutput
VDDA 54 Analogsupplyof ClosedCaptiondecoderanddigitalsupplyofTV-processor(3.3V)
VPE 55 Ground
VDDC 56 Digitalsupplytocore(3.3V)
OSCGND 57 Oscillatorgroundsupply
XTALIN 58 Crystaloscillatorinput
XTALOUT 59 Crystaloscillatoroutput
RESET 60 Ground
VDDP 61 Digitalsupplytoperiphery(+3.3V)
P1.0/INT1 62 AV1/AV2modeOutput.
P1.1/T0 63 AV/S-VHSmodeOutput.
P1.2/INT0 64 Remotecontrolsignalinput.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
10
Note Pin TV SVHS AV1 AV2
62 1 0 0 1
63 1 1 0 0
2.N902 24C08/PCF8598
PIN Function
1 GND
2 GND
3 Upperresistance
4 GND
5 SDAdatawire
6 SCLclockwire
7 GND
8 +5VPower
3.N601: Sound poweramplify(AN7522N)
Symbol PINFunction Symbol PIN
Function
Vcc 1 Powersupply GND 7 ground
Out 1(+) 2 Ch1output(+) In2 8 Ch2input
GND(out1) 3 Ch1Ground VOL 9 VolumeControl
Out 1(-) 4 Ch1output(-) Out 2(-) 10 Ch2output(-)
Standby 5 Muteinput GND(out2) 11 Ch2Ground
In1 6 Ch1input Out 2(+) 12 Ch2output(+)
4.N301: Verticaloutput (TDA8357A)
Symbol PIN
Function SymbolPIN
Function
INVIN 1 Input PUMPUP 6 Pumpuppower
INVIN 2 Input VOUT 7 Verticaloutput
Vcc 3 Pumpuppower VPRO 8 Verticalprotection
VOUT 4 Verticaloutput VFEEDBACK 9 Verticalfeedback
GND 5 Ground
5.U101：Tuner
PIN
Function PIN
Function
1 AGC 7 +5V
2 vacant 8 vacant
3 Gnd 9 Vt 33V
4 SCL 10 Gnd
5 SDA 11IFOut
6 +5V
6. Test pointWaveforms
2.5Vpp
2.5Vpp
3.8Vpp
H
H
H
1.2Vpp
2.6Vpp
H
H
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
11
7. ICvoltages
TDA9351
PIN
1 2 3 4 5 6 7 8 9 10
11
12
13
14
15
16
V 03.8
3.6
3.3
3.5
4.4
5.1
1.8
00.18
0.17
02.3
8 5 3
PIN
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
V 4 0 4 0.5
0.7
0.8
1.9
1.9
3.9
3.8
1.6
3.2
2.3
02.3
0.2
PIN
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
V 0.5
0.3
01.7
2.4
3.4
83.9
03.3
03.6
1.4
2.5
2.5
2.5
PIN
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
V 1.9
5.0
2.4
2.4
2.4
3.1
03.2
01.8
1.7
03.2
5.1
3.3
5
TDA8357
PIN
1 2 3 4 5 6 7 8 9
V 0.8
0.7
16 6.9
0 43 7.2 0.3 7.2
AN7522N
PIN
1 2 3 4 5 6 7 8 9 10 11 12
V 10 4.4 0 4.42.75
1.4 0 1.40.35
4.4 0 4.4
24C08/PCF8598
PIN
1 2 3 4 5 6 7 8
V 0 0 5.1
03.2
0 0 5.1
8. PURITY/ CONVERGENCE ADJUSTMENT
5Vpp
0.9Vpp
1.3Vpp
H
H
1Vpp
V
CRTKB
CRTKGCRTKR
95Vpp
95Vpp
95Vpp
H
H
H
TDA
9351
PI
N
33
TDA
9351
PIN
34
0.8Vpp
V
TDA9351 PIN21 TDA9351 PIN22 TDA9351 PIN59
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
12
PURITYADJUSTMENT
1.DemagnetizeCRTwiththe demagnetizer.
2.Loosen the retainerscrewofthe deflection yoke.
3.Removethe wedges.
4.Inputagreen rastersignalfromthe signalgenerator,
and turnthe screen togreen raster.
5.Movethe deflection yokebackward.
6.Bring the long lug ofthe puritymagnetson the short
lug and positionthemhorizontally. (Fig2)
7.Adjustthe gap betweentwolugssothatthe GREEN
RASTERwillcomeintothe centreofthe screen.
(Fig. 3)
8.Movethedeflection yokeforward,andfixtheposition
ofthedeflection yokesothatthe wholescreen will
becomegreen.
9.Insert the wedge tothe top side of the deflection yoke
sothat it will notmove.
10.Input acrosshatchsignal.
11.Verifythatthe screen ishorizontal.
12. Inputred and blue rastersignals,and makesurethat
purityisproperlyadjusted.
CRT
WEDGE
DEFLECTION YOKE
P
46
P:PURITYMAGNET
4:4-POLES (convergencemagnets)
6:6-POLES (convergencemagnets)
P/CMAGNETS
Fig. 1
PURITYMAGNETS
Longlug
Shortlug
Bring thelonglugovertheshortlugand
positionthem horizontally.
Fig. 2
(FRONTVIEW)
GREENRASTER
CENTER
Fig.3
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
13
STATICCONVERGENCEADJUSTMENT
1.Input acrosshatchsignal.
2.Using 4-poleconvergencemagnetsoverlapthered
and blue linesinthe centerofthe screen (Fig.1)and
turnthemtomagenta(red/blue).
3.Using 6-poleconvergencemagnetsoverlap the
magenta(red/blue)and green linesinthe centerofthe
screen and turnthemtowhite.
4.Repeat2and 3above,and makethe best
convergence.
DYNAMICCONVERGENCEADJUSTMENT
1.Movethedeflectionyokeupand downand overlap
linesinthe periphery.(Fig.2)
2.Movethe deflectionyokelefttorightand overlap the
linesinthe periphery.(Fig.3)
3.Repeat1and 2above,and makethe best
convergence.
Afteradjustment,fixthe wedge at the originalposition.
Fasten the retainerscrewof the deflection yoke.
Fixthe 6magnetswithglue.
(FRONTVIEW)
Fig. 1
(FRONTVIEW)
REDGREENBLUE
BLUE
RED
GREENGREEN
REDBLUE
BLUEGREENRED
Fig.2
(FRONTVIEW)
REDGREENBLUEBLUEGREENRED
RED
GREEN
BLUE
BLUE
GREEN
RED
Fig. 3
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
14
9. DVDPart:IntroductionofMTK1389Emaintenance
NOTE:MTK1389Eisatype ofLSICforDVDdecode .MTK1389EICconsistsof
RF,SERVO,DSP,DECODE,VIDEO DACandAUDIO DAC.
1.Undernormalpowersupplyconditions,the maintenanceplan forMT1389Emono-chipis: firstthe reset
circuit resetsthe MT1389E, afterthe crystaloscillatorcircuit gavetheclock signal toMT1389E, MT1389Ewill
start the initialization check forFlash、E2PROM、SDRAM, aftereverything ischecked tobe normal,it willstart
initialization checkforbuilt-inAudioDAC, servoand motorDriverIC.
2. Ifthe all the a.m.partsaregood,then MT1389Ewillsend signaltomotorDrivertodrivethe servo
system，pickup then togenerateDVDlightforcollection,tracing the mainshafttocheckifthereisanydisc,and
confirmifitisCD format orDVDformat disc. If the discisinDVDformat, the systemwillread the datafromthe
discdirectly;ifitisinCD format built-inservowilldrivethe CD lasertosend out CD light and read the data, the
datathen willbeamplifiedthroughbuilt-inRFamplifierand sent toMT1389Edecode partfordataprocessing,
released byMPEGand resolved intovideo dataand audiodata,then theywill be returned toanalog signals
through built-inVIDEODAC、AUDIODAC.
Decodersection
3.Thereispowersupply, clockand reset, butthe systemdoesnot work.
1）Check ifallthe address wiresrequired forFLASHareexist,and iftheyareinnormalstatus,
especiallycheck ifthe A0~A15 ofFLASHhavenormalsignals, iftherearen t, then inspect MT1389Etosee if
thereisfaultysoldering.IftherearenormalsignalsatA0~A15,checkifthe addressdatasignalofMT1389E
and SDRAMisnormal.If itisnormal,then check the signalatA16~A19 of MT1389E;iftherearealsosignals,
then checkthevideo outputwiresand AVfiltercircuit; ifthereisno signal,then check the corresponding pins
of MT1389Etosee if thereisanyshort circuit,breakorfaultysoldering.
4.Systeminnormal operation,butthe audiohasno sound.
1）Becausethe AUDIO DACisbuiltinMTK1389EIC.you need tocheck the lowerpassing
amplifying circuit and the MUTEcircuit atthe back oftheLPF circuit.Alsocheck if thereisanypowersupplyto
the LPFcircuit.
2）Check if the powersupplyvoltage required forplaying isat normallevel.
ServoSection
5.Afterthe LOGO ofthemachineshowsnormally,thereisno OSDdisplay.Thisproblemmainlyiscaused
bythe abnormalitybuilt-inRFand servo,possibleproblemsmaybe:
1）BuiltinRF and itssurrounding circuitshaveproblems.
2)Servopart of MT1389Ehasproblems.
6.OSDdisplayisnormal，whilethereisno action ofservopart（feedingmotordoesnotwork,mainshaft does
no turn, possiblefault statusare:
1)The corresponding signalsgiving byMT1389EtoDMSO、FMSOaremissing,the reason maybe the
problemof MT1389Eorthe communication between MT1389Eand motorDriverICSA5668.
2)NotoutputfromMotorDriver,thereason maybe the problemon motorDriveroritscorresponding
circuit.
7.Servopartingood status, whilethereisno pickup action（no light,no focus）
1）No light, checkthe powersupply（powersupplyforpick up）,orthelight producing driving circuit tosee
if theyareinnormalstatus.
2）No focus, check MT1389Etosee ifthereissignaloutputfromFOSO、TRSO.
Secondly,check motordrivertosee if thereisF+、F-、T+、T-signaloutput.
Thirdly, checkthe externalcorresponding circuit of themotordrivertosee if thereisanyproblem.
8.Allthe servopart hasaction, whileitcannot read outthedisc
1）Check MT1389EifthereisRFnetpictureoutput, ifthereisn t, thenitmustbe the problemof
MT1389Eand external surrounding circuits,itthereisoutput, then itmightthe problemof MT1389E
and itssurrounding circuits.
2）ThereisRFsignal，butnotinnormalstatus，then check MT1389Eand surrounding circuits.
3 ）Everything isnormal,butthe disccannot beread out, check MT1389Eand itssurrounding circuit
10. List ofParts
MATERIAL
CODE LOCATION PARTS NAME TYPE Q'TY
DA0RZ0E0C00
DTA1486(Ukraine):TV/DVD-1432
1
0090804174 Front-Frame Subassembly BCJ7008-----Q 1
0090204478 Front-Frame Assembly MTZA7008AA--Q 1
0090204521 Front-Frame MTAA7010AA--Q 1
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
15
0090204510 light transmission pillar MTAA7011AA--Q 1
0090600011 Tapping Screw SJ2824-87 ST3X10F 1
0090204511 Nine Buttons MTAA7012AA--Q 3
0090600011 Tapping Screw SJ2824-87 ST3X10F 2
0090204513 TOP pad MTAA7014AA--Q 2
0090204514 Bottom pad MTAA7015AA--Q 1
0090204512 Power Switch Cap MTAA7013AA--Q 1
0090100663 Spring MTBH7004BC--Q 2
0094002137 Speaker YDT0407-9AU-8W-8Ω2
0090401453 Speaker Wire (550mm) SpeakerWire -500 8
0090600012 Tapping Screw SJ2824-87 ST3X8F 7
0090600012 Tapping Screw SJ2824-87 ST3X8F 2
0090600012 Tapping Screw SJ2824-87 ST3X8F 1
0090800020 Metal Clamp 2
0090600203 Tapping Screw SJ2824-87 ST4X8F 1
0090401676 Wire D2006-12P-D2512-10P-TJC3-2P-350 1
0090401336 Front-AVConnector Wire
1
0090808978 DVD Subassembly 1
0094012898 DVD Assembly 1
0090204556 DVD Bracket 1
0090100709 DVD Shielding cover（Top）1
0090100710 DVD Shielding cover（Bottom）
4
0090600011 Tapping Screw SJ2824-87 ST3x10F 1
0094011442 DIVX Subassembly DS-C010C 8
0090203564 Sponge bar 1
0090204529 DVD
1
0090701017 Back-Cover Subassembly BJH7008-----Q 1
0090810119 Back-Cover Assembly MTZA7008AC--Q 1
0090204526 Back-Cover（Double SCART）MTFC7011AJ--Q 4
0090600037 Tapping Screw SJ2825-87 ST3X10F 1
0090204528 AV Label（Double SCART）69.6X71.4 1
0090402611 DC BoardConnector Wire 300 1
DC PowerJack 2
0090600011 Tapping Screw SJ2824-87 ST3x10F
1
0090100652 Assemblymaterialsubassembly
MTZC7008AA--Q 1
0090200008 High-Voltage Wire Clamp TEM101 3
0090200047 Wire Clamp TMMOA411-1 1
0090204563 14 DVD MTAH7008AA--Q 1
0090205631 Power Clamp MTAH4066AA--Q 2
0090600015 Tapping Screw SJ2824-87 ST4X12F 5
0090600023 Tapping Screw SJ2824-87 SJ4X16F 1
0090600023 Tapping Screw SJ2824-87 SJ4X16F 1
0090204751 Laser Label 1
0090503689 Foam pad(top) MTEE7013AB--Q 1
0090503690 Foam pad(bottom) MTEE7014AB--Q
1
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
16
0090701029 Bracket Subassembly 1
0090402257 Main Board andDCConnector
Wire TJC1-3Y-500-TJC1-3Y 1
0090204544 Bracket MTAC7013AA--Q 9
0090600037 Tapping Screw SJ2825-87 ST3X10F 1
0090201400 Press Bar PS 1
0090200038 040Wire Clamp MTAJ1001AG--Q
1
0094013485 Power Wire Subassembly BJG7006-----Q 1
0094000141 Power Switch KDC-A04MU017 4
0090200232 Thermal Shrinkage Pipes 4*20 1
0090400437 Power Wire 2.3m 1
0090400587 Power Connector Wire 1
0090100664 Power Switch Bracket MTBH7005BC--Q 2
0090600074 Tapping Screw GB9074.4-88 M3X8F
1
0094013481 CRT Subassembly 1
0094007554 CRT14" A34AGT13X53 1
0090401302 Wire JE215-0C3014Q 1
0094501271 Degaussing Coil HXC-35F 4
0090100297 Bolt SJ2824-87 ST5X25
1
0090700954 Carton Subassembly 1
0090207073 Back-Cover Label Russian 1
0090506371B
Carton 2
0094000105 Battery 5# 1
0090204759 Specification Bag(Small）1
0094013897E
Remote Control 1
0090204758 14”Plastic Bag 1
0090500018 Power Wire Plastic Bag 1
0090506993 Specification Three Languages 1
0090507041 Warrantycard 1
0090507042 Telephone Book1
0090100306 Metal Wire 60mm 1
0090402118 DCC onnector Wire 1
0094501060 Antenna Subassembly TLT-2000-I
1
0090701030 Main Board Subassembly 1
0094009813 Main Board Premaching
Subassembly 1
0090100450 N301B Radiator Radiator 1
0094401409 N301C IC TDA8357J 1
0090600097 N301D Tapping Screw ST3X8F SJ2831-87 1
0090600097 V401B Tapping Screw ST3X8F SJ2831-87 1
0090100017 V401A Radiator QHS-30184A 1
0094401644 V401 Triode TT2140（） 1
0090100765 N801A Radiator MTBT3048BC--Q 1
0094401392 N801C IC KA5Q0765RTH-YDTU 1
0090600097 N801D Tapping Screw ST3X8F SJ2831-87 1
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
17
0094400808 N802C IC L7809CS 1
0090600097 N802B Tapping Screw ST3X8F SJ2831-87 1
0090100017 N802A Radiator QHS-30184A 1
0094401684 N601B IC AN7522N 1
0090100665 N601A Radiator QHS-30184A 2
0090600097 N601C Tapping Screw ST3X8F SJ2831-87 1
0094401923 N804B IC KA278R05（） 1
0090100010 N804A Radiator MTBH4070BC--Q 2
0090600097 N804C Tapping Screw ST3X8F SJ2831-87 1
0094400450 N808 IC L7805CV 1
0094100023 R625 Oxide-Film Resistor RT13-1/6W-1K-J------T 1
0094102578 R110 Oxide-Film Resistor RY16S-1W-33-J-05-E-A 1
0094102667 R407 Oxide-Film Resistor RY16S-1W-3.9K-J-12.5-E-A 1
0094100097 R307 Oxide-Film Resistor RY17S-2W-390-J-05-E-A 1
0094102457 R414 Oxide-Film Resistor RY17S-2W-1K-J-05-E-A 1
0094100098 R413 Oxide-Film Resistor RY17S-2W-7.5K-J-05-E-A 1
0094102580 R810 Oxide-Film Resistor RY17S-2W-18K-J-17.5-L-A 1
0094101653 R404 Oxide-Film Resistor RY15-1/2W-120Ω-J-12-D 1
0094100101 R802 Oxide-Film Resistor RY17S-2W-33K-J-05-E-A 1
0094100101 R801 Oxide-Film Resistor RY17S-2W-33K-J-05-E-A 1
0094102581 R825 Oxide-Film Resistor RY17S-2W-47K-J-05-E-A 1
0094100085 R818 Oxide-Film Resistor RY15S-1/2W-1.5K-J------T 1
0094100095 R820 Fusion Resistor RY17-2W-24Ω-J-05-C 1
0094100125 R821 Fusion Resistor RF10-2W-1-J-05-C 1
0094102583 R824 Fusion Resistor RF10-1/2W-1-J-05-E-A 1
0094102583 R415 Fusion Resistor RF10-1/2W-1-J-05-E-A 1
0094102668 R302 Fusion Resistor RF10-1/2W-10-J-05-E-A 1
0094102584 R409 Fusion Resistor RF10-1/2W-0.22-J-05-E-A 1
0094102586 R306 Fusion Resistor RF10-2W-0.68-J-05-E-A 1
0094102669 R815 Fusion Resistor RF10-2W-0.18-J-15-L-A 1
0094401811 P801 PTC Thermistor PDC7RQPP6B744 1
0094400047 RP801 PTC Thermistor MF72-2-5Ω±N 1
0094201617 C248 Ceramic Capacitor CS1-F-63V-0.1μF-Z-F05 1
0094201373 C410 Ceramic Capacitor CT1-B-2kV-681pF-K-07-A 1
0094201373 C419 Ceramic Capacitor CT1-B-2kV-681pF-K-07-A 1
0094200067 C807 Ceramic Capacitor CT1-B-2kV-561pF-K-07-A 1
0094201449 C810 Ceramic Capacitor CT1-B-500V-560pF-K-F05 1
0094202412 C823 Ceramic Capacitor CT81-400VAC-18B-2E4-332-M-10-C-A
1
0094201617 C311 Ceramic Capacitor CS1-F-63V-0.1μF-Z-F05 1
0094200982 C305 Ceramic Capacitor CS1-B-63V-0.01μF-K-F05 1
0094201071 C805 Film Capacitor CT1-B-1kV-1000pF-K-07-A 1
0094201463 C216 Film Capacitor CL21X-63V-224-J------F 1
0094200098 C414 Film Capacitor CL21X-400V-104-J-07-A-A 1
0094200099 C227 Film Capacitor CBB13-50V-104-J-07-A-A 1
0094200101 C416 Film Capacitor CBB21-400V-364-J-20-G-A 1
0094201669 C409 Film Capacitor CBB81-1.5KV-622-J-20-B-A 1
0094200105 C802A Film Capacitor MKT61-275V-104-M-15-G-A 1
0094200994 C725 AL Electrolytic Capacitor CD71-50V-1uF-M-F05 1
0094200043 C222 AL Electrolytic Capacitor CD110X-50V-1μF-M-F05 1
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
18
0094201043 C236 AL Electrolytic Capacitor CD110X-16V-22μF-M-F05 1
0094201011 C846 AL Electrolytic Capacitor CD110X-25V-1000μF-M-05-A 1
0094201011 C848 AL Electrolytic Capacitor CD110X-25V-1000μF-M-05-A 1
0094201319 C811 AL Electrolytic Capacitor CD110X-25V-2200μF-M-05-A 1
0094201011 C610 AL Electrolytic Capacitor CD110X-25V-1000μF-M-05-A 1
0094202297 C304 AL Electrolytic Capacitor CD263-100V-33uF-M-05-A 1
0094202297 C418 AL Electrolytic Capacitor CD263-100V-33uF-M-05-A 1
0094200736 C808 AL Electrolytic Capacitor CD263-160V-100μF-M-07-A 1
0094201604 C411 AL Electrolytic Capacitor CD288H-250V-22uF±20%-05-G-A 1
0094201341 C801 AL Electrolytic Capacitor CD293-400V-150μF-M-10-A 1
0094200802 C852 AL Electrolytic Capacitor CD110X-16V-1000μF-M-F05 1
0094401993 VD802 Diode T1R5GU41-12.5-M 1
0094401993 VD803 Diode T1R5GU41-12.5-M 1
0094401513 VD806 Diode FFPF10U60STU 1
0094402112 N201 IC TDA9351 1
0094400636 N202 IC M24C08(BR24C08) 1
0094400196 PC801 IC PC817C 1
0094400138 N703 IC TC4052BP 1
0094400503 N702 IC HEF4053() 1
0094600198 X201 Oscillators JA12D-12MHZ-20PF 1
0094600239 Z201 Ceramic Trap XT6.5MB 1
0094600013 Z202 Ceramic Trap XT5.5MB 1
0094600276 SF101 SAW Filter D2901C 1
0094000137 F801 Fusion TSG-3.15A-250V 1
0090100021 F801A Fuze Nip FC503 1
0090100021 F801B Fuze Nip FC503 1
0094501053 L401 horizontal linearitycoil LX034 1
0094500686 L801 Power Filter LCL-207 1
0094501114 T444 FBT BSC25-0284G 1
0094501146 T801 Power Transformer BCK-07-DE7 1
0094500034 T401 HORIZONTAL DRIVE transformer
AA26-50001B 1
0094501148 LW coil TK116 1
0094005862 TU101 Tuner TD05EFS-01 1
0094300442 V999 CRT Jack GZS8-6-CD 1
0094300193 CN801 Jack TJC1-3A 1
0094300063 CN802 Jack TJC2-2A 1
0094300193 CN804 Jack TJC1-3A 1
0094300092 CN601 Jack TJC3-2A 1
0094300092 CN602 Jack TJC3-2A 1
0094300111 CN502 Jack TJC3-3A 1
0094300012 CN200 Jack TJC3-3A 1
0094300012 CN211 Jack TJC3-3A 1
0094300104 CN210 Jack TJC3-5A 1
0094300104 CN503 Jack TJC3-5A 1
0094300111 SERVICE Jack TJC3-3A 1
0094300307 CN401 Jack TJC1-4A 1
0094300104 CN809 Jack TJC3-5A 1
0094300090 GT501 Jack TJC1-1A 1
0094300090 GT502 Jack TJC1-1A 1
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
19
0090401872 CN702 S-TerminalSignal Connetor
Wire Three Pins Wire 1
0090401670 CN706 DVDAudioConnector Wire 1
0094300106 CN703 Jack TJC3-8A 1
0090402610 S DVDVideoConnector Wire 1
0090400514 CN810 DVDPowerConnector Wire TJC3-4A 1
0090401317 CN818 Connector Wire TJC3-2A-2Y-450 1
0090401671 CN807-N401(I-G)
两脚 Connector Wire 1
0090400064 G Control Wire 150mm 1
0090401669 CN501 VideoConnectorWire TJC3-8B-3Y-5Y-260mm 1
0094100101 R527 Oxide-Film Resistor RY17S-2W-33K-J-05-E-A 1
0094102168 R511 Oxide-Film Resistor RY17-2W-18KΩ-J-20-D 1
0094102168 R521 Oxide-Film Resistor RY17-2W-18KΩ-J-20-D 1
0094102168 R531 Oxide-Film Resistor RY17-2W-18KΩ-J-20-D 1
0094102710 R505 Fusion Resistor RF10-2W-2.8-J-05-E-A 1
0094100128 R506 Fusion Resistor RF10-2W-68-J-05-E-A 1
0094200727 C509 Electrolytic Capacitor CD110X-250V-4.7μF-M-F05 1
0094200971 C510 Ceramic Capacitor CT1-B-2KV-1000PF-K-07-A 1
0094200105 C800 Film Capacitor MKT61-275V-104-M-15-G-A 1
0094300457 DVD SCART TerminalJack CS-103
1
0090701031 Main Board Auto-insert
Subassembly 1
0091801280 PCB 0091801280 V2.2 1
0094100065 R104 Carbon Film Resistor RT13-1/6W-10-J------T 1
0094100065 R752 Carbon Film Resistor RT13-1/6W-10-J------T 1
0094100065 R742 Carbon Film Resistor RT13-1/6W-10-J------T 1
0094100066 R216 Carbon Film Resistor RT13-1/6W-47-J------T 1
0094100066 R943 Carbon Film Resistor RT13-1/6W-47-J------T 1
0094100066 R250 Carbon Film Resistor RT13-1/6W-47-J------T 1
0094100066 R257 Carbon Film Resistor RT13-1/6W-47-J------T 1
0094100067 R258* Carbon Film Resistor RT13-1/6W-75-J------T 1
0094100067 R265 Carbon Film Resistor RT13-1/6W-75-J------T 1
0094100067 R715 Carbon Film Resistor RT13-1/6W-75-J------T 1
0094100067 R735 Carbon Film Resistor RT13-1/6W-75-J------T 1
0094100067 R733 Carbon Film Resistor RT13-1/6W-75-J------T 1
0094100067 R734 Carbon Film Resistor RT13-1/6W-75-J------T 1
0094100067 RS03 Carbon Film Resistor RT13-1/6W-75-J------T 1
0094100067 R718 Carbon Film Resistor RT13-1/6W-75-J------T 1
0094100067 RS01 Carbon Film Resistor RT13-1/6W-75-J------T 1
0094100017 R743 Carbon Film Resistor RT13-1/6W-100-J------T 1
0094100017 R744 Carbon Film Resistor RT13-1/6W-100-J------T 1
0094100017 R745 Carbon Film Resistor RT13-1/6W-100-J------T 1
0094100017 RS02 Carbon Film Resistor RT13-1/6W-100-J------T 1
0094100017 R208 Carbon Film Resistor RT13-1/6W-100-J------T 1
0094100017 R209 Carbon Film Resistor RT13-1/6W-100-J------T 1
0094100017 R210 Carbon Film Resistor RT13-1/6W-100-J------T 1
0094100017 R230 Carbon Film Resistor RT13-1/6W-100-J------T 1
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
20
0094100017 R235 Carbon Film Resistor RT13-1/6W-100-J------T 1
0094100017 R236 Carbon Film Resistor RT13-1/6W-100-J------T 1
0094100017 R237 Carbon Film Resistor RT13-1/6W-100-J------T 1
0094100017 R245 Carbon Film Resistor RT13-1/6W-100-J------T 1
0094100017 R252 Carbon Film Resistor RT13-1/6W-100-J------T 1
0094100017 R740 Carbon Film Resistor RT13-1/6W-100-J------T 1
0094100017 R741 Carbon Film Resistor RT13-1/6W-100-J------T 1
0094100017 W235 Carbon Film Resistor RT13-1/6W-100-J------T 1
0094100017 W236 Carbon Film Resistor RT13-1/6W-100-J------T 1
0094100017 R280 Carbon Film Resistor RT13-1/6W-100-J------T 1
0094100017 R281 Carbon Film Resistor RT13-1/6W-100-J------T 1
0094100133 R251 Carbon Film Resistor RT13-1/6W-200-J------T 1
0094100133 R263 Carbon Film Resistor RT13-1/6W-200-J------T 1
0094100019 R843 Carbon Film Resistor RT13-1/6W-220-J------T 1
0094100134 R244 Carbon Film Resistor RT13-1/6W-390-J------T 1
0094100069 R255 Carbon Film Resistor RT13-1/6W-430-J------T 1
0094100020 R106 Carbon Film Resistor RT13-1/6W-470-J------T 1
0094100020 R256 Carbon Film Resistor RT13-1/6W-470-J------T 1
0094100023 R242 Carbon Film Resistor RT13-1/6W-1K-J------T 1
0094100023 R243 Carbon Film Resistor RT13-1/6W-1K-J------T 1
0094100023 R258 Carbon Film Resistor RT13-1/6W-1K-J------T 1
0094100070 R840 Carbon Film Resistor RT13-1/6W-510-J------T 1
0094100023 R227 Carbon Film Resistor RT13-1/6W-1K-J--------T 1
0094100023 R841 Carbon Film Resistor RT13-1/6W-1K-J------T 1
0094101350 R310 Carbon Film Resistor RT13-1/6W-1.5KΩ-J-T52 1
0094101350 R861 Carbon Film Resistor RT13-1/6W-1.5KΩ-J-T52 1
0094100026 R102 Carbon Film Resistor RT13-1/6W-2.2KΩ-J-T52 1
0094101328 R215 Carbon Film Resistor RT13-1/6W-3.3K-J------T 1
0094101328 R266 Carbon Film Resistor RT13-1/6W-3.3K-J------T 1
0094101328 R247 Carbon Film Resistor RT13-1/6W-3.3K-J------T 1
0094101328 R220 Carbon Film Resistor RT13-1/6W-3.3K-J------T 1
0094101328 R278 Carbon Film Resistor RT13-1/6W-3.3K-J------T 1
0094101328 R747 Carbon Film Resistor RT13-1/6W-3.3K-J------T 1
0094101328 R746 Carbon Film Resistor RT13-1/6W-3.3K-J------T 1
0094100071 R229 Carbon Film Resistor RT13-1/6W-3.9K-J------T 1
0094101328 R830 Carbon Film Resistor RT13-1/6W-3.3K-J------T 1
0094100029 R207 Carbon Film Resistor RT13-1/6W-4.7K-J------T 1
0094100029 R211 Carbon Film Resistor RT13-1/6W-4.7K-J------T 1
0094100029 R212 Carbon Film Resistor RT13-1/6W-4.7K-J------T 1
0094100029 R262* Carbon Film Resistor RT13-1/6W-4.7K-J------T 1
0094100029 R241 Carbon Film Resistor RT13-1/6W-4.7K-J------T 1
0094100029 R623 Carbon Film Resistor RT13-1/6W-4.7K-J------T 1
0094100721 R605 Carbon Film Resistor RT13-1/6W-5.6KΩ-J------T 1
0094100721 R606 Carbon Film Resistor RT13-1/6W-5.6KΩ-J------T 1
0094100721 R610 Carbon Film Resistor RT13-1/6W-5.6KΩ-J------T 1
0094100721 R611 Carbon Film Resistor RT13-1/6W-5.6KΩ-J------T 1
0094100072 R213 Carbon Film Resistor RT13-1/6W-6.2K-J------T 1
0094100034 R848 Carbon Film Resistor RT13-1/6W-15K-J------T 1
0094100034 R847 Carbon Film Resistor RT13-1/6W-15K-J------T 1
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
Other manuals for DTA-1486
1
Table of contents
Other Haier TV manuals
Haier
Haier D21FA11-AM User manual
Haier
Haier BH2004D User manual
Haier
Haier DTA-2196PF User manual
Haier
Haier HL42B-B User manual
Haier
Haier 29FV6 User manual
Haier
Haier LE22C2380 User manual
Haier
Haier RGBTV-25F99 User manual
Haier
Haier L24T9FD User manual
Haier
Haier TN201AUV User manual
Haier
Haier HLC26 User manual
Haier
Haier 29FA11-AM User manual
Haier
Haier LE20F6500 User manual
Haier
Haier L32A7A-A1 User manual
Haier
Haier LT22R3CWW2 User manual
Haier
Haier BH1304D User manual
Haier
Haier 34F9B-T
Haier
Haier 32E2000 User manual
Haier
Haier HL19K1 - K-Series - 19" LCD TV User manual
Haier
Haier 21FA12-AM User manual
Haier
Haier 29F9B-P User manual
