Haier HW80-B14959U1 User manual

HW80-B14959U1
HW90-B14959U1
HW100-B14959U1
HW80-B14959S8U1
HW90-B14959S8U1
HW100-B14959S8U1

Thank You EN
2
Legend
Warning – Important Safety information
General information and tips
Environmental information
Disposal
Help protect the environment and human health. Put
the packaging in applicable containers to recycle it.
Help to recycle waste of electrical and electronic ap-
pliances. Do not dispose appliances marked with this
symbol with the household waste. Return the product
to your local recycling facility or contact your municipal
Thank you for purchasing a Haier Product.
Please read these instructions carefully before using this appliance. The instructions con-
tain important information which will help you get the best out of the appliance and ensure
safe and proper installation, use and maintenance.
Keep this manual in a convenient place so you can always refer to it for the safe and proper
use of the appliance.
If you sell the appliance, give it away, or leave it behind when you move house, make sure
you also pass this manual so that the new owner can become familiar with the appliance
and safety warnings.
WARNING!
of it. Remove the door catch to prevent children and pets to get closed in the appliance.

EN Content
3
1-Safety information........................................................................................................................... 4
2-Product description......................................................................................................................... 7
3-Control panel .................................................................................................................................... 8
4-Programmes...................................................................................................................................12
5-Consumption..................................................................................................................................13
6-Daily use...........................................................................................................................................14
7-hOn....................................................................................................................................................19
8-Eco-friendly washing ....................................................................................................................22
9-Care and cleaning ..........................................................................................................................23
10-Troubleshooting ..........................................................................................................................26
11-Installation.....................................................................................................................................29
12-Technical data...............................................................................................................................33
13-Customer service........................................................................................................................34

1-Safety information EN
4
Before switching on the appliance for the rst time read the follow-
ing safety hints!
WARNING!
Before rst use
▶Make sure there is no transport damage.
▶Make sure all transport bolts are removed.
▶Remove all packaging and keep out of children´s reach.
▶Handle the appliance always with at least two persons because it
is heavy.
Daily use
▶This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental ca-
pabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
▶Keep away children under 3 years of age from the appliance un-
less they are constantly supervised.
▶Children shall not play with the appliance.
▶Do not let children or pets come close to the appliance when the
door is open.
▶Store washing agents out of reach of children.
▶Pull up zips, x loose threads and take care for small items to pre-
vent laundry from being entangled. If necessary, use an appropri-
ate bag or net.
▶Do not touch or use the appliance when barefoot or with wet or
damp hands or feet.
▶Do not cover or encase the appliance during operation or after-
wards to allow any moisture or dampness to evaporate.
▶Do not place heavy objects or sources of heat or damp on top of
the appliance.
▶Do not use or store flammable detergent or dry cleaning agent in
close vicinity to the appliance.
▶Do not use any flammable sprays in close vicinity to the appliance.
▶Do not wash any garments treated with solvents in the appliance
without having dried them previously in the air.

EN 1-Safety information
5
WARNING!
Daily use
▶Do not remove or insert the plug in the presence of flammable
gas.
▶Do not hot wash foam rubber or sponge-like materials.
▶Do not wash any laundry which is polluted with flour.
▶Do not open detergent drawer during any wash cycle.
▶Do not touch the door during the washing process, it gets hot.
▶Do not open the door if the water level is visibly over the porthole.
▶Do not force the door to open. The door is tted with a self-lock
device and will open shortly after the washingprocedure is ended.
▶
undertaking any routine maintenance and disconnect the appli-
ance from the electrical supply to save electricity and for safety.
▶Hold the plug, not the cable, when unplugging the appliance.
Maintenance / cleaning
▶Make sure children are supervised if they carry out cleaning and
maintenance.
▶Disconnect the appliance from the electrical supply before un-
dertaking any routine maintenance.
▶Keep the lower part of the porthole clean and open door and de-
tergent drawer if appliance is not in use to prevent odours.
▶Do not use water spray or steam to clean the appliance.
▶Replace a damaged supply cord only by the manufacturer, its ser-
▶Do not try to repair the appliance by yourself. In case of repair
please contact our customer service.
Installation
▶The appliance should be placed in a well-ventilated place. Ensure
a location which allows opening the door fully.
▶Never install the appliance outdoors in a damp place, or in an area
which may be prone to water leaks such as under or near a sink
unit. In the event of a water leak cut power supply and allow the
machine to dry naturally.

1-Safety information EN
6
Intended use
This appliance is intended for washing machine-washable laun-
dry only. Anytime follow the instructions given on the label of each
garment label. It is designed exclusively for domestic use inside the
house. It is not intended for commercial or industrial use.
Changes or modications to the device are not allowed. Unintended
use may cause hazards and loss of of all warranty and liability claims.
WARNING!
Installation
▶Install or use the appliance only where the temperature is above
5 °C.
▶Do not place the appliance directly on a carpet, or close to a wall
or furniture.
▶Do not install the appliance in direct sunlight or in the near of heat
sources(e.g. stoves, heaters).
▶Make sure that the electrical information on the rating plate
agrees with the power supply. If it does not, contact an electri-
cian.
▶Do not use multi-plug adapters and extension cables.
▶Make sure only the delivered electric cable and hose set are used.
▶Make sure not to damage the electric cable and the plug. If dam-
aged have it replaced by an electrician.
▶Use a separate earthed socket for the power supply which is easy
accessible after installation. The appliance must be earthed.
Only for UK: The appliance’s power cable is tted with 3-cord
(grounding) plug that ts a standard 3-cord (grounded) socket.
Never cut o or dismount the third pin (grounding). After the ap-
pliance is installed, the plug should be accessible.
▶Make sure the hose joints and connections are rm and there is
no leakage.

EN 2-Product description
7
2.1 Picture of appliance
Front (Fig. 2-1): Rear side (Fig. 2-2):
2.2 Accessories
Check the accessories and literature in accordance with this list (Fig.2-3):
Note:
-
2-3
2-1 2-2
Inlet hose-
assembly 5 Blanking
plugs Drain hose
bracket User manual
Warranty
card
Noisereduc-
tionpads
2x
2x
1 Transportation bolts (T1-T4)
2Backcover
3Backcover screws(9EA)
4Power cord
5
Water inlet valve
6Drain hose
123 4 5 6
T1
T2
T3
T4
1Detergent/Softener drawer
2
Control panel
3
Worktop
4Door
5Filter cover
6 Adjustable feet
6
4
5
Steam
冰蓝色灯珠
TM1624
6.94
13.
74
30.06
11.82
红色灯珠
6x3.5
盲孔深度2.5mm
Mix Synthetic
Allergy Care Wool Spin
Refresh
Eco40-60Remote
Quick 15’Smart
Cotton
Cotton 20°C
13
2

3-2
3-3
Mix Synthetic
Allergy Care Wool Spin
Refresh
Eco 40-60
Remote
Quick 15’Smart
Cotton
Cotton 20°C
Steam
冰蓝色灯珠
TM1624
6. 94
13. 74
30. 06
11. 82
红色灯珠
6x 3.5
盲孔深度2.5 mm
Mix Synthetic
Allergy Care Wool Spin
Refresh
Eco 40-60Remote
Quick 15’Smart
Cotton
Cotton 20°C
3-1
activated within 2 minutes before starting the program or at the end of the
18
program.
With WIFI connection, the waiting time duration is 24h.

EN 3-Control panel
9
Control panel is locked.
Steam.
Alarm.
Pre-wash.
Delay.
3.4 Function buttons
The function buttons (Fig. 3-5) enable additional op-
tions in the selected programme before programme
starts. The related indicators are displayed. o-
gramme, all options are disabled.
If a button has multiple options, the desired option can
be selected by pressing the button sequentially.
Note: Factory settings
there is no special requirement default settings are recommended.
3-5
Steam
3-4
Display symbols
Speed, Temperature, etc
3.4.1-Function button “Delay“
Touch this button(Fig . 3-6) to start the programme with a delay. End time
delay could be increased in steps of 30 minutes from 0,5-24h(End time will
longer than original programme time).For example display off 6:30 means
end of programme cycle will be in 6 hours and 30 minutes.Touch “Start/Pa
use” button to activate the time delay. It is not applicable to programme Spin,
Refresh,Remote.
3-6
Delay
Delay

3-Control panel EN
10
3.4.4 Function button “Speed“
Touch this button (Fig. 3-9) to change or deselect the spin of
the programme. If no value is illuminated the display" "the
laundry will not spin.
0
3.4.7 Function button “Start/Pause“
Touch this button (Fig. 3-12) gently to start or interrupt the
currently displayed programme.
3.4.5 Function button “Extra Rinse”
Touch this button (Fig. 3-10) to rinse the laundry more intense
with fresh water. This is recommended for people with sensitive
skin.
By touching the button several times z ero to three additional
cycles can be selected. They appear in the display with P--0/
P--1/P--2/P--3.Different programme optiones are diffrent.
3.4.2 Function button “ Steam“
Touch this button (Fig. 3-7) the steam program can be selected.
When this program is selected, the default temperature is the
max temperature of this program.You can select if you require
this function when programs"Smart,Mix,Synthetic, Cotton,Alle-
rgy Care“ are used. When you select the program "steam " the
icon light up to warn you ,the icon turns off when the program is
canceled .
When you select the program , you cannot change the temper-
ature . If you press the temperature button the program will be
canceled .Switch on the washing machine and select this program
If the washing machine is working you can not select this program .
Steam
Extra Rinse
Speed
3-9
3-10
3-11
3-7
3-8
3-12
Temp.
Temp.
3.4.3 Function button “Temp.“
Touch this button (Fig. 3-8) to change the washing temperature
of the programme. If no value is illuminated(the display" ") the
water will not heated.
--
I-time
3.4.6 Function button ””
Not all programmes can select this function. See P12 for pro-
grams that can select this function.
different washing time. 11
Note: Liquid detergent
If usingliquid detergent, it is not recommended to activate the end time delay.

EN 3-Control panel
11
3.5 Child lock
Choosing a programme and then start,touch button“ Delay” and
”Steam”( Fig .3-13) for 3 seconds simultaneously to block all
panel elements against activation,panel display .For unlo-
cking please touch again the two buttons.The child lock indi-
cator lights up when the child lock works.Feature is optional
when the machine is running.
The display shows CL0I- (Fig. 3-14) if a button will be pressed,
when the child lock is activated. The change is not running.
Speed
3-13
3-14
Steam
3.6 Detergent drawer
Open dispenser drawer,the following components can
be seen (Fig. 3-15):
1: The main washing compartment,for powder or liquid
detergent.
2: Detergent flap selector: lift it up for powder detergent,
keep it down for liquid detergent.
3: Compartment for softner.
4: Pre-wash compartment, for a small amount of pow-
der detergent.
5: Lock tab, press it down to pull out dispenser drawer.
The recommendation on the type of detergents is su-
itable for the various washing temperatures, please re-
fer to the manual of detergent.
3-15
1
4
3
2
5
The child lock which is set up manually must be cancelled manually or will be can-
celed automatically at the end of the program.Power off and error information
won't canncel child lock.It still works when the applicance is powered on next time.

1)
Water is not heated up.
*Choose 90°C wash temperature only for special hygienic requirements.
2)
Reduce detergent amount because programme duration is short.
The design and specifications are subject to change without notice for quality
improvement purposes.
3)
No or a small amount of powder detergent.
Max. load Temperature Preset
spin
speed
in rpm
Function
in kg
3)
in °C 1)
2)
Preset
Steam Extra Rinse i-time
Programme selectable
range 1 2
Fabrics type
30 1000
1000Mix
Smart
/ / / /
1200
* to 60
30 •º
Lightly soiled mixed-
laundry of cotton and
synthetic
Lightly soiled mixed-
laundry of cotton and
synthetic
Remote
1000
/
/
/
* to 40
/
* to 60
•º
/
/
/
/
Quick 15’
60
*
•
Cotton / Synthetic
1000
800Wool *
Machine-washable
fabric made of wool
or with wool content
• • •
//
•
•
• •
•
•
•••
•
1000 //
//
Cotton / Synthetic
Cotton / Synthetic
/
Detergent compartment for:
1
2
D
Detergent
etergent
Softener or care product
8/9/10
8/9/10
1
/
2/2.5/2.5
/ / /
1400
/•
Spin 8/9/10 / /
all fabrics
/
8/9/10
8/9/10
/
/
/
/
º º
•º
Cotton
/
•
Delay
• • • •
•
• •
•
/
/
•
•
/
/
HW80/HW90
/HW100
//
•
•
1000 • •• /
/
/
•º
Allergy Care
•
Refresh
Cotton 20°C
* to 90
* to 90
40 •
8/9/10 º º
Cotton
Cotton
Eco 40-60
* to 40
3
•
Yes, º Optional, / No
3
º
Synthetic or mixed
fabric
Synthetics * to 60
40 •º 4/4.5/5
2
8/9/10
º
•ºº
º º
/
/
/
º
º
4-Programmes EN
12
1
2
3

Note: Auto Weight
The appliance is equipped with a loading recognition. At low loading, energy, water and
washing time will be reduced automatically in some progr ammes. The display default time
may vary depending on the load weight, involving the “Smart,Mix,Synthetic,Cotton,Cot-
ton 20°C ,Eco 40-60” program.
Scan QR code on energy label for energy consumption information.
The actual energy consumption may differ from the declared one according to local
conditions.
EN 5-Consumption
13

6.3 Preparing laundry
▶Sort out clothes according to fabric (cotton, syn-
thetics, wool or silk etc.) and how to dirty they are --wfognillebaleracehtotnoitnettayaP.)3-6.giF(
ashing labels.
▶Separate white clothes from coloured ones.
they fade or run.
▶Empty pockets (keys, coins, etc.) and remove
harder decorative objects (e.g. brooches).
▶
into a wash bag to care for this delicate laundry
(hand or dry cleaning would be better).
▶Close zippers, velco fastener and hooks, make
sure the buttons are sewn on tightly.
▶
hem, delicate underwear (Dessous) and small
items such as socks, belts, bras, etc. in a wash
bag.
▶Unfold large pieces of fabric such as bed sheets,
bedspreads etc.
▶Turn jeans and printed, decorated or color-inten-
sive textiles inside out; possibly wash separately.
6.1 Power supply
Connect the washing machine to a power supply
(220V to 240V~/50Hz; Fig. 6-1). Please refer also to
section INSTALLTION (see P29).
6.2 Water connection
▶Before connecting check the cleanliness and clar-
ity of the water inlet.
▶Turn on the tap (Fig.6-2).
Note: Tightness
Before use check for leakage in the joints between the tap and the inlet hose by turning on
the tap.
CAUTION!
Non-textile, as well as small, loose or sharp-edged items may cause malfunctions and
damage of clothes and appliance.
6-3
6-1 6-2
6-Daily use EN
14

Care chart
Washing
Washable up to 95°C
normal process Washable up to 60°C normal process Washable up to 60°C mild process
Washable up to 40°C
normal process Washable up to 40°C mild process Washable up to 40°C very mild process
Washable up to 30°C
normal process Washable up to 30°C mild process Washable up to 30°C very mild process
Wash by hand
max. 40°C Do notwash
Bleaching
Any bleaching allowed Only oxygen/
non-chlorine Do not bleach
Drying
Tumbledryingpossible
normal temperature Tumbledryingpossible lower temperature Do not tumble dry
Line drying Flat drying
Ironing
Iron at a maximum
temperature
up to 200 °C
Iron at a medial tem-
perature
up to 150°C
Iron at a low temper-
ature up to 110 °C;
withoutsteam(steam
ironing may cause irre-
versible damage)
Do not iron
Professional Textile Care
Dry cleaning in tetra-
chloroethene Dry cleaning in hy- drocarbons Do not dry clean
Professional wet clean Do not professional
wet clean
6.4 Loading the appliance
▶Put in the laundry piece by piece.
▶
thumb for maximum load: Keep six inches between load and drum top.
▶Close the door carefully. Make sure that no pieces of laundry are pinched.
EN 6-Daily use
15

6.5 Selecting detergent
▶
▶Use only machine wash approved detergent.
▶
▶See tips for countertop detergent stickers.
.
▶Do not use dry cleaning agents such as trichloroethylene and similar products.
Choose the best detergent
Programme
Kind of detergent
Universal Colour Delicate Special Softener
Smart L/P L/P - - o
Mix L-
L/P -
Synthetic -
Quick 15’ L/P L
- L/P
- -
Refresh - - -
o
Cotton 20°C L/P L/P -
Remote L/P L/P - L -
-
Cotton - - L/P L/P o
Allergy Care
L/P L/P - - o
Wool - L/P L/P o
Spin - - - -
Eco 40-60 L/P L/P - - o
L = gel-/liquid detergent P = powder detergent O = optional _= no
If using liquid detergent, it is not recommended to activate the time delay.
We recomment by using:
▶Laundry powder: 20°C to 90°C* (best use: 40-60°C)
▶Color detergent: 20°C to 60°C (best use: 30-60°C)
▶Wool/delicate detergent: 20°C to 30°C (best use:20-30°C)
* Choose 90 °C wash temperature only for special hygienic requirements.
If you choose the water temperature 60°C or above,we would like to advise you to use
less detergent.Please kindly use the special disinfectant,which is suitable for cotton or
synthetic cloth.
*
* It is better to use less or free suds detergent powder.
-
-
-
o
o
-
o
-
6-Daily use EN
16

6.7 Switch on the appliance
6.6 Adding detergent
1. Slide out the detergent drawer.
2. Put the required chemicals into corresponding
compartments (Fig. 6-4),
3. Push back the drawer gently.
Note:
▶Remove detergent residues before next wash cycle from the detergent drawer.
▶Do not overuse detergent or softener.
▶Please follow the instruction on the detergent package.
▶
▶Concentrated liquid detergent should be diluted before adding.
▶Do not use liquid detergent if function “Delay“ is selected.
▶Carefully choose the programme settings according to the care symbols on all laun-
dry labels and according to the programme table.
6.8 Select a programme
To get the best washing results, select a programme
type.
Turn the programme knob (Fig. 6-6) to select the right
programme. Related programme LED lights up and
the default settings are displayed.
6.9 Add individual selections
Select required options and settings (Fig. 6-7); refer to
Control Panel.
6-5
6-6
Note: Odour removal
amount of detergent in washing agent compartment (2) or special
“COTTON+90 °C+600rpm”
cleaner to remove possib
machine ly corruptive residues.
6-7
(Fig. 6-5). The LED of the „Start/Pause“ button is flas-
hing.
PowerTouch
Steam
Mix Synthetic
Allergy Care Wool Spin
Refresh
Eco 40-60
Remote
Quick 15’Smart
Cotton
Cotton 20°C
6-Daily use
17
EN
1
3
2
6-4

1. At programme cycle end EnD is displayed.
2.
3. Remove laundry as soon as possible to go easy on it and to prevent more wrinkling.
4.
5. Unplug the power cord.
6. Open the door to prevent formation of moisture and odours. Let it open while not used.
6.13 Activate or deactivate the buzzer
The acoustic signal can be deselected if necessary:
1. Switch on the appliance.
2. Select the programme.
e “Steam“ button and “Speed” button at the same time for about 3 sec-hthcuoT.3
onds. “
bEEP oFF ” will be displayed and the buzzer will be deactivated.
For activating the buzzer touch these two buttons at the same time again. “ bEEP on ”
will be displayed.
To interrupt a running programme press gently “Start/Pause“. The LED above the button
is flashing. Press it again to resume operation.
To cancel a running programme and all its individual settings:
1. Touch”Start/Pause” button to interrupt the running programme.
2.
3.
4. After closing the programm to restart the appliance,select a new programme and
6.12 After washing
Note: Door lock
For safety reasons the door is locked partially during the washing cycle. It is only pos-
sible to open the door atthe end of the programme or after the programme was can-
celled correctly (see description above).
In case of high water level, high water temperature and during spinning it is not pos-
sible to open the door; is displayed.
Note: Standby-mode / energy-saving mode
The switched on appliance will go into standby-mode if it will not be activated within 2
This saves energy. To interrupt the standby mode touch
6.10 Start wash programme
Touch“Start/Pause“ button (Fig. 6-8) to start. The LED of the”Start/
Pause“button stops flashing and lights up continuously.
Appliance operates according to present settings.
Changesareonlypossiblebycancellingtheprogramme.
6.11 Interrupt / cancel wash programme
6-8
PowerTouch
tcelesdnanipSemmargorpnur,ecnailppaehtnonrutotnottub"rewoP"ehthcuoT .retawehtniardot)ffoerasthgildeeps("deepSon"
.nottub"rewoP"
XIM
start it.
meme
▶
▶
6-Daily use EN
18

EN 7-hOn
19
Note: Deviations
Due to constant updates of hOn,the functions and the display interface of the APP
7.1 General
WARNING!
Please observe thesafety precautions in this user manual andmake surethat these
are complied even when operating the appliance via the hOn APP while you are
7.2 Requirements
One wireless router which supports only the band
of of is 1-31 1 and and pas-
The App is available for devices running Android, Huawei or iOS, both for tablets and
for smartphones.
The appliance shall be installed in a position where it can receive a strong Wi-Fi signal.
Once the appliance has been correctly associated with the APP, if it's not properly
connected to the wireless router, no Wi-Fi icon appears on the display
7.3 Download and installation of hOn APP:
Download the hOn App on your device
Note: Registration
closed. For further use, you need to enter user name and password when you log in.
or by the link: go.haier-europe.com/download-app

7-hOn EN
20
Note: W F network
i
malfunction.
7
to.
Note: Use same Wi Fi
ontrol
Note:
7 emote ontrol
1.
control panel. emote
2.
emote
4.
7 7 nd of ycle ith emote ontrol n
1.At the end of the cycle, the door will unlock and the remote control will deactivate.
2.After 2 minutes the appliance will automatically switch off.
Once the remote control is activated, if the end user doesn’t start any cycle from app in
10 minutes, the appliance will go to Networked Delay Start Mode, and keeps remote
control up to 24 hours, then shut off.
Select the “Remote” program
