Haier HWM120-01 User manual

Please read this manual carefully
before using.
Retain it for future reference.
User's manual
Full Automatic Washing Machine
This manual is for
HWM120-01/XQB120-01

Names of the parts............................ ....... .............. ....... .....1
Safety precautions .............................................. ....... ...........2
Installation and adjustment ............................. ....... .............. 4
Install the water inlet hose.............................. ....... .............. 6
Preparation before washing ........................ ....... ................. 8
Put in the laundries ........................................ ....... ............... 9
Usage of the detergent ............................... ....... ...... ............10
Use the operation buttons ......................... ....... ............... ..11
Close the top lid ......................................... ....... .......... ...... ..15
Finish washing ..................................... ....... ....................... ..15
Disposal after washing .............................. ....... .............. ......16
Trouble shooting Answer to question.................. ....... ...........17
Packing list................................................. ....... ....... .............18
Specification .................................. ............... ....... ................18
CONTENTS

Names of the parts
Top lid, I
Detergent box
Location of lint filter
Control panel seat
Inner tub
Control panel film
Pulsator
Cabinet
Lower cabinet
Top lid, II
Adjustable foot
Power cord
Drain hose
Fixing foot
(three)
Water absorption cushion Water inlet valve
Handle
Drain hose hanging hole
Back cover
Level meter
Meaning and description of the symbols
Contents marked with that symbol are actions forbidden
to perform. Performing of those action may result in damage of
the machine or influence the personal safety of the users.
Contents marked with that symbol are related to the
safety of the product and the personal safety of the users.
Please operate in strict conformity to the contents.
Warning sign
Forbidden sign

The ventilation
holes at the bottom
Soft object
Safety precautions
Do not put the machine at damp place like
the bathroom. Never wash it with water.
In case the washing machine is installed on ground with
carpet, do not block the ventilation hole with carpet.
Do not let the machine share one receptacle with other electric appliances. If the power plug is damaged, or the
plugging into the receptacle is loose, do not use the plug any more.
Do not wash water-proof laundries like the raincoat,
bike covers etc. to avoid abnormal vibrations in spinning.
Do not use water hotter than 50 C .
Please plug the power plug on special
receptacle. Be sure to use three-pins
power receptacle.Ensure that the earthing
prong of the power receptacle is earthed
reliably. Use leakage protector if possible.
In normalusage of the washing machine,
the power plug shall be ready to be pulled
or plugged with hand. Be sure to pull the
plug off and close the water faucet in
following cases: power failure, delivering
the machine, setting the machine idle or
cleaning the machine. Do not plug
or pull the power plug with wet hand.
Do not bend, stretch, twist, bind the power cord by force,
or reform it. Do not press or clamp it with heavy items. If the
power cord and power plug are bad, or the receptacle is loose,
be sure to have it replaced by the technicians of ourspecial shop
or our agent, or the after-sales service department for the sake
of avoiding any risk. Keep the prong of the power plug clean.
If dustis found on the power plug, please wipe it offwith dry cloth.

Do not stretch hands into the working machine.
It is dangerous even if the rotation is slow.
Take special care of the children.
Do not decompose, repair or alter the machine
by yourself.
Do not put any hot or heavy items (such as the kettle
with hot water) on the washing machine
Do not wash laundries with volatile materials
(such as thinner, petrol etc.).
Keep the machine away from direct sunlight and
heat source like the heater.
The handicapped or children without care shall not
use the machine.
The lint filter shall be kept in good condition, and
installed to proper position. If the lint filter is lost
or damaged, please contact the local after-sales
service department of our company.
Benzene
Safety precautions

Please install and adjust the machine according to the requirement of the manual.
It is very important to your security and correct operating the machine.
Installation and adjustment
Install the lint filter
After opening the package, please take out the
lint filter from the document bag and install it
into the Filter frame of the inner tub. See to the right Figure.
Lint filter
Filter frame
The largest allowed slope of the shank base of the machine is 2 . The slanting or rough ground will result in
unstable running or stoppage of the machine. Please adjust it with following methods:
Confirm it's horizontal
Hang the plumb to confirm it's horizontal
Adjust the Installation position
Adjust the adjustable foot
(1) To twist theadjustable foot atthe right frontof
the cabinet (front the sight of front),please first
lift up theside of thefoot slightly, loosen the
adjustable nut, andtwist the foot.
(2) Fasten thenut after adjustment.
Loosen Fasten
High Low
adjustable nut
adjustable foot
Confirm it's horizontal:
If the bulb of the level meter at the balance display
position is inside the standard circle, it indicates that
the machine is horizontal. Otherwise you need to
adjust the adjustable leg of the machine.
Air bubble
Standard circle
Suitable Not suitable

1.The height of the drain hose shall be
less than 10cm, or the drainage will not
be smooth, and cost such long time that
the machine may stop at mid way.
2.Do not ramp or press the drain hose.
3.If the drain hose is too long, cut it at mid
point. To make smooth drainage, cut the
front end of the hose slantingly.
4.If extra drain hose is needed, please
make separate purchase. The inner
diameter of the extra hose shall not
less than 40mm, and the length shall
not exceed 1.5m.
1.Lean the machinedown gently withthe front
surface facing theground.
3.Extend the drain hose from the left side. Push the
drain hose into the groove with hands.
2.Pull out the drain hose from the groove at the left side.
Back
Front
Soft item
Use groove at
this side after
direction changing
How to change the direction of the drain hose
Usage of the drain hose
The drain hoseshall drain smoothly
If the extrahose is toolong, cut it
either atA orat B point.

The exit end face of the faucet
Confirm the water faucet
Connection between the water inlet hose jointer and the water faucet
water faucet, suitable water faucet, not suitable
It is required that the front end shall be longer than 10mm.
The exit end face of the faucet shall be flat and smooth. If not please file it to avoid leakage.
2 Loosen the screw till the water faucet can be accessed. Put the jointer of the water inlet hose on the faucet.
See to Figure 2. (If the faucet is too large and the jointer can not be set on the water faucet, please loosen
the four screws and take out the bushing in the jointer. The front end of the faucet must be smooth, otherwise
it may leak water. See to Figure 3.)
1.Press the lower end of the lock lever and push down the slider. Take off the water inlet hose jointer from the
water inlet hose component. See to Figure 1.
3.Fasten the four screws evenly. See to Figure 4.
>10mm
about 4mm after twisting
Remark: .Before twisting the fastening nut, the threading is 4mm above the upper
surface of the nut. After twisting, the threading is less than 2mm above the upper
surface of the nut. See to Figure 6
About above 2mm after twisting
water inlet hose jointerwater inlet hose jointer
Screw knife
Screw
Bushing
Nameplate
Screw nut
water inlet hose Figure 1
Figure 4
Figure 2
Figure 5
Figure 3
Figure 6
Slider
Lock level
Install the water inlet hose
4 Take off the nameplate. Twist the fastening nut as per the indication of the figure
to seal up the exit end face of the faucet. See to Figure 5.

Connection between the water inlet hose and the washer
Dismantle the water inlet hose
Connection between the jointer of the water inlet hose and the
water inlet hose
Check the connection between the jointer of the water inlet hose
and the water faucet
1.Do not take off the water absorption cushion. Please check if the
cushion is dropped or damaged before each usage. If it happens
please contact our after-sale department immediately.
1.Swing the hose gently to confirm if it is fastened stable.
2.After installation, open the faucet to check if it leaks.
3.Do not bend the hose with overstrain.
1.Push down the slider. Insert the water inlet hose into the jointer.
2 Hang the lock lever to the jointer. Release the slider till a click sound is heard.
Locking level
Slider
water absorption cushion.
nut of the waterinlet hose
the jointer of the water inlet hose
Slider
Locking level
jointer of the waterinlet valve
1. Close the water faucet.
2. Press the locking lever. Push down the slider. Then pull of the water inlet hose.
If the machine is used frequently, the jointer of the water inlet hose can be kept
on the faucet to prevent damaging the fixing screw.
2 Put the nut of the water inlet hose on the valve jointer.
3 Fasten the nut. Swing it gently to confirm if it's suitable.
4.Before each usage please check if the connection
between the jointer of the water inlet hose and the
water faucet, and the installation of the water inlet
hose are firm, so as to prevent dropping from
improper installation position.

1 Preparation before washing
Pay attention to followings before washing the laundries
Preparation before washing
1.Connect the water inlet hose. Open the water faucet.
2.Confirm that the washing machine is earthed reliably.
Then insert the power plug into the receptacle. The
earth terminal shall not link to gas pipeline and
faucet water pipeline.
3.Put up the drain hose.
Pay attention to followings before washing the laundries
Check if
the laundries
has special
requirement
on washing
Clear the
pocket. Take
out the coins,
sand, hairpins
etc.
Tie the long
strips; fasten
the buttons;
close zippers.
When the pulsator
is running , the
buttons of the
laundries may
cause noise. For
the sake of
discretion, please
put the laundries
with buttons into
other laundries.
The quantity of
the laundries
shall not be too
large. Stretch
and loosen the
laundries before
putting them in
the tub.
a. Check if the laundries are applicable for washing with machine.
b. Divide the laundries that are not colorfast from other laundries.
c. Put those laundries difficult to absorb water into water with hand.
d. For those laundries with heavy soil, please first remove the dirt like mud or dust.
For the parts with heavy soil, please apply detergent on them in advance, which
can make it easier to remove the soil.
e. For those laundries that may get lint ball and those with long fur, turn it over before
putting in.
f. Do not put those laundries polluted by chemicals into the washing machine directly.
