Operating Manual
Hakomatic B115R (7090.11/.21/.35/.41/.51/.81/.91)

2
Preface
Dear Customer,
We are certain that the excellent quali-
ties of the vehicle will justify the faith
you have shown in us through your pur-
chase.
Please read the Chapter "Safety Infor-
mation" prior to starting the vehicle to
ensure it is operated and used safely.
Your safety, and that of others, basical-
ly lies in your ability to control and oper-
ate the vehicle. Before using the
equipment for the first time, read this
original manual thoroughly, act accord-
ing to the information contained and
keep it in a safe place for future refer-
ence or subsequent owners. The oper-
ating manual contains all the most
important information regarding opera-
tion, maintenance and service.
Throughout this manual, texts which
concern safety are indicated by the cor-
responding danger pictogram. Should
you have any questions in respect of
the vehicle or operating instruction
manual, your authorized Hako dealer is
available to provide help at any time.
You are expressly advised that you
cannot base any legal claims on the in-
formation contained in this manual. En-
sure only original spare parts are used
should any repairs be necessary. Only
such original spare parts warrant that
the equipment is reliably ready to use at
all times. We reserve the right to make
technical modifications in the interest of
further development.
Valid as of: September 2011
Hako-Werke GmbH
D-23843 Bad Oldesloe
Hamburger Str. 209-239
Tel. ++49 (04531) 8060
Intended use
The Hakomatic B115R is a scrubber
dryer for the wet cleaning of hard floors.
Any use beyond this is regarded as im-
proper use. The manufacturer is not
considered liable for any damage re-
sulting from improper use; the user is
solely responsible for all the potential
risks involved. Intended use also in-
cludes maintaining and observing the
operating, maintenance and repair con-
ditions prescribed by the manufacturer.
The Hakomatic B115R may only be op-
erated, serviced and repaired by per-
sonnel who are familiar with the work
involved and are aware of the risks.
The applicable accident prevention
laws must be observed and any gener-
ally accepted health and safety direc-
tives must be maintained. The
manufacturer is not deemed liable for
any damage resulting from unauthor-
ized modifications to the vehicle.
Introduction

3
Based on the conception, design and
construction of the model introduced
onto the market by us, the machine
complies with the applicable basic safe-
ty and health requirements stipulated in
the EC directives (refer to the Declara-
tion of Conformity). The EC Declaration
of Conformity is no longer considered
valid in the event of modifications to the
machine not authorized by us.
The manufacturer is not deemed liable
for any damage resulting from unau-
thorized modifications to the vehicle.
Notes on warranty
The terms defined in the purchase
agreement apply. Claims for compen-
sation related to damage are excluded
from the terms of warranty when the
damage is the result of failure to ob-
serve regulations concerning service
and maintenance. Maintenance work
must be performed by authorized Hako
service centers and confirmed in the
“Maintenance Report” which serves as
a warranty logbook.
The following are excluded from the
terms of warranty: wear and tear
through overuse, defective fuses, im-
proper handling and use or unauthor-
ized modifications. Claims under the
terms of warranty are annulled when
damage occurs to the vehicle resulting
from the use of parts or accessories not
explicitly approved by us or from failure
to observe maintenance regulations.
Acceptance of the vehicle
The vehicle must be inspected directly
after delivery for signs of transport dam-
age. Replacements for transport dam-
age will be made when confirmation is
provided immediately by the transport-
ing company with regard to the damage
and send the damage report to us to-
gether with the consignment note.
Introduction

4
Table of Contents
Preface. . . . . . . . . . . . . . . . . . 2
Intended use . . . . . . . . . . . . . 2
Notes on warranty . . . . . . . . . 3
Acceptance of the vehicle . . . 3
1 Safety Information . . . . . . . . 6
1.1 Safety and warning labels . . . 6
1.2 General information . . . . . . . . 7
1.3 Operating information. . . . . . . 7
1.4 Maintenance information . . . . 8
1.5 Particular risks . . . . . . . . . . . . 9
1.6 Environmental protection . . . 10
1.7 Labels on the vehicle . . . . . . 11
2 Operation . . . . . . . . . . . . . . 15
2.1 Unpacking . . . . . . . . . . . . . . 15
2.2 Prior to starting up for the first
time . . . . . . . . . . . . . . . . . . . 15
2.2.1 Instruction. . . . . . . . . . . . . . . 15
2.2.2 Assembling the squeegee . . 15
2.2.3 Battery type . . . . . . . . . . . . . 16
2.2.4 Installing the trough battery . 17
2.2.5 Installing the driving/block
battery . . . . . . . . . . . . . . . . . 18
2.2.6 Checking the battery plugs. . 19
2.2.7 Initial battery charge. . . . . . . 19
2.3 Cleaning operation. . . . . . . . 20
2.3.1 Check the battery charge. . . 21
2.3.2 Charging the battery. . . . . . . 21
2.3.3 Emptying the waste water tank
23
2.3.4 Filling the clean water tank. . 24
2.3.5 Adjusting the driver's seat . . 25
2.3.6 Switching the vehicle on. . . . 26
2.3.7 Charge status indicator . . . . 27
2.3.8 Switching the vehicle off. . . . 28
2.3.9 After completing cleaning. . . 29
2.4 Service code table . . . . . . . . 30
2.5 Loading and transporting . . . 31
2.6 Special equipment and
accessories . . . . . . . . . . . . . 32
3 Operation . . . . . . . . . . . . . . 34
3.1 Method of operation . . . . . . . 34
3.2 Operating and indicator
elements. . . . . . . . . . . . . . . . 35
3.2.1 Left-hand operating panel . . 35
3.2.2 Right-hand operating panel . 37
3.2.3 On the vehicle . . . . . . . . . . . 43
4 Technical Data . . . . . . . . . . 46
5 Maintenance and
Service . . . . . . . . . . . . . . . . 49
5.1 Hako system maintenance. . 49
5.2 Proof of Maintenance . . . . . 50
5.3 Maintenance Plan . . . . . . . . 51
5.4 Battery system . . . . . . . . . . . 55
5.4.1 Water filling system . . . . . . . 56
5.4.2 Charge status indicator (TSG) .
56
5.4.3 Servicing the driving batteries .
56
5.4.4 Disposing of batteries. . . . . . 56
5.5 Waste water and clean water
tank . . . . . . . . . . . . . . . . . . . 57
5.5.1 Cleaning the clean water tank .
58
5.5.2 Cleaning the clean water filter .
58
5.5.3 Cleaning the waste water tank.
58
5.6 Disk brush head . . . . . . . . . . 59
5.6.1 Cleaning the brushes . . . . . . 60
5.6.2 Changing the brushes . . . . . 60
5.7 Cylindrical brush head . . . . . 61
5.7.1 Emptying the dirt hopper . . . 62

5
Table of Contents
5.7.2 Disassembling the brushes . 62
5.7.3 Installing the brushes . . . . . . 62
5.8 Deflector. . . . . . . . . . . . . . . . 63
5.8.1 Pivoting the deflector away . 63
5.8.2 Changing the deflector rubber .
63
5.9 Squeegee. . . . . . . . . . . . . . . 64
5.9.1 Cleaning the squeegee . . . . 65
5.9.2 Changing the sealing strips . 65
5.9.3 Adjusting the sealing strips. . 66
EC Declaration of Conformity
69

6
Safety Information
1 Safety Information
1.1 Safety and warning labels
All information related to personal safe-
ty, safety of the vehicle and environ-
mental protection are assigned the
following symbols throughout the oper-
ating manual:
Symbol Hazardous for ... Definition
Danger persons
or property Safety information to prevent the development of haz- ardous situations resulting from ignoring or failing to
follow instructions or prescribed work procedures.
Note the equipment Important information on handling the equipment in
order to maintain its functionality.
Ecological hazard the environment Ecological hazard through the use of substances
which represent a potential hazard to health and the
environment.

7
Safety Information
1.2 General information
• In addition to the information provid-
ed in this operating manual, all the
legally applicable health and safety
provisions must be observed.
• Before starting up the vehicle for the
first time, read the operating manual
supplied with it thoroughly as well as
any separate manuals provided with
additional or attachment devices and
observe all the information during
work.
• The vehicle may only be operated,
serviced and repaired by personnel
trained by Hako technical experts.
• Particular attention should be paid to
the information regarding safety.
Technical expertise is the key to pre-
venting errors when operating the
equipment and ensuring trouble-free
operation.
• The operating manual must always
be kept at the operating location of
the vehicle and, as a result, should
kept in a safe place on the vehicle.
• If the equipment is sold or rented out,
these documents should be trans-
ferred to the new owner/operator.
The transfer should be confirmed!
• The warning labels attached to the
equipment provide important infor-
mation concerning safe operation.
Labels which are illegible or missing
must be replaced.
• Original spare parts must be used to
ensure safety.
1.3 Operating information
• Before starting the vehicle up for the
first time, the battery to be used must
be fully charged, properly, by imple-
menting the initial battery charge
routine. Please pay attention to the
operating manual provided with the
charging unit as well as the manual
from the battery manufacturer. Hako
assumes no liability for damage to
the battery caused by a fault when
the battery is charged for the first
time.
• Check the operational safety of the
vehicle each time before starting it
up! Clear any faults immediately!
• Before starting work, the operator
must be fully familiar with all adjust-
ment, operating and control ele-
ments as well as their respective
function! It is too late to do this when
the vehicle is actually in operation!
• Always wear heavy duty, non-slip
footwear when working with the vehi-
cle.
• The vehicle may only be driven and
the equipment used on those surfac-
es which have been approved by the
contractor or person appointed by
him.

8
Safety Information
• When using the vehicle, it is essen-
tial to pay attention to third parties,
especially children.
• Start driving immediately after
switching on the brush head drive
otherwise imprints of the brush could
be produced on the floor. Always
raise the brush head before driving
over thresholds.
• Only use cleaning agents suitable for
the vendor (non-foaming) and ob-
serve all the use, disposal and warn-
ing information provided by the
cleaning agent manufacturer.
• Never vacuum up any explosive flu-
ids, undiluted acids or solvents! Ex-
amples of these include gasoline,
paint thinner and heating oil, which
can form explosive gases or mix-
tures when swirled up with the vacu-
umed air, and also acetone,
undiluted acids and solvents if they
corrode materials in the vehicle.
• For safety reasons, the driver's seat
is equipped with a seat contact
switch. The vehicle can only be start-
ed when the operator is sitting on the
driver's seat. The function of the seat
contact switch must not be by-
passed.
• The vehicle is not suitable for clear-
ing up hazardous, inflammable or
explosive fluids, dust or substances.
• It is forbidden to use the vehicle in
potentially explosive atmospheres.
• It is forbidden to transport persons or
heavy objects.
• It is forbidden to tow machines or op-
erate as a trailer.
• Remove the ignition key to prevent
unauthorized use of the vehicle.
• When driving the vehicle to the area
of use, the squeegee and brush
head must be raised. The style of
driving must be adapted to the local
conditions.
• The vehicle has been conceived for
use on level surfaces with a maxi-
mum gradient of 2%.
• Drive slowly on wet ground due to
the risk of skidding, particularly when
cornering. Drive especially slowly
when cornering while driving down-
hill.
• Only drive uphill on gradients up to
10% for maximally 1 minute and with
the utmost care.
1.4 Maintenance information
• Operating personnel must complete
the necessary daily and weekly
maintenance work. All other mainte-
nance work must be completed at
your nearest authorized Hako ser-
vice center.
• The maintenance work and mainte-
nance intervals prescribed in the op-
erating manual must be adhered to.
• Suitable tools must be used for
cleaning and maintenance work.
• The vehicle must be inspected by a
recognized technical expert in re-
spect of operational safety, within
the terms of the applicable accident
prevention laws, at reasonable inter-
vals (we recommend at least once a
year) and following modification or
repairs .
• Spare parts must comply with the
minimum technical requirements
stipulated by the manufacturer! This
is ensured by the use of original
spare parts.
• The vehicle and motors must be
switched off prior to cleaning or ser-
vicing it or to replacing parts.
• Remove the ignition key to prevent
unauthorized use of the vehicle.

9
Safety Information
• Always disconnect the battery plug
before starting any work on the elec-
trical installation.
• It is not permitted to clean the vehicle
with a pressure washer or steam
blaster.
• It is not permitted to use aggressive
and corrosive cleaning agents.
• Allow the vehicle to dry after being
cleaned, e.g. over the weekend.
• Only start the vehicle up when all the
safety equipment has been installed
and brought to its protecting position.
• When working in the area of the
raised waste water tank, it must be
opened fully to prevent it accidentally
slamming shut.
1.5 Particular risks
Electronics
• Only use original fuses with the pre-
scribed amperage.
• In the case of defects in the electrical
installation, switch the vehicle off im-
mediately and clear the fault.
• Work on the electrical equipment
may only be carried out by electri-
cians who have received the neces-
sary training and in accordance with
the electrical engineering regula-
tions.
• The vehicle's electrical equipment
must be inspected/checked at regu-
lar intervals. Defects, such as loose
connections and cable damage,
must be rectified immediately.
Batteries
• Observe the information in the oper-
ating manual provided by the battery
manufacturer.
• Batteries may only be handled and
changed by properly skilled mainte-
nance personnel.
• Due to a change in the center of
gravity, only approved batteries may
be installed at the intended position.
• Never lay any metallic objects or
tools on batteries - risk of short cir-
cuit!
• Ensure sufficient ventilation in the
charging area when charging the
batteries – risk of explosion!
• To prevent creeping currents,
always keep the batteries clean and
dry and protect from becoming
soiled, e.g. by metal dust.
• Batteries must not be connected or
disconnected when live.
• When closing the seat console, pay
attention that no cables are dam-
aged.
• It is forbidden to eat, drink and
smoke in battery charging rooms.
• Wash you hands thoroughly after
handling batteries.
• For further safety information, see
supplementary sheet 88-60-2556 -
Notes on driving batteries.
Safety equipment
• Never operate the vehicle without
the hood being closed and locked
(safety regulation)!

10
Safety Information
1.6 Environmental protection
• Personnel must have the necessary
skills when working with substances
which represent a risk to health and
the environment, e.g. oils and lubri-
cants.
• Always observe the applicable legal
regulations and local directives when
disposing of refuse, waste water and
cleaning agents, also refer to the
German Water Resources Act
(WHG).
• Used batteries must not be thrown in
the household waste.

11
Safety Information
1.7 Labels on the vehicle
The following safety and warning labels
are attached to the vehicle where easily
legible. Missing or illegible labels must
be replaced immediately.
Company logo (Fig. 1/1)
Machine model (Fig. 1/2)
Rating plate (Fig. 1/3)
Water temperature, max. 50°(Fig. 1/4)
Label: Do not step on deflectors!
(Fig. 1/5)
Read and observe the operating
manual (Fig. 2/6)
Label: Explosive gases! (Fig. 2/7)
Label: Water overflow! (Fig. 2/8)
Waste water drainage (Fig. 3/9)
Clean water drainage (Fig. 3/10)
Label: Working width (Fig. 3/11)
Hakomatic B115R
XXX/XX

12
Safety Information
Fig.1
1
1
2
3
4
5

13
Safety Information
Fig.2
6
7
8

14
Safety Information
Fig.3
10
9
11

15
Operation
2 Operation
2.1 Unpacking
Remove the packaging and take the
Hakomatic B115R from the pallet after
loosening the tightening straps.
2.2 Prior to starting up for the
first time
2.2.1 Instruction
Operators must receive instruction be-
fore the vehicle is put into service. Only
technicians from your local authorized
Hako dealer are allowed to provide ini-
tial instruction on the machine. The
manufacturing plant will notify the deal-
er immediately after delivering the vehi-
cle and the dealer will contact you to
arrange a date.
2.2.2 Assembling the squeegee
1. Use the star-shaped knobs (Fig. 4/1)
to fix the squeegee on the squeegee
lift (Fig. 4/2).
2. Connect the suction hose (Fig. 4/3)
to the nozzle (Fig. 4/4).
Fig.4
1 4 123

16
Operation
2.2.3 Battery type
Various batteries can be selected for
use with the Hakomatic B115R. Refer
to the table for the various battery types
and it must then be set in the Configura-
tion menu. The settings can only be
made at an authorized Hako service
center!
Battery type Order no.
Trough battery 24 Volt/320 Ah - PzS low-maintenance
Trough battery 24 Volt/280 Ah - PzV maintenance-free
Driving battery 6 Volt/180 Ah - GiV maintenance-free
Block battery 6 Volt/240 Ah - GiV maintenance-free
745002
7451
7411
7401

17
Operation
2.2.4 Installing the trough battery
1. Switch off the vehicle with the key
switch and secure it by applying the
parking brake.
2. Open the seat console (Fig. 5/1).
3. Install the battery (Fig. 5/2) in the
battery trough accordance with illus-
tration.
Replacing/Installing is only
possible with the aid of a crane
and appropriate lifting gear.
Please read the information
provided in the operating man-
ual of the battery manufactur-
er. Trough batteries weigh up
to 280 kg. For reasons of safe-
ty, we strongly recommend
having this work completed at
an authorized Hako service
center.
4. Check the battery plug (Fig. 5/3),
refer to Section 2.2.6.
Fig.5
1
2
3

18
Operation
2.2.5 Installing the driving/block
battery
1. Switch off the vehicle with the key
switch and secure it by applying the
parking brake.
2. Open the seat console (Fig. 6/1).
3. Position the batteries in the battery
tray in accordance with the figure.
Replacing/Installing is only
possible with the aid of appro-
priate lifting gear. Please read
the information provided in the
operating manual of the bat-
tery manufacturer. For reasons
of safety, we strongly recom-
mend having this work com-
pleted at an authorized Hako
service center.
4. Connect the battery poles in accor-
dance with the connection diagram
(Fig. 6/2).
5. Pay attention they are firmly fixed
and grease the poles.
6. Check the battery plug (Fig. 6/3),
refer to Section 2.2.6.
Fig.6
1
2
3

19
Operation
2.2.6 Checking the battery plugs
The battery plugs (Fig. 7/1 and 2) on
the vehicle, batteries and stationary
chargers must be coded with the col-
ored coding pins (Fig. 7/3) according to
the battery and nominal voltage. The
connectors on the charger are coded at
the factory according to the charge
characteristic curve so that on changing
the charge characteristic curve (accord-
ing to the battery), the connector coding
must be changed.
Fig.7
Connector coding
Socket housing of the battery:
• Gray for wet batteries
• Green for maintenance-free gel bat-
teries
Connector body on the vehicle:
• Yellow for both battery types
Voltage coding
Insert the coding pin (Fig. 7/3) so that
the nominal voltage can be read
through the window in the housing.
Always select the same nominal volt-
age for the socket and connector.
The following three conditions must be
fulfilled for the complete system:
1. The voltage coding must be the
same for all connectors and sockets.
2. The color of the coding pin in the
vehicle is yellow.
3. The color of the coding pin in the
charger connector (vehicles without
built-in charger) complies with the
battery plug.
2.2.7 Initial battery charge
Before starting the vehicle up
for the first time, the batteries
to be used must be fully
charged, properly, by imple-
menting the initial battery
charge routine. Please pay at-
tention to the operating manual
provided with the charging unit
as well as the manual from the
battery manufacturer. Hako
assumes no liability for dam-
age to the battery caused by a
fault when the battery is
charged for the first time.
1
24 V 24 V
36 V
36 V
3
2

20
Operation
2.3 Cleaning operation
Read and follow the safety in-
formation in Chapter 1 before
operating the vehicle.
1. Check the parking space for signs of
leaks. Hoses, lines and tanks must
show no signs of leaks or damage.
2. Check the battery charge, refer to
Section 2.3.1.
The current charge status ap-
pears in the indicator field.
Charge the battery, if neces-
sary, refer to Section 2.3.2.
3. Drain off the waste water tank, refer
to Section 2.3.3.
You are informed the waste
water tank is full via the indica-
tor field.
4. Fill the clean water tank, refer to Sec-
tion 2.3.4.
The maximum temperature is
50°C.
5. Adjust the driver's seat, refer to Sec-
tion 2.3.5.
6. Lock the side deflector.
7. Switch on the vehicle with the key
switch and set the required driving
direction using the driving direction
selection switch, refer to Section
2.3.6.
The operating hour counter
displays the software version,
the last service code (if appli-
cable) and operating hours in
succession. Service code
table, refer to Section 2.4
8. Press the button for the brush head
and squeegee.
The vehicle is ready for opera-
tion.
9. Press the button for the clean water
supply.
The clean water supply is acti-
vated.
10.Press the button for the clean water
dosing.
The clean water quantity is set.
11.If necessary, press the button for
brush pressure adjustment.
The brush pressure is activat-
ed.
Start driving immediately after
switching on the brush head
drive otherwise imprints of the
brush could be produced on
the floor!
Always raise the brush head
before driving over thresholds!
