Aqua Pulse Series
Pond Pump
OWNER’S MANUAL

Aqua Pulse Series Pond Pumps
Pump Models:AP-550, AP-800, AP-1200, AP-1600, AP-2000,
AP-3000, AP-4000, AP-5200, AP-6100, AP-8000,
AP-10000, AP-12000
Please read these instructions thoroughly and understand them prior to
installation or use. If you have any questions, please call 1-866-831-6558.
Model
Rated
Volts /
Hz
Rated
Watts /
Amps
Outlet
Diameter
Max
Flow
(GPH)
Max
Head
Max.
Depth
AP-550
120 / 60
54 / .45
1.5
550
11’
6.5
AP-880
120 / 60
82 / .68
1.5
800
13’
6.5
AP-1200
120 / 60
144 / 1.2
1.5
1,200
17’
6.5
AP-1600
120 / 60
156 / 1.3
1.5
1,600
18’
6.5
AP-2000
120 / 60
190 / 1.6
1.5
2,000
20
6.5
AP-3000
120 / 60
290 / 2.4
1.5
3,000
21
6.5
AP-4000
120 / 60
320 / 2.7
1.5
4,000
21
6.5
AP-5200
120 / 60
420 / 3.5
2
5,200
24
6.5
AP-6100
120 / 60
520 / 4.3
2
6,100
27
6.5
AP-8000
120 / 60
660 / 5.5
2
8,000
29
6.5
AP-10000
120 / 60
1000 / 8.3
3
10,000
39
6.5
AP-12000
120 / 60
960 / 8.0
3
10,000
39
6.5
PROPER USE
These pumps are to be used as submersible pumps in Koi ponds, water
gardens, waterfalls, and fountain applications to circulate and oxygenate clear
water. You can use the suction cups or four screws to mount it. If mounted to
an appropriate base, make sure that the pump is securely installed before
operation.
Proper care and maintenance will keep your pump functioning efficiently, and
will extend the service life of the pump. Please review the Proper Care and
Maintenance section of this manual for care and maintenance tips.
These pumps are not designed or intended for use in applications other than
those listed. Using these pumps in non-approved applications may subject the
user to dangers and hazards, and will void the warranty.
WARRANTY
These products, distributed by Half Off Ponds (HOP) are warranted to the original user
only to be free of defects in material and workmanship for a period of 24 months from
the date of purchase, but not more than 30 months from the date of manufacture. HOP
liability under this warranty shall be limited to repairing or replacing, at HOP’s discretion,
without charge, F.O.B. HOP will not be liable for any cost of removal, installation,
transportation, or other charges which may arise related to a warranty claim.
Pump Models:AP-550, AP-800, AP-1200, AP-1600, AP-2000,
AP-3000, AP-4000, AP-5200, AP-6100, AP-8000,
AP-10000, AP-12000
To obtain service under this warranty, the defective product must be returned to HOP
together with proof of purchase and installation date, failure date, and supporting
installation data. Any defective product to be returned to HOP or a service center must
be sent freight prepaid: documentation supporting the warranty claim and/or an
Authorized Warranty Return (AWR) must be included if so instructed. In the absence of
suitable proof of purchase date, the effective date of this warranty will be based upon
the date of manufacture.
Any replacement product may be either new or like-new, provided it has functionality at
least equal to that of the product being replaced. No requests for service under this
warranty will be accepted if received more than 30 days after the term of the warranty.
Correction of defects, in the manner and for the duration of the warranty described in
this warranty, shall constitute complete fulfillment of all liabilities and responsibilities of
HOP to the user with respect to the product, and shall constitute full satisfaction of all
claims, whether based on contract, negligence, strict liability or otherwise. Except for
the obligations specifically set forth in this warranty, in no event shall HOP be liable for
direct, indirect, special, incidental, or consequential damages, whether based on
contract, tort, or any other legal theory and whether advised of the possibility of such
damages.
HOP reserves the right to change or improve its products or any portions thereof without
being obligated to provide such a change or improvement for units sold and/or shipped
prior to such a change or improvement.
THERE ARE NO EXPRESS OR IMPLIED WARRANTIES, INCLUDING
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, WHICH
EXTEND BEYOND THOSE WARRANTIES DESCRIBED OR REFERRED TO ABOVE
EXCEPT AS EXPRESSLY HERIN PROVIDED THE GOODS ARE SOLD “AS IS”, THE
ENTIRE RISK AS TO QUALITY AND FITNESS FOR A PARTICULAR PURPOSE, AND
PERFORMANCE OF THE GOODS IS WITH THE BUYER, AND SHOULD THE
GOODS PROVE DEFECTIVE FOLLOWING THEIR PURCHASE, THE BUYER AND
NOT THE MANUFACTUREER, DISTRIBUTOR, OR RETAILER ASSUMES THE
ENTIRE RISK OF ALL NECESSARY SERVICING AND REPAIR.

IMPORTANT: Do not run the pump dry – this will cause damage to the
motor and void the warranty.
FIGURE 1
Used as a Submersible Pump
•Submerse the pump completely in your pond to make the pump body
fill with water.
•A minimum water level of approx. 6 in. is required for submersible use
in order to prevent the pump from taking in air. (see fig.1)
•Place the fountain pump above the mud in the pond to prevent the
filter becoming prematurely clogged.
•The pump is designed to accommodate internal threads as well as
external threads through the socket (fountain jets, nozzles, water
height regulators, standpipes, etc.).
•Running in conjunction with fountain jets, the pump should be
stationed firmly and horizontally.
•The pump can be switched on by simply plugging it in and switched
off by un-plugging it.
•The water temperature should not exceed 95°F (35°C) and do not let
the pump freeze in the wintertime.
•This pump is not intended for use by persons, (including children) with
reduced physical sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or
instruction concerning use of the pump by a person responsible for
their safety.
•Children should be supervised to ensure that they do not play with the
pump.
FIGURES 2 & 3
Proper Care and Maintenance
•Always follow the safety instructions. Make sure that the pump is
unplugged.
•If the pump is housed in a skimmer make sure the screens and
filters in the skimmer are kept clean and free of debris. This will
allow water to flow unrestricted into the pump chamber. Every
water feature is different; learn how frequently your skimmer
needs to be cleaned to allow unrestricted water flow. Pumps run
dry and damaged due to restricted water flow in a clogged
skimmer are not covered under the terms of the warranty.
•If the pump is operated directly in the water feature make sure the
pump intake screen is kept clean and free of debris. Pumps that
run dry and damaged due to restricted water flow are not covered
under the terms of the warranty.
1
4
6
8
7
9
A
B
A
B
FIGURE 1
FIGURE 2
FIGURE 3

•In hard water conditions, it is recommended that you periodically
remove the pump from the water feature and operate it for up to
36 hours in a solution of CLR (Calcium Lime Rust Remover) and
water. Rinse thoroughly before re-installing the pump in the water
feature.
Disassembling the Pump
•Follow these step by step instructions if the pump requires more
intensive cleaning.
•Press the intake cover (1) together laterally and take it from the
pump housing.
•Loosen the 4 outer screws (9).
•Rotate the pump housing (6) ¼ turn counter-clockwise. Unclip it
from the motor housing (4).
•Remove the rotor (8) from the motor housing (4).
•Clean all parts using water and a soft sponge. In hard water
conditions a mixture of CLR and water bath is recommended.
Assembling the Pump
•Place the rotor (8) in motor housing (4) with caution.
•Make sure the rotor is assembled correctly and will turn freely and
check the position of the sealing ring (7) on the pump housing (6).
•Put the pump housing (6) on and turn clockwise ¼ turn. Tighten
the 4 screws (9) uniformly.
•Place the intake cover (1) on the pump housing (6).
Questions?
Please call us 1-866-831-6558 or email [e-mail]
CAUTION
These pumps are not for use in swimming pools! Swimming in water being
circulated or oxygenated by these pumps poses a severe, imminent and
potentially fatal risk to human health.
These pumps should be installed per your local electrical code. Please contact
an electrician. For all technical data, please refer to the content stated on the
rating label of the pump.
Do not operate these pumps without water. If the pump runs, for any length of
time, in a dry condition without water it will damage the pump and void the
warranty.
Safety Instructions
•Read and observe all the instructions supplied with the pump and on
the pump.
•Make sure that your outlet voltage corresponds to those stated on the
rating label of the pump(s).
•Make sure the pump is securely installed before operating it.
•The electrical connection should be in a water-proof area and should
be at least 6 feet away from the edge of the pond. (see fig. 1)
•Keep the electrical connections dry! Droop the electrical cord below
the electrical outlet to form a “Drip Loop”. This will prevent water from
running down the cord into the electrical outlet
•Always unplug the pump when not in use, before putting on or taking
off parts, before cleaning the pump and before doing any work for the
fountain or pond.
•The pump must not be used when people are working in water. Please
disconnect the pump first.
•Do not operate any appliance with a damaged cord or plug, or in
abnormal state. The supply cord of the pump cannot be replaced.
•If the cord is damaged the pump should be scrapped.
•Do not cut the plug end off the cord for any reason. Cutting the
cord voids the warranty and may create an electrical hazard.
•For safety reasons, any repair work should be done only by the
manufacturer of the products or the authorized service facility or
discard it
•Never hang or transport the pump by means of pulling the power cord!
•Close supervision is necessary when the pump is used by or near
children.
•If you want to disconnect the pump, you can pull out the plug and the
plug must be placed where you can access it.
•Never use any accessories which are not recommended by the pump
manufacturer. It may result in fire, electric shock, personal injury
and/or voided warranty.
•The pump is to be supplied through a Ground Fault Circuit Interrupter
(GFCI) with a rated residual operating current not exceeding 30mA.
•To protect against the risk of electrical shock, do not immerse the plug-
in water or other liquid.

SHOP OUR FULL SELECTION AT HALF OFF PONDS
Complete Pond & Pondless Kits
Largest online selection of complete, everything-you-need kits. Choose from
our standard kits or full custom options.
Pond Liner & Underlayment Combos
Half Off Ponds offers the widest range of pond liner materials and sizes. Your
trusted source for EPDM, PVC & HDPE liners.
Submersible Pond Pumps
Complete range of energy efficient small statuary and fountain pumps to high
flow 10,000+ GPH large fish pond and waterfall pumps.
Water Treatments
Create healthy environments for
your water garden or prized koi fish.
Fish Food
Select from growth, color enhancing,
or cold weather formulations.
Filtering Waterfalls, Skimmers & Pressure Filters
Establish and maintain pristine pond water.
Pond & Landscape Lighting
Beautiful finishing touches that show
off your pond & landscape.
Lighted Spillways & Kits
Build striking formal falls with lighted
acrylic & stainless steel spillways.
Seasonal Care & Maintenance
Everything you need to prepare & maintain your pond all year long.

OVERLOAD PROTECTION
The pump has a built-in thermal overload trip which prevents the pump from
overheating. The pump must be allowed to cool down before restarting. If the
pump will not start again automatically when cooling down, please check the
following conditions;
•Is there sufficient water supply? → add water if necessary
•Has the filter become clogged? → Clean if necessary
•Has dirt entered the pump housing? → follow the cleaning
instructions in the Proper Care and Maintenance section.
•Have hoses or jets become clogged? → Clean if necessary
•Has the pump sufficiently cooled down after overheating?
•As soon as you have completed this checklist, you can start the
pump again by plugging it back in.
WARNING:
•Risk of electric shock – This pump is supplied with a grounding conductor and
grounding type attachment plug. To reduce risk of electric shock, be certain
that it is connected only to properly grounded, grounding-type receptacle
•To reduce the risk of electrical shock, use only on portable self-contained
fountains no larger than 5 ft. in any dimension.
•Risk of electric shock. Do not remove cord and strain relief. Do not connect
conduit to pump.
•This pump has been evaluated for use with water only.
•Reduce risk of electric shock during operation of this pump requires the
provision of acceptable grounding
•Risk of electric shock – This pump has not been investigated for use in
swimming pool or marine areas.
•Do not connect to any voltage other than that shown on the pump
•Always disconnect from electrical supply before handling pump.
•Don’t operate without water
•Operate pump completely submerged for proper cooling
