Halma Ampac EV3000 Guide

Fire detection and evacuation solutions that save lives.
EV3000
Emergency Warning & Intercommunications
System
(2 Wire / S004)
Installation & Commissioning
MAN1813-9

MAN1813-9
Contents
1 Non Disclosure Agreement ........................................................................................................ 1
2 Certification Information ........................................................................................................... 2
3 Equipment Manufacturing Details.............................................................................................. 2
4 Purpose ..................................................................................................................................... 3
4.1 Scope .................................................................................................................................. 3
4.2 References .......................................................................................................................... 3
4.2.1 EV3000 System Manuals:.............................................................................................. 3
4.2.2 Australian Standards..................................................................................................... 3
4.3 System Overview................................................................................................................. 3
5 System Description.................................................................................................................... 4
5.1 Emergency Warning System ................................................................................................ 4
5.2 Emergency Intercommunication System.............................................................................. 4
6 ECP & Main Equipment Layout................................................................................................... 5
7 EWIS Components ..................................................................................................................... 6
7.1 The Emergency Control Panel.............................................................................................. 6
7.2 Ancillary Components ECP................................................................................................... 6
7.2.1 MICROPHONE............................................................................................................... 6
7.2.2 Master EIS Handset and All Call Switch ......................................................................... 6
7.2.3 Emergency Alarm Initiating Device (EAID)..................................................................... 6
8 EWS, EIS And ECP Operation...................................................................................................... 7
8.1 Emergency Control Panel..................................................................................................... 7
8.1.1 Operating Instructions.................................................................................................. 7
8.1.2 Automatic / Manual / Isolate Key Switch ...................................................................... 8
8.1.3 All Call Facility............................................................................................................... 9
8.1.4 Buzzer .......................................................................................................................... 9
8.1.5 Buzzer Mute / Alarm Acknowledge............................................................................... 9
8.1.6 Master Reset.............................................................................................................. 10
8.1.7 Lamp Test Facility ....................................................................................................... 10
8.1.8 System Test Facility .................................................................................................... 10
8.1.9 System Status Indicators............................................................................................. 10
8.1.10 Zone Status (Fault Diagnostics)................................................................................ 11
8.2 EWS Zone Control Panel .................................................................................................... 12
8.2.1 EWS Zone Control Switches and Indicators ................................................................. 12
8.2.2 EWS Zone Fault........................................................................................................... 12
8.2.3 Alarm Origin............................................................................................................... 12
8.2.4 Zone Labelling ............................................................................................................ 12
8.3 EIS Control Panel ............................................................................................................... 13
8.3.1 WIP Select Switch....................................................................................................... 13
8.3.2 WIP Select Indicator (Red) .......................................................................................... 13
8.3.3 WIP Call Buzzer........................................................................................................... 13
8.3.4 Zone Cleared Switch ................................................................................................... 13
8.3.5 WIP Fault Indicator (Amber) ....................................................................................... 13
8.4 EIS System Operation ........................................................................................................ 14
8.4.1 WIP Calling ECP .......................................................................................................... 14
8.4.2 Conference Call .......................................................................................................... 14

MAN1813-9
8.4.3 Completing the Call by the WIP .................................................................................. 14
8.4.4 Completing the Call by the ECP................................................................................... 14
8.4.5 ECP Calling WIP .......................................................................................................... 14
8.4.6 ECP To All WIPS (ALL CALL) ......................................................................................... 14
8.4.7 Completing The All Call............................................................................................... 15
8.4.8 EIS Controlling ECP ..................................................................................................... 15
8.4.9 Zone Labelling - Refer to Appendix A .......................................................................... 15
8.4.10 Remote Paging Console........................................................................................... 15
8.5 Main Equipment Description ............................................................................................. 17
8.5.1 Common Board Frame................................................................................................ 17
8.5.2 Tone Generator .......................................................................................................... 18
8.5.3 Standby Tone Generator............................................................................................. 19
8.5.4 Microphone / BGM Mixer Board................................................................................. 19
8.5.5 Standby Microphone / BGM Mixer Board ................................................................... 19
8.5.6 FACP Input CPU Board ................................................................................................ 19
8.5.7 Main CPU ................................................................................................................... 20
8.5.8 Amplifier Rack Frame.................................................................................................. 20
8.5.9 40-Watt Amplifier....................................................................................................... 20
8.5.10 120-Watt Amplifier ................................................................................................. 21
8.5.11 Warden Intercom Control Frame............................................................................. 22
8.5.12 EIS Control CPU....................................................................................................... 23
8.5.13 EIS Selector Board................................................................................................... 23
8.5.14 Fan Module............................................................................................................. 23
8.5.15 Power Supply.......................................................................................................... 23
8.5.16 Fault Relay .............................................................................................................. 24
9 Installation............................................................................................................................... 25
9.1 Unpacking And Inspection ................................................................................................. 25
9.2 Anti-Static Precautions ...................................................................................................... 25
9.3 Working on The System..................................................................................................... 25
9.4 Cabinet Installation ........................................................................................................... 25
9.4.1 Surface Mount............................................................................................................ 25
9.4.2 Recess Mount............................................................................................................. 25
10 Connecting The EV3000 ........................................................................................................... 26
10.1 FACP Input Connections (Individual inputs).................................................................... 26
10.1.1 Connections............................................................................................................ 26
10.1.2 Fusing ..................................................................................................................... 26
10.1.3 Address Setting....................................................................................................... 26
10.2 Common FACP Input Connections.................................................................................. 27
10.3 EWS, BGM and EIS Handset Input Connections .............................................................. 27
10.3.1 Connections............................................................................................................ 28
10.4 100V Line Speaker Connections...................................................................................... 28
10.4.1 Connections............................................................................................................ 29
10.4.2 Fusing ..................................................................................................................... 29
10.4.3 Field Wiring............................................................................................................. 30
10.5 Visual Indicators Output Connections............................................................................. 31
10.5.1 Connections............................................................................................................ 31
10.5.2 Fusing ..................................................................................................................... 31

MAN1813-9
10.5.3 Field Wiring............................................................................................................. 33
10.6 Warning Sign Driver Board (BRD42WSD) ........................................................................ 34
10.7 WIP/EAID Extension Connections................................................................................... 35
10.7.1 Connections............................................................................................................ 35
10.7.2 Field Wiring............................................................................................................. 35
10.8 MECP To SECP Data Connections.................................................................................... 36
10.8.1 Connections............................................................................................................ 36
10.9 CN5 + CN6 Power Supply to Board ................................................................................. 36
10.9.1 Fusing ..................................................................................................................... 36
10.10 Mains Connection .......................................................................................................... 37
11 Devices.................................................................................................................................... 38
11.1 Speakers ........................................................................................................................ 38
11.2 Visual Warning Devices .................................................................................................. 39
11.3 Warden Intercommunication Point (WIP)....................................................................... 40
11.4 EAID............................................................................................................................... 41
12 SECP And Remote Console Connections................................................................................... 42
13 Placing System Into Operation ................................................................................................. 43
13.1 System Power Up Sequence........................................................................................... 43
13.2 Time Out Setting For Automatic Evacuation Sequence ................................................... 44
14 Faults....................................................................................................................................... 45
14.1 Fault Indicators .............................................................................................................. 45
14.2 Fault Diagnostics............................................................................................................ 45
15 Trouble Shooting ..................................................................................................................... 46
16 Appendix A: Zone Labelling...................................................................................................... 48
17 Appendix B: Compatible Devices.............................................................................................. 49
18 Appendix C: Amplifier Addressing ............................................................................................ 50
19 Appendix D: Amplifier Strapping.............................................................................................. 51
20 Appendix E: Information on the Obsolete Tone Generator....................................................... 52
20.1.1 Signal Generator Settings........................................................................................ 52
21 Glossary Of Terms.................................................................................................................... 53
22 Definitions............................................................................................................................... 54
