Instruction Manual AD1000/BA1000
2
Revision overview
Version:
Date:
Author:
Amendments:
A
04/2012
Re
Initial Revision
B
04/2017
Me
Formula for reduction
C
01/2018
Me
Decl. of conformity; Technical drawing
D
12/2022
Me
Update technical data, Revision Overview; QR-Code
© 2022
The manufacturer owns the copyright to this instruction manual. It contains technical data,
instructions and drawings detailing the device’s features and how to use them. It must not be
copied either wholly or in part or made available to third parties.
The instruction manual is part of the product. Please read this manual carefully, follow our
instructions, and pay special attention to the safety information provided. This instruction
manual should be available at all times. Please contact the manufacturer if you do not
understand any part of the instructions.
The manufacturer reserves the right to continue developing this device model without
documenting such development in each individual case. The manufacturer will be happy to
determine whether this manual is up-to-date.
Instruction Manual AD1000/BA1000
3
Purpose of instruction manual
This instruction manual describes the features of the AD 1000 absolute pressure transmitter /
BA 1000 barometer and provides guidelines for its use.
Improper use of these instruments or failure to follow these instructions may cause injury or
equipment damage. Every person who uses this device must therefore read the manual and
understand the possible risks. The instruction manual, and in particular the safety precautions
contained therein, must be followed carefully. Contact the manufacturer if you do not
understand any part of this instruction manual.
Handle this manual with care:
It must be readily available throughout the lifecycle of the instrument.
It must be provided to any individuals who assume responsibility for operating the
instrument at a later date.
It must include any supplementary materials provided by the manufacturer.
Conformity
This device is state of the art.
It complies with the statutory requirements of the EC and UK-directives.
This is documented by the CE and the UKCA mark being affixed.
Instruction Manual AD1000/BA1000
4
Table of Contents
1 Safety precautions................................................................................................................5
1.1 Appropriate use ...............................................................................................................5
1.2 Shipping, assembly, electrical connections and start-up..................................................5
1.3 Troubleshooting, maintenance, repairs, disposal.............................................................5
1.4 Symbols...........................................................................................................................6
2 Instrument description...........................................................................................................7
3 Start-up.................................................................................................................................7
3.1 Features ..........................................................................................................................7
3.2 Electrical instrument connections:....................................................................................7
4 Technical data ......................................................................................................................8
5 Certificate of conformity ........................................................................................................10
Instruction Manual AD1000/BA1000
5
1Safety precautions
1.1 Appropriate use
The AD 1000 absolute pressure transmitter / BA 1000 barometer is designed for displaying
atmospheric pressure and absolute pressure in such areas as weather stations and airports.
Always observe the operating requirements—particularly the permissible supply voltage—
indicated on the rating plate and in the “Technical data” section of this manual.
The instrument may only be handled as indicated in this manual. Modifications to the
instrument are prohibited. The manufacturer is not liable for damages caused by improper use
or failure to follow these instructions. Violations of this type render all warranty claims null and
void.
1.2 Shipping, assembly, electrical connections and start-up
Do not close the pressure input ports when shipping, as changes in barometric pressure could
damage instruments with low measuring ranges.
Only technical personnel who are appropriately trained and authorized by the operator of the
facility may assemble the instrument and set up its electrical connections.
The instrument may only be operated by appropriately trained individuals who have been
authorized by the operator of the facility.
Pressurized air or breath is not to be used for performance tests, as this could damage
instruments with low measurement ranges.
Measurement errors may occur if the instrument is not kept protected from sunlight.
Specific safety precautions are given in individual sections of this manual.
1.3 Troubleshooting, maintenance, repairs, disposal
The individual responsible for the electrical connections must be notified immediately if the
instrument is damaged or if errors occur.
This individual must take the instrument out of service until the error has been corrected and
ensure that it cannot be used unintentionally.
Always unplug the power cord before opening the instrument!
This instrument requires no maintenance.
Only the manufacturer may perform repairs that require the housing to be opened.
The electronic components of the instrument contain materials that can be reused.
For this reason the instrument must be recycled in accordance with the environmental
guidelines of the jurisdiction in question once it has been taken permanently out of service.
Instruction Manual AD1000/BA1000
6
1.4 Symbols
The symbols given below are used throughout this manual to indicate instances when
improper operation could result in the following hazards:
WARNING!
This warns you of a potential hazard that could lead
to bodily injury up to and including death if the
corresponding instructions are not followed.
CAUTION!
This warns you of a potential hazard that could lead
to significant property damage if corresponding
instructions are not followed.
INFORMATION!
This indicates that the corresponding information is
important for operating the instrument properly.
Instruction Manual AD1000/BA1000
7
2 Instrument description
The AD 1000 absolute pressure transmitter / BA 1000 barometer is designed for displaying
atmospheric pressure and absolute pressure in such areas as weather stations and airports.
At the heart of the unit is an evacuated CuBe chamber that contracts in proportion to
barometric pressure. An inductive displacement transducer measures the movement of the
chamber without making contact. The pressure port is led through in the AD 1000.
3 Start-up
3.1 Features
Although the AD 1000 absolute pressure transmitter / BA 1000 barometer is highly robust, it is
nevertheless a precision instrument and should be handled with care. Avoid mounting the AD
1000 / BA 1000 in the direct vicinity of any sources of heat or radiation. Ideally, the instrument
should be mounted vertically (pressure and vacuum ports should be pointing down) and on a
wall not subject to vibration.
3.2 Electrical instrument connections:
Observe the required supply voltage (see rating plate)
The pressure transmitter is protected against reverse polarity of the supply voltage.
The signal output is protected against short circuits for a short period.
0V
U/I
Instruction Manual AD1000/BA1000
8
4 Technical data
Measurement data
measurement ranges
AD 1000: 0… 50 kPa
0…100 kPa
80…120 kPa
90…110 kPa
100… 0 kPa
BA1000: 80…120 kPa
85…115 kPa
90…110 kPa
95…115 kPa
Measurement accuracy
(setting limiting value)
±1 % of measurement range
reference ± 0.5 hPa with respect to sea level
Temperature coefficient span
0.04%/ K (within the +10°C...+60 °C range)
calibration temperature
+22 °C ± 4 K
Signal stability
0.3 hPa / year
Ambient conditions
medium
air, all non-aggressive gases
operating temperature
+10° C to +60° C
storage temperature
-10° C to +70° C
relative humidity
0…80 %
certificates
CE / UKCA (upon request)
Electrical data
power consumption
max. 3 VA
supply voltage
230 VAC ±10 %, 50/60 Hz
115 VAC ±10 %, 50/60 Hz
24 VDC +20 % -15 %
24 VAC ±10 %, 50/60 Hz
output signal
0 to 10 V, 0 to 20 mA or 4 to 20 mA
minimum load resistance RL
RL2 kfor an output voltage of 0...10 V
maximum effect of load resistance = 0.3%
maximum output load RB
RB≤ 500 for current output
output load dependence: < 0.3 %
reduction
0…850 m above sea level acc. to DIN ISO 2533:1979-12
p= pbexp[–gnR-1 T-1 (H –Hb) ]
Instruction Manual AD1000/BA1000
9
Physical data
pressure port
Ø 6.5 mm for NW6 tubing
electrical connection
screw terminals for cables up to 2.5 mm2
2x PG 7 or 2x PG 11 cable glands
mounting orientation
vertical
(if horizontal, use potentiometer 0 to reset)
dimensions (w x h x d)
151 x 80 x 73 mm
122 x 120 x 75 mm (option with display)
protection class
BA1000: IP53; AD1000: IP54
weight
0.6 kg
options
factory calibration
calibration according to DKD-R 6-1
3½ digit LCD
Appendix A: Parts in contact with measurement medium
Beryllium bronze CuBe2 Araldite CY236 / HY988
Brass CuZn39Pb3 Carbonyl iron
KEL (FPM: fluorinated rubber) Viton (tubing)
Crastin (PTBP) UHU-Plus endfest 300 binder
Loctite 242e
For more information on our measurement technology products, please visit our
homepage at
www.halstrup-walcher.de/en/products/measurement-technology/
Instruction Manual AD1000/BA1000
10
5 Certificate of conformity
7100.003864D_AD1000.docx 12/2022 Me
Instruction Manual AD1000/BA1000
11
