Hamilton Beach Professional MG03 User manual

840331800 | 09/19
GB #12 Electric
Meat Grinder
& Sausage Stuffer
Operation Manual
(Original Instructions) (2)
Visit https://hamiltonbeach.global for our complete
line of products and Use and Care Guides – as well as
delicious recipes, tips, and to register your product online.
ZH #12 電動絞肉機及香腸充
 填機
操作手冊  (38)
請前往 https://hamiltonbeach.global 參閱我們的全面產
品系列、使用和護理指南和一系列美食菜譜，以及在網上
為您的產品進行登記！
MS #12 Pengisar Daging
& Pengisi Sosej Elektrik
Manual Pengendalian (56)
Lawati https://hamiltonbeach.global untuk barisan
produk kami yang lengkap dan Panduan Penggunaan
dan Penjagaan – begitu juga dengan resipi yang sedap,
tip dan mendaftar produk anda secara atas talian
FR N° 12 Moulin à viande
et poussoir à
saucisses électrique
Manuel d’utilisation (74)
Rendez-vous sur https://hamiltonbeach.global pour
consulter tous nos produits, les Guides d’utilisation et
d’entretien, de délicieuses recettes, des conseils ainsi que
pour enregistrer votre produit en ligne.
Type: MG03

2
GB
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions
should always be followed to reduce the risk of fire, electric
shock, and/or injury to persons, including the following:
1. Read
all instructions.
2. This appliance is not intended for use by persons with
reduced physical, sensory, or mental capabilities, or lack of
experience and knowledge, unless they are closely supervised
and instructed concerning use of the appliance by a person
responsible for their safety.
3. This appliance shall not be used by children. Keep the
appliance and its cord out of reach of children.
4. Close supervision is necessary when any appliance is used by
or near children. Children should be supervised to ensure that
they do not play with the appliance.
5. To protect against risk of electrical shock, do not put main
body of the grinder, cord, or plug in water or other liquid.
6. Turn the appliance OFF
( ) , then unplug from outlet when
not in use, before putting on or taking off parts, and before
cleaning. To unplug, grasp the plug and pull from the outlet.
Never pull from the power cord.
7. The use of attachments not recommended by the
manufacturer may cause fire, electrical shock, or injury, and
will void your warranty.
8. Do not operate any appliance with a damaged supply cord or
plug, or after the appliance malfunctions or has been dropped
or damaged in any manner. Supply cord replacement and
repairs must be conducted by the manufacturer, its service
agent, or similarly qualified persons in order to avoid a hazard.
Call the provided customer service number for information on
examination, repair, or adjustment.

3
9. Check if the voltage indicated on the appliance corresponds to
the local voltage before you connect the appliance.
10.
Do not use outdoors.
11.
Do not let cord hang over edge of table or counter, or touch
hot surfaces, including the stove.
12.
Do not place on or near a hot gas or electric burner or in a
heated oven.
13.
Grinder must be operated on a flat surface away from the
edge of the counter to prevent accidental tipping.
14.
Check that the appliance is OFF ( ) before plugging cord into
wall outlet. To disconnect, turn the control to OFF
( ) ; then
remove plug from wall outlet. To unplug, grasp the plug and
pull from the outlet. Never pull from the power cord.
15.
Avoid contacting moving parts. Never feed food by hand.
Always use food pusher.
16.
Never use fingers to scrape food away from the grinding plate
while the grinder is in operation. Severe injury may result.
17.
Do not operate the grinder without the tray in place.
18.
Never feed food by hand. Always use the provided food
pusher. Keep fingers clear of the auger and cutting blades at
all times. Never reach into the grinder. Doing so may cause
serious injury.
19.
Never feed food with out the tray.
20.
To reduce the risk of severe personal injury, and/or damage
to the grinder, tie back loose hair and clothing, and roll up
long sleeves before operating the grinder. Remove ties, rings,
watches, bracelets, or other jewelry before operating the
grinder.
21.
Never operate the grinder unattended. Be safe. Disconnect
the grinder from power source before leaving the work area.
22.
Do not attempt to grind bones or other hard items.

4
23.Do not operate the appliance for more than 5 minutes at one
time. After 5 minutes of continuous use, allow a few minutes
for the appliance to rest before next use.
24.
Do not run the grinder without meat in the head. Severe
damage to the head and auger may occur.
25.
Grinding blade is sharp. Handle carefully.
26.
Wear eye protection. Wear safety glasses that conform to
ANSI Z87.1 requirements. Everyday eye glasses are not
safety glasses.
27.
CAUTION! In order to avoid a hazard due to inadvertent
resetting of the thermal cut-out, this appliance must not be
supplied through an external switching device, such as a timer,
or connected to a circuit that is regularly switched on and off
by the utility.
28.
Your plug is provided with a fuse approved by ASTA to
B.S. 1362. If you need a replacement fuse carrier, it must be
replaced with the same colour-coded carrier with the same
markings. Fuse covers and carriers can be obtained from
approved service agents.
SAVE THESE INSTRUCTIONS

5
Other Consumer Safety Information
This product is intended for household use only.
w WARNING Entanglement Hazard: To avoid serious injury do not reach
into grinder inlet. Always use stomper. Do not operate without tray in place.
The length of the cord used on this appliance was selected to reduce the
hazards of becoming tangled in or tripping over a longer cord. If a longer
cord is necessary, an approved extension cord may be used. The electrical
rating of the extension cord must be equal to or greater than the rating of the
appliance. Care must be taken to arrange the extension cord that it will not
drape over the countertop or tabletop where it can be pulled on by children
or accidently tripped over. Carry the unit by the motor housing with both
hands. Do not carry by the tray or neck.
NOTE: This machine is equipped with motor overload protection. If the
motor stops during operation due to overheating, unplug and allow it to cool
down for approximately 30 minutes. Plug machine back in to resume normal
operation.
Recycling the Product at the End of Its Service Life
The wheeled bin symbol marked on this appliance signies
that it must be taken over by a selective collection system
conforming to the WEEE Directive so that it can be either
recycled or dismantled in order to reduce any impact to
the environment. The user is responsible for returning the
product to the appropriate collection facility, as specied
by your local code. For additional information regarding
applicable local laws, please contact the municipal facility
and/or local distributor.

6
Model: 78403-SAU
Type: MG03
Ratings:
220–240 V~ 50–60 Hz 800 W
Stomper
Stainless Steel
Grinder Knife
Tray
Grinder
Head
Auger
Assembly
Stuffing Funnel
Front Ring Nut
Main Body
Control Dial
Parts and Features
8 mm Stainless
Steel Coarse
Grinding Plate
5mm Stainless
Steel Medium
Grinding Plate
Kibbe
3mm Noodle Cross
Plate

7
Cleaning
1. Unplug from outlet.
2. Unscrew the Ring Nut and remove all parts from the
Grinder Head.
3. To remove the Grinder Head, push the lever on
the Cam Action Lock up, unlocking the Grinder Head,
and remove the Grinder Head by pulling it straight out
(FIGURE A).
4. Wash all parts that come in contact with food in hot
soapy water by hand. Dry immediately. The Grinding
plates should be cleaned after each use, otherwise the
residue will block the holes and it’s difcult to clean
when dry. The Grinder parts are not dishwasher safe.
Do NOT use bleach.
NOTE: Be careful when washing. The grinder knife
that may hurt hands. Rinse with clear water.
5. Fully lubricate the Grinder Head, Grinding Plates
and the Knife with food grade silicone spray before
and after each use.
6. Clean the Main Body with a soft damp towel. Dry
immediately. DO NOT immerse the Main Body of the
Grinder in water or other liquids.
Cam Action Lock
ELECTRICAL SHOCK HAZARD: Disconnect power before
cleaning, disassembling or assembling. Do not immerse cord, plug or motor in
water or other liquid.
!WARNING
FIGURE A

8
Grinder Assembly
1. Remove the Ring Nut, Grinding Plate, Knife and
Auger from the Grinder Head before installing the
Grinder Head to the Main Body.
2. Align the notches on the Grinder Head with the tabs
on the Main body.
3. Insert the Grinder Head into the Main Body and
push the lever down to lock into position. The lever will
be at the lock graphic ( ) when locked (FIGURE B).
4. Insert the Auger into the Grinder Head, Auger Driver
end rst (FIGURE C).
5. Place the Grinder Knife onto the square portion of
the Auger Pin. The cutting edges (at side) of the Knife
should be facing out (FIGURE D).
6. Place the Grinding Plate of your choice onto the
Auger Pin. Ensure the pin of the Grinder Plate ts into
the notch position of the Grinder Head (FIGURE C).
7. Turn the Ring Nut clockwise onto the threaded end
of the Grinder Head until it touches the Grinder Plate
and is snug. DO NOT over-tighten the Ring Nut.
8. Place the Tray on the upright part of the Grinder
Head. NEVER use the Grinder without the Tray
installed!
FIGURE B
FIGURE C
FIGURE D
Auger
Pin
Cutting edges of the Knife facing out.
ENTANGLEMENT HAZARD: Disconnect power before
cleaning, disassembling or assembling.
!WARNING

9
1. Follow the “Grinder Assembly Instructions” to fully assemble the Grinder
including the Tray.
NOTE: It is best to grind the meat using the coarse, 8 mm Grinding Plate
rst. If a ner grind of meat is desired, run the coarse ground meat through the
Grinder a second time using the ne, 5 mm Grinding Plate.
2. Trim the meat of all cords, tendons,
bones, shot, etc.
3. For best results, be sure that all meat has
been chilled to between 32-34oF (0-1oC)
before grinding. DO NOT ALLOW MEAT
TO SIT OUT AT ROOM TEMPERATURE
LONGER THAN ABSOLUTELY NEEDED.
Closely follow the “Food Safety” instructions
as outlined by the USDA.
4. Cut meat into sizes small enough to t into
the Feed Chute. Approximately 1” (2.5 cm)
cubes.
5. Place cubed meat to be ground into the
Tray. Do not overll the Tray, place just
enough meat to leave the Feed Chute area
open.
6. Place a dish or bowl to collect the ground
meat at the end of the Grinder Head
(FIGURE E).
7. Make sure the Grinder is in the OFF ( )
position. Attach the Grinder to the power
supply
8. Turn the Grinder Knob to ON (I). Carefully
start feeding cubes of meat into the Feed
Chute. ONLY USE THE STOMPER TO
PUSH MEAT INTO THE HEAD, DO NOT
USE YOUR FINGERS OR ANY OTHER
OBJECT.
NOTE:
To prevent
overheating, do not
operate the Grinder for
more than 5 minutes
at a time.
Allow the Grinder
to cool
periodically.
ENTANGLEMENT HAZARD: To avoid serious injury
do not reach into grinder inlet. Always use stomper. Do not operate
without Tray in place.
!WARNING
FIGURE E
Grinder Instructions

10
1. Unplug from outlet.
2. Remove the Ring Nut, Grinding Plate, Knife and
Auger from the Grinder Head before installing the
Grinder Head to the Main Body.
3. Align the notches on the Grinder Head with the
tabs on the Main body.
4. Insert the Grinder Head into the Main Body and
push the lever down to lock into position (FIGURE
F).
5. Insert the Auger into the Grinder Head, Auger
Driver end rst (FIGURE G).
6. Place the Grinder Knife onto the square portion
of the Auger Pin. The cutting edges (at side) of
the Knife should be facing out.
7. Place the Grinding Plate of your choice onto
the Auger Pin. Make sure the notch of the Grinder
Plate ts into the positioning pin of the Grinder
Head.
8. Insert the Stufng Funnel through the Ring Nut
and then onto the Grinder Head.
9. Turn the Ring Nut clockwise onto the threaded
end of the Grinder Head until it touches the Stufng
Funnel. DO NOT over-tighten the Ring Nut.
10. Place the Tray on the upright part of the
Grinder Head. NEVER use the Grinder without the
Tray installed!
ENTANGLEMENT HAZARD: Disconnect power before cleaning,
disassembling or assembling.
!WARNING
FIGURE F
FIGURE G
Auger
Driver
Stuffer Assembly
