Hamilton Beach 52300 User manual

blender
owners manual
SAVE THIS USE AND CARE BOOK
Please call 1-800-851-8900 with questions
840141300 Blender 12/20/05 11:23 AM Page 1

When using electric appliances, basic safety precautions
should always be followed, including the following:
■Read all instructions.
■To protect against risk of electrical shock, do not put
cord, plug, base, or motor in water or other liquid.
■Close supervision is necessary when any appliance is
used by or near children.
■Unplug cord from outlet when not in use, before putting
on or taking off parts, and before cleaning.
■Avoid contact with moving parts.
■Do not operate any appliance with a damaged cord or
plug, or after the appliance malfunctions, or is dropped
or damaged in manner. Call our toll-free customer service
number for information on examination, repair or
electrical or mechanical adjustment.
■The use of attachments, including canning jars, not
recommended or sold by Hamilton Beach/Proctor-Silex,
Inc. may cause a risk of injury to persons.
■Do not use outdoors.
■Do not let cord hang over edge of table or counter, or
touch hot surfaces, including the stove.
IMPORTANT SAFEGUARDS
2
Shock Hazard
■Do not immerse this appliance in water or other
liquid.
■This appliance has a polarized plug (one wide blade)
that reduces the risk of electrical shock. The plug fits
only one way into a polarized outlet. Do not defeat
the safety purpose of the plug by modifying the plug
in any way or using an adaptor. If the plug does not
fit, reverse the plug. If it still does not fit, have an
electrician replace the outlet.
WARNING
840141300 Blender 12/20/05 11:23 AM Page 2

■Keep hands and utensils out of jar while blending to
reduce the risk of severe personal injury and/or damage
to blender. A rubber spatula may be used but must be
used only when blender is not running.
■Blades are sharp; handle carefully– especially when
assembling, disassembling or cleaning inside blender jar.
■Do not use a broken, chipped, or cracked blender jar.
■Do not use broken, cracked, or loose cutting blades.
■To reduce the risk of injury, never place cutting blades on
base without jar properly attached.
■Always operate blender with lid in place.
■When blending hot liquids:
— Remove center piece of two-piece lid.
— Do not fill blender jar beyond the 3-cup (750 ml) level.
— Always begin processing at the lowest speed setting.
— Keep hands and other exposed skin away from the
cover opening to reduce the risk of possible burns.
■Screw on jar nut firmly. Injury can result if moving blades
accidentally become exposed.
■If the jar should turn when the motor is switched ON, switch
OFF immediately and tighten jar in jar nut, Sure Rest™ base,
or cutting assembly.
■Do not leave blender unattended while it is operating.
■To disconnect cord, turn the control to OFF. Then remove
plug from wall outlet.
■Do not use appliance for other than intended purpose.
OTHER CONSUMER SAFETY INFORMATION
This appliance is intended for household use only.
The length of the cord used on this appliance was selected to
reduce the hazards of becoming tangled in, or tripping over,
a longer cord. If a longer cord is necessary, an approved
extension cord may be used. The electrical rating of the
extension cord must be equal to or greater than the rating of
the blender. Care must be taken to arrange the extension
cord so that it will not drape over the countertop or tabletop
where it can be pulled on by children or accidentally tripped
over.
SAVE THESE INSTRUCTIONS
3
840141300 Blender 12/20/05 11:23 AM Page 3

OTHER CONSUMER SAFETY INFORMATION (cont.)
The wattage rating of the blender is determined by an
Underwriter’s Laboratory test and is based on available cut-
ting blades and jar combinations that may not be provided
with your unit, but are available as replacement parts. This is a
measure of input wattage after 30 seconds of operation. The
blender as provided may draw significantly less power. Peak
power is the measure of the motor wattage during the first
seconds of operation. This is when a blender requires the most
power to crush ice, frozen fruit, etc. This is a better measure of
what a blender motor can deliver when power is needed
most.
If the cutting blades lock and do not move, it will damage
the motor. Do not use. Call the toll-free customer service num-
ber for information.
Do not place blender jar in the freezer filled with food or liq-
uid. This will freeze and can result in damage to the cutting
blades, jar, blender and possibly result in personal injury.
Thank you for purchasing our product!
Your blender is designed with Wave ~Action™blending
technology. This revolutionary system does not require the
use of a stir stick or wooden spoon.
We know you will enjoy many years of superior blending
performance.
4
840141300 Blender 12/20/05 11:23 AM Page 4

PARTS AND FEATURES
48
40
32
24
16
6
5
4
3
2
8
1
Filler Cap
Lid
Jar
Cutting Blades
NOTE: The gasket
is permanently
affixed to the
cutting blades.
Do not try to
remove it.
Control
Panel Base
Sure Rest™
Jar Base
5
840141300 Blender 12/20/05 11:23 AM Page 5

CONTROL PANEL
First select and push a
LOW or HIGH power but-
ton then push desired
speed button.
The blender will run until you push the OFF button.
The OFF button is also the Ice Breaker™/Pulse Button.
When using Pulse or IceBreaker, the blender will only
run as long as the button is pushed. As buttons are
pushed left to right, the speed at which the blades
spin will increase.
BEFORE FIRST USE
After unpacking the blender, wash everything except
the blender base in hot, soapy water. Dry thoroughly.
Wipe the blender base with a damp cloth or sponge.
DO NOT IMMERSE THE BASE IN WATER. Care should be
taken when handling the cutting blades as they are
very sharp.
HOW TO ASSEMBLE AND USE
6
IMPORTANT: Your blender jar and cutting blades are sub-
ject to wear during normal use. Always inspect jar for
nicks, chips, or cracks. Always inspect cutting blades for
broken, cracked, or loose blades. If jar or cutting blades
are damaged, do not use. Call our toll-free customer
service number to obtain replacement parts.
■Make sure blender is unplugged. Place blender base
on clean, dry surface to keep foreign particles from
being pulled up into motor during operation.
■Place cutting blades in Sure Rest™jar base. Set jar on
top of cutting blades and tighten on jar base.
■Make sure the Sure Rest™jar base is firmly screwed
onto the jar. If not, it may loosen later when motor is
turned on.
840141300 Blender 12/20/05 11:23 AM Page 6

■Set assembled jar into place on blender base, making
sure it is securely seated. If not, gently rock the jar until
seated.
■Plug cord into outlet.
■Put ingredients in jar; place lid on jar. Place hand on
lid when blending.
■Blending hot liquid: Do not place hand on lid. Always
use caution when blending hot liquid. Keep hands and
exposed skin away from opening during blending.
■Process food or beverages. See the “Blending Specific
Foods” section for speeds and processing tips.
■ALWAYS turn blender off and wait until blades have
stopped rotating before removing jar.
■To remove jar after blending is complete, lift the jar
straight up. If it is not easily removed, rock gently and
lift. Do not twist.
■NEVER replace jar onto unit while motor is running.
GENERAL TIPS
■Processing hot foods or liquids in the blender may
cause hot liquid to spurt out when the cover is
removed. Always remove the filler cap of the cover
before blending hot foods or liquids.
■To add foods when blender is operating, remove
filler cap from container cover and add ingredients
through the opening.
■For best performance, the minimum amount of liquid
needed per recipe is one cup (8 ounces/250 ml). Add
more liquid if food is not blending properly.
■If blending action stops during blending or ingredi-
ents stick to sides of the jar, there may not be
enough liquid in the jar to blend efficiently.
■Do not try to mash potatoes, mix stiff dough, whip
egg whites, grind raw meat, or extract juices from
fruits and vegetables. The blender is not made to
perform these tasks.
■Do not store food or liquids in the blender jar.
■Avoid bumping or dropping the blender.
7
840141300 Blender 12/20/05 11:23 AM Page 7

BLENDING SPECIFIC FOODS
Baby Foods
Follow feeding guidelines appropriate for age. Place 1
cup (250 ml) cooked fruits or vegetables in blender jar.
Add liquid, such as water, milk, or juice, if needed. Press
a desired speed control button for 10 seconds or until
smooth.
Bread Crumbs
Tear bread into pieces and put in blender jar. Pulse
about 10 times.
Cookie or Cracker Crumbs
Break cookies or crackers into pieces and put in blender
jar. Process 1 cup (250 ml) at a time. Pulse about 10
times. For a finer consistency, process a few more sec-
onds after Pulsing.
Chopped Nuts
Place 1 cup (250 ml) nuts in blender jar. Pulse a few
times. Remove jar from base and shake to redistribute
pieces. Place jar on base and Pulse a few more times.
Chopping Vegetables
Cabbage, carrots, onion, green pepper, potatoes. Place
2 cups (500 ml) of chunks in blender jar. Cover with
water. Pulse until desired chopped consistency is
reached. Pour into colander to drain off water.
Coffee Beans
Place 1⁄2cup (125 ml) beans in blender jar. Press a
desired speed control button for 30 seconds or until
desired grind is reached.
Frozen Juice Concentrate
Place 6 ounces (170 g) frozen juice in blender jar with
recommended amount of water. Press a desired speed
control button for 20 seconds. Or place 12 ounces (350
g) frozen juice in blender jar with 1 can of water. Press a
desired speed control button for 30 seconds. Pour into
pitcher and stir in remaining 2 cans water.
Grated Baking Chocolate
On a cutting board, cut 2 to 3 ounces (50 to 85 g) bak-
ing chocolate into chunks. Place in blender jar. Pulse for
10 seconds.
8
840141300 Blender 12/20/05 11:23 AM Page 8

Smooth Gravy
If your gravy has lumps, place in blender jar. Remove
filler cap from cover to allow steam to escape. Press a
desired speed control button for 5 seconds or until
smooth.
Pancakes or Waffles
Place liquid ingredients into blender jar; then dry ingredi-
ents. Press a desired speed control button for 10 seconds
or until blended.
Parmesan Cheese
Cut cheese into half-inch (1 cm) chunks and place in
blender jar. Press a desired speed control button for 30
seconds or until blended.
Superfine Sugar
Place 1 cup (250 ml) regular granulated sugar in blender
jar. Press a desired speed control button for 30 seconds
to make superfine sugar which dissolves instantly in iced
tea.
Crushing Ice
Your Wave
~Action blender will crush ice at any speed,
but for best results use the Pulse speed.
“Thickened” Whipping Cream
The blender will not whip cream but produces a spoon-
able topping. Pour 1 cup (250 ml) heavy or whipping
cream in blender jar. Process for 20 seconds or until thick-
ened.
9
840141300 Blender 12/20/05 11:23 AM Page 9

HOW TO CLEAN
■Unplug blender from electrical outlet.
■Wipe blender base, control panel, and cord with a
damp cloth or sponge. To remove stubborn spots, use
a mild, non-abrasive cleanser.
■To clean jar, unscrew Sure Rest™jar base and remove
cutting assembly.
■Carefully remove blades and gasket from bottom of
Sure Rest™jar base.
■Carefully wash cutting blades, Sure Rest™jar base, jar
(if plastic), and cover in hot, soapy water. Rinse and
dry thoroughly. Do not soak. Glass jars may be
washed in an automatic dishwasher. If desired, all
parts except the cutting assembly may be washed in
the dishwasher in the top rack only.
Please note: some part distortion may occur if your
household dishwasher temperature is higher than nor-
mal or if parts are placed too close to the heating ele-
ment.
NOTE: Do not wash cutting blades in a dishwasher.
■Reassemble cutting blades. Replace jar onto blender
base.
■Store blender with lid ajar to prevent container odor.
QUICK CLEAN
The Quick Clean function should only be used to rinse
the blender between batches of processing the same
food. When the processing of a single type of food is
finished, the blender should be disassembled and
thoroughly cleaned as instructed in “How to Clean.”
To Quick Clean, pour 2 cups (500 ml) warm water in jar
and add 1 drop liquid dishwashing detergent. Run the
blender on HIGH SPEED for 10 seconds. Discard soapy
water. Rinse with clean water.
This function is not a substitute for regular cleaning as
instructed in “How to Clean.” This function should never
be used when blending any mixture containing eggs,
milk, or any other dairy products, meats, or seafood.
10
840141300 Blender 12/20/05 11:23 AM Page 10

For more blender recipes, call our toll-free number or
check our Web site at www.hamiltonbeach.com.
Triple Chocolate Milkshake
11⁄2cups (375 ml) milk
8 chocolate sandwich cookies
1⁄3 cup (80 ml) chocolate syrup
6 scoops chocolate ice cream
Place all ingredients in blender. Press a desired speed con-
trol button for 15 seconds or until cookies are coarsely
chopped and shake is smooth. Makes 32 ounces (950 ml).
Frothy Pineapple-Banana Smoothie
11.5-ounce (339 ml) can pineapple-orange juice
concentrate (found in juice aisle)
11⁄2cups (375 ml) ice cubes
1⁄2cup (125 ml) pineapple chunks
1 ripe banana, broken into pieces
Place all ingredients in blender jar; cover. Press a desired
speed control button for 45 seconds or until blended.
Makes 40 ounces (1.25 L).
Orange Pineapple Smoothie
15-ounce (425 g) can crushed pineapple
1 cup (250 ml) orange juice
1 cup (250 ml) ice cubes
8 ounces (250 ml) pineapple yogurt
Place all ingredients in blender jar; cover. Press a desired
speed control button for 45 seconds or until blended.
Makes 36 ounces (1.125 L).
Banana Berry Smoothie
11⁄2cups (375 ml) milk
2 cups (500 ml) frozen strawberries
2 ripe bananas, broken into pieces
2 8-ounce (450 g) containers vanilla or strawberry yogurt.
Place all ingredients in blender jar; cover. Press a desired
speed control button for 45 seconds or until blended.
Makes 48 ounces (1.5 L). 11
RECIPES
840141300 Blender 12/20/05 11:23 AM Page 11

Orange-Sicle Smoothie
21⁄2cups (625 ml) orange juice
6 scoops vanilla frozen yogurt
Place all ingredients in blender jar; cover. Press a desired
speed control button for 45 seconds or until blended.
Makes 36 ounces (1.125 L).
Mocha-Cocoa Shake
11⁄2cups (375 ml) milk
2 teaspoons (10 ml) instant coffee powder
6 scoops chocolate ice cream
Place all ingredients in blender. Press a desired speed
control button for 15 seconds or until shake is smooth.
Makes 24 ounces (750 ml).
Adult Mocha Shake
1 cup (250 ml) milk
3⁄4cup (175 ml) coffee-flavored liqueur like Kahlua
4 scoops chocolate ice cream, softened
Place all ingredients in blender jar; cover. Press a desired
speed control button for 45 seconds or until blended.
Makes 32 ounces (950 ml).
Strawberry Daiquiri
16-ounce (450 g) package frozen strawberries in syrup,
slightly thawed
6-ounce (170 g) can frozen limeade concentrate
1 cup (250 ml) rum
2 cups (500 ml) ice
Place all ingredients in blender. Press a desired speed
control button for 45 seconds or until ice is crushed.
Makes 40 ounces (1.25 L).
Margaritas
1⁄2cup (125 ml) tequila
1⁄2cup (125 ml) Triple Sec
2 cups (500 ml) ice
Juice of 16 limes
1⁄2cup (125 ml) sugar
Place all ingredients in blender jar; cover. Press a desired
speed control button for 45 seconds or until ice is crushed.
Makes 32 ounces (950 ml).
12
840141300 Blender 12/20/05 11:23 AM Page 12

Mexican Jack Omelet
3 eggs
2 ounces (56 g) Monterey Jack or pepper jack cheese
1 tablespoon (15 ml) water or milk
Salt and pepper to taste
Place all ingredients in blender jar. Press a desired speed
control button for 10 seconds. Over medium heat, melt
a small pat of margarine or butter in a skillet. Pour
omelet into skillet. Cook until just set; then flip over and
cook until done. Fold and serve. Makes 1 omelet.
Hummus
19-ounce (535 g) can garbanzo beans, undrained
3 tablespoons (45 ml) lemon juice
2 tablespoons (30 ml) tahini
1 tablespoon (15 ml) olive oil
11⁄2 teaspoons (7.5 ml) minced garlic
1 teaspoon (5 ml) cumin
1⁄2 teaspoon (2.5 ml) salt
Combine the seven ingredients in blender jar. Press a
desired speed control button until blended. Turn blender
off. Scrape sides of jar with spatula. Turn blender on and
process an additional 30 seconds until smooth. Transfer to
serving dish. Serve with rye toast or pita wedges. Yield:
about 3 cups (750 ml).
Chocolate Cream Mousse
1 teaspoon vanilla (5 ml)
2 tablespoons (30 ml) sugar
1 cup (250 ml) mini-chocolate chips
1⁄2cup (175 ml) milk
3-ounce (85 g) package cream cheese, cut in cubes
Put vanilla, sugar, and chocolate chips in blender jar.
Heat milk to steaming. Pour milk into jar. Press a desired
speed control button for 15 seconds or until smooth. Add
cream cheese and press a desired speed control button
for 10 seconds or until smooth. Pour into individual
dessert dishes and refrigerate at least 2 hours or until set.
Makes 4 to 6 servings.
13
840141300 Blender 12/20/05 11:23 AM Page 13

If you have a question, call our customer service number.
Before calling, please note the model, type, and series
numbers. These numbers can be found on the bottom of
your toaster and will help us answer your question.
LIMITED WARRANTY
This product is warranted to be free from defects in material and
workmanship for a period of three (3) years for Hamilton Beach
products and Michael Graves by Hamilton Beach products, or one
hundred eighty (180) days for Proctor-Silex and Traditions products
from the date of original purchase, except as noted below. During
this period, we will repair or replace this product, at our option, at no
cost. THE FOREGOING WARRANTY IS IN LIEU OF ANY OTHER
WARRANTY OR CONDITION, WHETHER EXPRESS OR IMPLIED, WRITTEN
OR ORAL INCLUDING, WITHOUT LIMITATION, ANY STATUTORY
WARRANTY OR CONDITION OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. ANY LIABILITY IS EXPRESSLY LIMITED TO AN
AMOUNT EQUAL TO THE PURCHASE PRICE PAID, AND ALL CLAIMS FOR
SPECIAL, INCIDENTAL AND CONSEQUENTIAL DAMAGES ARE HEREBY
EXCLUDED. There is no warranty with respect to the following, which
may be supplied with this product, including without limitation: glass
parts, glass containers, cutter/strainers, blades, seals, gaskets,
clutches, motor brushes, and/or agitators, etc. This warranty extends
only to the original consumer purchaser and does not cover a defect
resulting from abuse, misuse, neglect including failure to clean
product regularly in accordance with manufacturer’s instructions, use
for commercial purposes, or any use not in conformity with the
printed directions. This warranty gives you specific legal rights, and
you may also have other legal rights which vary from state to state,
or province to province. Some states or provinces do not allow
limitations on implied warranties or special, incidental or
consequential damages, so the foregoing limitations may not apply
to you.
If you have a claim under this warranty, DO NOT RETURN THE
APPLIANCE TO THE STORE! Please call our CUSTOMER SERVICE
NUMBER. (For faster service please have model, series, and type
numbers ready for operator to assist you.)
CUSTOMER SERVICE NUMBER
1-800-851-8900
Web site address:
hamiltonbeach.com or proctorsilex.com
KEEP THIS NUMBER FOR FUTURE REFERENCE!
14
CUSTOMER SERVICE
840141300 Blender 12/20/05 11:23 AM Page 14

840141300
15
840141300 Blender 12/20/05 11:30 AM Page 15

blender
Michael Graves
Michael Graves, recipient of the National Medal of Arts and the
American Institute of Architects' Gold Medal, has been at the fore-
front of architecture and design since founding his practice in
Princeton, New Jersey in 1964. By integrating architecture, interior
design, product design and graphic design, his unique practice has
developed a powerful lifestyle brand with an impressive portfolio of
projects throughout the world. His design practice, Michael Graves
Design Group, has created products that range from building compo-
nents to consumer products for home and office, including the
Michael Graves Design™ collection for Target.
840141300 Blender 12/20/05 11:23 AM Page 16
